“Turning acoustic probabilities into coherent text.”

1. Introduction

Automatic Speech Recognition (ASR) converts speech audio into text. The decoding stage is where we take the acoustic model’s output (probabilities over characters/tokens) and produce the final transcription.

Pipeline:

Audio → Feature Extraction (MFCC) → Acoustic Model → Decoder → Text

The decoder’s job is to find the most likely text sequence given the acoustic observations.

2. The Decoding Problem

Mathematically: \(\hat{W} = \arg\max_W P(W | O)\)

Where:

  • $O$ = Acoustic observations (audio features).
  • $W$ = Word sequence (transcription).

Using Bayes’ theorem: \(P(W | O) = \frac{P(O | W) P(W)}{P(O)}\)

Since $P(O)$ is constant, we maximize: \(\hat{W} = \arg\max_W P(O | W) \cdot P(W)\)

  • $P(O W)$ = Acoustic Model (AM): How likely is this audio given these words?
  • $P(W)$ = Language Model (LM): How likely is this word sequence?

3. Decoding Strategies

3.1. Greedy Decoding

Algorithm:

  1. At each time step, pick the most likely token.
  2. Concatenate to form the output.
def greedy_decode(probs):
    # probs: (T, vocab_size)
    tokens = []
    for t in range(len(probs)):
        token = np.argmax(probs[t])
        tokens.append(token)
    return tokens

Pros: Fast, simple. Cons: Doesn’t consider context. Often produces suboptimal results.

Algorithm:

  1. Maintain top-k hypotheses (beams).
  2. At each step, extend each hypothesis with all possible tokens.
  3. Keep only the top-k scoring hypotheses.
  4. Repeat until end-of-sequence.
def beam_search(probs, beam_width=5):
    # probs: (T, vocab_size)
    sequences = [[[], 0.0]]  # (tokens, score)

    for t in range(len(probs)):
        all_candidates = []
        for seq, score in sequences:
            for token in range(len(probs[t])):
                new_seq = seq + [token]
                new_score = score + np.log(probs[t][token])
                all_candidates.append((new_seq, new_score))

        # Keep top-k
        sequences = sorted(all_candidates, key=lambda x: x[1], reverse=True)[:beam_width]

    return sequences[0][0]  # Return best sequence

Pros: Considers multiple hypotheses. Usually better than greedy. Cons: Computationally expensive. Still not globally optimal.

3.3. CTC Decoding

Connectionist Temporal Classification (CTC) is a loss function for sequence-to-sequence tasks where alignment is unknown.

Key Idea:

  • Add a “blank” token (ε) to handle alignment.
  • Multiple CTC paths map to the same output (e.g., “aa-ab” and “a-aab” both → “ab”).

CTC Decoding:

  1. Apply greedy or beam search to CTC output.
  2. Collapse consecutive duplicate tokens.
  3. Remove blank tokens.
def ctc_decode(probs, blank_token=0):
    tokens = []
    prev = -1

    for t in range(len(probs)):
        token = np.argmax(probs[t])
        if token != prev and token != blank_token:
            tokens.append(token)
        prev = token

    return tokens

3.4. Attention-Based Decoding

In encoder-decoder models (like Whisper, Seq2Seq), the decoder uses attention to focus on relevant parts of the encoder output.

Algorithm:

  1. Encoder processes audio → hidden states.
  2. Decoder autoregressively generates tokens.
  3. At each step, attention weights determine which encoder states to focus on.
def attention_decode(encoder_output, decoder, max_length=100):
    tokens = [BOS_TOKEN]  # Begin of sequence

    for _ in range(max_length):
        output = decoder(tokens, encoder_output)
        next_token = np.argmax(output[-1])
        tokens.append(next_token)

        if next_token == EOS_TOKEN:
            break

    return tokens[1:-1]  # Remove BOS and EOS

4. Language Model Integration

Problem: Acoustic model output may be noisy. Language models can correct grammatical errors.

Approaches:

4.1. Shallow Fusion

Idea: Combine AM and LM scores during beam search.

\[\text{score} = \log P_{AM}(y | x) + \lambda \log P_{LM}(y)\]

Where $\lambda$ is a tunable weight.

def beam_search_with_lm(am_probs, lm, beam_width=5, lm_weight=0.5):
    sequences = [[[], 0.0, 0.0]]  # (tokens, am_score, lm_score)

    for t in range(len(am_probs)):
        all_candidates = []
        for seq, am_score, lm_score in sequences:
            for token in range(len(am_probs[t])):
                new_seq = seq + [token]
                new_am_score = am_score + np.log(am_probs[t][token])
                new_lm_score = lm_score + lm.score(new_seq)

                combined = new_am_score + lm_weight * new_lm_score
                all_candidates.append((new_seq, new_am_score, new_lm_score, combined))

        # Keep top-k by combined score
        sequences = sorted(all_candidates, key=lambda x: x[3], reverse=True)[:beam_width]

    return sequences[0][0]

4.2. Deep Fusion

Idea: Train the AM and LM jointly. The LM’s hidden states are fed into the AM.

Benefits: Tighter integration, better performance. Drawbacks: Requires retraining. Less flexible.

4.3. Rescoring (N-Best Rescoring)

Idea:

  1. Generate N-best hypotheses with AM only.
  2. Rescore each hypothesis with a powerful LM (e.g., GPT).
  3. Return the highest-scoring hypothesis.

Benefits: Can use large, pretrained LMs. Drawbacks: Two-pass (slower).

5. CTC Beam Search with Language Model

Prefix Beam Search: Handles CTC’s blank tokens and collapsed outputs properly.

Algorithm:

  1. Track two scores for each prefix:
    • Pb (blank): Probability of prefix ending with blank.
    • Pnb (non-blank): Probability of prefix not ending with blank.
  2. At each step, extend prefixes by:
    • Adding a blank (only affects Pb).
    • Repeating the last character (affects Pb/Pnb transition).
    • Adding a new character (affects Pnb).
def ctc_beam_search_with_lm(probs, lm, beam_width=10, blank=0, lm_weight=0.5):
    # probs: (T, vocab_size)
    # Initialize
    beams = {(): (1.0, 0.0)}  # prefix: (pb, pnb)

    for t in range(len(probs)):
        new_beams = defaultdict(lambda: (0.0, 0.0))

        for prefix, (pb, pnb) in beams.items():
            for c in range(len(probs[t])):
                p = probs[t][c]

                if c == blank:
                    # Extend with blank
                    key = prefix
                    new_beams[key] = (new_beams[key][0] + (pb + pnb) * p, new_beams[key][1])

                elif prefix and c == prefix[-1]:
                    # Repeat character (needs blank before)
                    new_beams[prefix] = (new_beams[prefix][0], new_beams[prefix][1] + pb * p)
                    # Or new character after blank
                    new_key = prefix + (c,)
                    new_beams[new_key] = (new_beams[new_key][0], new_beams[new_key][1] + pnb * p)

                else:
                    # New character
                    new_key = prefix + (c,)
                    lm_factor = lm.score(new_key) ** lm_weight
                    new_beams[new_key] = (new_beams[new_key][0], new_beams[new_key][1] + (pb + pnb) * p * lm_factor)

        # Prune to beam_width
        beams = dict(sorted(new_beams.items(), key=lambda x: sum(x[1]), reverse=True)[:beam_width])

    # Return best prefix
    best_prefix = max(beams, key=lambda x: sum(beams[x]))
    return list(best_prefix)

6. System Design: Production ASR Decoder

Scenario: Build a real-time ASR system for voice assistants.

Requirements:

  • Latency: < 200ms from end of utterance to transcription.
  • Accuracy: WER < 10%.
  • Streaming: Start transcribing before the user finishes speaking.

Architecture:

Step 1: Streaming Audio Input

  • Audio arrives in 20ms chunks.
  • Feature extraction (MFCC/Mel) in real-time.

Step 2: Streaming Acoustic Model

  • Use a streaming-compatible architecture (e.g., Conformer with lookahead).
  • Output probabilities every 20ms.

Step 3: Online Decoding

  • Run CTC beam search incrementally.
  • Emit partial results as hypotheses stabilize.

Step 4: Endpointing

  • Detect when the user stops speaking.
  • Finalize the transcription.

Step 5: Rescoring (Optional)

  • Rescore final hypothesis with a larger LM.

7. Deep Dive: Weighted Finite State Transducers (WFST)

WFST is a mathematical framework for composing AM, LM, and lexicon.

Components:

  • H (HMM): Maps senones to context-dependent phones.
  • C (Context): Maps context-dependent phones to context-independent phones.
  • L (Lexicon): Maps phones to words.
  • G (Grammar): Language model (n-gram).

Composition: \(\text{Decoding Graph} = H \circ C \circ L \circ G\)

Benefits:

  • Efficient decoding using Viterbi algorithm on the composed graph.
  • Caching: Precompute and store the composed graph.

Tools:

  • Kaldi: Open-source ASR toolkit using WFST.
  • OpenFst: Library for finite-state transducers.

8. Deep Dive: Streaming vs Non-Streaming

Non-Streaming (Offline):

  • Process entire audio at once.
  • Can use bidirectional models (look at future).
  • Higher accuracy.

Streaming (Online):

  • Process audio chunk by chunk.
  • Cannot look at future (causality constraint).
  • Lower latency, slightly lower accuracy.

Hybrid (Look-Ahead):

  • Allow small lookahead (e.g., 200ms).
  • Balance between latency and accuracy.

9. Word Error Rate (WER)

Definition: \(WER = \frac{S + D + I}{N}\)

Where:

  • S = Substitutions (wrong word).
  • D = Deletions (missing word).
  • I = Insertions (extra word).
  • N = Total words in reference.

Example:

  • Reference: “the cat sat on the mat”
  • Hypothesis: “the cat hat on a mat”
  • Errors: S=1 (sat→hat), S=1 (the→a)
  • WER = 2 / 6 = 33.3%

10. Decoding Optimizations

10.1. Pruning

Beam Pruning: Keep only top-k hypotheses. Threshold Pruning: Discard hypotheses with score < best_score - threshold. Histogram Pruning: Limit hypotheses per frame.

10.2. Lattice Generation

Instead of outputting a single transcription, output a lattice—a compact representation of all hypotheses.

Benefits:

  • Rescoring: Apply different LMs later.
  • Confidence Estimation: Compute confidence scores.
  • N-Best Lists: Extract top-N transcriptions.

10.3. GPU Acceleration

  • Batched Beam Search: Process multiple utterances in parallel.
  • CUDA Implementations: Use GPU for matrix operations.
  • TensorRT: Optimize inference.

11. Production Case Study: Whisper

Whisper (OpenAI):

  • Architecture: Encoder-Decoder Transformer.
  • Decoding: Greedy or beam search with temperature.
  • Language Model: Implicit in the decoder.
  • Multilingual: 99 languages.

Decoding Features:

  • Timestamps: Predict start/end times for each word.
  • Temperature Fallback: If greedy fails (repetition), retry with temperature sampling.
  • Compression Threshold: Skip segments with too much compression (repetition).

12. Interview Questions

  1. Greedy vs Beam Search: When would you use each?
  2. CTC Decoding: Explain how blank tokens work.
  3. Language Model Integration: What is shallow fusion?
  4. Streaming ASR: How do you handle causality constraints?
  5. WFST: What is the role of the lexicon (L)?
  6. Calculate WER: Given reference and hypothesis, compute WER.

13. Common Mistakes

  • Ignoring Blanks in CTC: Not collapsing consecutive tokens.
  • Beam Width Too Small: Missing the correct hypothesis.
  • LM Weight Too High: Over-relying on LM, ignoring AM.
  • Not Handling OOV Words: Out-of-vocabulary words cause errors.
  • Ignoring Latency: Production systems have strict latency requirements.

14. Deep Dive: Confidence Estimation

Problem: Not all transcriptions are equally reliable. How do we estimate confidence?

Approaches:

1. Posterior Probability:

  • Use the probability of the best hypothesis.
  • $\text{confidence} = P(W O)$.

2. Entropy:

  • High entropy = low confidence (many competing hypotheses).

3. Word-Level Confidence:

  • Compute confidence for each word using lattice posteriors.

4. Model-Based:

  • Train a separate model to predict confidence from ASR features.

15. Deep Dive: Hot Words (Contextual Biasing)

Problem: ASR fails on domain-specific terms (e.g., product names, jargon).

Solution: Bias decoding towards expected words.

Approaches:

  1. N-Gram Boosting: Increase LM probability for hot words.
  2. Contextual LM: Condition LM on context (e.g., user’s recent queries).
  3. Shallow Fusion with Boosted LM: Add bonus score for hot words.

Example:

hot_words = ["Alexa", "Siri", "Cortana"]
hot_word_boost = 2.0  # Log-scale boost

def score_with_hotwords(seq, am_score, lm_score):
    bonus = sum(hot_word_boost for word in seq if word in hot_words)
    return am_score + lm_weight * lm_score + bonus

1. End-to-End LM Integration:

  • Train AM and LM jointly (e.g., Hybrid Transducers).

2. LLM for Error Correction:

  • Use GPT/LLaMA to post-process ASR output.

3. Multimodal Decoding:

  • Use video (lip reading) to improve decoding.

4. On-Device Decoding:

  • Run decoding on mobile devices (requires efficient implementations).

17. Conclusion

ASR decoding is the bridge between acoustic probabilities and human-readable text. The key is balancing:

  • Accuracy: Use beam search and language models.
  • Latency: Use streaming architectures and pruning.
  • Flexibility: Use lattices and rescoring for adaptability.

Key Takeaways:

  • Greedy: Fast but suboptimal.
  • Beam Search: Better quality, higher cost.
  • CTC: Handles alignment automatically.
  • LM Integration: Shallow fusion, deep fusion, rescoring.
  • WFST: Classical approach for composing AM/LM/Lexicon.
  • Streaming: Essential for real-time applications.

Mastering decoding is essential for building production ASR systems. The techniques here apply to any sequence-to-sequence task: machine translation, speech synthesis, and beyond.

18. Deep Dive: RNN-Transducer (RNN-T) Decoding

RNN-T is a popular architecture for streaming ASR (used by Google, Meta).

Architecture:

  • Encoder: Processes audio, outputs acoustic features.
  • Prediction Network: RNN that processes output history.
  • Joint Network: Combines encoder + prediction network outputs.
  • Output: Probability over vocabulary + blank.

Decoding Algorithm:

def rnnt_greedy_decode(encoder_output, predictor, joint):
    T = len(encoder_output)
    U = 0  # Output index
    outputs = []
    pred_state = predictor.initial_state()

    t = 0
    while t < T:
        # Get encoder output at time t
        enc_t = encoder_output[t]

        # Get prediction network output
        pred_output, pred_state = predictor(outputs[-1:] if outputs else [BOS], pred_state)

        # Joint network
        logits = joint(enc_t, pred_output)
        token = np.argmax(logits)

        if token == BLANK:
            t += 1  # Advance time
        else:
            outputs.append(token)
            # Don't advance time (can emit multiple tokens at same time step)

    return outputs

Key Difference from CTC:

  • CTC: One output per time step.
  • RNN-T: Can emit multiple tokens per time step (or none).

Architecture:

  • Model: Conformer encoder + RNN-T decoder.
  • Decoding: Beam search with shallow fusion LM.
  • Latency: < 200ms.
  • WER: < 5% on conversational speech.

Optimizations:

  • Quantized Model: INT8 for mobile.
  • Speculative Decoding: Start decoding before audio ends.
  • Hot Word Boosting: Boost contact names, app names.
  • Contextual LM: Condition on user’s search history.

20. Production Case Study: Amazon Alexa

Architecture:

  • First Pass: CTC decoding with small LM.
  • Second Pass: Rescoring with large LM.
  • Third Pass: NLU (intent recognition).

Latency Breakdown:

  • Audio capture: 50ms.
  • CTC decoding: 100ms.
  • LM rescoring: 50ms.
  • Total: ~200ms.

Optimization:

  • Endpointing: Detect speech end quickly.
  • Prefetch: Start cloud processing during endpointing.

21. Benchmarking ASR Decoders

Metrics:

  • WER: Word Error Rate.
  • Latency: Time from audio end to transcription.
  • RTF (Real-Time Factor): Processing time / Audio duration. RTF < 1 means faster than real-time.

Benchmark (LibriSpeech): | Model | WER (test-clean) | RTF (GPU) | RTF (CPU) | |——-|——————|———–|———–| | Wav2Vec 2.0 + Greedy | 2.7% | 0.1 | 1.5 | | Whisper (small) + Beam | 3.0% | 0.2 | 3.0 | | Conformer + RNN-T | 2.1% | 0.15 | 2.0 |

22. Decoding for Low-Resource Languages

Challenge: Language models may not exist for low-resource languages.

Solutions:

  1. Multilingual Models: Use models trained on 100+ languages.
  2. Cross-Lingual Transfer: Fine-tune on target language with limited data.
  3. Character-Level LM: Train a small character LM.
  4. Phoneme-Based LM: Use phoneme sequences instead of words.

23. Advanced: Minimum Bayes Risk (MBR) Decoding

Problem: Beam search finds the most likely sequence, but not necessarily the one with the lowest WER.

MBR Approach:

  • Generate N-best hypotheses.
  • For each hypothesis, compute expected WER against all other hypotheses.
  • Return the hypothesis with lowest expected WER.

Algorithm:

def mbr_decode(n_best_list):
    # n_best_list: [(hypothesis, probability), ...]
    best_hyp = None
    best_risk = float('inf')

    for hyp, prob in n_best_list:
        risk = 0
        for other_hyp, other_prob in n_best_list:
            risk += other_prob * word_error_rate(hyp, other_hyp)

        if risk < best_risk:
            best_risk = risk
            best_hyp = hyp

    return best_hyp

Use Case: When WER is more important than likelihood.

24. Deep Dive: Subword Units

Problem: Character-level models have long sequences. Word-level models have OOV issues.

Solution: Subword units (BPE, SentencePiece).

Algorithm (BPE):

  1. Start with characters.
  2. Iteratively merge the most frequent adjacent pair.
  3. Stop when vocabulary size reached.

Example:

  • “lower” → “l o w e r” → “lo we r” → “low er” → “lower”

Benefits:

  • Handles rare words.
  • Shorter sequences than characters.
  • No OOV (can spell any word).

25. Decoding with Word Timestamps

Problem: Beyond transcription, we need to know when each word was spoken.

Approaches:

1. CTC Alignment:

  • After decoding, use forced alignment to find timestamps.

2. Attention Weights:

  • Use encoder-decoder attention to infer timestamps.

3. Whisper-Style:

  • Predict <|start_time|> and <|end_time|> tokens.

26. Decoding for Dictation vs Conversation

Dictation:

  • User speaks clearly, slowly.
  • Expects exact transcription.
  • Punctuation and formatting expected.

Conversation:

  • Multiple speakers, overlapping speech.
  • Disfluencies (uh, um, repetitions).
  • Informal language.

Decoding Differences:

  • Dictation: Use strong LM, inverse text normalization (numbers, dates).
  • Conversation: Use disfluency model, speaker diarization.
import torch
from torchaudio.models.decoder import ctc_decoder

# Load lexicon and LM
decoder = ctc_decoder(
    lexicon="lexicon.txt",
    tokens="tokens.txt",
    lm="language_model.arpa",
    beam_size=50,
    lm_weight=0.5,
    word_score=-0.2
)

# Decode
emissions = model(audio)  # (T, vocab_size)
hypotheses = decoder(emissions)

# Get best hypothesis
best = hypotheses[0][0]
text = " ".join(best.words)

28. Interview Strategy: ASR Decoding

Step-by-Step:

  1. Explain the Problem: AM gives probabilities, need to find best text.
  2. Greedy: Simple but suboptimal.
  3. Beam Search: Better, introduce beam width.
  4. CTC Specifics: Blank token, collapsing.
  5. LM Integration: Shallow fusion, rescoring.
  6. Streaming: Discuss latency constraints.
  7. Trade-offs: Accuracy vs latency vs compute.

29. Testing ASR Decoders

Unit Tests:

  • Test CTC collapsing: “aa-a-bb” → “ab”.
  • Test beam search ranking.
  • Test LM weight behavior.

Integration Tests:

  • End-to-end: audio → transcription.
  • Compare with baseline (e.g., Whisper).

Regression Tests:

  • Test on standard benchmarks (LibriSpeech, Common Voice).
  • Alert if WER increases.

30. Conclusion & Mastery Checklist

Mastery Checklist:

  • Implement greedy decoding
  • Implement beam search
  • Implement CTC decoding (with blank collapsing)
  • Integrate language model (shallow fusion)
  • Understand RNN-T decoding
  • Implement N-best list generation
  • Calculate WER correctly
  • Handle streaming ASR
  • Implement hot word boosting
  • Benchmark RTF and WER

ASR decoding is where the magic happens—turning probabilities into words. The techniques you’ve learned here are the foundation for building voice assistants, transcription services, and real-time translation systems. As LLMs become more integrated with speech, the importance of efficient, accurate decoding will only grow.

Next Steps:

  • Implement a CTC decoder from scratch.
  • Add LM integration.
  • Build a streaming decoder.
  • Explore RNN-T for production systems.
  • Study WFST-based decoding (Kaldi).

The journey from “audio in” to “text out” is complex but rewarding. Master it, and you’ll have the skills to build world-class speech systems.
