“Giving machines a voice.”

1. The Evolution of TTS

1. Concatenative Synthesis (1990s - 2010s)

  • Method: Record a voice actor reading thousands of sentences. Chop them into phonemes/diphones. Glue them together at runtime.
  • Pros: Very natural sound for recorded segments.
  • Cons: “Glitchy” at boundaries. Cannot change emotion or style. Requires massive database (GBs).

2. Statistical Parametric Synthesis (HMMs) (2000s - 2015)

  • Method: Generate acoustic features (F0, spectral envelope) from text using HMMs. Use a vocoder to convert features to audio.
  • Pros: Flexible, small footprint.
  • Cons: “Muffled” or “robotic” sound (due to averaging in HMMs).

3. Neural / End-to-End TTS (2016 - Present)

  • Method: Deep Neural Networks map Text $\to$ Spectrogram $\to$ Waveform.
  • Pros: Human-level naturalness. Controllable style/emotion.
  • Cons: Computationally expensive.

2. Anatomy of a Modern TTS System

A typical Neural TTS system has two stages:

  1. Acoustic Model (Text $\to$ Mel-Spectrogram):
    • Converts character/phoneme sequence into a time-frequency representation (Mel-spectrogram).
    • Example: Tacotron 2, FastSpeech 2, VITS.
  2. Vocoder (Mel-Spectrogram $\to$ Waveform):
    • Inverts the spectrogram back to time-domain audio.
    • Example: WaveNet, WaveGlow, HiFi-GAN.

3. Deep Dive: Tacotron 2 Architecture

Tacotron 2 (Google, 2017) is the gold standard for high-quality TTS.

1. Encoder

  • Input: Character sequence.
  • Layers: 3 Convolutional layers (context) + Bi-directional LSTM.
  • Output: Encoded text features.

2. Attention Mechanism

  • Location-Sensitive Attention: Crucial for TTS.
  • Unlike translation (where reordering happens), speech is monotonic.
  • The attention weights must move forward linearly.
  • Uses previous attention weights as input to calculate current attention.

3. Decoder

  • Type: Autoregressive LSTM.
  • Input: Previous Mel-frame.
  • Output: Current Mel-frame.
  • Stop Token: Predicts when to stop generating.

4. Post-Net

  • Purpose: Refine the Mel-spectrogram.
  • Layers: 5 Convolutional layers.
  • Residual Connection: Adds detail to the decoder output.

Loss Function: MSE between predicted and ground-truth Mel-spectrograms.

4. Deep Dive: Neural Vocoders

The Mel-spectrogram is lossy (phase information is discarded). The Vocoder must “hallucinate” the phase to generate high-fidelity audio.

1. Griffin-Lim (Algorithm)

  • Method: Iterative algorithm to estimate phase.
  • Pros: Fast, no training.
  • Cons: Robotic, metallic artifacts.

2. WaveNet (Autoregressive)

  • Method: Predicts sample $x_t$ based on $x_{t-1}, x_{t-2}, …$
  • Architecture: Dilated Causal Convolutions.
  • Pros: State-of-the-art quality.
  • Cons: Extremely slow (sequential generation). 1 second of audio = 24,000 steps.

3. WaveGlow (Flow-based)

  • Method: Normalizing Flows. Maps Gaussian noise to audio.
  • Pros: Parallel inference (fast). High quality.
  • Cons: Huge model (hundreds of millions of parameters).

4. HiFi-GAN (GAN-based)

  • Method: Generator produces audio, Discriminator distinguishes real vs fake.
  • Pros: Very fast (real-time on CPU), high quality.
  • Cons: Training instability (GANs).
  • Current Standard: HiFi-GAN is the default for most systems today.

5. FastSpeech 2: Non-Autoregressive TTS

Problem with Tacotron:

  • Autoregressive generation is slow ($O(N)$).
  • Attention failures (skipping or repeating words).

FastSpeech 2 Solution:

  • Non-Autoregressive: Generate all frames in parallel ($O(1)$).
  • Duration Predictor: Explicitly predict how many frames each phoneme lasts.
  • Pitch/Energy Predictors: Explicitly model prosody.

Architecture:

  • Encoder (Transformer) $\to$ Variance Adaptor (Duration/Pitch/Energy) $\to$ Decoder (Transformer).

Pros:

  • Extremely fast training and inference.
  • Robust (no skipping/repeating).
  • Controllable (can manually adjust speed/pitch).

6. System Design: Building a TTS API

Scenario: Build a scalable TTS service like Amazon Polly.

Requirements:

  • Latency: < 200ms time-to-first-byte (streaming).
  • Throughput: 1000 concurrent streams.
  • Voices: Support multiple speakers/languages.

Architecture:

  1. Frontend (Text Normalization):
    • “Dr. Smith lives on St. John St.” $\to$ “Doctor Smith lives on Saint John Street”.
    • “12:30” $\to$ “twelve thirty”.
    • G2P (Grapheme-to-Phoneme): Convert text to phonemes (using CMU Dict or Model).
  2. Synthesis Engine:
    • Model: FastSpeech 2 (for speed) + HiFi-GAN.
    • Optimization: ONNX Runtime / TensorRT.
    • Streaming: Chunk text into sentences. Synthesize sentence 1 while user listens.
  3. Caching:
    • Cache common phrases (“Your ride has arrived”).
    • Hit rate for TTS is surprisingly high for navigational/assistant apps.
  4. Scaling:
    • GPU inference is preferred (T4/A10G).
    • Autoscaling based on queue depth.

7. Evaluation Metrics

1. MOS (Mean Opinion Score):

  • Human raters listen and rate from 1 (Bad) to 5 (Excellent).
  • Ground Truth: ~4.5.
  • Tacotron 2: ~4.3.
  • Parametric: ~3.5.

2. Intelligibility (Word Error Rate):

  • Feed generated audio into an ASR system.
  • Check if the ASR transcribes it correctly.

3. Latency (RTF - Real Time Factor):

  • Time to generate / Duration of audio.
  • RTF < 1.0 means faster than real-time.

8. Advanced: Voice Cloning (Zero-Shot TTS)

Goal: Generate speech in a target speaker’s voice given only a 3-second reference clip.

Architecture (e.g., Vall-E, XTTS):

  1. Speaker Encoder: Compresses reference audio into a fixed-size vector (d-vector).
  2. Conditioning: Feed d-vector into the TTS model (AdaIN or Concatenation).
  3. Language Modeling: Treat TTS as a language modeling task (Audio Tokens).

Vall-E (Microsoft):

  • Uses EnCodec (Audio Codec) to discretize audio.
  • Trains a GPT-style model to predict audio tokens from text + acoustic prompt.

9. Common Challenges

1. Text Normalization:

  • “$19.99” -> “nineteen dollars and ninety-nine cents”.
  • Context dependency: “I read the book” (past) vs “I will read” (future).

2. Prosody and Emotion:

  • Default TTS is “neutral/newsreader” style.
  • Generating “angry” or “whispering” speech requires labeled data or style transfer.

3. Long-Form Synthesis:

  • Attention mechanisms can drift over long paragraphs.
  • Fix: Windowed attention or sentence-level splitting.

10. Ethical Considerations

1. Deepfakes:

  • Voice cloning can break biometric auth (banks).
  • Used for scams (“Grandma, I’m in jail, send money”).
  • Mitigation: Watermarking audio (inaudible noise).

2. Copyright:

  • Training on audiobooks without consent.
  • Impact: Voice actors losing jobs.

11. Deep Dive: Tacotron 2 Attention Mechanism

Why does standard Attention fail for TTS?

  • In Machine Translation, alignment is soft and can jump (e.g., “red house” -> “maison rouge”).
  • In TTS, alignment is monotonic and continuous. You never read the end of the sentence before the beginning.

Location-Sensitive Attention: Standard Bahdanau Attention uses query $s_{i-1}$ and values $h_j$. \(e_{i,j} = v^T \tanh(W s_{i-1} + V h_j + b)\)

Location-Sensitive Attention adds the previous alignment $\alpha_{i-1}$ as a feature. \(f_i = F * \alpha_{i-1}\) \(e_{i,j} = v^T \tanh(W s_{i-1} + V h_j + U f_{i,j} + b)\)

Effect:

  • The model “knows” where it attended last time.
  • It learns to simply shift the attention window forward.
  • Prevents “babbling” (repeating the same word forever) or skipping words.

12. Deep Dive: WaveNet Dilated Convolutions

WaveNet generates raw audio sample-by-sample (16,000 samples/sec). To generate sample $x_t$, it needs context from a long history (e.g., 1 second).

Problem: Standard convolution with size 3 needs thousands of layers to reach a receptive field of 16,000.

Solution: Dilated Convolutions:

  • Skip input values with a step size (dilation).
  • Layer 1: Dilation 1 (Look at $t, t-1$)
  • Layer 2: Dilation 2 (Look at outputs of Layer 1 at $t, t-2$)
  • Layer 3: Dilation 4 (Look at outputs of Layer 2 at $t, t-4$)
  • …
  • Layer 10: Dilation 512.

Receptive Field: Exponential growth: $2^L$. With 10 layers, we cover 1024 samples. Stack multiple blocks to reach 16,000.

Conditioning: WaveNet is conditioned on the Mel-spectrogram $c$. \(P(x_t | x_{<t}, c) = \text{softmax}(W \cdot \tanh(W_f x + V_f c) \cdot \sigma(W_g x + V_g c))\) (Gated Activation Unit).

13. Deep Dive: HiFi-GAN Architecture

HiFi-GAN (High Fidelity GAN) is the current state-of-the-art vocoder because it’s fast and high quality.

Generator:

  • Input: Mel-spectrogram.
  • Multi-Receptive Field Fusion (MRF):
    • Instead of one ResNet block, it runs multiple ResNet blocks with different kernel sizes and dilation rates in parallel.
    • Sums their outputs.
    • Allows capturing both fine-grained details (high frequency) and long-term dependencies (low frequency).

Discriminators:

  1. Multi-Period Discriminator (MPD):
    • Reshapes 1D audio into 2D matrices of height $p$ (periods 2, 3, 5, 7, 11).
    • Applies 2D convolution.
    • Detects periodic artifacts (metallic sounds).
  2. Multi-Scale Discriminator (MSD):
    • Operates on raw audio, 2x downsampled, 4x downsampled audio.
    • Ensures structure is correct at different time scales.

Loss:

  • GAN Loss (Adversarial).
  • Feature Matching Loss (Match intermediate layers of discriminator).
  • Mel-Spectrogram Loss (L1 distance).

14. System Design: Streaming TTS Architecture

Challenge: User shouldn’t wait 5 seconds for a long paragraph to be synthesized.

Architecture:

  1. Text Chunking:
    • Split text by punctuation (., !, ?).
    • “Hello world! How are you?” -> [“Hello world!”, “How are you?”].
  2. Incremental Synthesis:
    • Send Chunk 1 to TTS Engine.
    • While Chunk 1 is playing, synthesize Chunk 2.
  3. Buffer Management:
    • Client maintains a jitter buffer (e.g., 200ms).
    • If synthesis is faster than playback (RTF < 1.0), buffer fills up.
    • If synthesis is slower, buffer underruns (stuttering).
  4. Protocol:
    • WebSocket / gRPC: Bi-directional streaming.
    • Server sends binary audio chunks (PCM or Opus encoded).

Stateful Context:

  • Simply splitting by sentence breaks prosody (pitch resets at start of sentence).
  • Contextual TTS: Pass the embedding of the previous sentence’s end state as the initial state for the next sentence.

15. Advanced: Style Transfer and Emotion Control

Global Style Tokens (GST):

  • Learn a bank of “style embeddings” (tokens) during training in an unsupervised way.
  • At inference, we can choose a token (e.g., Token 3 might capture “fast/angry”, Token 5 “slow/sad”).
  • We can mix styles: $0.5 \times \text{Happy} + 0.5 \times \text{Whisper}$.

Reference Audio:

  • Feed a 3-second clip of expressive speech.
  • Reference Encoder extracts style vector.
  • TTS synthesizes new text with that style.

16. Case Study: Voice Cloning for Accessibility

Scenario: A patient with ALS (Lou Gehrig’s disease) is losing their voice. They want to “bank” their voice to use with a TTS system later.

Process:

  1. Recording: Patient records 30-60 minutes of reading scripts while they can still speak.
  2. Fine-Tuning:
    • Take a pre-trained multi-speaker model (e.g., trained on LibriTTS).
    • Freeze the encoder/decoder layers.
    • Fine-tune the Speaker Embedding and last few decoder layers on the patient’s data.
  3. Deployment: Run the model on an iPad (using CoreML/TensorFlow Lite).

Challenges:

  • Fatigue: Patient cannot record for hours. Need data-efficient adaptation (Few-Shot Learning).

  • Dysarthria: If speech is already slurred, the model will learn the slur. Need “Voice Repair” (mapping slurred speech to healthy speech space).

  • Dysarthria: If speech is already slurred, the model will learn the slur. Need “Voice Repair” (mapping slurred speech to healthy speech space).

17. Deep Dive: VITS (Conditional Variational Autoencoder with Adversarial Learning)

VITS (2021) is the current state-of-the-art “all-in-one” model. It combines Acoustic Model and Vocoder into a single end-to-end network.

Key Idea:

  • Training: It’s a VAE.
    • Encoder: Takes Audio $\to$ Latent $z$.
    • Decoder: Takes Latent $z$ $\to$ Audio (HiFi-GAN generator).
    • Prior: The latent $z$ is forced to follow a distribution predicted from Text.
  • Inference:
    • Text Encoder predicts the distribution of $z$.
    • Sample $z$.
    • Decoder generates audio.

Flow-based Prior:

  • To make the text-to-latent prediction expressive, it uses Normalizing Flows.

Monotonic Alignment Search (MAS):

  • VITS learns the alignment between text and audio unsupervised during training using Dynamic Programming (MAS). No external aligner needed.

Pros:

  • Higher quality than Tacotron+WaveGlow.
  • Faster than autoregressive models.
  • No mismatch between acoustic model and vocoder.

18. Deep Dive: Prosody Modeling (Pitch, Energy, Duration)

To make speech sound human, we need to control how it’s said.

1. Duration:

  • How long is each phoneme?
  • Model: Predict log-duration for each phoneme.
  • Control: Multiply predicted durations by 1.2x to speak slower.

2. Pitch (F0):

  • Fundamental frequency contour.
  • Model: Predict continuous F0 curve.
  • Control: Shift F0 mean to make voice higher/lower. Scale variance to make it more expressive/monotone.

3. Energy:

  • Loudness (L2 norm of frame).
  • Model: Predict energy per frame.

Architecture:

  • Add these predictors after the Text Encoder.
  • Add the predicted embeddings to the content embedding before the Decoder.

19. Deep Dive: Multi-Speaker and Multi-Lingual TTS

1. Speaker Embeddings (d-vectors):

  • Train a speaker verification model (e.g., GE2E loss).
  • Extract the embedding from the last layer.
  • Condition the TTS model on this vector (Concatenate or AdaIN).

2. Code-Switching:

  • “I want to eat Sushi today.” (English sentence, Japanese word).
  • Challenge: English TTS doesn’t know Japanese phonemes.
  • Solution: Shared Phoneme Set (IPA).
  • Model: Train on mixed data. Use a Language ID embedding.

20. Deep Dive: Audio Codecs for Generative Audio

With models like Vall-E and AudioLM, we treat audio generation as language modeling. But audio is continuous.

Neural Audio Codecs (EnCodec / DAC):

  • Encoder: Compresses audio to low-framerate latent.
  • Quantizer (RVQ - Residual Vector Quantization):
    • Discretizes latent into “codebook indices” (tokens).
    • Hierarchical: Codebook 1 captures coarse structure, Codebook 2 captures residual error, etc.
  • Decoder: Reconstructs audio from tokens.

Result:

  • 1 second of audio $\to$ 75 tokens.
  • Now we can use GPT-4 on these tokens!

21. System Design: On-Device TTS Optimization

Scenario: Siri/Google Assistant running on a phone without internet.

Constraints:

  • Size: Model < 50MB.
  • Compute: < 10% CPU usage.

Techniques:

  1. Quantization: Float32 $\to$ Int8. (4x smaller).
  2. Pruning: Remove 50% of weights that are near zero.
  3. Knowledge Distillation: Train a tiny student model to mimic the large teacher.
  4. Streaming Vocoder: Use LPCNet (combines DSP with small RNN) or Multi-Band MelGAN (generates 4 frequency bands in parallel).

22. Evaluation: MUSHRA Tests

MOS is simple but subjective. MUSHRA (Multiple Stimuli with Hidden Reference and Anchor) is more rigorous.

Setup:

  • Listener hears:
    • Reference: Original recording (Ground Truth).
    • Anchor: Low-pass filtered version (Bad quality baseline).
    • Samples: Model A, Model B, Model C (blinded).
  • Task: Rate all of them from 0-100 relative to Reference.

Why Anchor?

  • Calibrates the scale. If someone rates the Anchor as 80, their data is discarded.

23. Interview Questions

Q1: Why use Mel-spectrograms instead of linear spectrograms? Answer: Mel-scale matches human hearing (logarithmic perception of pitch). It compresses the data dimension (e.g., 1024 linear $\to$ 80 Mel), making the model easier to train.

Q2: Autoregressive vs Non-Autoregressive TTS? Answer:

  • AR (Tacotron): Higher quality, better prosody, slow, robustness issues.
  • Non-AR (FastSpeech): Fast, robust, controllable, slightly lower prosody quality (averaged).

Q3: How to handle OOV words? Answer: Use a G2P (Grapheme-to-Phoneme) model that predicts pronunciation from spelling, rather than a dictionary lookup.

24. Further Reading

  1. “Natural TTS Synthesis by Conditioning WaveNet on Mel Spectrogram Predictions” (Shen et al., 2017): Tacotron 2 paper.
  2. “FastSpeech 2: Fast and High-Quality End-to-End TTS” (Ren et al., 2020).
  3. “HiFi-GAN: Generative Adversarial Networks for Efficient and High Fidelity Speech Synthesis” (Kong et al., 2020).

25. Conclusion

End-to-End TTS has crossed the “Uncanny Valley”. With models like Tacotron 2 and HiFi-GAN, synthesized speech is often indistinguishable from human speech. The focus has now shifted from “quality” to “control” (emotion, style), “efficiency” (on-device TTS), and “adaptation” (zero-shot cloning). As generative audio models (like Vall-E) merge with LLMs, we are entering an era of conversational AI that sounds as human as it thinks.

26. Summary

Component Role Examples
Frontend Text $\to$ Phonemes G2P, Normalization
Acoustic Model Phonemes $\to$ Mel-Spec Tacotron 2, FastSpeech 2
Vocoder Mel-Spec $\to$ Audio WaveNet, HiFi-GAN
Speaker Encoder Voice Cloning d-vector, x-vector

Originally published at: arunbaby.com/speech-tech/0039-end-to-end-tts
