12 minute read

Real-time ASR is hard. Offline ASR is big.

The Use Case: “Transcribe This Meeting”

In Real-Time ASR (Siri), latency is king. You sacrifice accuracy for speed. In Batch ASR (Otter.ai, YouTube Captions), Accuracy is king. You have the whole file. You can look ahead. You can run massive models.

Key Differences:

  • Lookahead: Batch models can see the future context (Bidirectional RNNs/Transformers). Real-time models are causal (Unidirectional).
  • Compute: Batch can run on a massive GPU cluster overnight.
  • Features: Batch enables Speaker Diarization (“Who said what?”) and Summarization.

High-Level Architecture: The Batch Pipeline

+-----------+     +------------+     +-------------+
| Raw Audio | --> | Preprocess | --> | Segmentation|
+-----------+     +------------+     +-------------+
(MP3/M4A)         (FFMpeg/VAD)       (30s Chunks)
                                           |
                                           v
+-----------+     +------------+     +-------------+
| Final Txt | <-- | Post-Proc  | <-- | Transcription|
+-----------+     +------------+     +-------------+
(SRT/JSON)        (Diarization)      (Whisper/ASR)

Pipeline Architecture

A typical Batch Speech Pipeline has 4 stages:

  1. Preprocessing (FFMpeg):
    • Convert format (MP3/M4A -> WAV).
    • Resample (44.1kHz -> 16kHz).
    • Mixdown (Stereo -> Mono).
    • VAD (Voice Activity Detection): Remove silence to save compute.
  2. Segmentation:
    • Split long audio (1 hour) into chunks (30 seconds).
    • Why? Transformer attention scales quadratically (O(N^2)). You can’t feed 1 hour into BERT.
  3. Transcription (ASR):
    • Run Whisper / Conformer on each chunk.
    • Get text + timestamps.
  4. Post-Processing:
    • Diarization: Cluster segments by speaker.
    • Punctuation & Capitalization: “hello world” -> “Hello world.”
    • Inverse Text Normalization (ITN): “twenty dollars” -> “$20”.

Deep Dive: Speaker Diarization

Goal: Partition the audio stream into homogeneous segments according to the speaker identity. Output: “Speaker A spoke from 0:00 to 0:10. Speaker B spoke from 0:10 to 0:15.”

Algorithm:

  1. Embedding: Extract a vector (d-vector / x-vector) for every 1-second sliding window.
  2. Clustering: Use Spectral Clustering or Agglomerative Hierarchical Clustering (AHC) to group similar vectors.
  3. Re-segmentation: Refine boundaries using a Viterbi decode.

Tool: pyannote.audio is the industry standard library.

Deep Dive: Forced Alignment

Goal: Align text to audio at the phoneme level. Input: Audio + Transcript (“The cat sat”). Output: “The” (0.1s - 0.2s), “cat” (0.2s - 0.5s)…

How? We know the sequence of phonemes (from the text). We just need to find the optimal path through the audio frames that matches this sequence. This is solved using Viterbi Alignment (HMMs) or CTC Segmentation.

Use Case:

  • Karaoke: Highlighting lyrics.
  • Video Editing: “Delete this word” -> Cuts the audio frame. (Descript).

System Design: YouTube Auto-Captions

Scale: 500 hours of video uploaded every minute.

Architecture:

  1. Upload: Video lands in Colossus (Google File System).
  2. Trigger: Pub/Sub message to ASR Service.
  3. Sharding: Video is split into 5-minute chunks.
  4. Parallelism: 12 chunks are processed by 12 TPUs in parallel.
  5. Merge: Results are stitched together.
  6. Indexing: Captions are indexed for Search (SEO).

Python Example: Batch Transcription with Whisper

import whisper

# Load model (Large-v2 is slow but accurate)
model = whisper.load_model("large")

# Transcribe
# beam_size=5: Better accuracy, slower
result = model.transcribe("meeting.mp3", beam_size=5)

print(result["text"])

# Segments with timestamps
for segment in result["segments"]:
    start = segment["start"]
    end = segment["end"]
    text = segment["text"]
    print(f"[{start:.2f} - {end:.2f}]: {text}")

Deep Dive: Whisper Architecture (The New Standard)

OpenAI’s Whisper changed the game in 2022. Architecture: Standard Transformer Encoder-Decoder. Key Innovation: Weakly Supervised Training on 680,000 hours of internet audio.

Input:

  • Log-Mel Spectrogram (80 channels).
  • 30-second windows (padded/truncated).

Decoder Tasks (Multitasking): The model predicts special tokens to control behavior:

  • <|startoftranscript|>
  • <|en|> (Language ID)
  • <|transcribe|> or <|translate|>
  • <|timestamps|> (Predict time alignment)

Why it wins: It’s robust to accents, background noise, and technical jargon because it was trained on “wild” data, not just clean audiobooks (LibriSpeech).

Deep Dive: Word Error Rate (WER)

How do we measure accuracy? Levenshtein Distance. WER = (S + D + I) / N

  • S (Substitution): “cat” -> “bat”
  • D (Deletion): “the cat” -> “cat”
  • I (Insertion): “cat” -> “the cat”
  • N: Total words in reference.

Example: Ref: “The cat sat on the mat” Hyp: “The bat sat on mat”

  • Sub: cat->bat (1)
  • Del: the (1)
  • WER = (1 + 1 + 0) / 6 = 33%

Pitfall: WER doesn’t care about meaning. “I am happy” -> “I am not happy” is a small WER but a huge semantic error.

Engineering: Inverse Text Normalization (ITN)

ASR output: “i have twenty dollars” User wants: “I have $20.”

ITN is the process of converting spoken-form text to written-form text. Techniques:

  1. FST (Finite State Transducers): Rule-based grammars (Nvidia NeMo). Fast, deterministic.
  2. LLM Rewriting: “Rewrite this transcript to be formatted correctly.” Slower, but handles complex cases (“Call 1-800-FLOWERS”).

Advanced Topic: CTC vs. Transducer vs. Attention

How does the model align Audio (T frames) to Text (L tokens)? T >> L.

1. CTC (Connectionist Temporal Classification):

  • Output a probability for every frame.
  • Merge repeats: cc-aa-t -> cat.
  • Pros: Fast, parallel.
  • Cons: Conditional independence assumption (frame t doesn’t know about t-1).

2. RNN-Transducer (RNN-T):

  • Has a “Prediction Network” (Language Model) that feeds back previous tokens.
  • Pros: Streaming friendly, better accuracy than CTC.
  • Cons: Hard to train (memory intensive).

3. Attention (Encoder-Decoder):

  • The Decoder attends to the entire Encoder output.
  • Pros: Best accuracy (Global context).
  • Cons: Not streaming friendly (requires full audio). Perfect for Batch.

Deep Dive: Voice Activity Detection (VAD)

In Batch processing, VAD is a Cost Optimization. If 50% of the recording is silence, VAD saves 50% of the GPU/API cost.

Silero VAD: The current state-of-the-art open-source VAD.

  • Model: Enterprise-grade DNN.
  • Size: < 1MB.
  • Speed: < 1ms per chunk.

Pipeline:

  1. Run VAD. Get timestamps [(0, 10), (15, 20)].
  2. Crop audio.
  3. Batch the speech segments.
  4. Send to Whisper.
  5. Re-align timestamps to original file.

Appendix B: Interview Questions

  1. Q: “Why is Whisper better than Wav2Vec 2.0?” A: Wav2Vec 2.0 is Self-Supervised (needs fine-tuning). Whisper is Weakly Supervised (trained on labeled data). Whisper handles punctuation and casing out-of-the-box.

  2. Q: “How do you handle ‘Hallucinations’ in Whisper?” A:
    • Beam Search: Increase beam size.
    • Temperature Fallback: If log-prob is low, increase temperature.
    • VAD: Don’t feed silence to Whisper (it tries to transcribe noise as words).
  3. Q: “What is the difference between Speaker Diarization and Speaker Identification?” A:
    • Diarization: “Who spoke when?” (Speaker A, Speaker B). No names.
    • Identification: “Is this Elon Musk?” (Matches against a database of voice prints).

Deep Dive: Conformer Architecture (The “Macaron” Net)

Whisper uses Transformers. But Google uses Conformers. Idea: Transformers are good at global context (Attention). CNNs are good at local features (Edges). Conformer = CNN + Transformer.

The Block:

  1. Feed Forward (Half-Step): Like a Macaron sandwich.
  2. Self-Attention: Captures long-range dependencies.
  3. Convolution Module: Captures local patterns (phonemes).
  4. Feed Forward (Half-Step).
  5. Layer Norm.

Why? It converges faster and requires less data than pure Transformers for speech.

Deep Dive: SpecAugment (Data Augmentation)

How do you prevent overfitting in ASR? SpecAugment: Augment the Spectrogram, not the Audio.

Transformations:

  1. Time Warping: Stretch/squeeze parts of the spectrogram.
  2. Frequency Masking: Zero out a block of frequencies (Simulates a broken mic).
  3. Time Masking: Zero out a block of time (Simulates packet loss).

Impact: It forces the model not to rely on any single frequency band or time slice. It learns robust features.

System Design: Privacy and PII Redaction

Scenario: You are transcribing Call Center audio. It contains Credit Card numbers. Requirement: Redact PII (Personally Identifiable Information).

Pipeline:

  1. ASR: Transcribe audio to text + timestamps.
  2. NER (Named Entity Recognition): Run a BERT model to find [CREDIT_CARD], [PHONE_NUMBER].
  3. Redaction:
    • Text: Replace with [REDACTED].
    • Audio: Beep out the segment using the timestamps.

Challenge: “My name is Art” vs “This is Art”. NER is hard on lowercase ASR output. Solution: Use a Truecasing model first.

Engineering: GPU Inference Optimization

Batch processing is expensive. How do we make it cheaper?

1. Dynamic Batching:

  • Don’t run 1 file at a time.
  • Pack 32 files into a batch.
  • Padding: Pad all files to the length of the longest file.
  • Sorting: Sort files by duration before batching to minimize padding (and wasted compute).

2. TensorRT / ONNX Runtime:

  • Compile the PyTorch model to TensorRT.
  • Fuses layers (Conv + ReLU).
  • Quantization (FP16 or INT8).
  • Speedup: 2x - 5x.

3. Flash Attention:

  • IO-aware exact attention.
  • Reduces memory usage from (O(N^2)) to (O(N)). Allows processing 1-hour files in one go.

Advanced Topic: Multilingual ASR

Problem: Code-switching (“Hindi-English”). Solution:

  1. Language ID: Predict language every 5 seconds.
  2. Multilingual Model: Train one model on 100 languages (Whisper).
    • It learns a shared representation of “Speech”.
    • It can even do Zero-Shot Translation (Speech in French -> Text in English).

Case Study: Spotify Podcast Transcription

Goal: Transcribe 5 million podcasts for Search. Challenges:

  • Music: Podcasts have intro music. ASR tries to transcribe lyrics.
  • Overlapping Speech: 3 people laughing.
  • Length: Joe Rogan is 3 hours long.

Solution:

  1. Music Detection: Remove music segments.
  2. Chunking: Split into 30s chunks with 5s overlap.
  3. Deduplication: Merge the overlap regions using “Longest Common Subsequence”.

Appendix C: Advanced Interview Questions

  1. Q: “How does CTC Loss handle alignment?” A: It introduces a “blank” token <eps>. c-a-t aligns to c <eps> a <eps> t. It sums over all possible alignments that produce the target text.

  2. Q: “What is the difference between Online and Offline Diarization?” A:
    • Online: Must decide “Who is speaking?” now. Hard.
    • Offline: Can look at the whole file. Can run clustering (Spectral/AHC) on all embeddings. Much better accuracy.
  3. Q: “How do you optimize ASR for a specific domain (e.g., Medical)?” A:
    • Fine-tuning: Train the acoustic model on medical audio.
    • Language Model Fusion: Train a text-only LM on medical journals. Fuse it with the ASR output during decoding (Shallow Fusion).

Deep Dive: Beam Search Decoding

The model outputs probabilities for each token: P(token | audio). Greedy Search: Pick the highest probability token at each step.

  • Problem: It misses the global optimum. “The” (0.9) -> “cat” (0.1) might be worse than “A” (0.4) -> “dog” (0.8).

Beam Search: Keep the top K (Beam Width) hypotheses alive at each step.

  1. Start with [<s>].
  2. Expand all K paths by 1 token.
  3. Calculate score: log(P(path)).
  4. Keep top K.
  5. Repeat.

Beam Width Trade-off:

  • K=1: Greedy (Fast, Bad).
  • K=5: Good balance (Whisper default).
  • K=100: Diminishing returns, very slow.

Advanced Topic: Language Model Integration (Shallow vs. Deep Fusion)

ASR models know phonetics. Language Models (GPT) know grammar. How do we combine them?

1. Shallow Fusion: Score = log P_ASR(y|x) + lambda * log P_LM(y)

  • We interpolate the scores during Beam Search.
  • Pros: No retraining of ASR. Can swap LMs easily (Medical LM, Legal LM).

2. Deep Fusion:

  • Concatenate the hidden states of ASR and LM before the softmax layer.
  • Pros: Better integration.
  • Cons: Requires retraining.

System Design: Audio Fingerprinting (Shazam)

Problem: Identify the song in the background. Algorithm:

  1. Spectrogram: Convert audio to Time-Frequency.
  2. Peaks: Find local maxima (constellation map).
  3. Hashes: Form pairs of peaks (Anchor point + Target point).
    • Hash = (Freq1, Freq2, DeltaTime)
  4. Database: Store Hash -> (SongID, AbsoluteTime).
  5. Query: Match hashes. Find a cluster of matches with consistent time offset.

Engineering: FFMpeg Tricks for Speech

FFMpeg is the Swiss Army Knife of Batch Processing.

1. Normalization (Loudness): ffmpeg -i input.wav -filter:a loudnorm output.wav Ensures consistent volume (-14 LUFS).

2. Silence Removal: ffmpeg -i input.wav -af silenceremove=stop_periods=-1:stop_duration=1:stop_threshold=-50dB output.wav Trims silence > 1 second.

3. Speed Up (without changing pitch): ffmpeg -i input.wav -filter:a atempo=1.5 output.wav Listen to podcasts at 1.5x.

Case Study: Alexa’s Wake Word Detection (Cascade)

Alexa is always listening. But sending audio to the cloud is expensive (and creepy). Solution: Cascade Architecture.

  1. Stage 1 (DSP): Low power chip. Detects energy. (mW).
  2. Stage 2 (Tiny NN): On-device model. Detects “Alexa”. (High Recall, Low Precision).
  3. Stage 3 (Cloud): Full ASR. Verifies “Alexa” and processes the command. (High Precision).

Appendix D: The “Long-Tail” Problem

ASR works great for “Standard American English”. It fails for:

  • Accents: Scottish, Singaporean.
  • Stuttering: “I… I… want to go”.
  • Code Switching: “Chalo let’s go”.

Solution:

  • Data Augmentation: Add noise, speed perturbation.
  • Transfer Learning: Fine-tune on specific accent datasets (Common Voice).

Conclusion

Batch processing allows us to use the “Heavy Artillery” of AI. We can use the biggest models, look at the entire context, and perform complex post-processing. If you found this helpful, consider sharing it with others who might benefit.

Related across topics
