Speech Quality Monitoring

How do we know if the audio sounds “good” without asking a human?

The Problem: Subjectivity

In Image Classification, “Accuracy” is objective. Is it a cat? Yes/No. In Speech, “Quality” is subjective.

• “The audio is intelligible but robotic.”
• “The audio is natural but has background noise.”
• “The audio cuts in and out (packet loss).”

For decades, the gold standard was MOS (Mean Opinion Score).

1. Gather 20 humans.
2. Play them an audio clip.
3. Ask them to rate it 1 (Bad) to 5 (Excellent).
4. Average the scores.

Problem: This is slow, expensive, and impossible to run in real-time on a Zoom call. We need Objective Metrics.

Intrusive vs. Non-Intrusive Metrics

1. Intrusive (Full-Reference)

You have the “Clean” (Reference) audio and the “Degraded” (Test) audio. You compare them.

• Use Case: Codec development (MP3 vs AAC), Denoising model training.
• Metrics:
  • PESQ (Perceptual Evaluation of Speech Quality): The classic telecom standard. Models human hearing.
  • POLQA (Perceptual Objective Listening Quality Analysis): The successor to PESQ. Handles wideband (HD) voice better.
  • ViSQOL (Virtual Speech Quality Objective Listener): Google’s open-source metric. Uses similarity of spectrograms.

2. Non-Intrusive (No-Reference)

You only have the “Degraded” audio. You don’t know what the original sounded like.

• Use Case: Real-time monitoring (Zoom, Discord). You receive audio from the internet; you don’t have the sender’s microphone feed.
• Metrics:
  • P.563: Old standard.
  • NISQA (Non-Intrusive Speech Quality Assessment): Deep Learning based.
  • DNS-MOS: Microsoft’s Deep Noise Suppression MOS predictor.

Deep Dive: ViSQOL (Google)

How does a machine “listen”? ViSQOL aligns the reference and degraded signals in time, then compares their spectrograms using a Structural Similarity Index (SSIM)-like approach.

1. Spectrogram: Convert audio to Time-Frequency domain.
2. Alignment: Use dynamic time warping to align the two signals (handling delays/jitter).
3. Patch Comparison: Compare small patches of the spectrograms.
4. Mapping: Map the similarity score to a MOS (1-5).

Deep Dive: NISQA (Deep Learning for Quality)

NISQA is a CNN-LSTM model trained to predict human MOS scores directly from raw audio.

Architecture:

• Input: Mel-Spectrogram.
• CNN Layers: Extract local features (noise, distortion).
• Self-Attention / LSTM: Capture temporal dependencies (dropouts, silence).
• Output: Predicted MOS (e.g., 3.8).

Why is this revolutionary? It allows Reference-Free monitoring. You can run this on the client side (in the browser) to tell the user: “Your microphone quality is poor.”

If you found this helpful, consider sharing it with others who might benefit.

High-Level Architecture: Real-Time Quality Monitor

+-----------+     +------------+     +-------------+
| VoIP App  | --> | Edge Calc  | --> | Metrics Agg |
+-----------+     +------------+     +-------------+
(Microphone)      (DNS-MOS/VAD)      (Prometheus)
                                           |
                                           v
+-----------+     +------------+     +-------------+
| Codec Sw  | <-- | Alerting   | <-- | Dashboard   |
+-----------+     +------------+     +-------------+
(Opus Mode)       (Slack/PD)         (Grafana)

System Design: Real-Time Quality Monitor for VoIP

Scenario: You are building the quality monitoring system for a Zoom competitor.

1. Client-Side (Edge):

• Packet Loss Rate: Simple counter.
• Jitter: Variance in packet arrival time.
• Energy Level: Is the user speaking? (VAD).
• Lightweight ML: Run a tiny TFLite model (DNS-MOS) every 10 seconds on a 1-second slice.

2. Server-Side (Aggregator):

• Ingest metrics into Prometheus.
• Alerting: If Avg MOS < 3.0 for a specific region (e.g., “India-South”), trigger an alert. It might be a network outage.

3. Feedback Loop:

• If quality drops, the client automatically switches codecs (e.g., Opus 48kbps -> Opus 12kbps) or enables aggressive packet loss concealment (PLC).

Deep Dive: The Math of PESQ

PESQ (ITU-T P.862) isn’t just a simple subtraction. It simulates the human ear.

Steps:

1. Level Alignment: Adjust volume so Reference and Degraded are equally loud.
2. Input Filter: Simulate the frequency response of a telephone handset (300Hz - 3400Hz).
3. Auditory Transform:
   • Convert FFT to Bark Scale (perceptual pitch).
   • Convert Amplitude to Sone Scale (perceptual loudness).
4. Disturbance Calculation:
   • Subtract the two “Loudness Spectra”.
   • D = |L_ref - L_deg|.
   • Apply asymmetric masking (we notice added noise more than missing sound).
5. Aggregation: Average the disturbance over time and frequency to get a score ( -0.5 to 4.5).

Engineering Component: Voice Activity Detection (VAD)

You can’t measure quality if no one is talking. Silence is always “perfect quality”. We need a VAD to filter out silence frames.

Simple Energy-Based VAD (Python):

import numpy as np

def simple_vad(audio, frame_len=160, threshold=0.01):
    # audio: numpy array of samples
    # frame_len: 10ms at 16kHz

    frames = []
    for i in range(0, len(audio), frame_len):
        frame = audio[i:i+frame_len]
        energy = np.sum(frame ** 2) / len(frame)

        if energy > threshold:
            frames.append(frame)

    return np.concatenate(frames) if frames else np.array([])

Advanced VAD: WebRTC VAD uses a Gaussian Mixture Model (GMM) to distinguish speech from noise.

Network Engineering: WebRTC Internals

How does Zoom know your quality is bad? RTCP (Real-time Transport Control Protocol).

Every few seconds, the receiver sends an RTCP Receiver Report (RR) back to the sender. Fields:

1. Fraction Lost: Percentage of packets lost since last report.
2. Cumulative Lost: Total packets lost.
3. Interarrival Jitter: Variance in packet delay.

The Quality Estimator: MOS_est = 4.5 - PacketLossPenalty - JitterPenalty - LatencyPenalty This is the E-Model (ITU-T G.107). It’s a heuristic formula, not a neural net.

Audio Processing: Packet Loss Concealment (PLC)

When a packet is lost, you have a 20ms gap in audio. Option 1: Silence. (Sounds like a click/pop). Bad. Option 2: Repeat. (Repeat last 20ms). Robotic. Option 3: Waveform Similarity Overlap-Add (WSOLA). Stretch the previous packet to cover the gap. Option 4: Deep PLC (Packet Loss Concealment).

• Use a Generative Model (GAN/RNN) to predict what the missing packet should have been based on context.
• NetEQ (WebRTC): Uses a jitter buffer and DSP-based PLC to smooth out network bumps.

Deep Dive: DNS-MOS (Microsoft)

Microsoft’s Deep Noise Suppression (DNS) dataset is huge. They trained a metric to evaluate it. Architecture:

• Input: Log-Mel Spectrogram.
• Backbone: ResNet-18 or Polyphonic Inception.
• Heads:
  1. SIG: Signal Quality (How natural is the speech?).
  2. BAK: Background Quality (How intrusive is the noise?).
  3. OVRL: Overall Quality.
• Training: Trained on P.808 crowdsourced data (humans rating noisy clips).

Why separate SIG and BAK? Sometimes a denoiser removes noise (Good BAK) but makes the voice sound muffled (Bad SIG). We need to balance both.

Deep Dive: Psychoacoustics

Why do we need complex metrics like PESQ? Why not just use MSE (Mean Squared Error)? MSE is terrible for audio.

• Phase Shift: If you shift a signal by 1ms, MSE is huge, but it sounds identical.
• Masking: If a loud sound plays at 1000Hz, you can’t hear a quiet sound at 1100Hz.
• Equal Loudness: A 50Hz tone needs to be much louder than a 1000Hz tone to be heard (Fletcher-Munson curves).

Perceptual Loss Functions: In Deep Learning (e.g., Speech Enhancement), we minimize a “Perceptual Loss”. Loss = |VGG(Ref) - VGG(Deg)| We pass audio through a pre-trained network (like VGGish or wav2vec) and compare the activations, not the raw pixels/samples.

Advanced Metric: STOI (Short-Time Objective Intelligibility)

PESQ measures “Quality” (How pleasant?). STOI measures “Intelligibility” (Can you understand the words?).

Use Case: Cochlear Implants, Hearing Aids. A signal can be ugly (robotic) but perfectly intelligible (High STOI, Low PESQ). A signal can be beautiful but mumbled (Low STOI, High PESQ).

Algorithm:

1. Decompose signal into TF-units (Time-Frequency).
2. Calculate correlation between Reference and Degraded envelopes in each band.
3. Average the correlations.

System Design: The “Netflix for Audio” Quality Pipeline

Scenario: You are building Spotify’s ingestion pipeline. Goal: Reject tracks with bad encoding artifacts.

Pipeline:

1. Ingest: Upload WAV/FLAC.
2. Transcode: Convert to Ogg Vorbis (320kbps, 160kbps, 96kbps).
3. Quality Check (ViSQOL): Compare Transcoded vs. Original.
   • If ViSQOL < 4.5 for 320kbps, something is wrong with the encoder.
4. Loudness Normalization (LUFS):
   • Measure Integrated Loudness (EBU R128).
   • If track is too quiet (-20 LUFS), gain up.
   • If track is too loud (-5 LUFS), gain down to target (-14 LUFS).

Codec Comparison: Opus vs. AAC vs. EVS

Feature	Opus	AAC-LD	EVS (5G)
Latency	Ultra Low (5ms)	Low (20ms)	Low (20ms)
Bitrate	6kbps - 510kbps	32kbps+	5.9kbps - 128kbps
Quality	Excellent	Good	Excellent
Packet Loss	Built-in FEC	Poor	Channel Aware
Use Case	Zoom, Discord	FaceTime	VoLTE, 5G Calls

Why Opus wins: It switches modes (SILK for speech, CELT for music) dynamically.

Appendix C: Subjective Testing (MUSHRA)

When MOS isn’t enough, we use MUSHRA (Multiple Stimuli with Hidden Reference and Anchor).

1. Hidden Reference: The original audio (should be rated 100).
2. Anchor: A low-pass filtered version (should be rated 20).
3. Test Systems: The models we are testing.

Why? It calibrates the listeners. If a listener rates the Anchor as 80, we disqualify them.

Deep Dive: Room Acoustics and RT60

Quality isn’t just about the codec; it’s about the Room. RT60 (Reverberation Time): Time it takes for sound to decay by 60dB.

• Studio: 0.3s (Dry).
• Living Room: 0.5s.
• Cathedral: 4.0s (Wet).

Impact on ASR: High RT60 smears the spectrogram. ASR models fail. Solution: Dereverberation (WPE - Weighted Prediction Error).

Hardware Engineering: Microphone Arrays

How does Alexa hear you from across the room? Beamforming. Using multiple microphones, we can steer the “listening beam” towards the speaker and nullify noise from the TV.

Metrics:

1. Directivity Index (DI): Gain in the look direction vs. average gain.
2. White Noise Gain (WNG): Robustness to sensor noise.

MVDR Beamformer (Minimum Variance Distortionless Response): Mathematically minimizes output power while maintaining unity gain in the target direction.

Advanced Topic: Spatial Audio Quality

With VR/AR (Apple Vision Pro), audio is 3D. HRTF (Head-Related Transfer Function): How your ears/head filter sound based on direction.

Quality Metrics for Spatial Audio:

1. Localization Accuracy: Can the user pinpoint the source?
2. Timbral Coloration: Does the HRTF distort the tone?
3. Externalization: Does it sound like it’s “out there” or “in your head”?

Security: Audio Watermarking and Deepfake Detection

The Threat: AI Voice Cloning (ElevenLabs). The Defense: Watermarking. Embed an inaudible signal (spread spectrum) into the audio.

Detection:

1. Artifact Analysis: GANs leave traces in the high frequencies.
2. Phase Continuity: Natural speech has specific phase relationships. Vocoders often break them.
3. Biometrics: Verify the “Voice Print” against a known enrollment.

Accessibility: Hearing Loss Simulation

To ensure quality for everyone, we must simulate hearing loss. Presbycusis: Age-related high-frequency loss. Recruitment: Loud sounds become painful quickly.

Testing: Run the audio through a “Hearing Loss Simulator” (Low-pass filter + Dynamic Range Compression) and run STOI. If STOI drops too much, the content is not accessible.

Deep Dive: Audio Codec Internals (MDCT)

How does MP3/Opus actually compress audio? MDCT (Modified Discrete Cosine Transform). It’s like FFT, but with overlapping windows (50% overlap) to prevent “blocking artifacts”.

Process:

1. Windowing: Multiply signal by a window function (Sine/Kaiser).
2. MDCT: Convert to frequency domain.
3. Quantization: Round the float values to integers. This is where loss happens.
4. Entropy Coding: Huffman coding to compress the integers.

Psychoacoustic Model: The encoder calculates the Masking Threshold for each frequency band. If the quantization noise is below the masking threshold, the human ear can’t hear it. So, we can quantize heavily (low bitrate) without perceived loss.

Deep Dive: Opus Internals (SILK + CELT)

Opus is the king of VoIP. Why? It’s a hybrid.

1. SILK (Skype):

• Type: LPC (Linear Predictive Coding).
• Best for: Speech (Low frequencies).
• Mechanism: Models the vocal tract as a tube. Transmits the “excitation” (glottis) and “filter” (throat/mouth).

2. CELT (Xiph.org):

• Type: MDCT (Transform Coding).
• Best for: Music (High frequencies).
• Mechanism: Transmits the spectral energy.

Hybrid Mode: Opus sends Low Frequencies (< 8kHz) via SILK and High Frequencies (> 8kHz) via CELT. Best of both worlds.

Network Engineering: Congestion Control (GCC vs. BBR)

If the network is congested, sending more data makes it worse. We need to lower the bitrate.

Google Congestion Control (GCC):

• Delay-based: If RTT increases, reduce bitrate.
• Loss-based: If packet loss > 2%, reduce bitrate.
• Kalman Filter: Predicts the network capacity.

BBR (Bottleneck Bandwidth and Round-trip propagation time):

• Probes the network to find the max bandwidth and min RTT.
• Much more aggressive than GCC. Used in QUIC.

Hardware: MEMS vs. Condenser Microphones

Quality starts at the sensor. MEMS (Micro-Electro-Mechanical Systems):

• Pros: Tiny, cheap, solderable (SMD). Used in phones/laptops.
• Cons: High noise floor (SNR ~65dB).

Condenser (Electret):

• Pros: High sensitivity, low noise (SNR > 70dB). Studio quality.
• Cons: Large, requires phantom power (48V).

Clipping: If the user screams, the mic diaphragm hits the limit. The signal is “clipped” (flat top). Digital Clipping: Exceeding 0dBFS. Solution: Analog Gain Control (AGC) before the ADC.

Appendix E: The Future of Quality

Neural Codecs (EnCodec/SoundStream): They don’t optimize SNR. They optimize Perceptual Quality. At 3kbps, they sound better than Opus at 12kbps, but the waveform looks completely different. Implication: Traditional metrics (SNR, PSNR) are dead. We must use Neural Metrics (NISQA, CDPAM).

Appendix F: Interview Questions

1. Q: “How do you handle packet loss in a real-time audio app?” A:
   • Jitter Buffer: Hold packets for 20-50ms to reorder them.
   • FEC (Forward Error Correction): Send redundant data (XOR of previous packets).
   • PLC (Packet Loss Concealment): Generate fake audio to fill gaps.

2. Q: “Why is 44.1kHz the standard sample rate?” A: Nyquist Theorem. Humans hear up to 20kHz. We need 2 * MaxFreq to reconstruct the signal. 2 * 20kHz = 40kHz. The extra 4.1kHz is for anti-aliasing filter roll-off.

3. Q: “What is the Cocktail Party Problem?” A: The ability to focus on one speaker in a noisy room. Humans do it easily (binaural hearing). Machines struggle. Solved using Blind Source Separation (BSS) or Target Speech Extraction (TSE).

Conclusion

Speech Quality Monitoring is moving from “Signal Processing” (PESQ) to “Deep Learning” (NISQA). Just like in Vision (Perceptual Loss) and NLP (BERTScore), we are learning that Neural Networks are the best judges of Neural Networks.

from pesq import pesq
from scipy.io import wavfile

# Load audio (must be 8k or 16k for PESQ)
rate, ref = wavfile.read("reference.wav")
rate, deg = wavfile.read("degraded.wav")

# Calculate PESQ (Wideband)
score = pesq(rate, ref, deg, 'wb')
print(f"PESQ Score: {score:.2f}")
# Output: 3.5 (Fair to Good)

Appendix A: The “Silent” Failure in Speech

In ASR (Speech-to-Text), a common failure is Hallucination.

• Silence -> Model outputs “Thank you very much.”
• Noise -> Model outputs “I will kill you.” (This actually happens!).

Quality Monitoring for ASR:

• Log-Likelihood: If the model is confident.
• Speech-to-Noise Ratio (SNR): If SNR is too low, don’t transcribe.
• VAD (Voice Activity Detection): Only send audio that contains speech.

Conclusion

Speech Quality Monitoring is moving from “Signal Processing” (PESQ) to “Deep Learning” (NISQA). Just like in Vision (Perceptual Loss) and NLP (BERTScore), we are learning that Neural Networks are the best judges of Neural Networks.
