ASR Beam Search Implementation

Implementing the core decoding logic of modern Speech Recognition systems, handling alignment, blanks, and language models.

Problem

Standard Beam Search (for Transformers) generates one token at a time. CTC Beam Search processes a sequence of probabilities over time steps.

The Rules of CTC:

1. Blank Token (<blk>): A special token that represents “silence” or “no transition”.
2. Collapse Repeats: AA -> A.
3. Blanks Separate: A <blk> A -> AA. (This allows us to spell words like “Aaron”).

Example:

• Output: h h e e l l l <blk> l l o
• Collapse: h e l <blk> l o
• Remove Blanks: h e l l o

Background: A Brief History of Decoders

To understand CTC, we must understand what came before.

1. HMM-GMM (1980s-2000s): The “Dark Ages”. We modeled speech as a Hidden Markov Model. The decoder was a massive Viterbi search over a graph of Phonemes -> Triphones -> Words -> Sentences. It was complex, fragile, and required expert linguistic knowledge.
2. HMM-DNN (2010-2015): We replaced the Gaussian Mixture Models (GMMs) with Deep Neural Networks (DNNs) to predict phoneme probabilities. The decoder remained the same Viterbi beast.
3. CTC (2006/2015): Alex Graves introduced CTC. Suddenly, we didn’t need phoneme alignment. The model learned to align itself. The decoder became a simple “Prefix Search”.
4. RNN-T (Transducer): An upgrade to CTC that removes the conditional independence assumption. It’s the standard for streaming ASR today (Siri, Google Assistant).
5. Attention (Whisper): The decoder is just a text generator (like GPT) that attends to the audio. Simple, but hard to stream.

Standard Beam Search (for Transformers) generates one token at a time. CTC Beam Search processes a sequence of probabilities over time steps.

The Rules of CTC:

1. Blank Token (<blk>): A special token that represents “silence” or “no transition”.
2. Collapse Repeats: AA -> A.
3. Blanks Separate: A <blk> A -> AA. (This allows us to spell words like “Aaron”).

Example:

• Output: h h e e l l l <blk> l l o
• Collapse: h e l <blk> l o
• Remove Blanks: h e l l o

Why Greedy Fails in Speech

Imagine the audio for “The cat”.

• Frame 10: P(The) = 0.6, P(A) = 0.4
• Frame 11: P(cat) = 0.4, P(car) = 0.6

Greedy might pick “The car”. But maybe “A cat” was more likely overall if we looked at the whole sequence. Beam Search allows us to keep “A” alive as a hypothesis until we see “cat”, which confirms it.

Algorithm: CTC Beam Search

This is more complex than standard Beam Search because we have to track two probabilities for each hypothesis:

1. P_b: Probability ending in a Blank.
2. P_nb: Probability ending in a Non-Blank.

Why? Because if the next token is the same as the last one, the behavior depends on whether there was a blank in between.

• A + A = A (Merge)
• A + <blk> + A = AA (No Merge)

The State Space

A hypothesis is defined by the text prefix (e.g., “hel”). At each time step t, we update the probabilities of all active prefixes based on the acoustic probabilities y_t.

Python Implementation

This is a simplified version of the algorithm used in libraries like pyctcdecode.

import numpy as np
from collections import defaultdict

def ctc_beam_search(probs, vocab, beam_width=10):
    """
    probs: (T, V) numpy array of probabilities
    vocab: list of characters (index 0 is <blk>)
    """
    T, V = probs.shape

    # beam: dict mapping prefix -> probability
    # We work in log domain to avoid underflow
    beam = defaultdict(lambda: float('-inf'))

    # Initialize with empty prefix
    # We track two scores: (score_blank, score_non_blank)
    beam[()] = (0.0, float('-inf'))

    for t in range(T):
        next_beam = defaultdict(lambda: (float('-inf'), float('-inf')))

        # Get top-K prefixes from previous step
        # Sort by total score (logsumexp of blank and non-blank)
        sorted_prefixes = sorted(
            beam.items(),
            key=lambda x: np.logaddexp(x[1][0], x[1][1]),
            reverse=True
        )[:beam_width]

        for prefix, (p_b, p_nb) in sorted_prefixes:
            # 1. Handle Blank Token (Index 0)
            pr_blank = probs[t, 0]
            # If we add a blank, the prefix doesn't change.
            # New blank score = log(P(blank at t)) + log(P_total at t-1)
            n_p_b, n_p_nb = next_beam[prefix]
            n_p_b = np.logaddexp(n_p_b, pr_blank + np.logaddexp(p_b, p_nb))
            next_beam[prefix] = (n_p_b, n_p_nb)

            # 2. Handle Non-Blank Tokens
            for v in range(1, V):
                pr_char = probs[t, v]
                char = vocab[v]

                # Case A: Repeat character (e.g., "l" -> "l")
                if len(prefix) > 0 and prefix[-1] == char:
                    # 1. Merge (from non-blank): "l" + "l" -> "l"
                    # We update the NON-blank score of the SAME prefix
                    n_p_b, n_p_nb = next_beam[prefix]
                    n_p_nb = np.logaddexp(n_p_nb, pr_char + p_nb)
                    next_beam[prefix] = (n_p_b, n_p_nb)

                    # 2. No Merge (from blank): "l" + <blk> + "l" -> "ll"
                    # We extend the prefix
                    new_prefix = prefix + (char,)
                    n_p_b, n_p_nb = next_beam[new_prefix]
                    n_p_nb = np.logaddexp(n_p_nb, pr_char + p_b)
                    next_beam[new_prefix] = (n_p_b, n_p_nb)

                # Case B: New character
                else:
                    new_prefix = prefix + (char,)
                    n_p_b, n_p_nb = next_beam[new_prefix]
                    # We can come from blank OR non-blank
                    n_p_nb = np.logaddexp(n_p_nb, pr_char + np.logaddexp(p_b, p_nb))
                    next_beam[new_prefix] = (n_p_b, n_p_nb)

        beam = next_beam

    # Final cleanup: Return top hypothesis
    best_prefix = max(beam.items(), key=lambda x: np.logaddexp(x[1][0], x[1][1]))[0]
    return "".join(best_prefix)

# Mock Data
# T=3, V=3 (<blk>, A, B)
probs = np.log(np.array([
    [0.1, 0.8, 0.1], # Mostly A
    [0.8, 0.1, 0.1], # Mostly Blank
    [0.1, 0.1, 0.8]  # Mostly B
]))
vocab = ['<blk>', 'A', 'B']
print(ctc_beam_search(probs, vocab)) # Output: "AB"

Adding a Language Model (LM)

The acoustic model (AM) is good at sounds, but bad at grammar.

• AM hears: “I want to wreck a nice beach.”
• LM knows: “I want to recognize speech.”

We fuse them during the beam search. Score = Score_AM + (alpha * Score_LM) + (beta * Word_Count)

• Alpha: Weight of the LM (usually 0.5 - 2.0).
• Beta: Word insertion bonus (encourages longer sentences).

KenLM Integration

In production, we use KenLM, a highly optimized C++ library for n-gram language models. We query the LM every time we append a space character (end of a word).

# Pseudo-code for LM scoring
if char == ' ':
    word = get_last_word(new_prefix)
    lm_score = lm.score(word)
    n_p_nb += alpha * lm_score

Measuring Success: Word Error Rate (WER)

In classification, we use Accuracy. In ASR, we use WER. WER = (S + D + I) / N

• S (Substitutions): “cat” -> “hat”
• D (Deletions): “the cat” -> “cat”
• I (Insertions): “cat” -> “the cat”
• N: Total number of words in the reference.

Note: WER can be > 100% if you insert a lot of garbage!

Python Implementation of WER

This uses the Levenshtein Distance algorithm (Dynamic Programming!).

def calculate_wer(reference, hypothesis):
    r = reference.split()
    h = hypothesis.split()
    n = len(r)
    m = len(h)

    # DP Matrix
    d = np.zeros((n+1, m+1))

    for i in range(n+1): d[i][0] = i
    for j in range(m+1): d[0][j] = j

    for i in range(1, n+1):
        for j in range(1, m+1):
            if r[i-1] == h[j-1]:
                d[i][j] = d[i-1][j-1]
            else:
                sub = d[i-1][j-1] + 1
                ins = d[i][j-1] + 1
                rem = d[i-1][j] + 1
                d[i][j] = min(sub, ins, rem)

    return d[n][m] / n

ref = "the cat sat on the mat"
hyp = "the cat sat on mat" # Deletion
print(calculate_wer(ref, hyp)) # 1/6 = 16.6%

Streaming ASR: The Infinite Loop

Standard Beam Search waits for the end of the file. In a live meeting, you can’t wait. We need Streaming Decoding.

Challenges:

1. Latency: Users expect text to appear < 200ms after they speak.
2. Stability: The decoder might change its mind. “I want to…” -> “I want two…”. This “flicker” is annoying.

Solution:

• Partial Results: Output the current best hypothesis every 100ms.
• Endpointing: If the user pauses for > 500ms, finalize the sentence and clear the beam history.
• Stability Heuristic: Only display words that have been stable for 3 frames.

Hot-Word Boosting (Contextual Biasing)

If you build an ASR for a medical app, it needs to know “Hydrochlorothiazide”. A generic LM won’t know it. We use Contextual Biasing.

Algorithm:

1. Build a Trie of hot-words (e.g., contact names, drug names).
2. During Beam Search, traverse the Trie with the current prefix.
3. If we are inside a hot-word node, add a bonus score.

# Pseudo-code
if current_prefix in hot_word_trie:
    score += boosting_weight

Debugging the Decoder

When your WER (Word Error Rate) is high, how do you know if it’s the Model or the Decoder?

1. Force Alignment: Feed the correct transcript into the decoder and see its probability. If the probability is high but the decoder didn’t pick it, your Beam Width is too small (search error).
2. Greedy Check: If Greedy Search gives garbage, your Model is bad (modeling error).
3. LM Weight Tuning: Grid search alpha and beta on a validation set. A bad alpha can ruin a perfect acoustic model.

Appendix A: The Mathematics of CTC

For those who want to understand the “Forward-Backward” algorithm used in CTC training.

Objective: Maximize P(Y|X). Since many paths map to Y (e.g., AA and A both map to A), we sum over all valid paths.

P(Y|X) = Sum_{pi in Path(Y)} P(pi|X)

Dynamic Programming (Forward Variable alpha): alpha_t(s): Probability of outputting the first s characters of Y after t time steps.

Transitions:

• If Y[s] == Y[s-2] (repeat char): We can only come from alpha_{t-1}(s) or alpha_{t-1}(s-1).
• If Y[s] != Y[s-2] (new char): We can also come from alpha_{t-1}(s-2) (skipping the blank).

This O(T * S) algorithm is what allows CTC to be differentiable and trainable via backpropagation.

Appendix B: Complete Python Decoder Class

import numpy as np
from collections import defaultdict

class CTCDecoder:
    def __init__(self, vocab, beam_width=100, alpha=0.5, beta=1.0):
        self.vocab = vocab
        self.beam_width = beam_width
        self.alpha = alpha
        self.beta = beta

    def decode(self, probs):
        """
        probs: (T, V)
        Returns: best_string
        """
        # Initialization
        beam = defaultdict(lambda: (float('-inf'), float('-inf')))
        beam[()] = (0.0, float('-inf'))

        for t in range(len(probs)):
            next_beam = defaultdict(lambda: (float('-inf'), float('-inf')))

            # Pruning: Only keep top beam_width
            sorted_beam = sorted(
                beam.items(),
                key=lambda x: np.logaddexp(x[1][0], x[1][1]),
                reverse=True
            )[:self.beam_width]

            for prefix, (p_b, p_nb) in sorted_beam:
                # ... (Same logic as above) ...
                # See main article for the core loop
                pass

            beam = next_beam

        return self._get_best_hypothesis(beam)

    def _get_best_hypothesis(self, beam):
        best_prefix = max(beam.items(), key=lambda x: np.logaddexp(x[1][0], x[1][1]))[0]
        return "".join(best_prefix)

Appendix C: The ASR Troubleshooting Guide

Problem: The decoder outputs nothing.

• Cause: Your blank probability is 1.0 everywhere.
• Fix: Check your training data. Are your labels aligned? Is the learning rate too high (exploding gradients)?

Problem: The decoder repeats words (“hello hello hello”).

• Cause: The model is confident for too many frames.
• Fix: Increase the blank probability penalty or use a Language Model with a repetition penalty.

Problem: WER is 100%.

• Cause: Vocabulary mismatch. Are you using the same char-to-int mapping as training?
• Fix: Verify vocab.json.

Appendix D: Deep Dive into WFST (Weighted Finite State Transducers)

Before Deep Learning took over, ASR was built on WFSTs. Even today, the Kaldi toolkit (which powers many production systems) uses them.

What is a WFST? It’s a graph where edges have:

1. Input Label (e.g., Phoneme)
2. Output Label (e.g., Word)
3. Weight (Probability)

The Composition (H o C o L o G): We build a massive static graph by composing four smaller graphs:

• H (HMM): Maps HMM states to Context-Dependent Phones.
• C (Context): Maps Context-Dependent Phones to Phones.
• L (Lexicon): Maps Phones to Words (Pronunciation Dictionary).
• G (Grammar): Maps Words to Sentences (Language Model).

Decoding: Decoding is simply finding the shortest path in the H o C o L o G graph. This is extremely fast because the graph is pre-compiled and optimized (determinized and minimized).

Why learn this? If you work on Edge AI (embedded devices), you might not have the RAM for a Transformer. A WFST decoder is incredibly memory-efficient and fast.

Conclusion

Implementing a CTC Beam Search decoder is a rite of passage. It forces you to understand the probabilistic nature of speech.

While end-to-end models (like Whisper) are replacing complex decoders with simple model.generate(), understanding Beam Search is still crucial for:

1. Streaming ASR (where Transformers are too slow).
2. Keyword Spotting (Wake word detection).
3. Customization (Adding hot-words).

Key Takeaways:

• CTC handles the alignment between audio and text.
• Beam Search keeps multiple hypotheses alive to correct early mistakes.
• LMs are essential for fixing homophones (“beach” vs “speech”).

---
