Compute Allocation for Speech Models
Optimize speech pipeline throughput by allocating compute to bottleneck stages using greedy resource management.
Problem Statement
Design a compute allocation system for speech processing pipelines that efficiently distributes CPU/GPU resources across multiple stages (feature extraction, acoustic model, language model, post-processing) to maximize throughput while meeting strict latency SLAs.
Functional Requirements
- Multi-stage pipeline: Allocate resources across 4-6 pipeline stages
- Real-time processing: Meet <100ms latency for streaming ASR
- Dynamic scaling: Adjust allocation based on load and bottlenecks
- Multi-model support: Handle ASR, TTS, speaker recognition, etc.
- Heterogeneous compute: Mix of CPU (feature extraction) and GPU (neural models)
- Batch optimization: Dynamic batching for GPU efficiency
- Quality-aware: Maintain accuracy while optimizing for speed
- Cost-efficient: Minimize cloud spending per request
Non-Functional Requirements
- Latency: p95 < 100ms for ASR, <200ms for TTS
- Throughput: 10,000+ concurrent requests
- Accuracy: WER < 5% (ASR), MOS > 4.0 (TTS)
- Availability: 99.95% uptime
- Cost: <$0.001 per request
- GPU utilization: >80%
- Scalability: Handle 10x traffic spikes
Understanding the Problem
Speech processing pipelines are compute-intensive and latency-sensitive. Poor compute allocation leads to:
- Bottlenecks: One slow stage limits entire pipeline throughput
- Wasted resources: Over-provisioning fast stages wastes money
- Latency violations: Under-provisioning causes SLA breaches
- Poor GPU utilization: Inefficient batching leaves GPUs idle
Typical Speech Pipeline
Audio Input (16kHz PCM)
↓
┌─────────────────────────────────────────────────────────────┐
│ Speech Pipeline │
├─────────────────────────────────────────────────────────────┤
│ │
│ Stage 1: Feature Extraction (CPU) │
│ - Convert audio to mel spectrograms │
│ - Time: ~5ms per 100ms audio │
│ - Memory: 1MB per request │
│ ↓ │
│ Stage 2: Acoustic Model (GPU) │
│ - Neural network (Conformer/Wav2Vec2) │
│ - Time: ~20ms per 100ms audio (batched) │
│ - Memory: 500MB model + 10MB per request │
│ ↓ │
│ Stage 3: Language Model (GPU/CPU) │
│ - Beam search with n-gram or neural LM │
│ - Time: ~15ms per 100ms audio │
│ - Memory: 2GB model + 5MB per request │
│ ↓ │
│ Stage 4: Post-processing (CPU) │
│ - Punctuation, capitalization, formatting │
│ - Time: ~2ms per request │
│ - Memory: 100KB per request │
│ ↓ │
│ Text Output │
└─────────────────────────────────────────────────────────────┘
Total latency: ~42ms (with perfect pipelining)
Bottleneck: Acoustic Model (47% of time)
The Greedy Optimization Connection
Just like the Container With Most Water problem and Resource Allocation for ML systems:
| Container Problem | Speech Compute Allocation |
|---|---|
| Two lines (heights) | Multiple pipeline stages |
| Bottleneck (shorter line) | Slowest stage limits throughput |
| Maximize area | Maximize throughput |
| Greedy: move shorter pointer | Greedy: allocate to bottleneck |
| Width vs height tradeoff | Latency vs throughput tradeoff |
Core insight: Identify the bottleneck stage and allocate resources greedily to maximize end-to-end throughput.
High-Level Architecture
┌─────────────────────────────────────────────────────────────────┐
│ Compute Allocation Controller │
│ │
│ ┌──────────────────────┐ ┌──────────────────────┐ │
│ │ Profiler │ │ Optimizer │ │
│ │ - Measure latency │─────▶│ - Identify │ │
│ │ - Track utilization │ │ bottleneck │ │
│ │ - Detect bottleneck │ │ - Reallocation │ │
│ └──────────────────────┘ │ strategy │ │
│ └──────────┬───────────┘ │
│ │ │
│ ▼ │
│ ┌──────────────────────┐ │
│ │ Resource Manager │ │
│ │ - CPU pool │ │
│ │ - GPU pool │ │
│ │ - Batch scheduler │ │
│ └──────────┬───────────┘ │
└────────────────────────────────────────────┼────────────────────┘
│
▼
┌─────────────────────────────────────────────────────────────────┐
│ Speech Pipeline Workers │
│ │
│ ┌────────────┐ ┌────────────┐ ┌────────────┐ ┌──────────┐ │
│ │ Feature │ │ Acoustic │ │ Language │ │ Post- │ │
│ │ Extract │─▶│ Model │─▶│ Model │─▶│ Process │ │
│ │ │ │ │ │ │ │ │ │
│ │ CPU × N │ │ GPU × M │ │ GPU × K │ │ CPU × P │ │
│ └────────────┘ └────────────┘ └────────────┘ └──────────┘ │
│ │
│ Compute: 4 CPUs → 2 GPUs → 1 GPU → 2 CPUs (example) │
└─────────────────────────────────────────────────────────────────┘
Key Components
- Profiler: Continuously measures stage latencies and resource utilization
- Optimizer: Identifies bottlenecks and computes optimal allocation
- Resource Manager: Executes allocation decisions (spawn/kill workers)
- Pipeline Workers: Actual compute resources running each stage
Component Deep-Dives
1. Pipeline Profiler - Bottleneck Detection
The profiler tracks per-stage metrics to identify bottlenecks.
from dataclasses import dataclass
from typing import Dict, List, Optional
from collections import deque
from datetime import datetime
import numpy as np
@dataclass
class StageMetrics:
"""Metrics for a single pipeline stage."""
stage_name: str
latency_ms: deque # Rolling window of latencies
utilization: float # 0.0 to 1.0
throughput_rps: float # Requests per second
queue_size: int
num_workers: int
worker_type: str # "CPU" or "GPU"
def __post_init__(self):
if not isinstance(self.latency_ms, deque):
self.latency_ms = deque(maxlen=1000) # Last 1000 requests
@property
def avg_latency_ms(self) -> float:
"""Average latency over window."""
return np.mean(self.latency_ms) if self.latency_ms else 0.0
@property
def p95_latency_ms(self) -> float:
"""P95 latency over window."""
return np.percentile(self.latency_ms, 95) if self.latency_ms else 0.0
@property
def p99_latency_ms(self) -> float:
"""P99 latency over window."""
return np.percentile(self.latency_ms, 99) if self.latency_ms else 0.0
@property
def is_bottleneck(self) -> bool:
"""
Heuristic: stage is bottleneck if:
1. High utilization (>80%)
2. Growing queue
3. High latency variance
"""
high_utilization = self.utilization > 0.80
has_queue = self.queue_size > 10
high_variance = (
self.p99_latency_ms > 1.5 * self.avg_latency_ms
if self.latency_ms else False
)
return high_utilization and (has_queue or high_variance)
class PipelineProfiler:
"""
Profiles speech pipeline to identify bottlenecks.
Similar to Container With Most Water:
- Each stage is a "line" with capacity (height)
- Bottleneck stage (shortest line) limits throughput (area)
"""
def __init__(self, stages: List[str]):
self.stages = stages
self.metrics: Dict[str, StageMetrics] = {
stage: StageMetrics(
stage_name=stage,
latency_ms=deque(maxlen=1000),
utilization=0.0,
throughput_rps=0.0,
queue_size=0,
num_workers=1,
worker_type="CPU" if stage in ["feature_extraction", "post_process"] else "GPU"
)
for stage in stages
}
self.request_count = 0
self.start_time = datetime.now()
def record_latency(self, stage: str, latency_ms: float):
"""Record latency measurement for a stage."""
if stage in self.metrics:
self.metrics[stage].latency_ms.append(latency_ms)
self.request_count += 1
def update_utilization(self, stage: str, utilization: float):
"""Update utilization measurement."""
if stage in self.metrics:
self.metrics[stage].utilization = utilization
def update_queue_size(self, stage: str, queue_size: int):
"""Update queue size."""
if stage in self.metrics:
self.metrics[stage].queue_size = queue_size
def identify_bottleneck(self) -> Optional[str]:
"""
Identify bottleneck stage using greedy heuristic.
Greedy choice: stage with highest "pressure" score.
Pressure = weighted combination of:
- Latency (40%)
- Utilization (30%)
- Queue size (30%)
Returns:
Bottleneck stage name or None
"""
if not self.metrics:
return None
max_pressure = 0.0
bottleneck = None
# Normalize metrics for comparison
max_latency = max(m.avg_latency_ms for m in self.metrics.values())
max_queue = max(m.queue_size for m in self.metrics.values())
for stage, metrics in self.metrics.items():
# Calculate pressure score
latency_score = (
metrics.avg_latency_ms / max_latency if max_latency > 0 else 0
)
util_score = metrics.utilization
queue_score = (
metrics.queue_size / max_queue if max_queue > 0 else 0
)
# Weighted pressure
pressure = (
0.40 * latency_score +
0.30 * util_score +
0.30 * queue_score
)
if pressure > max_pressure:
max_pressure = pressure
bottleneck = stage
return bottleneck if max_pressure > 0.5 else None
def get_pipeline_summary(self) -> Dict:
"""Get overall pipeline statistics."""
total_latency = sum(m.avg_latency_ms for m in self.metrics.values())
# Find bottleneck
bottleneck = self.identify_bottleneck()
bottleneck_metrics = self.metrics.get(bottleneck) if bottleneck else None
# Calculate end-to-end throughput
# Limited by bottleneck stage
if bottleneck_metrics:
e2e_throughput = (
bottleneck_metrics.num_workers *
(1000.0 / bottleneck_metrics.avg_latency_ms)
if bottleneck_metrics.avg_latency_ms > 0 else 0
)
else:
e2e_throughput = 0
return {
"total_requests": self.request_count,
"avg_latency_ms": total_latency,
"bottleneck_stage": bottleneck,
"bottleneck_latency_ms": (
bottleneck_metrics.avg_latency_ms if bottleneck_metrics else 0
),
"estimated_throughput_rps": e2e_throughput,
"stage_breakdown": {
stage: {
"avg_latency_ms": m.avg_latency_ms,
"p95_latency_ms": m.p95_latency_ms,
"utilization": m.utilization,
"queue_size": m.queue_size,
"is_bottleneck": m.is_bottleneck,
}
for stage, m in self.metrics.items()
}
}
2. Compute Optimizer - Greedy Allocation Strategy
The optimizer decides how to allocate compute resources to maximize throughput.
from typing import Tuple, List
import math
@dataclass
class ComputeResource:
"""A compute resource (CPU core or GPU)."""
resource_id: str
resource_type: str # "CPU" or "GPU"
cost_per_hour: float
max_batch_size: int = 1 # For GPUs
@dataclass
class AllocationPlan:
"""Compute allocation plan for pipeline."""
stage_allocations: Dict[str, int] # stage -> num_workers
expected_throughput_rps: float
expected_latency_ms: float
estimated_cost_per_hour: float
class ComputeOptimizer:
"""
Greedy optimizer for compute allocation.
Strategy (like Container With Most Water):
1. Identify bottleneck stage (shortest line)
2. Allocate more resources to bottleneck (greedy choice)
3. Repeat until:
- Throughput target met
- Budget exhausted
- Bottleneck shifts to different stage
"""
def __init__(
self,
profiler: PipelineProfiler,
target_throughput_rps: float,
max_latency_ms: float,
budget_per_hour: float
):
self.profiler = profiler
self.target_throughput = target_throughput_rps
self.max_latency = max_latency_ms
self.budget = budget_per_hour
# Resource costs (example AWS pricing)
self.cpu_cost = 0.10 # per core per hour
self.gpu_cost = 3.00 # per GPU per hour (T4)
def compute_optimal_allocation(self) -> AllocationPlan:
"""
Compute optimal resource allocation using greedy algorithm.
Greedy approach:
1. Start with minimal allocation (1 worker per stage)
2. Iteratively add resources to bottleneck
3. Stop when target met or budget exhausted
Time: O(N × M) where N=stages, M=max_workers
Similar to two-pointer approach in container problem
"""
# Start with baseline allocation
allocation = {
stage: 1
for stage in self.profiler.stages
}
# Iteratively improve
max_iterations = 100
for iteration in range(max_iterations):
# Simulate current allocation
throughput, latency, cost = self._simulate_allocation(allocation)
# Check if targets met
if (throughput >= self.target_throughput and
latency <= self.max_latency and
cost <= self.budget):
# Success!
return AllocationPlan(
stage_allocations=allocation,
expected_throughput_rps=throughput,
expected_latency_ms=latency,
estimated_cost_per_hour=cost
)
# Greedy: add resource to bottleneck
bottleneck = self._find_bottleneck_stage(allocation)
if not bottleneck:
break
# Check if adding resource exceeds budget
new_cost = self._calculate_incremental_cost(bottleneck, allocation)
if cost + new_cost > self.budget:
break # Budget constraint
# Add resource to bottleneck (greedy choice)
allocation[bottleneck] += 1
# Return best effort allocation
throughput, latency, cost = self._simulate_allocation(allocation)
return AllocationPlan(
stage_allocations=allocation,
expected_throughput_rps=throughput,
expected_latency_ms=latency,
estimated_cost_per_hour=cost
)
def _simulate_allocation(
self,
allocation: Dict[str, int]
) -> Tuple[float, float, float]:
"""
Simulate pipeline performance with given allocation.
Returns:
(throughput_rps, latency_ms, cost_per_hour)
"""
# Get baseline metrics from profiler
summary = self.profiler.get_pipeline_summary()
# Calculate per-stage throughput
stage_throughputs = {}
for stage, num_workers in allocation.items():
metrics = self.profiler.metrics[stage]
if metrics.avg_latency_ms > 0:
# Throughput = workers / latency
# With batching for GPU stages
batch_factor = 1.0
if metrics.worker_type == "GPU":
batch_factor = min(8, num_workers * 2) # Assume batch size ~8-16
throughput = (
num_workers * batch_factor * 1000.0 / metrics.avg_latency_ms
)
stage_throughputs[stage] = throughput
else:
stage_throughputs[stage] = float('inf')
# End-to-end throughput limited by slowest stage
min_throughput = min(stage_throughputs.values())
# End-to-end latency is sum of stage latencies
# (assuming perfect pipelining, otherwise add queuing delays)
total_latency = sum(
self.profiler.metrics[stage].avg_latency_ms
for stage in self.profiler.stages
)
# Calculate cost
cost = 0.0
for stage, num_workers in allocation.items():
worker_type = self.profiler.metrics[stage].worker_type
if worker_type == "GPU":
cost += num_workers * self.gpu_cost
else:
cost += num_workers * self.cpu_cost
return min_throughput, total_latency, cost
def _find_bottleneck_stage(self, allocation: Dict[str, int]) -> Optional[str]:
"""
Find bottleneck stage given current allocation.
Bottleneck = stage with lowest throughput capacity.
(Like finding shorter line in container problem)
"""
min_throughput = float('inf')
bottleneck = None
for stage in self.profiler.stages:
metrics = self.profiler.metrics[stage]
num_workers = allocation[stage]
if metrics.avg_latency_ms > 0:
# Calculate stage throughput
batch_factor = 1.0
if metrics.worker_type == "GPU":
batch_factor = min(8, num_workers * 2)
throughput = (
num_workers * batch_factor * 1000.0 / metrics.avg_latency_ms
)
if throughput < min_throughput:
min_throughput = throughput
bottleneck = stage
return bottleneck
def _calculate_incremental_cost(
self,
stage: str,
current_allocation: Dict[str, int]
) -> float:
"""Calculate cost of adding one more worker to stage."""
worker_type = self.profiler.metrics[stage].worker_type
return self.gpu_cost if worker_type == "GPU" else self.cpu_cost
3. Dynamic Batch Scheduler - GPU Optimization
For GPU stages (acoustic model, language model), batching is critical for efficiency.
import asyncio
from asyncio import Queue
from typing import List
import time
@dataclass
class SpeechRequest:
"""A speech processing request."""
request_id: str
audio_data: bytes
duration_ms: float
timestamp: float
class DynamicBatchScheduler:
"""
Dynamic batching for GPU inference.
Trade-off:
- Large batches: Higher throughput, higher latency
- Small batches: Lower latency, lower throughput
Greedy strategy:
- Wait for batch to fill up to `target_batch_size`
- But timeout after `max_wait_ms` to maintain latency SLA
"""
def __init__(
self,
target_batch_size: int = 16,
max_wait_ms: float = 10.0,
max_queue_size: int = 1000
):
self.target_batch_size = target_batch_size
self.max_wait_ms = max_wait_ms / 1000.0 # Convert to seconds
self.queue: Queue[SpeechRequest] = Queue(maxsize=max_queue_size)
self.batch_count = 0
async def add_request(self, request: SpeechRequest):
"""Add request to batch queue."""
await self.queue.put(request)
async def get_batch(self) -> List[SpeechRequest]:
"""
Get next batch using greedy strategy.
Greedy decision:
1. If batch_size reached: return immediately (maximize throughput)
2. If timeout: return partial batch (maintain latency SLA)
3. Else: keep waiting
Returns:
List of requests (1 to target_batch_size)
"""
batch = []
start_time = time.time()
while len(batch) < self.target_batch_size:
remaining_time = self.max_wait_ms - (time.time() - start_time)
# Timeout check (latency SLA)
if remaining_time <= 0 and batch:
break # Return partial batch
try:
# Wait for next request (with timeout)
request = await asyncio.wait_for(
self.queue.get(),
timeout=max(remaining_time, 0.001)
)
batch.append(request)
# Greedy: if we have enough, return immediately
if len(batch) >= self.target_batch_size:
break
except asyncio.TimeoutError:
# Timeout - return what we have
if batch:
break
else:
continue # Keep waiting if empty
self.batch_count += 1
return batch
def get_stats(self) -> Dict:
"""Get batching statistics."""
return {
"queue_size": self.queue.qsize(),
"batch_count": self.batch_count,
"avg_batch_size": "N/A", # Would track in production
}
# Example usage in acoustic model inference
class AcousticModelWorker:
"""GPU worker for acoustic model inference with batching."""
def __init__(self, model, device="cuda"):
self.model = model
self.device = device
self.scheduler = DynamicBatchScheduler(
target_batch_size=16,
max_wait_ms=10.0
)
async def process_loop(self):
"""Main processing loop."""
while True:
# Get batch (greedy batching)
batch = await self.scheduler.get_batch()
if not batch:
await asyncio.sleep(0.001)
continue
# Process batch on GPU
results = await self._inference_batch(batch)
# Return results to each request
# ... send results back ...
async def _inference_batch(self, batch: List[SpeechRequest]):
"""Run batched inference on GPU."""
# Prepare batch
# Run model
# Return results
pass
4. Resource Manager - Execute Allocation
import subprocess
from typing import Dict, List
class ResourceManager:
"""
Manages compute resources (spawn/kill workers).
Executes allocation decisions from optimizer.
"""
def __init__(self):
self.workers: Dict[str, List[subprocess.Popen]] = {}
for stage in ["feature_extraction", "acoustic_model", "language_model", "post_process"]:
self.workers[stage] = []
def apply_allocation(self, plan: AllocationPlan):
"""
Apply allocation plan by spawning/killing workers.
Greedy approach:
1. Calculate delta (target - current)
2. Spawn new workers if delta > 0
3. Kill excess workers if delta < 0
"""
for stage, target_count in plan.stage_allocations.items():
current_count = len(self.workers[stage])
delta = target_count - current_count
if delta > 0:
# Spawn new workers
self._spawn_workers(stage, delta)
elif delta < 0:
# Kill excess workers
self._kill_workers(stage, abs(delta))
def _spawn_workers(self, stage: str, count: int):
"""Spawn worker processes."""
for i in range(count):
# In production: spawn Kubernetes pod or start process
# Example: subprocess.Popen(["python", f"{stage}_worker.py"])
pass
def _kill_workers(self, stage: str, count: int):
"""Gracefully terminate workers."""
for i in range(count):
if self.workers[stage]:
worker = self.workers[stage].pop()
# worker.terminate()
# worker.wait(timeout=30)
Data Flow
Request Processing Flow
1. Request arrives
└─> Load balancer routes to available feature extraction worker
2. Feature Extraction (CPU)
└─> Extract mel spectrogram (5ms)
└─> Send to batch scheduler for acoustic model
3. Acoustic Model (GPU) - Batching
└─> Wait for batch (up to 10ms)
└─> Process batch of 16 requests (20ms)
└─> Amortized: ~1.25ms per request (batched)
└─> Send to language model
4. Language Model (GPU)
└─> Beam search decoding (15ms)
└─> Send to post-processing
5. Post-processing (CPU)
└─> Punctuation, capitalization (2ms)
└─> Return result
Total: 5ms + 10ms + 1.25ms + 15ms + 2ms ≈ 33ms (with batching)
Without batching: 5ms + 20ms + 15ms + 2ms = 42ms
Monitoring Loop
async def monitoring_loop(
profiler: PipelineProfiler,
optimizer: ComputeOptimizer,
resource_manager: ResourceManager
):
"""
Continuous monitoring and reallocation loop.
Every 60 seconds:
1. Check for bottlenecks
2. Compute optimal allocation
3. Apply if significantly different
"""
while True:
# Get current state
summary = profiler.get_pipeline_summary()
# Log metrics
print(f"Bottleneck: {summary['bottleneck_stage']}")
print(f"Throughput: {summary['estimated_throughput_rps']:.1f} rps")
print(f"Latency: {summary['avg_latency_ms']:.1f}ms")
# Recompute optimal allocation
new_plan = optimizer.compute_optimal_allocation()
# Apply if significant change (>20% difference)
if should_reallocate(new_plan, resource_manager):
print(f"Reallocating: {new_plan.stage_allocations}")
resource_manager.apply_allocation(new_plan)
# Wait before next check
await asyncio.sleep(60)
def should_reallocate(
new_plan: AllocationPlan,
resource_manager: ResourceManager
) -> bool:
"""Check if reallocation is worthwhile."""
# Avoid thrashing - only reallocate if significant change
for stage, target in new_plan.stage_allocations.items():
current = len(resource_manager.workers[stage])
if abs(target - current) >= 2: # At least 2 worker difference
return True
return False
Production Deployment
Multi-Region Architecture
┌─────────────────┐
│ Global LB │
│ (Route53) │
└────────┬────────┘
│
┌────────────────────┼────────────────────┐
│ │ │
┌────▼────┐ ┌────▼────┐ ┌────▼────┐
│ us-west │ │ us-east │ │ eu-west │
│ Region │ │ Region │ │ Region │
└────┬────┘ └────┬────┘ └────┬────┘
│ │ │
┌────▼─────────┐ ┌───▼──────────┐ ┌───▼──────────┐
│ Pipeline │ │ Pipeline │ │ Pipeline │
│ Cluster │ │ Cluster │ │ Cluster │
│ │ │ │ │ │
│ • 4 Feature │ │ • 4 Feature │ │ • 4 Feature │
│ • 2 Acoustic │ │ • 2 Acoustic │ │ • 2 Acoustic │
│ • 1 LM │ │ • 1 LM │ │ • 1 LM │
│ • 2 Post │ │ • 2 Post │ │ • 2 Post │
└──────────────┘ └──────────────┘ └──────────────┘
Kubernetes Deployment
# acoustic-model-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
name: acoustic-model
spec:
replicas: 2 # Managed by HPA + custom controller
selector:
matchLabels:
app: acoustic-model
template:
metadata:
labels:
app: acoustic-model
spec:
containers:
- name: model-server
image: speech-pipeline/acoustic-model:v1.2.3
resources:
requests:
nvidia.com/gpu: 1
cpu: "4"
memory: "16Gi"
limits:
nvidia.com/gpu: 1
cpu: "8"
memory: "32Gi"
env:
- name: BATCH_SIZE
value: "16"
- name: MAX_WAIT_MS
value: "10"
---
apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
name: acoustic-model-hpa
spec:
scaleTargetRef:
apiVersion: apps/v1
kind: Deployment
name: acoustic-model
minReplicas: 1
maxReplicas: 10
metrics:
- type: Pods
pods:
metric:
name: gpu_utilization
target:
type: AverageValue
averageValue: "80"
- type: Pods
pods:
metric:
name: queue_size
target:
type: AverageValue
averageValue: "50"
Model Optimization Techniques
import torch
import tensorrt as trt
from onnx import onnx
import onnxruntime as ort
class ModelOptimizer:
"""Optimize models for production inference."""
@staticmethod
def quantize_model(model: torch.nn.Module, calibration_data):
"""
Quantize model to INT8 for faster inference.
Benefits:
- 4x smaller model size
- 2-4x faster inference
- Cost: ~1-2% accuracy drop
"""
model.eval()
# Dynamic quantization (weights only)
quantized_model = torch.quantization.quantize_dynamic(
model,
{torch.nn.Linear, torch.nn.Conv1d},
dtype=torch.qint8
)
return quantized_model
@staticmethod
def export_to_onnx(model: torch.nn.Module, dummy_input: torch.Tensor, path: str):
"""
Export to ONNX for deployment.
Benefits:
- Framework agnostic
- Optimized runtime (ONNX Runtime)
- TensorRT compilation
"""
model.eval()
torch.onnx.export(
model,
dummy_input,
path,
input_names=["audio_features"],
output_names=["logits"],
dynamic_axes={
"audio_features": {0: "batch_size", 1: "time"},
"logits": {0: "batch_size", 1: "time"}
},
opset_version=14
)
@staticmethod
def compile_tensorrt(onnx_path: str, engine_path: str):
"""
Compile ONNX model to TensorRT engine.
Benefits:
- 2-6x faster on NVIDIA GPUs
- Automatic kernel fusion
- Mixed precision (FP16)
"""
# Build TensorRT engine
logger = trt.Logger(trt.Logger.WARNING)
builder = trt.Builder(logger)
network = builder.create_network(1 << int(trt.NetworkDefinitionCreationFlag.EXPLICIT_BATCH))
parser = trt.OnnxParser(network, logger)
# Parse ONNX
with open(onnx_path, 'rb') as model_file:
parser.parse(model_file.read())
# Build engine
config = builder.create_builder_config()
config.set_memory_pool_limit(trt.MemoryPoolType.WORKSPACE, 1 << 30) # 1GB
config.set_flag(trt.BuilderFlag.FP16) # Enable FP16
engine = builder.build_serialized_network(network, config)
# Save engine
with open(engine_path, 'wb') as f:
f.write(engine)
return engine_path
# Example usage
def optimize_acoustic_model():
"""Full optimization pipeline."""
# 1. Load PyTorch model
model = torch.load("acoustic_model.pt")
# 2. Quantize (optional - for CPU deployment)
quantized = ModelOptimizer.quantize_model(model, calibration_data=None)
# 3. Export to ONNX
dummy_input = torch.randn(1, 100, 80) # batch=1, time=100, features=80
ModelOptimizer.export_to_onnx(model, dummy_input, "acoustic_model.onnx")
# 4. Compile to TensorRT (for GPU deployment)
ModelOptimizer.compile_tensorrt("acoustic_model.onnx", "acoustic_model.trt")
print("Optimization complete!")
print("- Original: ~500MB, ~20ms latency")
print("- Quantized: ~125MB, ~15ms latency")
print("- TensorRT: ~125MB, ~5ms latency (batched)")
Scaling Strategies
Vertical Scaling - GPU Selection
| GPU | Memory | FP16 TFLOPS | Cost/hr | Use Case |
|---|---|---|---|---|
| T4 | 16GB | 65 | $0.35 | Small models, inference |
| V100 | 16GB | 125 | $2.50 | Medium models |
| A10 | 24GB | 125 | $0.75 | Cost-efficient inference |
| A100 | 40GB | 312 | $3.00 | Large models, training |
Greedy choice: Match GPU to model size and throughput requirements.
Horizontal Scaling - Auto-scaling Rules
@dataclass
class ScalingRule:
"""Auto-scaling rule for speech pipeline."""
metric: str
threshold: float
scale_up_by: int
cooldown_seconds: int
scaling_rules = [
ScalingRule(
metric="gpu_utilization",
threshold=85.0,
scale_up_by=1,
cooldown_seconds=120
),
ScalingRule(
metric="queue_size",
threshold=100,
scale_up_by=2,
cooldown_seconds=60
),
ScalingRule(
metric="p95_latency_ms",
threshold=150.0,
scale_up_by=1,
cooldown_seconds=90
),
]
Real-World Case Study: Google Assistant
Google’s Speech Pipeline
Google Assistant processes billions of speech requests daily with <100ms latency.
Architecture:
- Multi-tiered inference:
- On-device: Lightweight model for simple queries
- Edge: Medium model at regional data centers
- Cloud: Large model for complex queries
- Dynamic model selection:
- Greedy choice: use smallest model that meets confidence threshold
- Fallback to larger model if confidence < 0.9
- Batching strategy:
- Dynamic batch sizes: 1-32 based on queue
- Adaptive timeout: 5-20ms based on SLA
- Resource allocation:
- Per-region optimization
- TPU v4 pods for large models
- GPU for medium models
- CPU for feature extraction
Results:
- p95 latency: 85ms
- Throughput: 100K+ rps per region
- GPU utilization: 88%
- Cost: <$0.0005 per request
Key Lessons
- Multi-tiered models: Use appropriate model size for each query
- Aggressive batching: Critical for GPU efficiency
- Edge deployment: Reduces latency and cost
- Continuous profiling: Identify bottlenecks in real-time
- Greedy allocation works: Simple strategy scales to billions of requests
Cost Analysis
Cost Breakdown (10K rps speech pipeline)
| Component | Resources | Cost/hr | Cost/request |
|---|---|---|---|
| Feature extraction | 40 CPUs | $4 | $0.00010 |
| Acoustic model | 10 T4 GPUs | $3.50 | $0.00009 |
| Language model | 5 T4 GPUs | $1.75 | $0.00004 |
| Post-processing | 20 CPUs | $2 | $0.00005 |
| Total | $11.25/hr | $0.00028 |
Optimization strategies:
- Batching: Reduces GPU count by 50%
- Before: 20 GPUs @ $0.35/hr = $7/hr
- After: 10 GPUs @ $0.35/hr = $3.50/hr
- Savings: 50%
- Model quantization: Reduces GPU count by 30%
- INT8 models are 2-3x faster
- Need fewer GPUs for same throughput
- Savings: 30%
- Right-sizing instances:
- Use T4 ($0.35/hr) instead of V100 ($2.50/hr)
- Savings: 86%
- Spot instances:
- 70% discount on interruptible workloads
- Use for batch processing, not real-time
- Savings: 70% (for applicable workloads)
Total optimized cost: $0.00012 per request (57% reduction)
Key Takeaways
✅ Speech pipelines have bottlenecks - identify and optimize the slowest stage first (greedy)
✅ Dynamic batching is critical for GPU efficiency - trade off latency vs throughput
✅ Continuous profiling identifies bottlenecks in real-time
✅ Greedy allocation strategy - add resources to bottleneck stage iteratively
✅ Model optimization (quantization, TensorRT) reduces compute requirements by 50%+
✅ Multi-region deployment reduces latency and improves availability
✅ Right-sizing GPU types saves 80%+ on costs
✅ Kubernetes + auto-scaling enables dynamic resource allocation
✅ Same principles as DSA - bottleneck (shorter line) limits throughput (area)
✅ Same principles as ML systems - greedy optimization for resource allocation
Connection to Thematic Link: Greedy Optimization and Resource Management
All three topics converge on the same fundamental insight:
DSA (Container With Most Water):
- Two lines with heights h₁, h₂
- Container area = min(h₁, h₂) × width
- Bottleneck: shorter line limits capacity
- Greedy: Move pointer at shorter line
ML System Design (Resource Allocation):
- Multiple ML jobs competing for GPUs
- System throughput limited by resource bottleneck
- Greedy: Allocate to highest-priority job that fits
Speech Tech (Compute Allocation):
- Multi-stage pipeline with different latencies
- End-to-end throughput limited by slowest stage
- Greedy: Allocate compute to bottleneck stage
Universal Principle
The Bottleneck Principle:
In any multi-component system, the component with the lowest capacity determines the overall system throughput.
Greedy Optimization:
Iteratively improve the bottleneck until:
- Target performance achieved
- Budget exhausted
- Bottleneck shifts to different component
This principle applies to:
- Algorithm design (two-pointer technique)
- Infrastructure (resource allocation)
- Production systems (pipeline optimization)
- Real-time processing (compute allocation)
Why it works:
- Simple: Easy to implement and reason about
- Fast: O(N) time complexity
- Effective: Proven to work at scale (Google, Meta, etc.)
- Robust: Handles dynamic workloads and changing bottlenecks
Originally published at: arunbaby.com/speech-tech/0013-compute-allocation-for-speech-models
If you found this helpful, consider sharing it with others who might benefit.
