Audio Preprocessing & Signal Processing
Clean audio is the foundation of robust speech systems, master preprocessing pipelines that handle real-world noise and variability.
Introduction
Audio preprocessing transforms raw audio into clean, standardized representations suitable for ML models.
Why it matters:
- Garbage in, garbage out: Poor audio quality destroys model performance
- Real-world audio is messy: Background noise, varying volumes, different devices
- Standardization: Models expect consistent input formats
- Data augmentation: Increase training data diversity
Pipeline overview:
Raw Audio (microphone)
↓
[Loading & Format Conversion]
↓
[Resampling]
↓
[Normalization]
↓
[Noise Reduction]
↓
[Voice Activity Detection]
↓
[Segmentation]
↓
[Feature Extraction]
↓
Clean Features → Model
Audio Fundamentals
Digital Audio Representation
Analog Sound Wave:
∿∿∿∿∿∿∿∿∿∿∿
Sampling (digitization):
●─●─●─●─●─●─●─● (sample points)
Key parameters:
- Sample Rate: Samples per second (Hz)
- CD quality: 44,100 Hz
- Speech: 16,000 Hz or 22,050 Hz
- Telephone: 8,000 Hz
- Bit Depth: Bits per sample
- 16-bit: 65,536 possible values
- 24-bit: 16,777,216 values
- 32-bit float: Highest precision
- Channels:
- Mono: 1 channel
- Stereo: 2 channels (left, right)
Nyquist-Shannon Sampling Theorem
Rule: To capture frequency f, sample rate must be ≥ 2f
Human hearing: 20 Hz - 20 kHz
→ Need ≥40 kHz sample rate
→ CD uses 44.1 kHz (margin above 40 kHz)
Speech frequencies: ~300 Hz - 8 kHz
→ 16 kHz sample rate is sufficient
Loading & Format Conversion
Loading Audio
import librosa
import soundfile as sf
import numpy as np
def load_audio(file_path, sr=None):
"""
Load audio file
Args:
file_path: Path to audio file
sr: Target sample rate (None = keep original)
Returns:
audio: np.array of samples
sr: Sample rate
"""
# Librosa (resamples automatically)
audio, sample_rate = librosa.load(file_path, sr=sr)
return audio, sample_rate
# Example
audio, sr = load_audio('speech.wav', sr=16000)
print(f"Shape: {audio.shape}, Sample Rate: {sr} Hz")
print(f"Duration: {len(audio) / sr:.2f} seconds")
Format Conversion
from pydub import AudioSegment
def convert_audio_format(input_path, output_path, output_format='wav'):
"""
Convert between audio formats
Supports: mp3, wav, ogg, flac, m4a, etc.
"""
audio = AudioSegment.from_file(input_path)
# Export in new format
audio.export(output_path, format=output_format)
# Convert MP3 to WAV
convert_audio_format('input.mp3', 'output.wav', 'wav')
Mono/Stereo Conversion
def stereo_to_mono(audio_stereo):
"""
Convert stereo to mono by averaging channels
Args:
audio_stereo: Shape (2, n_samples) or (n_samples, 2)
Returns:
audio_mono: Shape (n_samples,)
"""
if audio_stereo.ndim == 1:
# Already mono
return audio_stereo
# Average across channels
if audio_stereo.shape[0] == 2:
# Shape: (2, n_samples)
return np.mean(audio_stereo, axis=0)
else:
# Shape: (n_samples, 2)
return np.mean(audio_stereo, axis=1)
# Example
audio_stereo, sr = librosa.load('stereo.wav', sr=None, mono=False)
audio_mono = stereo_to_mono(audio_stereo)
Resampling
Purpose: Convert sample rate to match model requirements
High-Quality Resampling
import librosa
def resample_audio(audio, orig_sr, target_sr):
"""
Resample audio using high-quality algorithm
Args:
audio: Audio samples
orig_sr: Original sample rate
target_sr: Target sample rate
Returns:
resampled_audio
"""
if orig_sr == target_sr:
return audio
# Librosa uses high-quality resampling (Kaiser window)
resampled = librosa.resample(
audio,
orig_sr=orig_sr,
target_sr=target_sr,
res_type='kaiser_best' # Highest quality
)
return resampled
# Example: Downsample 44.1 kHz to 16 kHz
audio_44k, _ = librosa.load('audio.wav', sr=44100)
audio_16k = resample_audio(audio_44k, orig_sr=44100, target_sr=16000)
print(f"Original length: {len(audio_44k)}")
print(f"Resampled length: {len(audio_16k)}")
print(f"Ratio: {len(audio_44k) / len(audio_16k):.2f}") # ~2.76
Resampling visualization:
Original (44.1 kHz):
●●●●●●●●●●●●●●●●●●●●●●●●●●●● (44,100 samples/second)
Downsampled (16 kHz):
●───●───●───●───●───●───●───● (16,000 samples/second)
Algorithm interpolates to avoid aliasing
Normalization
Amplitude Normalization
def normalize_audio(audio, target_level=-20.0):
"""
Normalize audio to target level (dB)
Args:
audio: Audio samples
target_level: Target RMS level in dB
Returns:
normalized_audio
"""
# Calculate current RMS
rms = np.sqrt(np.mean(audio ** 2))
if rms == 0:
return audio
# Convert target level from dB to linear
target_rms = 10 ** (target_level / 20.0)
# Scale audio
scaling_factor = target_rms / rms
normalized = audio * scaling_factor
# Clip to prevent overflow
normalized = np.clip(normalized, -1.0, 1.0)
return normalized
# Example
audio, sr = librosa.load('speech.wav', sr=16000)
normalized_audio = normalize_audio(audio, target_level=-20.0)
Peak Normalization
def peak_normalize(audio):
"""
Normalize to peak amplitude = 1.0
Simple but can be problematic if audio has spikes
"""
peak = np.max(np.abs(audio))
if peak == 0:
return audio
return audio / peak
DC Offset Removal
def remove_dc_offset(audio):
"""
Remove DC bias (mean offset)
DC offset can cause clicking sounds
"""
return audio - np.mean(audio)
# Example
audio_clean = remove_dc_offset(audio)
Noise Reduction
1. Spectral Subtraction
import scipy.signal as signal
def spectral_subtraction(audio, sr, noise_duration=0.5):
"""
Reduce noise using spectral subtraction
Assumes first noise_duration seconds are noise only
Args:
audio: Audio signal
sr: Sample rate
noise_duration: Duration of noise-only segment (seconds)
Returns:
denoised_audio
"""
# Extract noise profile from beginning
noise_samples = int(noise_duration * sr)
noise_segment = audio[:noise_samples]
# Compute noise spectrum
noise_fft = np.fft.rfft(noise_segment)
noise_power = np.abs(noise_fft) ** 2
noise_power_avg = np.mean(noise_power)
# STFT of full audio
f, t, Zxx = signal.stft(audio, fs=sr, nperseg=1024)
# Subtract noise spectrum
magnitude = np.abs(Zxx)
phase = np.angle(Zxx)
# Spectral subtraction
noise_estimate = np.sqrt(noise_power_avg)
magnitude_denoised = np.maximum(magnitude - noise_estimate, 0.0)
# Reconstruct
Zxx_denoised = magnitude_denoised * np.exp(1j * phase)
_, audio_denoised = signal.istft(Zxx_denoised, fs=sr)
return audio_denoised[:len(audio)]
# Example
audio, sr = librosa.load('noisy_speech.wav', sr=16000)
denoised = spectral_subtraction(audio, sr, noise_duration=0.5)
2. Wiener Filtering
def wiener_filter(audio, sr, noise_reduction_factor=0.5):
"""
Apply Wiener filter for noise reduction
More sophisticated than spectral subtraction
"""
from scipy.signal import wiener
# Apply Wiener filter
filtered = wiener(audio, mysize=5, noise=noise_reduction_factor)
return filtered
3. High-Pass Filter (Remove Low-Frequency Noise)
def high_pass_filter(audio, sr, cutoff_freq=80):
"""
Remove low-frequency noise (e.g., rumble, hum)
Args:
audio: Audio signal
sr: Sample rate
cutoff_freq: Cutoff frequency in Hz
Returns:
filtered_audio
"""
from scipy.signal import butter, filtfilt
# Design high-pass filter
nyquist = sr / 2
normalized_cutoff = cutoff_freq / nyquist
b, a = butter(N=5, Wn=normalized_cutoff, btype='high')
# Apply filter (zero-phase filtering)
filtered = filtfilt(b, a, audio)
return filtered
# Example: Remove rumble below 80 Hz
audio_filtered = high_pass_filter(audio, sr=16000, cutoff_freq=80)
Voice Activity Detection (VAD)
Purpose: Identify speech segments, remove silence
import librosa
def voice_activity_detection(audio, sr, frame_length=2048, hop_length=512, energy_threshold=0.02):
"""
Simple energy-based VAD
Args:
audio: Audio signal
sr: Sample rate
energy_threshold: Threshold for voice activity
Returns:
speech_segments: List of (start_sample, end_sample) tuples
"""
# Compute frame energy
energy = librosa.feature.rms(
y=audio,
frame_length=frame_length,
hop_length=hop_length
)[0]
# Normalize energy
energy_normalized = energy / (np.max(energy) + 1e-8)
# Threshold to get voice activity
voice_activity = energy_normalized > energy_threshold
# Convert to sample indices
def frame_to_sample(frame_idx):
start = frame_idx * hop_length
end = min(start + frame_length, len(audio))
return start, end
# Find continuous speech segments
segments = []
in_speech = False
start_frame = 0
for i, is_voice in enumerate(voice_activity):
if is_voice and not in_speech:
# Start of speech
start_frame = i
in_speech = True
elif not is_voice and in_speech:
# End of speech
end_frame = i
start_sample, _ = frame_to_sample(start_frame)
end_sample, _ = frame_to_sample(end_frame)
segments.append((start_sample, end_sample))
in_speech = False
# Handle case where speech goes to end
if in_speech:
start_sample, _ = frame_to_sample(start_frame)
end_sample = len(audio)
segments.append((start_sample, end_sample))
return segments
# Example
audio, sr = librosa.load('speech_with_pauses.wav', sr=16000)
segments = voice_activity_detection(audio, sr)
print(f"Found {len(segments)} speech segments:")
for i, (start, end) in enumerate(segments):
duration = (end - start) / sr
print(f" Segment {i+1}: {start/sr:.2f}s - {end/sr:.2f}s ({duration:.2f}s)")
VAD visualization:
Audio waveform:
___ ___ ___
/ \ / \ / \
___/ \______/ \___/ \___
Energy:
████ ████ ████
████ ████ ████
────████──────────████──────████──── ← threshold
VAD output:
SSSS SSSS SSSS
(S = Speech, spaces = Silence)
Segmentation
Fixed-Length Segmentation
def segment_audio_fixed_length(audio, sr, segment_duration=3.0, hop_duration=1.0):
"""
Segment audio into fixed-length chunks with overlap
Args:
audio: Audio signal
sr: Sample rate
segment_duration: Segment length in seconds
hop_duration: Hop between segments in seconds
Returns:
segments: List of audio segments
"""
segment_samples = int(segment_duration * sr)
hop_samples = int(hop_duration * sr)
segments = []
start = 0
while start + segment_samples <= len(audio):
segment = audio[start:start + segment_samples]
segments.append(segment)
start += hop_samples
return segments
# Example: 3-second segments with 1-second hop (2-second overlap)
segments = segment_audio_fixed_length(audio, sr=16000, segment_duration=3.0, hop_duration=1.0)
print(f"Created {len(segments)} segments")
Adaptive Segmentation (Based on Pauses)
def segment_by_pauses(audio, sr, min_silence_duration=0.3, silence_threshold=0.02):
"""
Segment audio at silence/pause points
Better than fixed-length for natural speech
"""
# Detect voice activity
speech_segments = voice_activity_detection(
audio, sr,
energy_threshold=silence_threshold
)
# Filter out very short segments
min_segment_samples = int(min_silence_duration * sr)
filtered_segments = [
(start, end) for start, end in speech_segments
if end - start >= min_segment_samples
]
# Extract audio segments
audio_segments = []
for start, end in filtered_segments:
segment = audio[start:end]
audio_segments.append(segment)
return audio_segments, filtered_segments
# Example
audio_segments, timestamps = segment_by_pauses(audio, sr=16000)
Data Augmentation
Purpose: Increase training data diversity, improve model robustness
1. Time Stretching
def time_stretch(audio, rate=1.0):
"""
Speed up or slow down audio without changing pitch
Args:
audio: Audio signal
rate: Stretch factor
> 1.0: speed up
< 1.0: slow down
Returns:
stretched_audio
"""
return librosa.effects.time_stretch(audio, rate=rate)
# Example: Speed up by 20%
audio_fast = time_stretch(audio, rate=1.2)
# Slow down by 20%
audio_slow = time_stretch(audio, rate=0.8)
2. Pitch Shifting
def pitch_shift(audio, sr, n_steps=2):
"""
Shift pitch without changing speed
Args:
audio: Audio signal
sr: Sample rate
n_steps: Semitones to shift (positive = higher, negative = lower)
Returns:
pitch_shifted_audio
"""
return librosa.effects.pitch_shift(audio, sr=sr, n_steps=n_steps)
# Example: Shift up 2 semitones
audio_high = pitch_shift(audio, sr=16000, n_steps=2)
# Shift down 2 semitones
audio_low = pitch_shift(audio, sr=16000, n_steps=-2)
3. Adding Noise
def add_noise(audio, noise_factor=0.005):
"""
Add random Gaussian noise
Args:
audio: Audio signal
noise_factor: Standard deviation of noise
Returns:
noisy_audio
"""
noise = np.random.randn(len(audio)) * noise_factor
return audio + noise
# Example
audio_noisy = add_noise(audio, noise_factor=0.01)
4. Background Noise Mixing
def mix_background_noise(speech_audio, noise_audio, snr_db=10):
"""
Mix speech with background noise at specified SNR
Args:
speech_audio: Clean speech
noise_audio: Background noise
snr_db: Signal-to-noise ratio in dB
Returns:
mixed_audio
"""
# Match lengths
if len(noise_audio) < len(speech_audio):
# Repeat noise to match speech length
repeats = int(np.ceil(len(speech_audio) / len(noise_audio)))
noise_audio = np.tile(noise_audio, repeats)[:len(speech_audio)]
else:
# Trim noise
noise_audio = noise_audio[:len(speech_audio)]
# Calculate signal and noise power
speech_power = np.mean(speech_audio ** 2)
noise_power = np.mean(noise_audio ** 2)
# Calculate scaling factor for noise
snr_linear = 10 ** (snr_db / 10)
noise_scaling = np.sqrt(speech_power / (snr_linear * noise_power))
# Mix
mixed = speech_audio + noise_scaling * noise_audio
# Normalize to prevent clipping
mixed = mixed / (np.max(np.abs(mixed)) + 1e-8)
return mixed
# Example: Mix with café noise at SNR=15dB
cafe_noise, _ = librosa.load('cafe_background.wav', sr=16000)
noisy_speech = mix_background_noise(audio, cafe_noise, snr_db=15)
5. SpecAugment (For Spectrograms)
def spec_augment(mel_spectrogram, num_mask=2, freq_mask_param=20, time_mask_param=30):
"""
SpecAugment: mask random time-frequency patches
Popular augmentation for speech recognition
Args:
mel_spectrogram: Shape (n_mels, time)
num_mask: Number of masks to apply
freq_mask_param: Max width of frequency mask
time_mask_param: Max width of time mask
Returns:
augmented_spectrogram
"""
aug_spec = mel_spectrogram.copy()
n_mels, n_frames = aug_spec.shape
# Frequency masking
for _ in range(num_mask):
f = np.random.randint(0, freq_mask_param)
f0 = np.random.randint(0, n_mels - f)
aug_spec[f0:f0+f, :] = 0
# Time masking
for _ in range(num_mask):
t = np.random.randint(0, time_mask_param)
t0 = np.random.randint(0, n_frames - t)
aug_spec[:, t0:t0+t] = 0
return aug_spec
# Example
mel_spec = librosa.feature.melspectrogram(y=audio, sr=16000)
aug_mel_spec = spec_augment(mel_spec, num_mask=2)
Connection to Feature Engineering (Day 7)
Audio preprocessing is feature engineering for speech:
class AudioFeatureEngineeringPipeline:
"""
Complete pipeline: raw audio → features
Similar to general ML feature engineering
"""
def __init__(self, sr=16000):
self.sr = sr
def process(self, audio_path):
"""
Full preprocessing pipeline
Analogous to feature engineering pipeline in ML
"""
# 1. Load (like data loading)
audio, sr = librosa.load(audio_path, sr=self.sr)
# 2. Normalize (like feature scaling)
audio = normalize_audio(audio)
# 3. Noise reduction (like outlier removal)
audio = high_pass_filter(audio, sr)
# 4. VAD (like removing null values)
segments = voice_activity_detection(audio, sr)
# 5. Feature extraction (like creating derived features)
features = self.extract_features(audio, sr)
return features
def extract_features(self, audio, sr):
"""
Extract multiple feature types
Like creating feature crosses and aggregations
"""
features = {}
# Spectral features (numerical features)
features['mfcc'] = librosa.feature.mfcc(y=audio, sr=sr, n_mfcc=13)
features['spectral_centroid'] = librosa.feature.spectral_centroid(y=audio, sr=sr)
features['zero_crossing_rate'] = librosa.feature.zero_crossing_rate(audio)
# Temporal features (time-based features)
features['rms_energy'] = librosa.feature.rms(y=audio)
# Aggregations (like SQL GROUP BY)
features['mfcc_mean'] = np.mean(features['mfcc'], axis=1)
features['mfcc_std'] = np.std(features['mfcc'], axis=1)
return features
Production Pipeline
class ProductionAudioPreprocessor:
"""
Production-ready audio preprocessing
Handles errors, logging, monitoring
"""
def __init__(self, config):
self.sr = config.get('sample_rate', 16000)
self.normalize_level = config.get('normalize_level', -20.0)
self.enable_vad = config.get('enable_vad', True)
def preprocess(self, audio_bytes):
"""
Preprocess audio from bytes
Returns: (processed_audio, metadata, success)
"""
metadata = {}
try:
# Load from bytes
audio = self._load_from_bytes(audio_bytes)
metadata['original_length'] = len(audio)
# Resample
if self.sr != 16000: # Assuming input is 16kHz
audio = resample_audio(audio, 16000, self.sr)
# Normalize
audio = normalize_audio(audio, self.normalize_level)
metadata['normalized'] = True
# VAD
if self.enable_vad:
segments = voice_activity_detection(audio, self.sr)
if segments:
# Keep only speech
speech_audio = np.concatenate([
audio[start:end] for start, end in segments
])
audio = speech_audio
metadata['vad_segments'] = len(segments)
metadata['final_length'] = len(audio)
metadata['duration_seconds'] = len(audio) / self.sr
return audio, metadata, True
except Exception as e:
return None, {'error': str(e)}, False
def _load_from_bytes(self, audio_bytes):
"""Load audio from bytes"""
import io
audio, _ = librosa.load(io.BytesIO(audio_bytes), sr=self.sr)
return audio
Real-World Challenges & Solutions
Challenge 1: Codec Artifacts
Problem: Different audio codecs introduce artifacts
def detect_codec_artifacts(audio, sr):
"""
Detect codec artifacts (e.g., from MP3 compression)
Returns: artifact_score (higher = more artifacts)
"""
import scipy.signal as signal
# Compute spectrogram
f, t, Sxx = signal.spectrogram(audio, fs=sr)
# MP3 artifacts often appear as:
# 1. High-frequency cutoff (lossy codecs)
cutoff_freq = 16000 # Hz
high_freq_mask = f > cutoff_freq
high_freq_energy = np.mean(Sxx[high_freq_mask, :])
# 2. Pre-echo artifacts
# Sudden changes in energy
energy = np.sum(Sxx, axis=0)
energy_diff = np.diff(energy)
pre_echo_score = np.std(energy_diff)
artifact_score = {
'high_freq_loss': high_freq_energy,
'pre_echo': pre_echo_score,
'overall': 1.0 - high_freq_energy + pre_echo_score
}
return artifact_score
# Example
audio_mp3, sr = librosa.load('compressed.mp3', sr=16000)
audio_wav, sr = librosa.load('lossless.wav', sr=16000)
artifacts_mp3 = detect_codec_artifacts(audio_mp3, sr)
artifacts_wav = detect_codec_artifacts(audio_wav, sr)
print(f"MP3 artifacts: {artifacts_mp3['overall']:.3f}")
print(f"WAV artifacts: {artifacts_wav['overall']:.3f}")
Challenge 2: Variable Sample Rates
class AdaptiveResampler:
"""
Handle audio from various sources with different sample rates
Production systems receive audio from:
- Phone calls: 8 kHz
- Bluetooth: 16 kHz
- Studio mics: 44.1 kHz / 48 kHz
"""
def __init__(self, target_sr=16000):
self.target_sr = target_sr
self.cache = {} # Cache resampling filters
def resample(self, audio, orig_sr):
"""
Efficiently resample with caching
"""
if orig_sr == self.target_sr:
return audio
# Check cache
cache_key = (orig_sr, self.target_sr)
if cache_key not in self.cache:
# Compute resampling filter once
self.cache[cache_key] = self._compute_filter(orig_sr, self.target_sr)
# Apply cached filter
return librosa.resample(
audio,
orig_sr=orig_sr,
target_sr=self.target_sr,
res_type='kaiser_fast' # Good balance of quality/speed
)
def _compute_filter(self, orig_sr, target_sr):
"""Compute and cache resampling filter"""
# In real implementation, would compute filter coefficients
return None
# Usage
resampler = AdaptiveResampler(target_sr=16000)
# Handle various sources
phone_audio = resampler.resample(phone_audio, orig_sr=8000)
bluetooth_audio = resampler.resample(bluetooth_audio, orig_sr=16000)
studio_audio = resampler.resample(studio_audio, orig_sr=48000)
Challenge 3: Clipping & Distortion
def detect_and_fix_clipping(audio, threshold=0.99):
"""
Detect clipped samples and attempt interpolation
Args:
audio: Audio signal
threshold: Clipping threshold (absolute value)
Returns:
fixed_audio, was_clipped
"""
# Detect clipping
clipped_mask = np.abs(audio) >= threshold
num_clipped = np.sum(clipped_mask)
if num_clipped == 0:
return audio, False
print(f"⚠️ Detected {num_clipped} clipped samples ({100*num_clipped/len(audio):.2f}%)")
# Simple interpolation for clipped regions
fixed_audio = audio.copy()
# Find clipped regions
clipped_indices = np.where(clipped_mask)[0]
for idx in clipped_indices:
# Skip edges
if idx == 0 or idx == len(audio) - 1:
continue
# Interpolate from neighbors
if not clipped_mask[idx-1] and not clipped_mask[idx+1]:
fixed_audio[idx] = (audio[idx-1] + audio[idx+1]) / 2
return fixed_audio, True
# Example
audio_with_clipping, sr = librosa.load('clipped_audio.wav', sr=16000)
fixed_audio, was_clipped = detect_and_fix_clipping(audio_with_clipping)
if was_clipped:
print("Applied clipping repair")
Challenge 4: Background Babble Noise
def reduce_babble_noise(audio, sr, noise_profile_duration=1.0):
"""
Reduce background babble (multiple speakers)
More challenging than stationary noise
"""
import noisereduce as nr
# Estimate noise profile from segments with lowest energy
frame_length = int(0.1 * sr) # 100ms frames
hop_length = frame_length // 2
# Compute frame energy
energy = librosa.feature.rms(
y=audio,
frame_length=frame_length,
hop_length=hop_length
)[0]
# Select low-energy frames as noise
noise_threshold = np.percentile(energy, 20)
noise_frames = np.where(energy < noise_threshold)[0]
# Extract noise samples
noise_samples = []
for frame_idx in noise_frames:
start = frame_idx * hop_length
end = start + frame_length
if end <= len(audio):
noise_samples.extend(audio[start:end])
noise_profile = np.array(noise_samples)
# Apply noise reduction
if len(noise_profile) > sr * noise_profile_duration:
reduced_noise = nr.reduce_noise(
y=audio,
y_noise=noise_profile[:int(sr * noise_profile_duration)],
sr=sr,
stationary=False, # Non-stationary noise
prop_decrease=0.8
)
return reduced_noise
else:
print("⚠️ Insufficient noise profile, returning original")
return audio
# Example
audio_with_babble, sr = librosa.load('meeting_audio.wav', sr=16000)
clean_audio = reduce_babble_noise(audio_with_babble, sr)
Audio Quality Metrics
Signal-to-Noise Ratio (SNR)
def calculate_snr(clean_signal, noisy_signal):
"""
Calculate SNR in dB
Args:
clean_signal: Ground truth clean signal
noisy_signal: Signal with noise
Returns:
SNR in dB
"""
# Ensure same length
min_len = min(len(clean_signal), len(noisy_signal))
clean = clean_signal[:min_len]
noisy = noisy_signal[:min_len]
# Compute noise
noise = noisy - clean
# Power
signal_power = np.mean(clean ** 2)
noise_power = np.mean(noise ** 2)
# SNR in dB
if noise_power == 0:
return float('inf')
snr = 10 * np.log10(signal_power / noise_power)
return snr
# Example
clean, sr = librosa.load('clean_speech.wav', sr=16000)
noisy, sr = librosa.load('noisy_speech.wav', sr=16000)
snr = calculate_snr(clean, noisy)
print(f"SNR: {snr:.2f} dB")
# Typical SNRs:
# > 40 dB: Excellent
# 25-40 dB: Good
# 10-25 dB: Fair
# < 10 dB: Poor
Perceptual Evaluation of Speech Quality (PESQ)
# PESQ is a standard metric for speech quality
# Requires pesq library: pip install pesq
from pesq import pesq
def evaluate_speech_quality(reference_audio, degraded_audio, sr=16000):
"""
Evaluate speech quality using PESQ
Args:
reference_audio: Clean reference
degraded_audio: Processed/degraded audio
sr: Sample rate (8000 or 16000)
Returns:
PESQ score (1.0 to 4.5, higher is better)
"""
# PESQ requires 8kHz or 16kHz
if sr not in [8000, 16000]:
raise ValueError("PESQ requires sr=8000 or sr=16000")
# Ensure same length
min_len = min(len(reference_audio), degraded_audio)
ref = reference_audio[:min_len]
deg = degraded_audio[:min_len]
# Compute PESQ
if sr == 8000:
mode = 'nb' # Narrowband
else:
mode = 'wb' # Wideband
score = pesq(sr, ref, deg, mode)
return score
# Example
reference, sr = librosa.load('clean.wav', sr=16000)
processed, sr = librosa.load('processed.wav', sr=16000)
quality_score = evaluate_speech_quality(reference, processed, sr)
print(f"PESQ Score: {quality_score:.2f}")
# PESQ interpretation:
# 4.0+: Excellent
# 3.0-4.0: Good
# 2.0-3.0: Fair
# < 2.0: Poor
Advanced Augmentation Strategies
Room Impulse Response (RIR) Convolution
def apply_room_impulse_response(speech, rir):
"""
Simulate room acoustics using RIR
Makes model robust to reverberation
Args:
speech: Clean speech signal
rir: Room impulse response
Returns:
Reverberant speech
"""
from scipy.signal import fftconvolve
# Convolve speech with RIR
reverb_speech = fftconvolve(speech, rir, mode='same')
# Normalize
reverb_speech = reverb_speech / (np.max(np.abs(reverb_speech)) + 1e-8)
return reverb_speech
# Example: Generate synthetic RIR
def generate_synthetic_rir(sr=16000, room_size='medium', rt60=0.5):
"""
Generate synthetic room impulse response
Args:
sr: Sample rate
room_size: 'small', 'medium', 'large'
rt60: Reverberation time (seconds)
Returns:
RIR signal
"""
# Duration based on RT60
duration = int(rt60 * sr)
# Exponential decay
t = np.arange(duration) / sr
decay = np.exp(-6.91 * t / rt60) # -60 dB decay
# Add random reflections
rir = decay * np.random.randn(duration)
# Initial spike (direct path)
rir[0] = 1.0
# Normalize
rir = rir / np.max(np.abs(rir))
return rir
# Usage
clean_speech, sr = librosa.load('speech.wav', sr=16000)
# Simulate different rooms
small_room_rir = generate_synthetic_rir(sr, 'small', rt60=0.3)
large_room_rir = generate_synthetic_rir(sr, 'large', rt60=1.2)
speech_small_room = apply_room_impulse_response(clean_speech, small_room_rir)
speech_large_room = apply_room_impulse_response(clean_speech, large_room_rir)
Codec Simulation
def simulate_codec(audio, sr, codec='mp3', bitrate=32):
"""
Simulate lossy codec compression
Makes model robust to codec artifacts
Args:
audio: Clean audio
sr: Sample rate
codec: 'mp3', 'aac', 'opus'
bitrate: Bitrate in kbps
Returns:
Codec-compressed audio
"""
import subprocess
import tempfile
import os
import soundfile as sf
# Save to temp file
with tempfile.NamedTemporaryFile(suffix='.wav', delete=False) as tmp_in:
sf.write(tmp_in.name, audio, sr)
input_path = tmp_in.name
with tempfile.NamedTemporaryFile(suffix='.wav', delete=False) as tmp_out:
output_path = tmp_out.name
try:
# Compress with ffmpeg
if codec == 'mp3':
subprocess.run([
'ffmpeg', '-i', input_path,
'-codec:a', 'libmp3lame',
'-b:a', f'{bitrate}k',
'-y', output_path
], capture_output=True, check=True)
elif codec == 'opus':
subprocess.run([
'ffmpeg', '-i', input_path,
'-codec:a', 'libopus',
'-b:a', f'{bitrate}k',
'-y', output_path
], capture_output=True, check=True)
# Load compressed audio
compressed_audio, _ = librosa.load(output_path, sr=sr)
return compressed_audio
finally:
# Cleanup
os.unlink(input_path)
if os.path.exists(output_path):
os.unlink(output_path)
# Usage
audio, sr = librosa.load('clean.wav', sr=16000)
# Simulate low-bitrate compression
audio_32kbps = simulate_codec(audio, sr, codec='mp3', bitrate=32)
audio_64kbps = simulate_codec(audio, sr, codec='mp3', bitrate=64)
Dynamic Range Compression
def dynamic_range_compression(audio, threshold=-20, ratio=4, attack=0.005, release=0.1, sr=16000):
"""
Apply dynamic range compression (like audio compressors)
Reduces loudness variation, simulating broadcast audio
Args:
audio: Input audio
threshold: Threshold in dB
ratio: Compression ratio (4:1 means 4dB input → 1dB output above threshold)
attack: Attack time in seconds
release: Release time in seconds
sr: Sample rate
Returns:
Compressed audio
"""
# Convert to dB
audio_db = 20 * np.log10(np.abs(audio) + 1e-8)
# Compute gain reduction
gain_db = np.zeros_like(audio_db)
for i in range(len(audio_db)):
if audio_db[i] > threshold:
# Above threshold: apply compression
excess_db = audio_db[i] - threshold
gain_db[i] = -excess_db * (1 - 1/ratio)
else:
gain_db[i] = 0
# Smooth gain reduction (attack/release)
attack_samples = int(attack * sr)
release_samples = int(release * sr)
smoothed_gain = np.zeros_like(gain_db)
for i in range(1, len(gain_db)):
if gain_db[i] < smoothed_gain[i-1]:
# Attack
alpha = 1 - np.exp(-1 / attack_samples)
else:
# Release
alpha = 1 - np.exp(-1 / release_samples)
smoothed_gain[i] = alpha * gain_db[i] + (1 - alpha) * smoothed_gain[i-1]
# Apply gain
gain_linear = 10 ** (smoothed_gain / 20)
compressed = audio * gain_linear
return compressed
# Example
audio, sr = librosa.load('speech.wav', sr=16000)
compressed = dynamic_range_compression(audio, threshold=-20, ratio=4, sr=sr)
End-to-End Preprocessing Pipeline
class ProductionAudioPipeline:
"""
Complete production-ready preprocessing pipeline
Handles all edge cases and monitors quality
"""
def __init__(self, config):
self.target_sr = config.get('sample_rate', 16000)
self.target_duration = config.get('target_duration', None)
self.enable_noise_reduction = config.get('noise_reduction', True)
self.enable_vad = config.get('vad', True)
self.augmentation_enabled = config.get('augmentation', False)
self.stats = {
'processed': 0,
'failed': 0,
'clipped': 0,
'too_short': 0,
'avg_snr': []
}
def process(self, audio_path):
"""
Process single audio file
Returns: (processed_audio, metadata, success)
"""
metadata = {'original_path': audio_path}
try:
# 1. Load
audio, orig_sr = librosa.load(audio_path, sr=None)
metadata['original_sr'] = orig_sr
metadata['original_duration'] = len(audio) / orig_sr
# 2. Detect issues
clipped = np.max(np.abs(audio)) >= 0.99
if clipped:
audio, _ = detect_and_fix_clipping(audio)
self.stats['clipped'] += 1
metadata['had_clipping'] = True
# 3. Resample
if orig_sr != self.target_sr:
audio = resample_audio(audio, orig_sr, self.target_sr)
metadata['resampled'] = True
# 4. Normalize
audio = normalize_audio(audio, target_level=-20.0)
metadata['normalized'] = True
# 5. Noise reduction
if self.enable_noise_reduction:
audio = high_pass_filter(audio, self.target_sr, cutoff_freq=80)
metadata['noise_reduction'] = True
# 6. Voice Activity Detection
if self.enable_vad:
segments = voice_activity_detection(audio, self.target_sr)
if segments:
speech_audio = np.concatenate([
audio[start:end] for start, end in segments
])
audio = speech_audio
metadata['vad_segments'] = len(segments)
else:
# No speech detected
return None, {'error': 'No speech detected'}, False
# 7. Duration handling
current_duration = len(audio) / self.target_sr
if self.target_duration:
target_samples = int(self.target_duration * self.target_sr)
if len(audio) < target_samples:
# Pad
audio = np.pad(audio, (0, target_samples - len(audio)), mode='constant')
metadata['padded'] = True
elif len(audio) > target_samples:
# Trim
audio = audio[:target_samples]
metadata['trimmed'] = True
# 8. Quality checks
if len(audio) < 0.5 * self.target_sr: # Less than 0.5 seconds
self.stats['too_short'] += 1
return None, {'error': 'Too short after VAD'}, False
# 9. Augmentation (training only)
if self.augmentation_enabled:
audio = self._augment(audio)
metadata['augmented'] = True
# 10. Final normalization
audio = audio / (np.max(np.abs(audio)) + 1e-8) * 0.95
metadata['final_duration'] = len(audio) / self.target_sr
metadata['final_samples'] = len(audio)
self.stats['processed'] += 1
return audio, metadata, True
except Exception as e:
self.stats['failed'] += 1
return None, {'error': str(e)}, False
def _augment(self, audio):
"""Apply random augmentation"""
import random
aug_type = random.choice(['noise', 'pitch', 'speed', 'none'])
if aug_type == 'noise':
audio = add_noise(audio, noise_factor=random.uniform(0.001, 0.01))
elif aug_type == 'pitch':
steps = random.choice([-2, -1, 1, 2])
audio = pitch_shift(audio, self.target_sr, n_steps=steps)
elif aug_type == 'speed':
rate = random.uniform(0.9, 1.1)
audio = time_stretch(audio, rate=rate)
return audio
def get_stats(self):
"""Get processing statistics"""
return self.stats
# Usage
config = {
'sample_rate': 16000,
'target_duration': 3.0,
'noise_reduction': True,
'vad': True,
'augmentation': False # True for training
}
pipeline = ProductionAudioPipeline(config)
# Process single file
audio, metadata, success = pipeline.process('input.wav')
if success:
print(f"✓ Processed successfully")
print(f"Duration: {metadata['final_duration']:.2f}s")
# Save
sf.write('output.wav', audio, pipeline.target_sr)
else:
print(f"✗ Failed: {metadata.get('error')}")
# Process batch
for audio_file in audio_files:
audio, metadata, success = pipeline.process(audio_file)
if success:
save_processed(audio, metadata)
# Get statistics
stats = pipeline.get_stats()
print(f"Processed: {stats['processed']}")
print(f"Failed: {stats['failed']}")
print(f"Clipped: {stats['clipped']}")
Key Takeaways
✅ Clean audio is critical - Preprocessing can make/break model performance
✅ Standardize formats - Consistent sample rate, bit depth, mono/stereo
✅ Remove noise - Spectral subtraction, filtering reduce artifacts
✅ VAD improves efficiency - Remove silence saves compute
✅ Augmentation boosts robustness - Time stretch, pitch shift, noise mixing
✅ Like feature engineering - Transform raw data into useful representations
✅ Pipeline thinking - Chain transformations like tree traversal
Originally published at: arunbaby.com/speech-tech/0007-audio-preprocessing
If you found this helpful, consider sharing it with others who might benefit.
