How voice assistants and video conferencing apps detect when you’re speaking vs silence, the critical first step in every speech pipeline.

Introduction

Voice Activity Detection (VAD) is the task of determining which parts of an audio stream contain speech vs non-speech (silence, background noise, music).

VAD is the gatekeeper of speech systems:

  • Triggers when to start listening (wake word detection)
  • Determines when utterance ends (endpoint detection)
  • Saves compute by only processing speech frames
  • Improves bandwidth by only transmitting speech

Why it matters:

  • Power efficiency: Voice assistants sleep until speech detected
  • Latency: Know when user finished speaking → respond faster
  • Bandwidth: Transmit only speech frames in VoIP
  • Accuracy: Reduce false alarms in ASR systems

What you’ll learn:

  • Energy-based VAD (simple, fast)
  • WebRTC VAD (production standard)
  • ML-based VAD (state-of-the-art)
  • Real-time streaming implementation
  • Production deployment considerations

Problem Definition

Design a real-time voice activity detection system.

Functional Requirements

  1. Detection
    • Classify each audio frame as speech or non-speech
    • Handle noisy environments
    • Detect speech from multiple speakers
  2. Endpoint Detection
    • Determine start of speech
    • Determine end of speech
    • Handle pauses within utterances
  3. Real-time Processing
    • Process audio frames as they arrive
    • Minimal buffering
    • Low latency

Non-Functional Requirements

  1. Latency
    • Frame-level detection: < 5ms
    • Endpoint detection: < 100ms after speech ends
  2. Accuracy
    • True positive rate > 95% (detect speech)
    • False positive rate < 5% (mistake noise for speech)
  3. Robustness
    • Work in SNR (Signal-to-Noise Ratio) down to 0 dB
    • Handle various noise types (music, traffic, crowds)
    • Adapt to different speakers

Approach 1: Energy-Based VAD

Simplest approach: Speech has higher energy than silence.

Implementation

import numpy as np
import librosa

class EnergyVAD:
    """
    Energy-based Voice Activity Detection

    Pros: Simple, fast, no training required
    Cons: Sensitive to noise, poor in low SNR
    """

    def __init__(
        self,
        sr=16000,
        frame_length_ms=20,
        hop_length_ms=10,
        energy_threshold=0.01
    ):
        self.sr = sr
        self.frame_length = int(sr * frame_length_ms / 1000)
        self.hop_length = int(sr * hop_length_ms / 1000)
        self.energy_threshold = energy_threshold

    def compute_energy(self, frame):
        """
        Compute frame energy (RMS)

        Energy = sqrt(mean(x^2))
        """
        return np.sqrt(np.mean(frame ** 2))

    def detect(self, audio):
        """
        Detect speech frames

        Args:
            audio: Audio signal

        Returns:
            List of booleans (True = speech, False = non-speech)
        """
        # Frame the audio
        frames = librosa.util.frame(
            audio,
            frame_length=self.frame_length,
            hop_length=self.hop_length
        )

        # Compute energy per frame
        energies = np.array([self.compute_energy(frame) for frame in frames.T])

        # Threshold
        is_speech = energies > self.energy_threshold

        return is_speech

    def get_speech_segments(self, audio):
        """
        Get speech segments (start, end) in seconds

        Returns:
            List of (start_time, end_time) tuples
        """
        is_speech = self.detect(audio)

        segments = []
        in_speech = False
        start_frame = 0

        for i, speech in enumerate(is_speech):
            if speech and not in_speech:
                # Speech started
                start_frame = i
                in_speech = True
            elif not speech and in_speech:
                # Speech ended
                end_frame = i
                in_speech = False

                # Convert frames to time
                start_time = start_frame * self.hop_length / self.sr
                end_time = end_frame * self.hop_length / self.sr

                segments.append((start_time, end_time))

        # Handle case where audio ends during speech
        if in_speech:
            end_time = len(is_speech) * self.hop_length / self.sr
            start_time = start_frame * self.hop_length / self.sr
            segments.append((start_time, end_time))

        return segments

# Usage
vad = EnergyVAD(energy_threshold=0.01)

# Load audio
audio, sr = librosa.load('speech_with_silence.wav', sr=16000)

# Detect speech
is_speech = vad.detect(audio)
print(f"Speech frames: {is_speech.sum()} / {len(is_speech)}")

# Get segments
segments = vad.get_speech_segments(audio)
for start, end in segments:
    print(f"Speech from {start:.2f}s to {end:.2f}s")

Adaptive Thresholding

Fixed thresholds fail in varying noise conditions. Use adaptive thresholds.

class AdaptiveEnergyVAD(EnergyVAD):
    """
    Energy VAD with adaptive threshold

    Threshold adapts to background noise level
    """

    def __init__(self, sr=16000, frame_length_ms=20, hop_length_ms=10):
        super().__init__(sr, frame_length_ms, hop_length_ms)
        self.noise_energy = 0.001  # Initial estimate
        self.alpha = 0.95  # Smoothing factor

    def detect(self, audio):
        """Detect with adaptive threshold"""
        frames = librosa.util.frame(
            audio,
            frame_length=self.frame_length,
            hop_length=self.hop_length
        )

        is_speech = []

        for frame in frames.T:
            energy = self.compute_energy(frame)

            # Adaptive threshold: 3x noise energy
            threshold = 3.0 * self.noise_energy

            if energy > threshold:
                # Likely speech
                is_speech.append(True)
            else:
                # Likely noise/silence
                is_speech.append(False)

                # Update noise estimate (during silence only)
                self.noise_energy = self.alpha * self.noise_energy + (1 - self.alpha) * energy

        return np.array(is_speech)

Approach 2: Zero-Crossing Rate + Energy

Combine energy with zero-crossing rate for better accuracy.

Implementation

class ZCR_Energy_VAD:
    """
    VAD using Energy + Zero-Crossing Rate

    Intuition:
    - Speech: Low ZCR (voiced sounds), moderate to high energy
    - Noise: High ZCR (unvoiced), varying energy
    - Silence: Low energy
    """

    def __init__(
        self,
        sr=16000,
        frame_length_ms=20,
        hop_length_ms=10,
        energy_threshold=0.01,
        zcr_threshold=0.1
    ):
        self.sr = sr
        self.frame_length = int(sr * frame_length_ms / 1000)
        self.hop_length = int(sr * hop_length_ms / 1000)
        self.energy_threshold = energy_threshold
        self.zcr_threshold = zcr_threshold

    def compute_zcr(self, frame):
        """
        Compute zero-crossing rate

        ZCR = # of times signal crosses zero / # samples
        """
        signs = np.sign(frame)
        zcr = np.mean(np.abs(np.diff(signs))) / 2
        return zcr

    def detect(self, audio):
        """
        Detect using both energy and ZCR
        """
        frames = librosa.util.frame(
            audio,
            frame_length=self.frame_length,
            hop_length=self.hop_length
        )

        is_speech = []

        for frame in frames.T:
            energy = np.sqrt(np.mean(frame ** 2))
            zcr = self.compute_zcr(frame)

            # Decision logic
            if energy > self.energy_threshold:
                # High energy: could be speech or noise
                if zcr < self.zcr_threshold:
                    # Low ZCR → likely speech (voiced)
                    is_speech.append(True)
                else:
                    # High ZCR → likely noise
                    is_speech.append(False)
            else:
                # Low energy → silence
                is_speech.append(False)

        return np.array(is_speech)

Approach 3: WebRTC VAD

Industry-standard VAD used in Chrome, Skype, etc.

Using WebRTC VAD

# WebRTC VAD requires: pip install webrtcvad
import webrtcvad
import struct

class WebRTCVAD:
    """
    WebRTC Voice Activity Detector

    Pros:
    - Production-tested (billions of users)
    - Fast, CPU-efficient
    - Robust to noise

    Cons:
    - Only works with specific sample rates (8/16/32/48 kHz)
    - Fixed frame sizes (10/20/30 ms)
    """

    def __init__(self, sr=16000, frame_duration_ms=30, aggressiveness=3):
        """
        Args:
            sr: Sample rate (must be 8000, 16000, 32000, or 48000)
            frame_duration_ms: Frame duration (10, 20, or 30 ms)
            aggressiveness: 0-3 (0=least aggressive, 3=most aggressive)
                - Higher = more likely to classify as non-speech
                - Use 3 for noisy environments
        """
        if sr not in [8000, 16000, 32000, 48000]:
            raise ValueError("Sample rate must be 8000, 16000, 32000, or 48000")

        if frame_duration_ms not in [10, 20, 30]:
            raise ValueError("Frame duration must be 10, 20, or 30 ms")

        self.sr = sr
        self.frame_duration_ms = frame_duration_ms
        self.frame_length = int(sr * frame_duration_ms / 1000)

        # Create VAD instance
        self.vad = webrtcvad.Vad(aggressiveness)

    def detect(self, audio):
        """
        Detect speech in audio

        Args:
            audio: numpy array of int16 samples

        Returns:
            List of booleans (True = speech)
        """
        # Convert float to int16 if needed (clip to avoid overflow)
        if audio.dtype == np.float32 or audio.dtype == np.float64:
            audio = np.clip(audio, -1.0, 1.0)
            audio = (audio * 32767).astype(np.int16)

        # Frame audio
        num_frames = len(audio) // self.frame_length
        is_speech = []

        for i in range(num_frames):
            start = i * self.frame_length
            end = start + self.frame_length
            frame = audio[start:end]

            # Convert to bytes
            frame_bytes = struct.pack('%dh' % len(frame), *frame)

            # Detect
            speech = self.vad.is_speech(frame_bytes, self.sr)
            is_speech.append(speech)

        return np.array(is_speech)

    def get_speech_timestamps(self, audio):
        """
        Get speech timestamps

        Returns:
            List of (start_time, end_time) in seconds
        """
        is_speech = self.detect(audio)

        segments = []
        in_speech = False
        start_frame = 0

        for i, speech in enumerate(is_speech):
            if speech and not in_speech:
                start_frame = i
                in_speech = True
            elif not speech and in_speech:
                in_speech = False
                start_time = start_frame * self.frame_length / self.sr
                end_time = i * self.frame_length / self.sr
                segments.append((start_time, end_time))

        if in_speech:
            start_time = start_frame * self.frame_length / self.sr
            end_time = len(is_speech) * self.frame_length / self.sr
            segments.append((start_time, end_time))

        return segments

# Usage
vad = WebRTCVAD(sr=16000, frame_duration_ms=30, aggressiveness=3)

audio, sr = librosa.load('audio.wav', sr=16000)
segments = vad.get_speech_timestamps(audio)

print("Speech segments:")
for start, end in segments:
    print(f"  {start:.2f}s - {end:.2f}s")

Approach 4: ML-Based VAD

Use neural networks for state-of-the-art performance.

CNN-based VAD

import torch
import torch.nn as nn

class CNNVAD(nn.Module):
    """
    CNN-based Voice Activity Detector

    Input: Mel-spectrogram (time, freq)
    Output: Speech probability per frame
    """

    def __init__(self, n_mels=40):
        super().__init__()

        # CNN layers
        self.conv1 = nn.Sequential(
            nn.Conv2d(1, 32, kernel_size=3, padding=1),
            nn.BatchNorm2d(32),
            nn.ReLU(),
            nn.MaxPool2d(2, 2)
        )

        self.conv2 = nn.Sequential(
            nn.Conv2d(32, 64, kernel_size=3, padding=1),
            nn.BatchNorm2d(64),
            nn.ReLU(),
            nn.MaxPool2d(2, 2)
        )

        # LSTM for temporal modeling
        self.lstm = nn.LSTM(
            input_size=64 * (n_mels // 4),
            hidden_size=128,
            num_layers=2,
            batch_first=True,
            bidirectional=True
        )

        # Classification head
        self.fc = nn.Linear(256, 1)  # Binary classification
        self.sigmoid = nn.Sigmoid()

    def forward(self, x):
        """
        Forward pass

        Args:
            x: (batch, 1, time, n_mels)

        Returns:
            Speech probabilities: (batch, time)
        """
        # CNN
        x = self.conv1(x)  # (batch, 32, time/2, n_mels/2)
        x = self.conv2(x)  # (batch, 64, time/4, n_mels/4)

        # Reshape for LSTM
        batch, channels, time, freq = x.size()
        x = x.permute(0, 2, 1, 3)  # (batch, time, channels, freq)
        x = x.reshape(batch, time, channels * freq)

        # LSTM
        x, _ = self.lstm(x)  # (batch, time, 256)

        # Classification
        x = self.fc(x)  # (batch, time, 1)
        x = self.sigmoid(x)  # (batch, time, 1)

        return x.squeeze(-1)  # (batch, time)

# Usage
model = CNNVAD(n_mels=40)

# Example input: mel-spectrogram
mel_spec = torch.randn(1, 1, 100, 40)  # (batch=1, channels=1, time=100, mels=40)

# Predict
speech_prob = model(mel_spec)  # (1, 100) - probability per frame
is_speech = speech_prob > 0.5  # Threshold at 0.5

print(f"Speech probability shape: {speech_prob.shape}")
print(f"Detected speech in {is_speech.sum().item()} / {is_speech.size(1)} frames")

Training ML VAD

class VADTrainer:
    """
    Train VAD model
    """

    def __init__(self, model, device='cuda'):
        self.model = model.to(device)
        self.device = device
        self.criterion = nn.BCELoss()
        self.optimizer = torch.optim.Adam(model.parameters(), lr=0.001)

    def train_epoch(self, train_loader):
        """Train for one epoch"""
        self.model.train()
        total_loss = 0

        for mel_specs, labels in train_loader:
            mel_specs = mel_specs.to(self.device)
            labels = labels.to(self.device)

            # Forward
            predictions = self.model(mel_specs)
            loss = self.criterion(predictions, labels)

            # Backward
            self.optimizer.zero_grad()
            loss.backward()
            self.optimizer.step()

            total_loss += loss.item()

        return total_loss / len(train_loader)

    def evaluate(self, val_loader):
        """Evaluate model"""
        self.model.eval()
        correct = 0
        total = 0

        with torch.no_grad():
            for mel_specs, labels in val_loader:
                mel_specs = mel_specs.to(self.device)
                labels = labels.to(self.device)

                predictions = self.model(mel_specs)
                predicted = (predictions > 0.5).float()

                correct += (predicted == labels).sum().item()
                total += labels.numel()

        accuracy = correct / total
        return accuracy

Real-Time Streaming VAD

Process audio as it arrives (streaming).

Streaming Implementation

from collections import deque
import numpy as np
import struct

class StreamingVAD:
    """
    Real-time VAD for streaming audio

    Use case: Voice assistants, VoIP, live transcription
    """

    def __init__(
        self,
        sr=16000,
        frame_duration_ms=30,
        aggressiveness=3,
        speech_pad_ms=300
    ):
        self.sr = sr
        self.frame_duration_ms = frame_duration_ms
        self.frame_length = int(sr * frame_duration_ms / 1000)
        self.speech_pad_ms = speech_pad_ms
        self.speech_pad_frames = int(speech_pad_ms / frame_duration_ms)

        # WebRTC VAD
        self.vad = webrtcvad.Vad(aggressiveness)

        # State
        self.buffer = deque(maxlen=10000)  # Audio buffer
        self.speech_frames = 0  # Consecutive speech frames
        self.silence_frames = 0  # Consecutive silence frames
        self.in_speech = False

        # Store speech segments
        self.current_speech = []

    def add_audio(self, audio_chunk):
        """
        Add audio chunk to buffer

        Args:
            audio_chunk: New audio samples (int16)
        """
        self.buffer.extend(audio_chunk)

    def process_frame(self):
        """
        Process one frame from buffer

        Returns:
            (is_speech, speech_ended, speech_audio)
        """
        if len(self.buffer) < self.frame_length:
            return None, False, None

        # Extract frame
        frame = np.array([self.buffer.popleft() for _ in range(self.frame_length)])

        # Convert to bytes
        frame_bytes = struct.pack('%dh' % len(frame), *frame)

        # Detect
        is_speech = self.vad.is_speech(frame_bytes, self.sr)

        # Update state
        if is_speech:
            self.speech_frames += 1
            self.silence_frames = 0

            if not self.in_speech:
                # Speech just started
                self.in_speech = True
                self.current_speech = []

            # Add to current speech
            self.current_speech.extend(frame)

        else:
            self.silence_frames += 1
            self.speech_frames = 0

            if self.in_speech:
                # Add padding
                self.current_speech.extend(frame)

                # Check if speech ended
                if self.silence_frames >= self.speech_pad_frames:
                    # Speech ended
                    self.in_speech = False
                    speech_audio = np.array(self.current_speech)
                    self.current_speech = []

                    return False, True, speech_audio

        return is_speech, False, None

    def process_stream(self):
        """
        Process all buffered audio

        Yields speech segments as they complete
        """
        while len(self.buffer) >= self.frame_length:
            is_speech, speech_ended, speech_audio = self.process_frame()

            if speech_ended:
                yield speech_audio

# Usage
streaming_vad = StreamingVAD(sr=16000, frame_duration_ms=30)

# Simulate streaming (process chunks as they arrive)
chunk_size = 480  # 30ms at 16kHz

for chunk_start in range(0, len(audio), chunk_size):
    chunk = audio[chunk_start:chunk_start + chunk_size]

    # Add to buffer
    streaming_vad.add_audio(chunk.astype(np.int16))

    # Process
    for speech_segment in streaming_vad.process_stream():
        print(f"Speech segment detected: {len(speech_segment)} samples")
        # Send to ASR, save, etc.

Production Considerations

Hangover and Padding

Add padding before/after speech to avoid cutting off words.

class VADWithPadding:
    """
    VAD with pre/post padding
    """

    def __init__(
        self,
        vad,
        pre_pad_ms=200,
        post_pad_ms=500,
        sr=16000
    ):
        self.vad = vad
        self.pre_pad_frames = int(pre_pad_ms / 30)  # Assuming 30ms frames
        self.post_pad_frames = int(post_pad_ms / 30)
        self.sr = sr

    def detect_with_padding(self, audio):
        """
        Detect speech with padding
        """
        is_speech = self.vad.detect(audio)

        # Add pre-padding
        padded = np.copy(is_speech)
        for i in range(len(is_speech)):
            if is_speech[i]:
                # Mark previous frames as speech
                start = max(0, i - self.pre_pad_frames)
                padded[start:i] = True

        # Add post-padding
        for i in range(len(is_speech)):
            if is_speech[i]:
                # Mark following frames as speech
                end = min(len(is_speech), i + self.post_pad_frames)
                padded[i:end] = True

        return padded

Performance Optimization

import time

class OptimizedVAD:
    """
    Optimized VAD for production
    """

    def __init__(self, vad_impl):
        self.vad = vad_impl
        self.stats = {
            'total_frames': 0,
            'speech_frames': 0,
            'processing_time': 0
        }

    def detect_with_stats(self, audio):
        """Detect with performance tracking"""
        start = time.perf_counter()

        is_speech = self.vad.detect(audio)

        end = time.perf_counter()

        # Update stats
        self.stats['total_frames'] += len(is_speech)
        self.stats['speech_frames'] += is_speech.sum()
        self.stats['processing_time'] += (end - start)

        return is_speech

    def get_stats(self):
        """Get performance statistics"""
        if self.stats['total_frames'] == 0:
            return None

        speech_ratio = self.stats['speech_frames'] / self.stats['total_frames']
        avg_time_per_frame = self.stats['processing_time'] / self.stats['total_frames']

        return {
            'speech_ratio': speech_ratio,
            'avg_latency_ms': avg_time_per_frame * 1000,
            'total_frames': self.stats['total_frames'],
            'speech_frames': self.stats['speech_frames']
        }

Integration with ASR Pipeline

VAD as the first stage in speech recognition systems.

End-to-End Pipeline

class SpeechPipeline:
    """
    Complete speech recognition pipeline with VAD

    Pipeline: Audio → VAD → ASR → Text
    """

    def __init__(self):
        # VAD
        self.vad = WebRTCVAD(sr=16000, frame_duration_ms=30, aggressiveness=3)

        # Placeholder for ASR model
        self.asr_model = None  # Would be actual ASR model

        # Buffering
        self.min_speech_duration = 0.5  # seconds
        self.max_speech_duration = 10.0  # seconds

    def process_audio_file(self, audio_path):
        """
        Process audio file end-to-end

        Returns:
            List of transcriptions
        """
        # Load audio
        import librosa
        audio, sr = librosa.load(audio_path, sr=16000)

        # Run VAD
        speech_segments = self.vad.get_speech_timestamps(audio)

        # Filter by duration
        valid_segments = [
            (start, end) for start, end in speech_segments
            if (end - start) >= self.min_speech_duration and
               (end - start) <= self.max_speech_duration
        ]

        transcriptions = []

        for start, end in valid_segments:
            # Extract speech segment
            start_sample = int(start * sr)
            end_sample = int(end * sr)
            speech_audio = audio[start_sample:end_sample]

            # Run ASR (placeholder)
            # transcript = self.asr_model.transcribe(speech_audio)
            transcript = f"[Speech from {start:.2f}s to {end:.2f}s]"

            transcriptions.append({
                'start': start,
                'end': end,
                'duration': end - start,
                'text': transcript
            })

        return transcriptions

    def process_streaming(self, audio_stream):
        """
        Process streaming audio

        Yields transcriptions as speech segments complete
        """
        streaming_vad = StreamingVAD(sr=16000, frame_duration_ms=30)

        for chunk in audio_stream:
            streaming_vad.add_audio(chunk)

            for speech_segment in streaming_vad.process_stream():
                # Run ASR on completed segment
                # transcript = self.asr_model.transcribe(speech_segment)
                transcript = "[Speech detected]"

                yield {
                    'audio': speech_segment,
                    'text': transcript,
                    'timestamp': time.time()
                }

# Usage
pipeline = SpeechPipeline()

# Process file
transcriptions = pipeline.process_audio_file('conversation.wav')
for t in transcriptions:
    print(f"{t['start']:.2f}s - {t['end']:.2f}s: {t['text']}")

Double-Pass VAD for Higher Accuracy

Use aggressive VAD first, then refine with ML model.

class TwoPassVAD:
    """
    Two-pass VAD for improved accuracy

    Pass 1: Fast WebRTC VAD (aggressive) → candidate segments
    Pass 2: ML VAD (accurate) → final segments
    """

    def __init__(self):
        # Fast pass: WebRTC VAD (aggressive)
        self.fast_vad = WebRTCVAD(sr=16000, frame_duration_ms=30, aggressiveness=3)

        # Accurate pass: ML VAD
        self.ml_vad = CNNVAD(n_mels=40)
        self.ml_vad.eval()

    def detect(self, audio):
        """
        Two-pass detection

        Returns:
            Refined speech segments
        """
        # Pass 1: Fast VAD to get candidate regions
        candidate_segments = self.fast_vad.get_speech_timestamps(audio)

        # Pass 2: ML VAD to refine each candidate
        refined_segments = []

        for start, end in candidate_segments:
            # Extract segment
            start_sample = int(start * 16000)
            end_sample = int(end * 16000)
            segment_audio = audio[start_sample:end_sample]

            # Run ML VAD on segment
            # Convert to mel-spectrogram
            import librosa
            mel_spec = librosa.feature.melspectrogram(
                y=segment_audio,
                sr=16000,
                n_mels=40
            )

            # ML model prediction
            # mel_tensor = torch.from_numpy(mel_spec).unsqueeze(0).unsqueeze(0)
            # with torch.no_grad():
            #     predictions = self.ml_vad(mel_tensor)
            #     is_speech_frames = predictions > 0.5

            # For now, accept if fast VAD said speech
            refined_segments.append((start, end))

        return refined_segments

Comparison of VAD Methods

Method Pros Cons Use Case
Energy-based Simple, fast, no training Poor in noise Quiet environments
ZCR + Energy Better than energy alone Still noise-sensitive Moderate noise
WebRTC VAD Fast, robust, production-tested Fixed aggressiveness Real-time apps, VoIP
ML-based (CNN) Best accuracy, adaptable Requires training, slower High-noise, accuracy-critical
ML-based (RNN) Temporal modeling Higher latency Offline processing
Hybrid (2-pass) Balance speed/accuracy More complex Production ASR

Production Deployment

Latency Budgets

For real-time applications:

Voice Assistant Latency Budget:
┌─────────────────────────────────────┐
│ VAD Detection:          5-10ms      │
│ Endpoint Detection:     100-200ms   │
│ ASR Processing:         500-1000ms  │
│ NLU + Dialog:           100-200ms   │
│ TTS Generation:         200-500ms   │
├─────────────────────────────────────┤
│ Total:                  ~1-2 seconds│
└─────────────────────────────────────┘

VAD must be fast to keep overall latency low!

Resource Usage

import psutil
import time

class VADProfiler:
    """
    Profile VAD performance
    """

    def __init__(self, vad):
        self.vad = vad

    def profile(self, audio, num_runs=100):
        """
        Benchmark VAD

        Returns:
            Performance metrics
        """
        latencies = []

        # Warm-up
        for _ in range(10):
            self.vad.detect(audio)

        # Measure
        process = psutil.Process()

        cpu_percent_before = process.cpu_percent()
        memory_before = process.memory_info().rss / 1024 / 1024  # MB

        for _ in range(num_runs):
            start = time.perf_counter()
            result = self.vad.detect(audio)
            end = time.perf_counter()

            latencies.append((end - start) * 1000)  # ms

        cpu_percent_after = process.cpu_percent()
        memory_after = process.memory_info().rss / 1024 / 1024  # MB

        return {
            'mean_latency_ms': np.mean(latencies),
            'p50_latency_ms': np.percentile(latencies, 50),
            'p95_latency_ms': np.percentile(latencies, 95),
            'p99_latency_ms': np.percentile(latencies, 99),
            'throughput_fps': 1000 / np.mean(latencies),
            'cpu_usage_pct': cpu_percent_after - cpu_percent_before,
            'memory_mb': memory_after - memory_before
        }

# Usage
profiler = VADProfiler(WebRTCVAD())

audio, sr = librosa.load('test.wav', sr=16000, duration=10.0)
metrics = profiler.profile(audio)

print(f"Mean latency: {metrics['mean_latency_ms']:.2f}ms")
print(f"P95 latency: {metrics['p95_latency_ms']:.2f}ms")
print(f"Throughput: {metrics['throughput_fps']:.0f} frames/sec")
print(f"CPU usage: {metrics['cpu_usage_pct']:.1f}%")
print(f"Memory: {metrics['memory_mb']:.1f} MB")

Mobile/Edge Deployment

Optimize VAD for on-device deployment.

class MobileOptimizedVAD:
    """
    VAD optimized for mobile devices

    Quantized model, reduced precision, smaller memory footprint
    """

    def __init__(self):
        # Use int8 quantization for mobile
        import torch

        self.model = CNNVAD(n_mels=40)

        # Quantize model
        # Dynamic quantization applies to Linear/LSTM; Conv2d not supported
        self.model = torch.quantization.quantize_dynamic(
            self.model,
            {torch.nn.Linear},
            dtype=torch.qint8
        )

        self.model.eval()

    def detect_efficient(self, audio):
        """
        Efficient detection with reduced memory

        Process in chunks to reduce peak memory
        """
        chunk_size = 16000  # 1 second chunks
        results = []

        for i in range(0, len(audio), chunk_size):
            chunk = audio[i:i+chunk_size]

            # Process chunk
            # result = self.process_chunk(chunk)
            # results.extend(result)
            pass

        return results

Monitoring & Debugging

VAD Quality Metrics

class VADEvaluator:
    """
    Evaluate VAD performance

    Metrics:
    - Precision: % of detected speech that is actual speech
    - Recall: % of actual speech that was detected
    - F1 score
    - False alarm rate
    - Miss rate
    """

    def __init__(self):
        pass

    def evaluate(
        self,
        predictions: np.ndarray,
        ground_truth: np.ndarray
    ) -> dict:
        """
        Compute VAD metrics

        Args:
            predictions: Binary array (1=speech, 0=non-speech)
            ground_truth: Ground truth labels

        Returns:
            Dictionary of metrics
        """
        # True positives, false positives, etc.
        tp = np.sum((predictions == 1) & (ground_truth == 1))
        fp = np.sum((predictions == 1) & (ground_truth == 0))
        tn = np.sum((predictions == 0) & (ground_truth == 0))
        fn = np.sum((predictions == 0) & (ground_truth == 1))

        # Metrics
        precision = tp / (tp + fp) if (tp + fp) > 0 else 0
        recall = tp / (tp + fn) if (tp + fn) > 0 else 0
        f1 = 2 * precision * recall / (precision + recall) if (precision + recall) > 0 else 0

        accuracy = (tp + tn) / (tp + tn + fp + fn)

        false_alarm_rate = fp / (fp + tn) if (fp + tn) > 0 else 0
        miss_rate = fn / (fn + tp) if (fn + tp) > 0 else 0

        return {
            'precision': precision,
            'recall': recall,
            'f1_score': f1,
            'accuracy': accuracy,
            'false_alarm_rate': false_alarm_rate,
            'miss_rate': miss_rate,
            'tp': int(tp),
            'fp': int(fp),
            'tn': int(tn),
            'fn': int(fn)
        }

# Usage
evaluator = VADEvaluator()

# Load ground truth
# ground_truth = load_annotations('test_audio.txt')

# Run VAD
vad = WebRTCVAD()
# predictions = vad.detect(audio)

# Evaluate
# metrics = evaluator.evaluate(predictions, ground_truth)

# print(f"Precision: {metrics['precision']:.3f}")
# print(f"Recall: {metrics['recall']:.3f}")
# print(f"F1 Score: {metrics['f1_score']:.3f}")
# print(f"False Alarm Rate: {metrics['false_alarm_rate']:.3f}")

Debugging Common Issues

Issue 1: Clipping Speech Beginnings

# Solution: Increase pre-padding
vad_with_padding = VADWithPadding(
    vad=WebRTCVAD(),
    pre_pad_ms=300,  # Increase from 200ms
    post_pad_ms=500
)

Issue 2: False Positives from Music

# Solution: Use ML VAD or add music classifier
class MusicFilteredVAD:
    """
    VAD with music filtering
    """

    def __init__(self, vad, music_classifier):
        self.vad = vad
        self.music_classifier = music_classifier

    def detect(self, audio):
        """Detect speech, filtering out music"""
        # Run VAD
        speech_frames = self.vad.detect(audio)

        # Filter music
        is_music = self.music_classifier.predict(audio)

        # Combine
        is_speech = speech_frames & (~is_music)

        return is_speech

Issue 3: High CPU Usage

# Solution: Downsample audio or use simpler VAD
class DownsampledVAD:
    """
    VAD with audio downsampling for efficiency
    """

    def __init__(self, target_sr=8000):
        self.target_sr = target_sr
        self.vad = WebRTCVAD(sr=8000)  # 8kHz instead of 16kHz

    def detect(self, audio, original_sr=16000):
        """Detect with downsampling"""
        # Downsample
        import librosa
        audio_downsampled = librosa.resample(
            audio,
            orig_sr=original_sr,
            target_sr=self.target_sr
        )

        # Run VAD on downsampled audio
        return self.vad.detect(audio_downsampled)

Advanced Techniques

Noise-Robust VAD

Use spectral subtraction for noise reduction before VAD.

class NoiseRobustVAD:
    """
    VAD with noise reduction preprocessing
    """

    def __init__(self, vad):
        self.vad = vad

    def spectral_subtraction(self, audio, noise_profile):
        """
        Simple spectral subtraction

        Args:
            audio: Input audio
            noise_profile: Estimated noise spectrum

        Returns:
            Denoised audio
        """
        import librosa

        # STFT
        D = librosa.stft(audio)
        magnitude = np.abs(D)
        phase = np.angle(D)

        # Subtract noise
        magnitude_clean = np.maximum(magnitude - noise_profile, 0)

        # Reconstruct
        D_clean = magnitude_clean * np.exp(1j * phase)
        audio_clean = librosa.istft(D_clean)

        return audio_clean

    def detect_with_denoising(self, audio):
        """Detect speech after denoising"""
        # Estimate noise from first 0.5 seconds
        noise_segment = audio[:8000]  # 0.5s at 16kHz

        import librosa
        noise_spectrum = np.abs(librosa.stft(noise_segment))
        noise_profile = np.median(noise_spectrum, axis=1, keepdims=True)

        # Denoise
        audio_clean = self.spectral_subtraction(audio, noise_profile)

        # Run VAD on clean audio
        return self.vad.detect(audio_clean)

Multi-Condition Training Data

For ML-based VAD, train on diverse conditions.

class DataAugmentationForVAD:
    """
    Augment training data for robust VAD
    """

    def augment(self, clean_speech):
        """
        Create augmented samples

        Augmentations:
        - Add various noise types
        - Vary SNR levels
        - Apply room reverberation
        - Change speaker characteristics
        """
        augmented = []

        # 1. Add white noise
        noise = np.random.randn(len(clean_speech)) * 0.01
        augmented.append(clean_speech + noise)

        # 2. Add babble noise (simulated)
        # babble = load_babble_noise()
        # augmented.append(clean_speech + babble)

        # 3. Apply reverberation
        # reverb = apply_reverb(clean_speech)
        # augmented.append(reverb)

        return augmented

Real-World Deployment Examples

Zoom/Video Conferencing

Requirements:

  • Ultra-low latency (< 10ms)
  • Adaptive to varying network conditions
  • Handle overlapping speech (multiple speakers)

Solution:

  • WebRTC VAD for speed
  • Adaptive aggressiveness based on network bandwidth
  • Per-speaker VAD in multi-party calls

Smart Speakers (Alexa, Google Home)

Requirements:

  • Always-on (low power)
  • Far-field audio (echoes, reverberation)
  • Wake word detection + VAD

Solution:

  • Two-stage: Wake word detector → VAD → ASR
  • On-device VAD (WebRTC or lightweight ML)
  • Cloud-based refinement for difficult cases

Call Centers

Requirements:

  • High accuracy (for analytics)
  • Speaker diarization integration
  • Post-processing acceptable

Solution:

  • ML-based VAD with large models
  • Two-pass processing
  • Combined with speaker diarization

Key Takeaways

✅ Energy + ZCR provides simple baseline VAD
✅ WebRTC VAD is production-standard, fast, robust, widely deployed
✅ ML-based VAD achieves best accuracy in noisy conditions
✅ Two-pass VAD balances speed and accuracy for production
✅ Streaming processing enables real-time applications
✅ Padding is critical to avoid cutting off speech (200-500ms)
✅ Adaptive thresholds handle varying noise levels
✅ Frame size tradeoff: Smaller = lower latency, larger = better accuracy
✅ Quantization & optimization essential for mobile/edge deployment
✅ Monitor precision/recall in production to catch degradation
✅ Integration with ASR requires careful endpoint detection logic
✅ Noise robustness via preprocessing or multi-condition training

Originally published at: arunbaby.com/speech-tech/0004-voice-activity-detection

If you found this helpful, consider sharing it with others who might benefit.

Related across topics

Best Time to Buy and Sell Stock

24 minute read

The single-pass pattern that powers streaming analytics, online algorithms, and real-time decision making in production systems.

Voice Activity Detection (VAD)

23 minute read

How voice assistants and video conferencing apps detect when you’re speaking vs silence, the critical first step in every speech pipeline.
