“Cron is not an orchestrator. A script is not a pipeline.”

1. Problem Statement

Standard software runs via Request -> Response. ML software runs as a Pipeline.

  • Step 1: Ingest Data (Wait for Hive partition).
  • Step 2: Clean Data (Requires Step 1).
  • Step 3: Distributed Training (Requires Step 2, Requires GPU cluster).
  • Step 4: Validation (Requires Step 3).
  • Step 5: Deploy.

The Problem: How do you manage this dependency graph reliably, handling retries, backfills, and distributed execution, without writing spaghetti bash scripts?

2. Understanding the Requirements

2.1 Why cron fails

0 2 * * * train_model.sh.

  1. Dependency Hell: What if the Data Ingest job (scheduled at 1:00 AM) is delayed? train_model.sh runs on empty data.
  2. No State: If Step 3 fails, cron doesn’t know. It won’t retry just Step 3. You have to re-run the whole thing.
  3. No Scaling: cron runs on one machine. We need to run Step 3 on a Kubernetes GPU cluster.

2.2 The Solution: The DAG

We represent the workflow as a Directed Acyclic Graph (DAG).

  • Directed: Data flows A -> B.
  • Acyclic: B cannot feed back into A (infinite loop).
  • Graph: Nodes are tasks, Edges are data/control dependencies.

3. High-Level Architecture

An MLOps Orchestrator (like Airflow or Kubeflow Pipelines) consists of:

[Scheduler (The Brain)]
   |  (Polls DAGs, Checks Time, Checks Dependencies)
   |
   +---> [Queue (Redis/RabbitMQ)]
            |
            v
   [Workers (The Brawn)]
      | Worker 1: [Task A: Data Prep]
      | Worker 2: [Task B: Training (GPU)]
      | Worker 3: [Task C: Evaluation]

Key Components

  1. Metastore (Postgres): “Task B failed at 2:03 PM”.
  2. Executor: “Launch this task on Kubernetes” vs “Launch this task in a local process”.

4. Component Deep-Dives

4.1 Airflow (The Scheduler King)

  • Python as Config: You define DAGs in Python code.
  • Operators: PostgresOperator, PythonOperator, BashOperator.
  • Sensors: Special tasks that “wait” for something (e.g., S3KeySensor waits for a file to appear).
  • Best For: Data Engineering, Scheduled jobs.

4.2 Kubeflow Pipelines (The ML Specialist)

  • Container Native: Every task is a Docker container.
  • Artifact Tracking: Automatically logs “Task A produced dataset.csv (hash: xyz)”.
  • Best For: Deep Learning workflows where reproducibility (Docker) is critical.

5. Data Flow: The Backfill

A unique feature of Orchestrators is Backfilling. Imagine you change your Feature Engineering logic today (Day 50). You want to re-train the model on data from Day 1 to Day 49 using the new logic.

With cron, this is a nightmare. With Airflow:

  1. Clear the state of “FeatureEng Task” for dates=[Day 1...Day 49].
  2. The Scheduler sees these tasks as “Null state”.
  3. Since they have no dependencies blocking them (historical data exists), it schedules them all in parallel (up to max_active_runs).

This turns “Historical Reprocessing” into a one-click operation.

6. Scaling Strategies

6.1 The Kubernetes Executor

Instead of having a fixed pool of workers (which sit idle or get overwhelmed), use the KubernetesExecutor.

  • Scheduler: “Task A needs to run.”
  • K8s: Spin up a Pod just for Task A.
  • Task A: Runs.
  • K8s: Kill Pod. Pros: Infinite scale. Zero cost when idle. Perfect isolation (Task A uses PyTorch 1.9, Task B uses PyTorch 2.0).

6.2 Caching (Memoization)

If Task A takes 5 hours to generate clean_data.csv, and Task B fails… When we retry, we don’t want to re-run Task A. Kubeflow natively checks inputs. If Hash(Inputs, Code) matches a previous run, it reuses the cached output.

7. Implementation: defining a DAG (Airflow)

from airflow import DAG
from airflow.operators.python import PythonOperator
from airflow.sensors.s3 import S3KeySensor
from datetime import datetime

def train_model(**context):
    # ML Logic here
    print("Training...")

with DAG("ml_pipeline_v1",
         start_date=datetime(2023, 1, 1),
         schedule_interval="@daily",
         catchup=False) as dag:

    # 1. Wait for data to arrive in S3
    wait_for_data = S3KeySensor(
        task_id="wait_for_input",
        bucket_key="s3://data/incoming//data.csv"
    )

    # 2. Train logic
    train = PythonOperator(
        task_id="train_model",
        python_callable=train_model
    )

    # 3. Dependency Definition
    wait_for_data >> train

8. Monitoring & Metrics

  1. DAG Parse Time: If your Python DAG file is slow to parse (e.g., connects to DB at top level), the Scheduler hangs. Anti-pattern!
  2. Task Latency: Track Input_Size vs Duration. If data grew 2x but time grew 10x, you have a non-linear scaling bug.

9. Failure Modes

  1. Thundering Herd: You backfill 1 year of data. 365 jobs launch instantly. Your Database crashes.
    • Fix: Set concurrency=10 at the DAG level.
  2. Deadlock: Task A waits for Task B. Task B waits for connection slot held by Task A.
  3. Zombies: The Scheduler thinks Task A is running. Task A’s pod died OOM. The state stays “Running” forever.
    • Fix: Frequent “Heartbeat” checks by the Scheduler.

10. Real-World Case Study: Lyft Flyte

Lyft built Flyte because Airflow wasn’t strict enough about data types. Flyte enforces Type Safety between tasks.

  • Task A output: dataframe_schema[age: int]
  • Task B input: dataframe_schema[age: String]
  • Flyte catches this mismatch at Compile Link Time, preventing runtime failures 5 hours into the pipeline.

11. Cost Analysis

  • Spot Instances: Since ML pipelines are fault-tolerant (auto-retry), use Spot Instances for the Heavy Workers. Savings: 70%.
  • Idle Clusters: Using K8s Executor prevents paying for idle workers at night.

12. Key Takeaways

  1. Dependency Management: This is the core value prop. “Run B only after A succeeds.”
  2. Idempotency: Every task must be idempotent. If run twice, it should produce the same result (or overwrite safely).
  3. Infrastructure as Code: The Pipeline is code. Version control your DAGs.
  4. Static vs Dynamic: Airflow is Static (DAG defined upfront). Prefect/Metaflow allow Dynamic (DAG defined at runtime).
