“Scaling from one GPU to thousands.”

1. The Need for Scale

Modern Deep Learning models are massive.

  • GPT-3: 175 Billion parameters.
  • PaLM: 540 Billion parameters.
  • Training Data: Trillions of tokens.

A single NVIDIA A100 GPU (80GB VRAM) cannot hold these models, let alone train them in a reasonable time. To train these models, we must distribute the computation across hundreds or thousands of GPUs.

2. Taxonomy of Parallelism

There are three main dimensions of parallelism in Deep Learning:

  1. Data Parallelism: Split the data across devices. Replicate the model.
  2. Model Parallelism: Split the model across devices. Replicate the data (or split it).
    • Pipeline Parallelism: Split layers across devices (Inter-layer).
    • Tensor Parallelism: Split individual operations (matrices) across devices (Intra-layer).
  3. 3D Parallelism: Combining all the above.

3. Data Parallelism (DP)

This is the simplest and most common form.

Mechanism:

  1. Copy the entire model to every GPU (Worker).
  2. Split the global batch into mini-batches. Assign one mini-batch to each GPU.
  3. Forward Pass: Each GPU computes predictions and loss for its mini-batch.
  4. Backward Pass: Each GPU computes gradients w.r.t. its local data.
  5. Synchronization: Gradients are aggregated (averaged) across all GPUs.
  6. Update: All GPUs update their model weights with the averaged gradients.

3.1. Parameter Server (PS) Architecture

  • Workers: Compute gradients.
  • Parameter Servers: Store global weights.
  • Flow: Workers pull weights -> Compute gradients -> Push gradients to PS -> PS updates weights.
  • Bottleneck: Network bandwidth at the PS.

3.2. Ring All-Reduce

Used in DistributedDataParallel (DDP) (PyTorch) and Horovod.

  • No central server.
  • GPUs are arranged in a logical ring.
  • Each GPU sends data to its neighbor and receives from the other neighbor.
  • Scatter-Reduce: Chunk gradients and reduce them as they pass around the ring.
  • All-Gather: Gather the reduced chunks back to all GPUs.
  • Bandwidth Optimal: Bandwidth usage is constant regardless of the number of GPUs.

4. Model Parallelism (MP)

When the model doesn’t fit in one GPU’s memory.

4.1. Pipeline Parallelism (PP)

Split the model layers into stages.

  • GPU 1: Layers 1-10
  • GPU 2: Layers 11-20
  • …
  • Naive Approach: GPU 2 waits for GPU 1. Huge “bubble” (idle time).
  • GPipe / PipeDream: Split the mini-batch into micro-batches. Pipeline the execution of micro-batches to fill the bubbles.

4.2. Tensor Parallelism (TP)

Split the tensors (matrices) themselves.

  • Example: Matrix Multiplication $Y = X \cdot A$.
  • Split $A$ into columns $A_1, A_2$.
  • GPU 1 computes $Y_1 = X \cdot A_1$.
  • GPU 2 computes $Y_2 = X \cdot A_2$.
  • Concatenate $Y = [Y_1, Y_2]$.
  • Requires high-bandwidth interconnect (NVLink) because synchronization happens per layer. Used in Megatron-LM.

5. ZeRO (Zero Redundancy Optimizer)

Standard Data Parallelism replicates the Optimizer States, Gradients, and Parameters on every GPU. This is wasteful.

ZeRO-DP (DeepSpeed):

  • ZeRO-1: Shard Optimizer States. (4x memory reduction).
  • ZeRO-2: Shard Gradients. (8x memory reduction).
  • ZeRO-3: Shard Parameters. (Memory usage scales linearly with number of GPUs).

With ZeRO-3, parameters are fetched on-demand just before the forward/backward pass of a layer and released immediately after. It effectively allows training trillion-parameter models on limited GPU memory.

6. System Design: Designing a Training Cluster

Scenario: Build a cluster to train a 100B parameter model.

6.1. Hardware

  • Compute: NVIDIA H100 or A100 GPUs.
  • Interconnect:
    • Intra-node: NVLink / NVSwitch (900 GB/s). Crucial for Tensor Parallelism.
    • Inter-node: InfiniBand or RoCE (RDMA over Converged Ethernet) (400 Gbps). Crucial for Data/Pipeline Parallelism.
  • Storage: High-performance parallel file system (Lustre, GPUDirect Storage) to feed data at line rate.

6.2. Network Topology

  • Rail-optimized: All GPU-0s across nodes communicate, all GPU-1s communicate, etc.
  • Non-Blocking Fat Tree: Ensures full bisection bandwidth.

6.3. Fault Tolerance

  • Checkpointing: Save model state frequently to S3/HDFS.
  • Elastic Training: If a node fails, the job should pause, reconfigure (remove bad node), and resume from the last checkpoint automatically (e.g., PyTorch Elastic / TorchRun).

7. Communication Primitives (NCCL)

Understanding the underlying collective operations is key.

  • Broadcast: One sends to all.
  • Scatter: One splits data and sends parts to all.
  • Gather: All send to one.
  • All-Gather: Everyone gathers data from everyone.
  • Reduce: Aggregate data to one (Sum, Min, Max).
  • All-Reduce: Aggregate data and distribute result to all. (The workhorse of DP).

8. Deep Dive: Gradient Accumulation

If you can’t fit a large enough batch size for convergence (e.g., batch size 32) even with parallelism:

  • Run forward/backward for batch size 1.
  • Don’t update weights.
  • Accumulate gradients.
  • Repeat 32 times.
  • Update weights.
  • Simulates a larger batch size at the cost of compute time (no extra memory).

9. Case Study: Training GPT-3

  • Architecture: Transformer Decoder.
  • Parallelism:
    • Tensor Parallelism: Within each node (8 GPUs).
    • Pipeline Parallelism: Across nodes.
    • Data Parallelism: Across replicas of the pipeline.
  • Infrastructure: Microsoft Azure AI Supercomputer (10,000+ GPUs).
  • Challenges: Stragglers (slow nodes), Silent Data Corruption (bit flips), Loss Spikes.

10. Deep Dive: Collective Communication (Ring All-Reduce)

The efficiency of Data Parallelism hinges on the All-Reduce operation. Goal: Every GPU starts with a gradient vector $G_i$. Every GPU ends with the sum $\sum G_i$.

Naive Approach:

  • All GPUs send their gradients to GPU 0 (Gather).
  • GPU 0 sums them.
  • GPU 0 sends the sum back to all GPUs (Broadcast).
  • Bottleneck: GPU 0’s bandwidth. Time scales linearly with $N$ (number of GPUs).

Ring All-Reduce:

  • Topology: GPU 0 -> GPU 1 -> … -> GPU N-1 -> GPU 0.
  • Step 1: Scatter-Reduce:
    • Split the gradient vector into $N$ chunks.
    • In each step, GPU $i$ sends a chunk to GPU $i+1$ and receives a chunk from GPU $i-1$.
    • It adds the received chunk to its local chunk and passes it on.
    • After $N-1$ steps, each GPU holds a fully summed chunk of the gradient vector (different chunk for each GPU).
  • Step 2: All-Gather:
    • Each GPU sends its fully summed chunk to the next neighbor.
    • After $N-1$ steps, all GPUs have all the fully summed chunks.
  • Complexity:
    • Data transmitted per GPU: $2(N-1) \frac{K}{N} \approx 2K$.
    • Crucially: Independent of $N$. This allows scaling to thousands of GPUs.

11. Deep Dive: ZeRO (Zero Redundancy Optimizer) Details

Let’s break down the memory savings for a model with $\Psi$ parameters. Using Mixed Precision (fp16/bf16) and Adam Optimizer.

Baseline (Standard DDP):

  • Parameters (fp16): $2\Psi$ bytes.
  • Gradients (fp16): $2\Psi$ bytes.
  • Optimizer States (fp32):
    • Master Weights: $4\Psi$ bytes.
    • Momentum: $4\Psi$ bytes.
    • Variance: $4\Psi$ bytes.
    • Total Opt States: $12\Psi$ bytes.
  • Total per GPU: $16\Psi$ bytes.

ZeRO-1 (Shard Optimizer States):

  • Partition the $12\Psi$ optimizer states across $N$ GPUs.
  • Each GPU stores $\frac{12\Psi}{N}$.
  • Total per GPU: $4\Psi + \frac{12\Psi}{N}$.
  • Savings: ~4x reduction.

ZeRO-2 (Shard Gradients):

  • Partition the $2\Psi$ gradients as well.
  • Each GPU stores $\frac{2\Psi + 12\Psi}{N}$.
  • Total per GPU: $2\Psi + \frac{14\Psi}{N}$.
  • Savings: ~8x reduction.

ZeRO-3 (Shard Parameters):

  • Partition the $2\Psi$ parameters too.
  • Total per GPU: $\frac{16\Psi}{N}$.
  • Savings: Linear reduction with $N$.
  • Trade-off: Increased communication. Parameters must be broadcasted (all-gather) before each layer’s forward/backward pass and discarded immediately.

12. Deep Dive: Pipeline Parallelism (1F1B)

GPipe:

  • Split batch into $M$ micro-batches.
  • Run all $M$ forward passes.
  • Run all $M$ backward passes.
  • Memory Issue: Need to store activations for all $M$ micro-batches until the backward pass starts.

1F1B (One Forward One Backward) - PipeDream:

  • Schedule: Forward 1, Forward 2, …, Backward 1, Forward 3, Backward 2…
  • As soon as the first micro-batch finishes its forward pass at the last stage, it starts its backward pass.
  • This frees up activation memory much earlier.
  • Bubble: The idle time at the start and end of the pipeline.
    • Bubble fraction $\approx \frac{P-1}{M}$, where $P$ is pipeline stages.
    • To minimize bubble, we need $M \gg P$.

13. Deep Dive: Tensor Parallelism (Megatron-LM)

How do we split a Transformer Layer across GPUs?

MLP Layer ($A \rightarrow GeLU \rightarrow B$):

  • $Y = GeLU(X A)$.
  • Split $A$ by columns ($A_1, A_2$).
  • Each GPU computes $Y_i = GeLU(X A_i)$.
  • Next matrix $B$ is split by rows ($B_1, B_2$).
  • Compute $Z = [Y_1, Y_2] \cdot \begin{bmatrix} B_1 \ B_2 \end{bmatrix} = Y_1 B_1 + Y_2 B_2$.
  • All-Reduce: Sum the results $Y_1 B_1 + Y_2 B_2$ across GPUs.
  • Benefit: Only one All-Reduce needed per MLP block.

Self-Attention Layer:

  • Split Query ($Q$), Key ($K$), Value ($V$) weight matrices by columns (split heads).
  • Each GPU computes attention for a subset of heads.
  • Output projection matrix $O$ is split by rows.
  • All-Reduce: Sum the outputs of the projection.

15. Deep Dive: Network Topologies for AI Clusters

The physical wiring of the cluster determines the maximum possible bandwidth and latency.

1. Fat Tree (Clos Network):

  • Structure: A tree where links near the root have higher bandwidth (fatter) than links near the leaves.
  • Non-Blocking: Guarantees that any node can communicate with any other node at full line rate (if the switch capacity allows).
  • Pros: Predictable performance, easy to route.
  • Cons: Expensive (lots of switches and cables).

2. Torus / Mesh:

  • Structure: Grid-like connection. 2D Torus connects neighbors in X and Y (wrapping around). 3D Torus adds Z.
  • Pros: Cheaper (fewer switches, direct node-to-node links). Good for local communication (stencil patterns).
  • Cons: Higher latency for distant nodes (multi-hop).

3. Dragonfly:

  • Structure: Groups of routers fully connected within the group, and groups are fully connected to other groups.
  • Pros: Low diameter (max 3 hops for any pair), highly scalable.
  • Cons: Complex routing (needs adaptive routing to avoid congestion).

NVIDIA SuperPOD: Uses a non-blocking Fat Tree with InfiniBand HDR/NDR to ensure 800 Gbps per GPU.

16. Deep Dive: Framework Internals (PyTorch DDP)

How does DistributedDataParallel actually work?

1. Bucketing:

  • Gradients are small (e.g., bias vector). Sending millions of tiny packets kills performance (latency overhead).
  • DDP groups parameters into Buckets (e.g., 25MB).
  • It waits for all gradients in a bucket to be computed, then triggers one All-Reduce for the entire bucket.

2. Gradient Hooks:

  • DDP registers autograd hooks on every parameter.
  • When a gradient is ready, the hook fires.
  • The hook copies the gradient into the bucket buffer.

3. Overlap (Compute-Comm):

  • While the backward pass is computing gradients for layer $L-1$, the All-Reduce for layer $L$ (already in bucket) is running asynchronously on the network card.
  • Goal: Hide communication time behind computation time.

17. Case Study: LLaMA 2 Training Infrastructure

Meta’s Research SuperCluster (RSC):

  • GPUs: 16,000 NVIDIA A100 (80GB).
  • Interconnect: InfiniBand 200 Gbps (Fat Tree).
  • Storage: 175 PB of Pure Storage FlashBlade.
  • Optimization:
    • xFormers: Optimized Attention kernels (FlashAttention).
    • Checkpointing: Saved to distributed storage every few hours.
    • Silent Data Corruption: Detected via loss spikes. If detected, roll back to previous checkpoint and skip the bad batch.

Training Stability:

  • Loss Spikes: Often caused by “bad” data or numerical instability (fp16 overflow).
  • Fix: Gradient Clipping (norm 1.0), Weight Decay decoupling (AdamW), and skipping batches with NaN gradients.

18. Deep Dive: Asynchronous vs Synchronous SGD

Synchronous SGD (Standard):

  • Wait for ALL workers to finish.
  • Update = Average of all.
  • Pros: Mathematically equivalent to large-batch SGD. Converges well.
  • Cons: Straggler problem (fastest worker waits for slowest).

Asynchronous SGD (Hogwild!):

  • Workers push gradients to PS whenever they are done.
  • PS updates weights immediately.
  • Workers pull new weights.
  • Pros: No waiting. High hardware utilization.
  • Cons: Stale Gradients. Worker computes gradient on $W_t$, but by the time it pushes, the global weights are $W_{t+10}$. The gradient is “stale” and points in the wrong direction.
  • Solution: Rarely used now. Sync SGD with backup workers (ignore slowest 5%) is preferred.

19. Interview Questions

  1. Explain All-Reduce. How does Ring All-Reduce work? What is its complexity? ($2(N-1) \frac{K}{N}$).
  2. Data Parallelism vs. Model Parallelism. When to use which?
  3. What is the “Stale Gradient” problem? In Asynchronous SGD, workers might compute gradients on old weights. How does Synchronous SGD fix this?
  4. How does ZeRO-3 work? How does it handle communication overhead? (Prefetching).
  5. Calculate Memory Footprint. For a model with $P$ parameters, using Adam optimizer and mixed precision.
    • Parameters: $2P$ bytes (fp16).
    • Gradients: $2P$ bytes (fp16).
    • Optimizer States: $12P$ bytes (fp32 copy of params, momentum, variance).
    • Total: $16P$ bytes. For 1B params, ~16GB.

20. Deep Dive: Gradient Checkpointing (Activation Recomputation)

Problem: During backprop, we need activations from the forward pass. For a 100-layer model, storing all activations requires massive memory. Solution: Trade compute for memory.

Algorithm:

  1. Forward Pass: Only save activations at checkpoints (e.g., every 10 layers). Discard intermediate activations.
  2. Backward Pass: When we need activations for layer 15:
    • Re-run forward from checkpoint 10 to layer 15.
    • Compute gradients.
    • Discard the recomputed activations.

Memory Savings:

  • Without checkpointing: $O(N)$ memory for $N$ layers.
  • With checkpointing every $\sqrt{N}$ layers: $O(\sqrt{N})$ memory.
  • Cost: $\sqrt{N}$ extra forward passes (33% compute overhead for Transformers).

PyTorch Implementation:

from torch.utils.checkpoint import checkpoint

class MyModel(nn.Module):
    def forward(self, x):
        # Checkpoint expensive blocks
        x = checkpoint(self.layer1, x)
        x = checkpoint(self.layer2, x)
        return x

21. Deep Dive: Mixed Precision Training (FP16/BF16)

Motivation: FP32 (32-bit floats) are slow and memory-hungry. FP16 (16-bit) is 2x faster and uses half the memory. Challenge: FP16 has limited range ($6 \times 10^{-8}$ to $65504$). Gradients can underflow (become zero) or overflow.

Solution: Mixed Precision (NVIDIA Apex / PyTorch AMP):

  1. Master Weights: Keep FP32 copy of weights.
  2. Forward/Backward: Use FP16 for matrix multiplications (fast).
  3. Loss Scaling: Multiply loss by a large number (e.g., 1024) before backprop. This shifts gradients into FP16’s representable range.
  4. Unscale Gradients: Divide gradients by the scale factor before updating FP32 master weights.
  5. Update: Update FP32 weights, then copy to FP16 for next iteration.

BFloat16 (BF16):

  • Same exponent range as FP32 (8 bits), but only 7 bits for mantissa.
  • Advantage: No loss scaling needed. Easier to use.
  • Disadvantage: Lower precision than FP16 for small numbers.
  • Used in: Google TPUs, AMD MI250, NVIDIA H100.

22. Deep Dive: FlashAttention (Memory-Efficient Attention)

Standard Attention: $O(N^2)$ memory for the attention matrix. For $N=4096$ tokens, this is 16M elements (64MB in FP16).

FlashAttention (Dao et al., 2022):

  • Idea: Never materialize the full $N \times N$ attention matrix.
  • Algorithm:
    1. Tile $Q$, $K$, $V$ into blocks that fit in SRAM (on-chip cache).
    2. Compute attention for each block.
    3. Use online softmax (incremental computation) to avoid storing intermediate results in HBM (slow GPU memory).
  • Result: 2-4x speedup, enables training with 64K context length.

Impact on Distributed Training:

  • Reduces activation memory, allowing larger batch sizes or longer sequences.
  • Critical for LLaMA, GPT-4, Claude.

23. Deep Dive: FSDP (Fully Sharded Data Parallel)

PyTorch FSDP is Meta’s implementation of ZeRO-3. Key Features:

  1. Auto-Wrapping: Automatically wraps model layers for sharding.
  2. CPU Offloading: Can offload parameters to CPU RAM when not in use (train 13B model on 1x A100).
  3. Mixed Precision: Native support for BF16.

Usage:

from torch.distributed.fsdp import FullyShardedDataParallel as FSDP

model = MyTransformer()
model = FSDP(model,
             auto_wrap_policy=transformer_auto_wrap_policy,
             mixed_precision=bf16_policy)

When to use FSDP vs DDP:

  • DDP: Model fits in one GPU. Simple, fast.
  • FSDP: Model doesn’t fit. Need memory efficiency.

24. Production Deployment: Monitoring & Observability

Training a model for weeks/months requires robust monitoring.

Metrics to Track:

  1. Loss Curves: Train/Val loss per step. Detect divergence early.
  2. Gradient Norms: Sudden spikes indicate instability.
  3. GPU Utilization: Should be >90%. If low, data loading is the bottleneck.
  4. Communication Time: Time spent in All-Reduce. Should be <10% of step time.
  5. Throughput: Tokens/second. Track degradation over time (memory leaks, stragglers).

Tools:

  • TensorBoard / Weights & Biases: Visualize metrics.
  • NVIDIA DCGM (Data Center GPU Manager): Monitor GPU health (temperature, power, ECC errors).
  • Prometheus + Grafana: Cluster-wide metrics.

Alerting:

  • Loss NaN: Immediate rollback.
  • GPU Failure: Auto-restart with elastic training.
  • Slow Node: Blacklist and redistribute work.

25. Production Deployment: Cost Optimization

Training GPT-3 cost ~$5M. How do we reduce this?

1. Spot Instances:

  • Use AWS/GCP spot instances (70% cheaper).
  • Risk: Can be preempted.
  • Mitigation: Frequent checkpointing + elastic training.

2. Gradient Accumulation:

  • Simulate large batch size without needing more GPUs.
  • Example: 8 GPUs, batch size 4 per GPU, accumulate 8 steps = effective batch size 256.

3. Selective Precision:

  • Use FP16 for most layers, FP32 for sensitive layers (LayerNorm, Softmax).

4. Data Loading Optimization:

  • Prefetching: Load next batch while GPU is computing.
  • Compression: Store data in compressed format (Parquet, Arrow).
  • Sharding: Shard dataset across nodes to avoid network bottleneck.

27. Deep Dive: Bandwidth Analysis & Bottleneck Detection

Theoretical Peak Performance: For a model with $P$ parameters and batch size $B$:

  • Compute: $2 \times P \times B$ FLOPs per forward pass (matrix multiplications).
  • Memory Bandwidth: $2 \times P$ bytes to load weights (fp16).

Roofline Model:

  • Arithmetic Intensity (AI): FLOPs / Bytes.
  • For Transformers: $AI \approx \frac{2PB}{2P} = B$ (batch size).
  • A100 GPU:
    • Peak Compute: 312 TFLOPS (fp16).
    • Peak Bandwidth: 2 TB/s.
    • Ridge Point: $AI = \frac{312}{2000} = 0.156$ FLOPs/Byte.
  • If $B < 0.156$, we are memory-bound. If $B > 0.156$, we are compute-bound.

Implication:

  • Small batch sizes (B=1, inference) are memory-bound. Need to optimize data loading.
  • Large batch sizes (B=256, training) are compute-bound. Need to optimize kernels (FlashAttention).

28. Deep Dive: Debugging Distributed Training

Common Issues:

1. Hanging (Deadlock):

  • Symptom: Training freezes. No error message.
  • Cause: One GPU is waiting for All-Reduce, but another GPU crashed before reaching it.
  • Debug: Set NCCL_DEBUG=INFO. Check which GPU is stuck.
  • Fix: Add timeouts to collective operations.

2. Loss Divergence:

  • Symptom: Loss becomes NaN after a few steps.
  • Cause: Gradient explosion, bad data, or numerical instability.
  • Debug:
    • Log gradient norms per layer.
    • Check for NaN/Inf in activations.
    • Reduce learning rate.
  • Fix: Gradient clipping, mixed precision with loss scaling.

3. Slow Training:

  • Symptom: Throughput is 50% of expected.
  • Cause: Communication overhead, data loading bottleneck, or stragglers.
  • Debug:
    • Profile with torch.profiler or NVIDIA Nsight.
    • Check GPU utilization (nvidia-smi dmon).
    • Measure communication time vs compute time.
  • Fix:
    • Increase batch size (reduce communication frequency).
    • Use faster interconnect (InfiniBand).
    • Optimize data loading (more workers, prefetching).

29. Advanced Topic: Sequence Parallelism

For very long sequences (e.g., 100K tokens), even the sequence dimension doesn’t fit in memory. Sequence Parallelism (Megatron-LM):

  • Split the sequence across GPUs along the time dimension.
  • Each GPU processes a chunk of the sequence.
  • Challenge: Self-Attention requires the full sequence. Need to gather all chunks for attention, then scatter back.
  • Optimization: Overlap communication with computation (pipeline the gather/scatter).

30. Advanced Topic: Expert Parallelism (MoE)

Mixture of Experts (MoE):

  • Replace the MLP layer with $N$ expert MLPs.
  • A router (gating network) decides which expert(s) to use for each token.
  • Benefit: Increase model capacity without increasing compute (only 1-2 experts are active per token).

Expert Parallelism:

  • Place each expert on a different GPU.
  • Tokens are routed to the appropriate GPU.
  • Challenge: Load imbalance (some experts get more tokens).
  • Solution: Auxiliary loss to encourage balanced routing.

Example: Switch Transformer (Google):

  • 1.6 Trillion parameters.
  • 128 experts per layer.
  • Trained with expert parallelism + data parallelism.

31. Summary & Best Practices

Choosing the Right Parallelism Strategy:

  • Model fits in 1 GPU: Use DDP (Data Parallelism).
  • Model fits in 1 node (8 GPUs): Use Tensor Parallelism (Megatron).
  • Model doesn’t fit in 1 node: Use Pipeline Parallelism + Tensor Parallelism.
  • Model is HUGE (>100B): Use 3D Parallelism (DP + TP + PP) or FSDP/ZeRO-3.

Optimization Checklist:

  1. ✅ Mixed Precision (BF16).
  2. ✅ Gradient Checkpointing.
  3. ✅ FlashAttention.
  4. ✅ Fused Kernels (AdamW, LayerNorm).
  5. ✅ Gradient Accumulation (if batch size is limited).
  6. ✅ Data Loading (prefetch, multiple workers).
  7. ✅ Profiling (find bottlenecks).

32. Common Pitfalls

  • OOM (Out of Memory): Not using gradient checkpointing (activation recomputation) or mixed precision.
  • Communication Overhead: Using Ethernet instead of InfiniBand for large models.
  • Uneven Load Balancing: In Pipeline Parallelism, if layers have different compute costs, some GPUs wait.
  • Batch Norm: Standard Batch Norm only sees the local batch. Need SyncBatchNorm to compute statistics across all GPUs.
  • Random Seed: Forgetting to set different random seeds per worker for data shuffling (all workers see same data).
  • Learning Rate Scaling: When increasing batch size from 256 to 2048, need to scale LR proportionally (Linear Scaling Rule).

33. Real-World Deployment: Kubernetes for ML

Challenges:

  • GPUs are expensive. Need efficient scheduling.
  • Jobs can fail. Need auto-restart.
  • Multi-tenancy. Need isolation.

Kubeflow:

  • Kubernetes-native ML platform.
  • Components:
    • TFJob / PyTorchJob: Operators for distributed training.
    • Katib: Hyperparameter tuning.
    • KFServing: Model serving.

Example PyTorchJob:

apiVersion: kubeflow.org/v1
kind: PyTorchJob
metadata:
  name: gpt-training
spec:
  pytorchReplicaSpecs:
    Master:
      replicas: 1
      template:
        spec:
          containers:
          - name: pytorch
            image: pytorch/pytorch:2.0
            command: ["python", "train.py"]
            resources:
              limits:
                nvidia.com/gpu: 8
    Worker:
      replicas: 15
      template:
        spec:
          containers:
          - name: pytorch
            image: pytorch/pytorch:2.0
            command: ["python", "train.py"]
            resources:
              limits:
                nvidia.com/gpu: 8

34. Conclusion

Distributed training is the backbone of modern AI. From GPT to Stable Diffusion, every large model relies on these techniques. Key Takeaways:

  • Start Simple: Use DDP for models that fit in one GPU.
  • Scale Gradually: Add Tensor/Pipeline Parallelism as needed.
  • Optimize Aggressively: Mixed precision, gradient checkpointing, FlashAttention are non-negotiable.
  • Monitor Everything: Loss, gradients, GPU utilization, communication time.
  • Expect Failures: Checkpointing and elastic training are essential.

The future of AI depends on our ability to train ever-larger models efficiently. Mastering distributed training is no longer optional—it’s a core skill for ML engineers.
