“Finding the perfect knobs to turn.”

1. The Problem: Too Many Knobs

Training a neural network involves many hyperparameters:

  • Learning rate: 0.001? 0.01? 0.0001?
  • Batch size: 32? 64? 128?
  • Number of layers: 3? 5? 10?
  • Dropout rate: 0.1? 0.3? 0.5?
  • Optimizer: Adam? SGD? AdamW?

Challenge: The search space is exponential. For 10 hyperparameters with 5 values each, that’s $5^{10} = 9.7$ million combinations!

2. Search Strategies

  • Idea: Try all combinations.
  • Pros: Exhaustive, guaranteed to find best in grid.
  • Cons: Exponentially expensive.
from sklearn.model_selection import GridSearchCV

param_grid = {
    'learning_rate': [0.001, 0.01, 0.1],
    'batch_size': [32, 64, 128],
    'num_layers': [3, 5, 7]
}

# Total trials: 3 × 3 × 3 = 27
  • Idea: Sample random combinations.
  • Pros: More efficient than grid search.
  • Insight: Most hyperparameters don’t matter much. Random search explores more of the important ones.
from sklearn.model_selection import RandomizedSearchCV

param_distributions = {
    'learning_rate': [0.0001, 0.001, 0.01, 0.1],
    'batch_size': [16, 32, 64, 128, 256]
}

# Try 20 random combinations

3. Bayesian Optimization

  • Idea: Build a probabilistic model of the objective function.
  • Acquisition Function: Decides where to sample next (balance exploration vs. exploitation).
  • Pros: Sample-efficient. Converges faster than random search.

3. Bayesian Optimization Deep Dive

Algorithm:

  1. Surrogate Model: Gaussian Process (GP) models $f(\theta) \approx \text{validation accuracy}$.
  2. Acquisition Function: Expected Improvement (EI) or Upper Confidence Bound (UCB). \(\text{EI}(\theta) = \mathbb{E}[\max(f(\theta) - f(\theta^*), 0)]\) Where $\theta^*$ is the current best.
  3. Optimize Acquisition: Find $\theta$ that maximizes EI.
  4. Evaluate: Train model with $\theta$, observe accuracy.
  5. Update GP: Add new observation, repeat.

Libraries:

  • Optuna: Most popular in ML.
  • Hyperopt: Tree-structured Parzen Estimator (TPE).
  • Ray Tune: Distributed tuning at scale.

4. Optuna Example

import optuna

def objective(trial):
    # Suggest hyperparameters
    lr = trial.suggest_float('lr', 1e-5, 1e-1, log=True)
    batch_size = trial.suggest_categorical('batch_size', [16, 32, 64])
    dropout = trial.suggest_float('dropout', 0.1, 0.5)

    # Train model
    model = build_model(lr, batch_size, dropout)
    val_acc = train_and_evaluate(model)

    return val_acc

study = optuna.create_study(direction='maximize')
study.optimize(objective, n_trials=100)

print(f"Best params: {study.best_params}")
print(f"Best value: {study.best_value}")

5. Advanced: Multi-Fidelity Optimization

Problem: Evaluating each trial is expensive (train for 100 epochs).

Solution: Successive Halving (Hyperband).

  1. Start with many trials, train for 1 epoch.
  2. Keep top 50%, train for 2 epochs.
  3. Keep top 50%, train for 4 epochs.
  4. Repeat until 1 trial remains, train for 100 epochs.

Speedup: 10-100x faster than full evaluation.

6. Ray Tune for Distributed Tuning

from ray import tune

def train_model(config):
    model = build_model(config['lr'], config['batch_size'])
    for epoch in range(10):
        loss = train_epoch(model)
        tune.report(loss=loss)

config = {
    'lr': tune.loguniform(1e-5, 1e-1),
    'batch_size': tune.choice([16, 32, 64])
}

analysis = tune.run(
    train_model,
    config=config,
    num_samples=100,
    resources_per_trial={'gpu': 1}
)

print(f"Best config: {analysis.best_config}")

7. Summary

Method Trials Needed Pros Cons
Grid $O(k^n)$ Exhaustive Exponential
Random $O(100)$ Simple Inefficient
Bayesian $O(50)$ Sample-efficient Complex
Hyperband $O(20)$ Very fast Needs early stopping

8. Deep Dive: Acquisition Functions

Acquisition functions decide where to sample next in Bayesian Optimization.

1. Expected Improvement (EI)

\(\text{EI}(\theta) = \mathbb{E}[\max(f(\theta) - f(\theta^*), 0)]\)

  • Intuition: How much better can we expect this point to be?
  • Pros: Balances exploration (high uncertainty) and exploitation (high mean).

2. Upper Confidence Bound (UCB)

\(\text{UCB}(\theta) = \mu(\theta) + \kappa \sigma(\theta)\)

  • $\mu$: Predicted mean.
  • $\sigma$: Predicted std dev (uncertainty).
  • $\kappa$: Exploration parameter (typically 2-3).
  • Intuition: Optimistic estimate. “This could be really good!”

3. Probability of Improvement (PI)

\(\text{PI}(\theta) = P(f(\theta) > f(\theta^*))\)

  • Intuition: What’s the chance this beats the current best?
  • Cons: Too greedy, doesn’t care how much better.

9. Deep Dive: Hyperband Algorithm

Problem: Training to convergence is expensive. Can we stop bad trials early?

Hyperband (Successive Halving + Adaptive Resource Allocation):

def hyperband(max_iter=81, eta=3):
    # max_iter: max epochs
    # eta: downsampling rate

    s_max = int(np.log(max_iter) / np.log(eta))
    B = (s_max + 1) * max_iter

    for s in reversed(range(s_max + 1)):
        n = int(np.ceil(B / max_iter / (s + 1) * eta**s))
        r = max_iter * eta**(-s)

        # Generate n random configurations
        configs = [random_config() for _ in range(n)]

        for i in range(s + 1):
            n_i = int(n * eta**(-i))
            r_i = int(r * eta**i)

            # Train each config for r_i epochs
            results = [train(c, r_i) for c in configs]

            # Keep top 1/eta
            configs = top_k(configs, results, int(n_i / eta))

    return best_config

Example: max_iter=81, eta=3

  • Round 1: 81 configs, 1 epoch each.
  • Round 2: 27 configs (top 1/3), 3 epochs each.
  • Round 3: 9 configs, 9 epochs each.
  • Round 4: 3 configs, 27 epochs each.
  • Round 5: 1 config, 81 epochs.

10. Deep Dive: Parallel Hyperparameter Tuning

Challenge: Bayesian Optimization is sequential (needs previous results to decide next point).

Solution 1: Batch Bayesian Optimization

  • Use acquisition function to select top-$k$ points.
  • Evaluate them in parallel.
  • Update GP with all $k$ results.

Solution 2: Asynchronous Successive Halving (ASHA)

  • Don’t wait for all trials to finish.
  • As soon as a trial completes an epoch, decide: promote or kill.
# Ray Tune with ASHA
from ray.tune.schedulers import ASHAScheduler

scheduler = ASHAScheduler(
    max_t=100,  # Max epochs
    grace_period=10,  # Min epochs before stopping
    reduction_factor=3
)

tune.run(
    train_model,
    config=config,
    num_samples=100,
    scheduler=scheduler,
    resources_per_trial={'gpu': 1}
)

11. System Design: Hyperparameter Tuning Platform

Scenario: Build a platform for 100 ML engineers to tune models.

Requirements:

  • Scalability: 1000s of concurrent trials.
  • Reproducibility: Track all experiments.
  • Visualization: Compare trials easily.

Architecture:

  1. Scheduler: Ray Tune (distributed).
  2. Tracking: Weights & Biases (W&B) or MLflow.
  3. Storage: S3 for checkpoints.
  4. Compute: Kubernetes cluster with autoscaling.

Code:

import wandb
from ray import tune

def train_with_logging(config):
    wandb.init(project='hyperparameter-tuning', config=config)

    model = build_model(config)
    for epoch in range(100):
        loss = train_epoch(model)
        wandb.log({'loss': loss, 'epoch': epoch})
        tune.report(loss=loss)

tune.run(
    train_with_logging,
    config=search_space,
    num_samples=1000
)

12. Deep Dive: Transfer Learning for Hyperparameters

Idea: If we tuned hyperparameters for Task A, can we use them for Task B?

Meta-Learning Approach:

  1. Collect tuning history from many tasks.
  2. Train a model: $f(\text{task features}) \rightarrow \text{good hyperparameters}$.
  3. For new task, predict good starting point.

Example: Google Vizier uses this internally.

13. Production Considerations

  1. Cost: Each trial costs GPU hours. Set a budget.
  2. Reproducibility: Always set random seeds.
  3. Monitoring: Track resource usage (GPU util, memory).
  4. Checkpointing: Save model every N epochs (for Hyperband).
  5. Early Stopping: Don’t waste time on diverging models.
  • Early Stopping: Don’t waste time on diverging models.

14. Deep Dive: Population-Based Training (PBT)

Origin: DeepMind (2017). Used to train AlphaStar and Waymo agents.

Concept:

  • Combines Random Search (exploration) with Greedy Selection (exploitation).
  • Instead of fixed hyperparameters, PBT evolves them during training.

Algorithm:

  1. Initialize: Start a population of $N$ models with random hyperparameters.
  2. Train: Train all models for $k$ steps.
  3. Eval: Evaluate performance.
  4. Exploit: Replace the bottom 20% of models with copies of the top 20%.
  5. Explore: Perturb the hyperparameters of the copied models (mutation).
    • lr = lr * random.choice([0.8, 1.2])
  6. Repeat: Continue training.

Benefits:

  • Dynamic Schedules: Discovers complex schedules (e.g., “start with high LR, then decay, then spike”).
  • Efficiency: No wasted compute on bad trials (they get killed).
  • Single Run: You get a fully trained model at the end, not just a config.

15. Deep Dive: Neural Architecture Search (NAS)

Hyperparameters aren’t just numbers (LR, Batch Size). They can be the architecture itself.

Search Space:

  • Number of layers.
  • Operation type (Conv3x3, Conv5x5, MaxPool).
  • Skip connections.

Algorithms:

  1. Reinforcement Learning (RL):
    • Controller (RNN) generates an architecture string.
    • Train child network, get accuracy (Reward).
    • Update Controller using Policy Gradient.
    • Cons: Extremely slow (2000 GPU-days for original NAS).
  2. Evolutionary Algorithms (EA):
    • Mutate architectures (add layer, change filter size).
    • Select best, repeat.
    • Example: AmoebaNet.
  3. Differentiable NAS (DARTS):
    • Relax discrete choices into continuous weights (softmax).
    • Train architecture weights $\alpha$ and model weights $w$ simultaneously using gradient descent.
    • Pros: Fast (single GPU-day).

16. Deep Dive: The Math of Gaussian Processes (GP)

Bayesian Optimization relies on GPs. What are they?

Definition: A GP is a distribution over functions, defined by a mean function $m(x)$ and a covariance function (kernel) $k(x, x’)$.

\[f(x) \sim GP(m(x), k(x, x'))\]

Kernels:

  • RBF (Radial Basis Function): Smooth functions. \(k(x, x') = \sigma^2 \exp(-\frac{||x - x'||^2}{2l^2})\)
  • Matern: Rougher functions (better for deep learning landscapes).

Posterior Update: Given observed data $D = {(x_i, y_i)}$, the predictive distribution for a new point $x_*$ is Gaussian: \(P(f_* | D, x_*) = \mathcal{N}(\mu_*, \Sigma_*)\)

\(\mu_* = K_*^T (K + \sigma_n^2 I)^{-1} y\) \(\Sigma_* = K_{**} - K_*^T (K + \sigma_n^2 I)^{-1} K_*\)

  • $\mu_*$: Predicted value (Exploitation).
  • $\Sigma_*$: Uncertainty (Exploration).

17. Deep Dive: Tree-Structured Parzen Estimator (TPE)

Optuna uses TPE by default. It’s faster than GPs for high dimensions.

Idea: Instead of modeling $P(y x)$ (GP), model $P(x y)$ and $P(y)$.
  1. Split Data: Divide observations into two groups:
    • Top 20% (Good): $l(x)$
    • Bottom 80% (Bad): $g(x)$
  2. Density Estimation: Fit Kernel Density Estimators (KDE) to $l(x)$ and $g(x)$.
    • “What do good hyperparameters look like?”
    • “What do bad hyperparameters look like?”
  3. Acquisition: Maximize Expected Improvement, which simplifies to maximizing: \(\frac{l(x)}{g(x)}\)

Intuition: Pick $x$ that is highly likely under the “Good” distribution and unlikely under the “Bad” distribution.

18. Case Study: Tuning BERT for Production

Scenario: Fine-tuning BERT-Large for Sentiment Analysis.

Search Space:

  • Learning Rate: $1e-5, 2e-5, 3e-5, 5e-5$.
  • Batch Size: 16, 32.
  • Epochs: 2, 3, 4.
  • Warmup Steps: 0, 100, 500.

Key Findings (RoBERTa paper):

  • Batch Size: Larger is better (up to a point).
  • Training Duration: Training longer with smaller LR is better than short/high LR.
  • Layer-wise LR Decay: Lower layers (closer to input) capture general features, need smaller LR. Higher layers need larger LR.
    • $\text{LR}{layer} = \text{LR}{base} \times \xi^{L - layer}$ where $\xi = 0.95$.

19. Case Study: AlphaGo Zero Tuning

Problem: Tuning Monte Carlo Tree Search (MCTS) + Neural Network.

Hyperparameters:

  • $c_{puct}$: Exploration constant in MCTS.
  • Dirichlet Noise $\alpha$: Noise added to root node for exploration.
  • Self-play games: How many games before retraining?

Strategy:

  • Self-Play Evaluation: New model plays 400 games against old model.
  • Gating: Only promote if win rate > 55%.
  • Massive Parallelism: Thousands of TPUs generating self-play data.

20. System Design: Scalable Tuning Infrastructure

Components:

  1. Experiment Manager (Katib / Ray Tune):
    • Stores search space config.
    • Generates trials.
  2. Trial Runner (Kubernetes Pods):
    • Pulls Docker image.
    • Runs training code.
    • Reports metrics to Manager.
  3. Database (MySQL / PostgreSQL):
    • Stores trial history (params, metrics).
  4. Dashboard (Vizier / W&B):
    • Visualizes parallel coordinate plots.

Scalability Challenges:

  • Database Bottleneck: 1000 concurrent trials reporting metrics every second.
    • Fix: Buffer metrics in Redis, flush to DB periodically.
  • Pod Startup Latency: K8s takes 30s to start a pod.
    • Fix: Use a pool of warm pods (Ray Actors).

21. Deep Dive: Multi-Objective Optimization

Real World: We don’t just want accuracy. We want:

  1. Maximize Accuracy.
  2. Minimize Latency.
  3. Minimize Model Size.

Pareto Frontier:

  • A set of solutions where you cannot improve one objective without hurting another.
  • Dominated Solution: Worse than another solution in all objectives.
  • Non-Dominated Solution: Better in at least one objective.

Scalarization:

  • Convert to single objective: $L = w_1 \cdot Acc + w_2 \cdot \frac{1}{Lat}$.
  • Problem: Need to tune weights $w$.

NSGA-II (Non-dominated Sorting Genetic Algorithm):

  • Used by Optuna for multi-objective search.
  • Maintains a population of Pareto-optimal solutions.

22. Code: Implementing a Simple Bayesian Optimizer

Let’s build a toy BO from scratch using scikit-learn.

import numpy as np
from sklearn.gaussian_process import GaussianProcessRegressor
from sklearn.gaussian_process.kernels import Matern
from scipy.stats import norm

class SimpleBayesianOptimizer:
    def __init__(self, objective_func, bounds):
        self.objective = objective_func
        self.bounds = bounds
        self.X = []
        self.y = []
        self.gp = GaussianProcessRegressor(kernel=Matern(nu=2.5))

    def expected_improvement(self, X_candidates):
        mu, sigma = self.gp.predict(X_candidates, return_std=True)
        mu_sample_opt = np.max(self.y)

        with np.errstate(divide='warn'):
            imp = mu - mu_sample_opt
            Z = imp / sigma
            ei = imp * norm.cdf(Z) + sigma * norm.pdf(Z)
            ei[sigma == 0.0] = 0.0

        return ei

    def optimize(self, n_iters=10):
        # Initial random samples
        for _ in range(2):
            x = np.random.uniform(self.bounds[0], self.bounds[1], 1).reshape(-1, 1)
            y = self.objective(x)
            self.X.append(x)
            self.y.append(y)

        for i in range(n_iters):
            # Fit GP
            self.gp.fit(np.array(self.X).reshape(-1, 1), np.array(self.y))

            # Find point with max EI
            X_grid = np.linspace(self.bounds[0], self.bounds[1], 100).reshape(-1, 1)
            ei = self.expected_improvement(X_grid)
            next_x = X_grid[np.argmax(ei)]

            # Evaluate
            next_y = self.objective(next_x)
            self.X.append(next_x)
            self.y.append(next_y)

            print(f"Iter {i}: Best y = {np.max(self.y):.4f}")

# Usage
def objective(x): return -1 * (x - 2)**2 + 10  # Max at x=2
opt = SimpleBayesianOptimizer(objective, bounds=(-5, 5))
opt.optimize(n_iters=10)

Goal: Evolve the algorithms themselves, not just parameters.

Method:

  • Represent ML algorithms as a sequence of basic math operations (add, multiply, sin, cos).
  • Use evolutionary algorithms to discover “Gradient Descent” or “Neural Networks” from scratch.
  • Result: Rediscovered backpropagation and linear regression.

Implication: Future ML engineers might tune “Search Space Definitions” rather than models.

24. Summary

ASHA $O(20)$ Parallel Requires Ray

25. Deep Dive: Hyperparameter Importance Analysis

After running 100 trials, you want to know: Which knob actually mattered?

Methods:

  1. fANOVA (Functional Analysis of Variance):
    • Decomposes the variance of the objective function into additive components.
    • “60% of variance comes from Learning Rate, 10% from Batch Size, 5% from interaction between LR and Batch Size.”
    • Tool: optuna.importance.get_param_importances(study).
  2. SHAP (SHapley Additive exPlanations):
    • Treats hyperparameter values as “features” and the objective value as the “prediction”.
    • Calculates the marginal contribution of each hyperparameter.
  3. Parallel Coordinate Plots:
    • Visualizes the high-dimensional relationships.
    • Useful for spotting “bad regions” (e.g., “High LR + Low Batch Size always crashes”).

Actionable Insight:

  • If num_layers has 1% importance, stop tuning it! Fix it to a reasonable default and save compute.

26. Deep Dive: Handling Categorical & Conditional Hyperparameters

Real-world search spaces are messy.

Categorical:

  • optimizer: [“Adam”, “SGD”, “RMSprop”]
  • Problem: GPs assume continuous distance. Distance(“Adam”, “SGD”) is undefined.
  • Solution: One-hot encoding or using Tree-based models (Random Forests, TPE) which handle splits naturally.

Conditional (Nested):

  • IF optimizer == "SGD" THEN tune momentum.
  • IF optimizer == "Adam" THEN tune beta1, beta2.
  • Problem: momentum is irrelevant if optimizer is Adam.
  • Solution:
    • TPE: Handles this naturally by splitting the tree.
    • ConfigSpace: A library specifically for defining DAG-structured search spaces.

27. Deep Dive: Warm-Starting Optimization

Problem: Every time we tune a new model, we start from scratch (random sampling). Reality: We have tuned 50 similar models before.

Strategies:

  1. Initial Points:
    • Instead of random initialization, seed the optimizer with the best configs from previous studies.
    • study.enqueue_trial({'lr': 1e-3, 'batch_size': 32}).
  2. Transfer Learning for GPs:
    • Use data from previous tasks to learn a “prior” for the GP mean function.
    • Multi-Task Bayesian Optimization: Model the correlation between Task A and Task B. If they are correlated, observations in A reduce uncertainty in B.
  3. Meta-Learning (Auto-Sklearn):
    • Compute meta-features of the dataset (num_rows, num_cols, class_balance).
    • Find nearest neighbors in the “dataset space”.
    • Reuse their best hyperparameters.

28. Case Study: Tuning XGBoost vs Neural Networks

XGBoost / LightGBM:

  • Key Params: max_depth, learning_rate, subsample, colsample_bytree, min_child_weight.
  • Landscape: Rugged but convex-ish locally.
  • Strategy: Random Search is often “good enough”. TPE works very well.
  • Cost: Fast to train (seconds/minutes). Can run 1000s of trials.

Neural Networks (ResNet/Transformer):

  • Key Params: lr, batch_size, optimizer, scheduler.
  • Landscape: Non-convex, saddle points, noise.
  • Strategy: Must use Learning Rate Schedules. Tuning the schedule is more important than tuning the fixed LR.
  • Cost: Slow (hours/days). Must use Early Stopping (Hyperband).

29. Ethical Considerations: The Carbon Footprint of Tuning

The Cost:

  • Training a Transformer with NAS can emit 600,000 lbs of CO2 (equivalent to 5 cars’ lifetime).
  • “Red AI” (buying performance with massive compute) vs “Green AI” (efficiency).

Mitigation Strategies:

  1. Green NAS: Penalize energy consumption in the objective function. \(L = \text{Error} + \lambda \cdot \text{Energy}\)
  2. Proxy Tasks: Tune on a subset of data (10%), then transfer to full data.
  3. Share Configs: Publish the best hyperparameters so others don’t have to re-tune. (Hugging Face Model Cards).

30. Further Reading

  1. “Algorithms for Hyper-Parameter Optimization” (Bergstra et al., 2011): Introduced TPE.
  2. “Hyperband: A Novel Bandit-Based Approach to Hyperparameter Optimization” (Li et al., 2018): The standard for resource allocation.
  3. “Google Vizier: A Service for Black-Box Optimization” (Golovin et al., 2017): How Google does it at scale.
  4. “Neural Architecture Search with Reinforcement Learning” (Zoph & Le, 2017): The paper that started the NAS craze.
  5. “On the Importance of On-Manifold Regularization” (Mixup): Data augmentation as a hyperparameter.
  • NAS: $O(1000)$ Finds architecture Very expensive

32. Deep Dive: The Future of Tuning - LLMs as Optimizers

OptiMus (2023):

  • Uses an LLM (GPT-4) to suggest hyperparameters.
  • Prompt: “I am training a ResNet-50. The loss is oscillating. Current LR is 0.1. What should I try next?”
  • Response: “Try reducing LR to 0.01 and adding a scheduler.”
  • Why it works: LLMs have read millions of papers and GitHub issues. They have “common sense” about training dynamics that Bayesian Optimization lacks.

OMNI (OpenAI):

  • Future systems will likely abstract tuning away entirely. You provide data + metric, the system handles the rest.

33. Deep Dive: Tuning for Robustness and Fairness

Robustness (Adversarial Training):

  • Hyperparams: Epsilon (perturbation size), Alpha (step size).
  • Trade-off: Increasing robustness often decreases clean accuracy.
  • Tuning Goal: Find the Pareto frontier between Accuracy and Robustness.

Fairness:

  • Hyperparams: Regularization strength for fairness constraints (e.g., Equalized Odds).
  • Objective: Minimize Error + $\lambda \cdot \text{Disparity}$.
  • Tuning: We need to find the $\lambda$ that satisfies legal/ethical requirements while maximizing utility.

34. Code: Grid Search from Scratch

To understand why Grid Search is bad, let’s implement it.

import itertools

def grid_search(objective, param_grid):
    keys = param_grid.keys()
    values = param_grid.values()
    combinations = list(itertools.product(*values))

    best_score = -float('inf')
    best_params = None

    print(f"Total combinations: {len(combinations)}")

    for combo in combinations:
        params = dict(zip(keys, combo))
        score = objective(params)

        if score > best_score:
            best_score = score
            best_params = params

    return best_params, best_score

# Usage
grid = {
    'lr': [0.1, 0.01, 0.001],
    'batch_size': [32, 64, 128],
    'dropout': [0.1, 0.5]
}
# 3 * 3 * 2 = 18 trials.
# If we add one more parameter with 5 options -> 90 trials.
# Exponential explosion!

35. Production Checklist for Hyperparameter Tuning

Before you launch a tuning job:

  1. Define Metric: Is it Accuracy? F1? AUC? Latency?
  2. Define Budget: How many GPU hours can I afford?
  3. Choose Algorithm:
    • < 10 params: Bayesian Optimization (Optuna).

    • 10 params: Random Search or Hyperband.

    • Neural Net: Hyperband / ASHA.
  4. Set Search Space:
    • Use Log Scale for LR and Regularization.
    • Don’t tune things that don’t matter (e.g., random seed).
  5. Enable Early Stopping: Don’t waste compute.
  6. Log Everything: Use W&B / MLflow.
  7. Verify on Test Set: Evaluate the single best model on the held-out test set.
  • NAS: $O(1000)$ Finds architecture Very expensive

36. Deep Dive: Bayesian Optimization Hyperband (BOHB)

Problem:

  • Bayesian Optimization is great at finding good configs but slow (doesn’t kill bad trials).
  • Hyperband is fast (kills bad trials) but random (doesn’t learn from history).

Solution: BOHB (2018)

  • Combines the best of both.
  • Uses Hyperband to determine how many resources (epochs) to allocate.
  • Uses Bayesian Optimization (TPE) to select the configurations to run at each step.
  • Result: Converges faster than either method alone. SOTA for many problems.

37. Deep Dive: The “No Free Lunch” Theorem in Tuning

Theorem: Averaged over all possible problems, every optimization algorithm performs equally well (same as random search).

Implication:

  • There is no “Best Optimizer” for every problem.
  • TPE might be best for XGBoost.
  • CMA-ES might be best for Reinforcement Learning.
  • Adam might be best for CNNs.
  • Lesson: Try multiple optimizers if you are stuck.

38. Deep Dive: Tuning Generative Models (GANs / Diffusion)

Tuning GANs is notoriously hard.

Challenges:

  • Mode Collapse: Generator produces only one image.
  • Non-Convergence: Discriminator becomes too strong too fast.

Key Hyperparameters:

  • Learning Rate Ratio: Often we set TTUR (Two-Time-Scale Update Rule).
    • $LR_{disc} = 4 \times LR_{gen}$.
  • Beta1: Momentum. Often set to 0.0 or 0.5 (instead of default 0.9).
  • Gradient Penalty: Weight $\lambda$ for WGAN-GP.

Diffusion Models:

  • Noise Schedule: Linear vs Cosine.
  • Timesteps: 1000? 4000?
  • EMA Decay: Exponential Moving Average of weights (crucial for quality).

39. Case Study: Tuning Stable Diffusion

Goal: Fine-tune Stable Diffusion on a specific style (e.g., “Disney Style”).

Method: Dreambooth / LoRA.

Hyperparameters:

  • Learning Rate: Extremely sensitive. $1e-6$ works, $1e-5$ destroys the model.
  • Text Encoder Training: Train it or freeze it? (Training = better likeness, Freezing = better editing).

  • Prior Preservation Loss: Weight of the class images (to prevent forgetting what a “dog” looks like).

  • Prior Preservation Loss: Weight of the class images (to prevent forgetting what a “dog” looks like).

40. The Psychology of Tuning

Why do humans struggle with tuning?

  1. Confirmation Bias: We try 3 things, one works, and we assume it’s the “Golden Config”. We stop searching.
  2. Sunk Cost Fallacy: “I spent 3 days tuning this ResNet. I can’t switch to EfficientNet now.”
  3. Dimensionality Curse: Humans can visualize 2D/3D. We cannot intuit 10D spaces. We miss interactions (e.g., “LR is only bad if Batch Size is small”).

Lesson: Trust the algorithm. Don’t “babysit” the tuner.

41. Checklist for Debugging Tuning Failures

If your tuner isn’t finding good results:

  1. Is the search space too big? Prune irrelevant parameters.
  2. Are the ranges correct? Is LR [1e-5, 1e-1] or [1, 10]? (Common bug).
  3. Is the metric noisy? If running the same config twice gives $\pm 5\%$ accuracy, the tuner is confused. Fix the seed or average over runs.
  4. Is the budget too small? 10 trials is not enough for 10 parameters.
  5. Is the model broken? Does it train with default parameters? If not, fix the code first.

42. Summary

Method Trials Needed Pros Cons
Grid $O(k^n)$ Exhaustive Exponential
Random $O(100)$ Simple Inefficient
Bayesian $O(50)$ Sample-efficient Complex
Hyperband $O(20)$ Very fast Needs early stopping
ASHA $O(20)$ Parallel Requires Ray
PBT $O(20)$ Dynamic schedules Complex setup
NAS $O(1000)$ Finds architecture Very expensive
BOHB $O(30)$ Best of both worlds Complex
LLM $O(10)$ Uses “common sense” New, experimental

43. Further Reading

  1. “Algorithms for Hyper-Parameter Optimization” (Bergstra et al., 2011): The paper that introduced TPE.
  2. “Hyperband: A Novel Bandit-Based Approach to Hyperparameter Optimization” (Li et al., 2018): The standard for resource allocation.
  3. “Google Vizier: A Service for Black-Box Optimization” (Golovin et al., 2017): How Google does it at scale.
  4. “Neural Architecture Search with Reinforcement Learning” (Zoph & Le, 2017): The paper that started the NAS craze.
  5. “Optuna: A Next-generation Hyperparameter Optimization Framework” (Akiba et al., 2019): The define-by-run philosophy.

44. Conclusion

Hyperparameter optimization is no longer a “nice to have”—it is a critical component of the modern ML stack. As models grow larger and compute becomes more expensive, the ability to efficiently navigate the search space becomes a competitive advantage. Whether you are using simple Random Search for a baseline or deploying massive Population-Based Training on a Kubernetes cluster, the principles remain the same: Explore the unknown, Exploit the promising, and Automate everything.

Originally published at: arunbaby.com/ml-system-design/0038-hyperparameter-optimization ```
