“Structuring the world’s information into connected entities and relationships.”

1. What is a Knowledge Graph (KG)?

A Knowledge Graph is a structured representation of facts, consisting of entities (nodes) and relationships (edges).

  • Entities: Real-world objects (e.g., “Barack Obama”, “Hawaii”, “President”).
  • Relationships: Connections between them (e.g., “born_in”, “role”).
  • Fact: (Barack Obama, born_in, Hawaii)

Why use KGs?

  • Search: “Who is the wife of the 44th president?” requires traversing relationships.
  • Recommendations: “Users who liked ‘Inception’ also liked movies directed by ‘Christopher Nolan’”.
  • Q&A Systems: Providing direct answers instead of just blue links.

2. Data Model: RDF vs. Labeled Property Graph

There are two main ways to model KGs:

1. Resource Description Framework (RDF)

  • Standard: W3C standard for semantic web.
  • Structure: Triples (Subject, Predicate, Object).
  • Example:
    • (DaVinci, painted, MonaLisa)
    • (MonaLisa, located_in, Louvre)
  • Query Language: SPARQL.
  • Pros: Great for interoperability, public datasets (DBpedia, Wikidata).
  • Cons: Verbose, hard to attach properties to edges (requires reification).

2. Labeled Property Graph (LPG)

  • Structure: Nodes and edges have internal key-value properties.
  • Example:
    • Node: Person {name: "DaVinci", born: 1452}
    • Edge: PAINTED {year: 1503}
    • Node: Artwork {title: "Mona Lisa"}
  • Query Language: Cypher (Neo4j), Gremlin.
  • Pros: Intuitive, efficient for traversal, flexible schema.
  • Cons: Less standardized than RDF.

Industry Choice: Most tech companies (LinkedIn, Airbnb, Uber) use LPG for internal applications due to performance and flexibility.

3. Knowledge Graph Construction Pipeline

Building a KG from unstructured text (web pages, documents) is a massive NLP challenge.

Step 1: Named Entity Recognition (NER)

Identify entities in text.

  • Input: “Elon Musk founded SpaceX in 2002.”
  • Output: [Elon Musk] (PERSON), [SpaceX] (ORG), [2002] (DATE).
  • Model: BERT-NER, BiLSTM-CRF.

Step 2: Entity Linking (Resolution)

Map the extracted mention to a unique ID in the KG.

  • Challenge: “Michael Jordan” -> Basketball player or ML researcher?
  • Solution: Contextual embeddings. Compare the context of the mention with the description of the candidate entities.

Step 3: Relation Extraction (RE)

Identify the relationship between entities.

  • Input: “Elon Musk” and “SpaceX”.
  • Context: “…founded…”
  • Output: founded_by(SpaceX, Elon Musk).
  • Model: Relation Classification heads on BERT.

Step 4: Knowledge Fusion

Merge facts from multiple sources.

  • Source A: (Obama, born, Hawaii)
  • Source B: (Obama, birth_place, Honolulu)
  • Resolution: “Honolulu” is part of “Hawaii”. Merge or create hierarchy.

4. Storage Architecture

How do we store billions of nodes and trillions of edges?

1. Native Graph Databases (Neo4j, Amazon Neptune)

  • Storage: Index-free adjacency. Each node physically stores pointers to its neighbors.
  • Pros: $O(1)$ traversal per hop. Fast for deep queries.
  • Cons: Hard to shard (graph partitioning is NP-hard).

2. Relational Backends (Facebook TAO, LinkedIn Liquid)

  • Storage: MySQL/PostgreSQL sharded by ID.
  • Schema: (id, type, data) and (id1, type, id2, time).
  • Pros: Extremely scalable, leverages existing DB infra.
  • Cons: Multi-hop queries require multiple DB lookups (higher latency).

3. Distributed Key-Value Stores (Google Knowledge Graph)

  • Storage: BigTable / HBase.
  • Key: Subject ID.
  • Value: List of (Predicate, Object).
  • Pros: Massive write throughput.

5. Knowledge Graph Inference

We don’t just store facts; we infer new facts.

Predict missing edges.

  • Query: (Tom Hanks, acted_in, ?)
  • Task: Rank all movies by probability.

2. Knowledge Graph Embeddings (KGE)

Map entities and relations to vector space.

  • TransE: $h + r \approx t$. The translation of head $h$ by relation $r$ should land near tail $t$.
  • RotatE: Models relations as rotations in complex space (handles symmetry/antisymmetry).
  • DistMult: Uses bilinear product.

3. Graph Neural Networks (GNNs)

  • GraphSAGE / GAT: Aggregate information from neighbors to generate node embeddings.
  • Use Case: Node classification (is this account a bot?), Link prediction (friend recommendation).

6. Real-World Case Studies

Case Study 1: Google Knowledge Graph

  • Scale: 500B+ facts.
  • Use: “Things, not strings.” Powers the info box on the right side of search results.
  • Innovation: Massive scale entity disambiguation using search logs.

Case Study 2: LinkedIn Economic Graph

  • Entities: Members, Companies, Skills, Jobs, Schools.
  • Edges: employed_by, has_skill, alumni_of.
  • Use: “People You May Know”, Job Recommendations, Skill Gap Analysis.
  • Tech: “Liquid” (Graph DB built on top of relational sharding).

Case Study 3: Pinterest Taste Graph

  • Entities: Users, Pins (Images), Boards.
  • Edges: saved_to, clicked_on.
  • Model: PinSage (GNN).
  • Innovation: Random-walk based sampling to train GNNs on billions of nodes.

7. Deep Dive: Graph RAG (Retrieval Augmented Generation)

LLMs hallucinate. KGs provide ground truth.

Architecture:

  1. User Query: “What drugs interact with Aspirin?”
  2. KG Lookup: Query KG for (Aspirin, interacts_with, ?).
  3. Context Retrieval: Get subgraph: (Aspirin, interacts_with, Warfarin), (Aspirin, interacts_with, Ibuprofen).
  4. Prompt Augmentation: “Context: Aspirin interacts with Warfarin and Ibuprofen. Question: What drugs interact with Aspirin?”
  5. LLM Generation: “Aspirin interacts with Warfarin and Ibuprofen…”

Pros: Factual accuracy, explainability (can cite the KG edge).

8. Deep Dive: Scaling Graph Databases

Sharding Problem: Cutting a graph cuts edges. Queries that traverse cuts are slow (network calls).

Solution 1: Hash Partitioning

  • ShardID = hash(NodeID) % N.
  • Pros: Even distribution.
  • Cons: Random cuts. A 3-hop query might hit 4 shards.

Solution 2: METIS (Graph Partitioning)

  • Minimize edge cuts. Keep communities on the same shard.
  • Pros: Faster local traversals.
  • Cons: Hard to maintain as graph changes dynamically.

Solution 3: Replication (Facebook TAO)

  • Cache the entire “social graph” in RAM across thousands of memcache nodes.
  • Read-heavy workload optimization.

9. System Design Interview: Design a KG for Movies

Requirements:

  • Store Movies, Actors, Directors.
  • Query: “Movies directed by Nolan starring DiCaprio”.
  • Scale: 1M movies, 10M people.

Schema:

  • Nodes: Movie, Person.
  • Edges: DIRECTED, ACTED_IN.

Storage:

  • Neo4j (Single instance fits in RAM). 11M nodes is small.
  • If 10B nodes -> JanusGraph on Cassandra.

API:

  • GraphQL is perfect for hierarchical graph queries.
    query {
director(name: "Christopher Nolan") {
  movies {
    title
    actors(name: "Leonardo DiCaprio") {
      name
    }
  }
}
}

10. Top Interview Questions

Q1: How do you handle entity resolution at scale? Answer: Blocking (LSH) to find candidates, then pairwise classification (XGBoost/BERT) to verify.

Q2: TransE vs GNNs? Answer: TransE is shallow (lookup table). GNNs are deep (aggregate features). GNNs generalize to unseen nodes (inductive), TransE is transductive.

Q3: How to update a KG in real-time? Answer: Lambda architecture. Batch pipeline re-builds the high-quality graph nightly. Streaming pipeline adds temporary edges from Kafka events.

11. Summary

Component Technology
Data Model Labeled Property Graph (LPG)
Storage Neo4j, JanusGraph, Amazon Neptune
Query Cypher, Gremlin, GraphQL
Inference GraphSAGE, TransE
Use Cases Search, RecSys, Fraud Detection
Scale Billions of nodes, Trillions of edges

12. Deep Dive: Graph Neural Networks (GNNs)

Traditional embeddings (TransE) are “shallow” — they learn a unique vector for every node. They cannot generalize to new nodes without retraining. GNNs solve this.

GraphSAGE (Graph Sample and Aggregate):

  • Idea: Generate node embeddings by sampling and aggregating features from a node’s local neighborhood.
  • Inductive: Can generate embeddings for unseen nodes if we know their features and neighbors.

Algorithm:

  1. Sample: For each node, sample a fixed number of neighbors (e.g., 10).
  2. Aggregate: Combine neighbor embeddings (Mean, LSTM, or Max Pooling).
  3. Update: Concatenate self-embedding with aggregated neighbor embedding and pass through a Neural Network.
  4. Repeat: Do this for $K$ layers (hops).

Code Snippet (PyTorch Geometric):

import torch
from torch_geometric.nn import SAGEConv

class GraphSAGE(torch.nn.Module):
    def __init__(self, in_channels, hidden_channels, out_channels):
        super().__init__()
        self.conv1 = SAGEConv(in_channels, hidden_channels)
        self.conv2 = SAGEConv(hidden_channels, out_channels)

    def forward(self, x, edge_index):
        # x: Node feature matrix
        # edge_index: Graph connectivity

        x = self.conv1(x, edge_index)
        x = x.relu()
        x = torch.nn.functional.dropout(x, p=0.5, training=self.training)

        x = self.conv2(x, edge_index)
        return x

Graph Attention Networks (GAT):

  • Idea: Not all neighbors are equal. Learn attention weights to prioritize important neighbors.
  • Mechanism: Compute attention coefficient $\alpha_{ij}$ for edge $i \to j$.
  • Benefit: Better performance on noisy graphs.

13. Deep Dive: Knowledge Graph Embeddings (KGE) Math

Let’s look at the math behind TransE and RotatE.

TransE (Translating Embeddings):

  • Score Function: $f(h, r, t) = -   h + r - t   $
  • Objective: Minimize margin-based ranking loss. \(L = \sum_{(h,r,t) \in S} \sum_{(h',r,t') \in S'} [\gamma + f(h, r, t) - f(h', r, t')]_+\)
  • Limitation: Cannot model 1-to-N relations (e.g., Teacher -> Student). If $h+r \approx t_1$ and $h+r \approx t_2$, then $t_1 \approx t_2$, forcing all students to be identical.

RotatE (Rotation Embeddings):

  • Idea: Map entities to the complex plane $\mathbb{C}$.
  • Relation: Rotation in complex space. $t = h \circ r$, where $ r_i = 1$.
  • Capability: Can model:
    • Symmetry: $r \circ r = 1$ (e.g., spouse).
    • Antisymmetry: $r \circ r \neq 1$ (e.g., parent).
    • Inversion: $r_2 = r_1^{-1}$ (e.g., hypernym vs hyponym).

14. Deep Dive: Entity Linking at Scale

How do you link “MJ” to “Michael Jordan” (Basketball) vs “Michael Jackson” (Singer) when you have 100M entities?

Two-Stage Pipeline:

Stage 1: Blocking / Candidate Generation (Recall)

  • Goal: Retrieve top-K (e.g., 100) candidates quickly.
  • Technique:
    • Inverted Index: Map surface forms (“MJ”, “Mike”) to Entity IDs.
    • Dense Retrieval: Encode mention context and entity description into vectors. Use FAISS to find nearest neighbors.

Stage 2: Re-Ranking (Precision)

  • Goal: Select the best match from candidates.
  • Model: Cross-Encoder (BERT).
    • Input: [CLS] Mention Context [SEP] Entity Description [SEP]
    • Output: Probability of match.
  • Features:
    • String Similarity: Edit distance.
    • Prior Probability: $P(Entity)$. “Michael Jordan” usually means the basketball player.
    • Coherence: Does this entity fit with other entities in the document? (e.g., “Chicago Bulls” is nearby).

15. Deep Dive: Graph RAG Implementation

Retrieval Augmented Generation with Graphs is powerful for multi-hop reasoning.

Scenario: “Who is the CEO of the company that acquired GitHub?”

Vector RAG Failure:

  • Vector search might find docs about “GitHub acquisition” and “Microsoft CEO”.
  • But it might miss the connection if they are in separate documents.

Graph RAG Success:

  1. Entity Linking: Extract “GitHub”. Link to GitHub (Company).
  2. Graph Traversal (1-hop): GitHub -[ACQUIRED_BY]-> Microsoft.
  3. Graph Traversal (2-hop): Microsoft -[CEO_IS]-> Satya Nadella.
  4. Context Construction: “GitHub was acquired by Microsoft. Microsoft’s CEO is Satya Nadella.”
  5. LLM Answer: “Satya Nadella.”

Implementation Steps:

  1. Ingest: Parse documents into triples (Subject, Predicate, Object).
  2. Index: Store triples in Neo4j.
  3. Query:
    • Use LLM to generate Cypher query.
    • MATCH (c:Company {name: "GitHub"})-[:ACQUIRED_BY]->(parent)-[:CEO]->(ceo) RETURN ceo.name
  4. Generate: Pass result to LLM for natural language response.

16. Deep Dive: Temporal Knowledge Graphs

Facts change over time.

  • (Obama, role, President) is true only for [2009, 2017].

Modeling Time:

  1. Reification: Turn the edge into a node.
    • (Obama) -> [Term] -> (President)
    • [Term] has property start: 2009, end: 2017.
  2. Quadruples: Store (Subject, Predicate, Object, Timestamp).
  3. Temporal Embeddings: $f(h, r, t, \tau)$. The embedding evolves over time.

17. Deep Dive: Quality Assurance in KGs

Garbage In, Garbage Out. How to ensure KG quality?

1. Schema Constraints (SHACL):

  • Define rules: Person can only marry another Person.
  • BirthDate must be a valid date.

2. Consistency Checking:

  • Logic rules: born_in(X, Y) AND located_in(Y, Z) -> born_in(X, Z).
  • If KG says born_in(Obama, Kenya) but also born_in(Obama, Hawaii) and Hawaii != Kenya, flag contradiction.

3. Human-in-the-Loop:

  • High-confidence facts -> Auto-merge.
  • Low-confidence facts -> Send to human annotators (crowdsourcing).

18. Deep Dive: Federated Knowledge Graphs

Enterprises often have data silos.

  • HR Graph: Employees, Roles.
  • Sales Graph: Customers, Deals.
  • Product Graph: SKUs, Specs.

Challenge: Query across silos. “Which sales rep sold Product X to Customer Y?”

Solution: Data Fabric / Virtual Graph

  • Leave data where it is (SQL, NoSQL, APIs).
  • Create a Virtual Semantic Layer on top.
  • Map local schemas to a global ontology.
  • Query Federation engine (e.g., Starogard) decomposes SPARQL/GraphQL query into sub-queries for each backend.

19. System Design: Real-Time Fraud Detection with KG

Problem: Detect credit card fraud. Insight: Fraudsters often share attributes (same phone, same IP, same device) forming “rings”.

Design:

  1. Ingestion: Kafka stream of transactions.
  2. Graph Update: Add node Transaction. Link to User, Device, IP.
  3. Feature Extraction (Real-time):
    • Count connected components size.
    • Cycle detection (User A -> Card B -> User C -> Card A).
    • PageRank (guilt by association).
  4. Inference: Pass graph features to XGBoost model.
  5. Latency: < 200ms.
    • Use in-memory graph (RedisGraph or Neo4j Causal Cluster).

20. Advanced: Neuro-Symbolic AI

Combining the learning capability of Neural Networks with the reasoning of Symbolic Logic (KGs).

Concept:

  • Neural: Good at perception (images, text).
  • Symbolic: Good at reasoning, math, consistency.

Application:

  • Visual Question Answering (VQA):
    • Image: “A red cube on a blue cylinder.”
    • Neural: Detect objects (Cube, Cylinder) and attributes (Red, Blue).
    • Symbolic: Build scene graph. Query on(Cube, Cylinder).

21. Summary

Component Technology
Data Model Labeled Property Graph (LPG)
Storage Neo4j, JanusGraph, Amazon Neptune
Query Cypher, Gremlin, GraphQL
Inference GraphSAGE, TransE
Use Cases Search, RecSys, Fraud Detection
Scale Billions of nodes, Trillions of edges

22. Deep Dive: Graph Databases vs. Relational Databases

When should you use a Graph DB over Postgres?

Relational (SQL):

  • Data Model: Tables, Rows, Foreign Keys.
  • Join: Computed at query time. $O(N \log N)$ or $O(N^2)$.
  • Use Case: Structured data, transactions, aggregations.
  • Query: “Find all users who bought item X.” (1 Join).

Graph (Neo4j):

  • Data Model: Nodes, Edges.
  • Join: Pre-computed (edges are pointers). $O(1)$ per hop.
  • Use Case: Highly connected data, pathfinding.
  • Query: “Find all users who bought item X, and their friends who bought item Y.” (Multi-hop).

Benchmark: For a 5-hop query on a social network:

  • SQL: 10+ seconds (5 joins).
  • Graph: < 100ms (pointer traversal).

23. Deep Dive: Ontology Design

An Ontology is the schema of your Knowledge Graph.

Components:

  1. Classes: Person, Company, City.
  2. Properties: name (string), age (int).
  3. Relationships: WORKS_AT (Person -> Company).
  4. Inheritance: Employee is a subclass of Person.

Design Patterns:

  • Reification: Don’t just link Actor -> Movie. Link Actor -> Role -> Movie to store “character name”.
  • Hierarchy: Use subClassOf sparingly. Too deep hierarchies make inference slow.

Example (OWL/Turtle):

:Person a owl:Class .
:Employee a owl:Class ;
    rdfs:subClassOf :Person .
:worksAt a owl:ObjectProperty ;
    rdfs:domain :Employee ;
    rdfs:range :Company .

24. Deep Dive: Reasoning Engines

Reasoning allows inferring implicit facts.

Types of Reasoning:

  1. RDFS Reasoning:
    • Rule: Employee subClassOf Person.
    • Fact: John is Employee.
    • Inference: John is Person.
  2. Transitive Reasoning:
    • Rule: partOf is transitive.
    • Fact: Finger partOf Hand, Hand partOf Arm.
    • Inference: Finger partOf Arm.
  3. Inverse Reasoning:
    • Rule: parentOf inverseOf childOf.
    • Fact: A parentOf B.
    • Inference: B childOf A.

Tools:

  • Jena Inference Engine (Java).
  • GraphDB (Ontotext).

25. Deep Dive: Graph Visualization Tools

Visualizing 1B nodes is impossible. We need tools to explore subgraphs.

Tools:

  1. Gephi: Desktop tool. Good for static analysis of medium graphs (100k nodes).
  2. Cytoscape: Bio-informatics focus. Good for protein interaction networks.
  3. Neo4j Bloom: Interactive exploration. “Show me the shortest path between X and Y.”
  4. KeyLines / ReGraph: JavaScript libraries for building web-based graph visualizers.

Visualization Techniques:

  • Force-Directed Layout: Simulates physics (nodes repel, edges attract).
  • Community Detection coloring: Color nodes by Louvain community.
  • Ego-Network: Only show node X and its immediate neighbors.

26. Code: Loading Data into Neo4j

How to ingest data programmatically.

from neo4j import GraphDatabase

class KnowledgeGraphLoader:
    def __init__(self, uri, user, password):
        self.driver = GraphDatabase.driver(uri, auth=(user, password))

    def close(self):
        self.driver.close()

    def add_person(self, name, age):
        with self.driver.session() as session:
            session.run(
                "MERGE (p:Person {name: $name}) SET p.age = $age",
                name=name, age=age
            )

    def add_friendship(self, name1, name2):
        with self.driver.session() as session:
            session.run(
                """
                MATCH (a:Person {name: $name1})
                MATCH (b:Person {name: $name2})
                MERGE (a)-[:FRIEND]->(b)
                """,
                name1=name1, name2=name2
            )

# Usage
loader = KnowledgeGraphLoader("bolt://localhost:7687", "neo4j", "password")
loader.add_person("Alice", 30)
loader.add_person("Bob", 32)
loader.add_friendship("Alice", "Bob")
loader.close()

27. Summary

Component Technology
Data Model Labeled Property Graph (LPG)
Storage Neo4j, JanusGraph, Amazon Neptune
Query Cypher, Gremlin, GraphQL
Inference GraphSAGE, TransE
Use Cases Search, RecSys, Fraud Detection
Scale Billions of nodes, Trillions of edges

28. Deep Dive: Graph Partitioning Algorithms

To scale to billions of nodes, we must shard the graph.

Problem: Minimizing “edge cuts” (edges that span across shards) to reduce network latency.

Algorithm 1: METIS (Multilevel Graph Partitioning)

  • Phase 1 (Coarsening): Collapse adjacent nodes into super-nodes to create a smaller graph.
  • Phase 2 (Partitioning): Partition the coarse graph.
  • Phase 3 (Uncoarsening): Project the partition back to the original graph and refine.
  • Pros: High quality partitions.
  • Cons: Slow, requires global graph view (offline).

Algorithm 2: Fennel (Streaming Partitioning)

  • Assign nodes to shards as they arrive in a stream.
  • Heuristic: Place node $v$ in shard $i$ that maximizes: \(Score(v, i) = |N(v) \cap S_i| - \alpha (|S_i|)^{\gamma}\)
    • Term 1: Attraction (place where neighbors are).
    • Term 2: Repulsion (load balancing).
  • Pros: Fast, scalable, works for dynamic graphs.

29. Deep Dive: Graph Query Optimization

Just like SQL optimizers, Graph DBs need to plan queries.

Query: MATCH (p:Person)-[:LIVES_IN]->(c:City {name: 'London'})-[:HAS_RESTAURANT]->(r:Restaurant)

Execution Plans:

  1. Scan Person: Find all people, check if they live in London… (Bad, 1B people).
  2. Index Scan City: Find ‘London’ (1 node). Traverse out to Person (8M nodes). Traverse out to Restaurant (20k nodes).
  3. Bi-directional: Start at ‘London’, traverse both ways.

Cost-Based Optimizer:

  • Uses statistics (node counts, degree distribution).
  • “City” has cardinality 10,000. “Person” has 1B.
  • Start with the most selective filter (name='London').

30. Deep Dive: Graph Analytics Algorithms

Beyond simple queries, we run global algorithms.

1. PageRank:

  • Measure node importance.
  • Use Case: Search ranking, finding influential Twitter users.
  • Update Rule: $PR(u) = (1-d) + d \sum_{v \in N_{in}(u)} \frac{PR(v)}{OutDegree(v)}$.

2. Louvain Modularity (Community Detection):

  • Detect clusters of densely connected nodes.
  • Use Case: Fraud rings, topic detection.

3. Betweenness Centrality:

  • Number of shortest paths passing through a node.
  • Use Case: Identifying bottlenecks in a supply chain or network router.

31. Deep Dive: Hardware Acceleration for Graphs

CPUs are bad at graph processing (random memory access = cache misses).

Graphcore IPU (Intelligence Processing Unit):

  • Architecture: Massive MIMD (Multiple Instruction, Multiple Data).
  • Memory: In-processor memory (SRAM) instead of HBM.
  • Benefit: 10x-100x speedup for GNN training and random walks.

Cerebras Wafer-Scale Engine:

  • A single chip the size of a wafer.
  • Holds the entire graph in SRAM.

  • Zero latency communication between cores.

  • Zero latency communication between cores.

32. Deep Dive: Semantic Web vs. Knowledge Graphs

History:

  • Semantic Web (2001): Tim Berners-Lee’s vision. A web of data readable by machines.
  • Standards: RDF, OWL, SPARQL.
  • Failure: Too complex, academic, and rigid. “Ontology engineering” was too hard.

Knowledge Graphs (2012):

  • Google’s Rebranding: “Things, not strings.”
  • Pragmatism: Focus on utility (Search, RecSys) rather than strict logical correctness.
  • Shift: From “Reasoning” to “Embedding”. From “XML” to “JSON/LPG”.

Key Difference:

  • Semantic Web: Open world assumption. If it’s not in the DB, it might still be true.
  • Enterprise KG: Closed world assumption. If it’s not in the DB, it’s false (usually).

33. Deep Dive: Hyper-Relational Knowledge Graphs

Standard KGs are triples: (Obama, President, USA). But reality is complex: (Obama, President, USA, Start:2009, End:2017, Source:Wikipedia).

Modeling Qualifiers:

  1. Star-Schema (LPG): Add properties to the edge.
  2. N-ary Relations (RDF): Create an intermediate node.
    • (Obama) -> [Presidency] -> (USA)
    • [Presidency] -> (Start: 2009)

StarE (Hyper-Relational Embedding):

  • Extends TransE/RotatE to handle qualifiers.
  • Embedding depends on $(h, r, t)$ AND $(key_1, value_1), (key_2, value_2)$.
  • Benefit: Better link prediction accuracy by using context.

34. Deep Dive: Inductive vs. Transductive Learning

Transductive (TransE, RotatE):

  • Learn an embedding for every node in the training set.
  • Problem: If a new user joins, we have no embedding. We must retrain the whole model.

Inductive (GraphSAGE, GAT):

  • Learn a function to generate embeddings from features.
  • $f(features, neighbors)$.
  • Benefit: Can handle dynamic graphs (new nodes arriving constantly) without retraining.

35. Case Study: Amazon Product Graph

Scale: Billions of products, users, reviews.

Entities: Product, Brand, Category, User. Edges: bought_together, viewed_together, is_compatible_with (Lens -> Camera).

Application: “Complementary Product Recommendation”

  • If user buys “Canon EOS R5”, recommend “RF 24-70mm Lens”.
  • Challenge: Compatibility is strict. A Nikon lens won’t fit.
  • Solution: KG explicitly models compatible_mount relationships. LLMs/Embeddings might guess “Lens fits Camera” generally, but KG ensures exact fit.

KG + LLM Convergence:

  1. KG-Enhanced LLM: RAG (Retrieval Augmented Generation).
  2. LLM-Enhanced KG: Use LLM to clean, populate, and reason over KG.
  3. LKM (Large Knowledge Model): A single transformer trained on both Text (Common Crawl) and Subgraphs (Wikidata).
    • Can output text OR graph structures.
    • “Draw the family tree of the Targaryens” -> Outputs JSON graph.
  • “Draw the family tree of the Targaryens” -> Outputs JSON graph.

37. Ethical Considerations in Knowledge Graphs

1. Bias in Entity Representation:

  • KGs built from Wikipedia over-represent Western entities.
  • Example: “Scientist” nodes are 90% male, 80% Western.
  • Impact: Recommendation systems amplify this bias.
  • Fix: Actively source diverse data (non-English Wikipedia, local databases).

2. Privacy:

  • KGs can link disparate data sources to de-anonymize individuals.
  • Example: (User123, lives_in, ZIP_12345) + (User123, age, 34) + (User123, disease, Rare_Condition) → Uniquely identifies a person.
  • Mitigation: Differential Privacy on graph queries. Add noise to aggregate statistics.

3. Misinformation:

  • Automated KG construction from web data ingests false facts.
  • Example: Conspiracy theories (“Vaccine causes autism”) might appear as edges if they’re widely discussed online.
  • Fix: Source credibility scoring. Prioritize facts from .gov, .edu, peer-reviewed sources.

38. Further Reading

  1. “Knowledge Graphs” (Hogan et al., 2021): Comprehensive survey covering all aspects.
  2. “Translating Embeddings for Modeling Multi-relational Data” (Bordes et al., 2013): The TransE paper.
  3. “Inductive Representation Learning on Large Graphs” (Hamilton et al., 2017): The GraphSAGE paper.
  4. “Google’s Knowledge Graph: Serving Billions of Queries” (Singhal, 2012): The original blog post.
  5. “PinSage: Graph Convolutional Neural Networks for Web-Scale Recommender Systems” (Ying et al., 2018): Pinterest’s production GNN.
  • “PinSage: Graph Convolutional Neural Networks for Web-Scale Recommender Systems” (Ying et al., 2018): Pinterest’s production GNN.

39. Conclusion

Knowledge Graphs represent a fundamental shift from “documents” to “facts.” They power the world’s most sophisticated AI systems—from Google Search to LinkedIn’s Economic Graph to fraud detection at banks. The convergence of symbolic reasoning (graphs) and neural learning (embeddings, GNNs) is creating a new generation of Neuro-Symbolic AI that combines the best of both worlds: the interpretability and structure of graphs with the learning power of deep learning. As we move toward Large Knowledge Models (LKMs), the boundary between “structured data” and “unstructured text” will blur, enabling AI systems that can reason, learn, and explain.

40. Summary

Component Technology
Data Model Labeled Property Graph (LPG)
Storage Neo4j, JanusGraph, Amazon Neptune
Query Cypher, Gremlin, GraphQL
Inference GraphSAGE, TransE
Use Cases Search, RecSys, Fraud Detection
Scale Billions of nodes, Trillions of edges
Future Graph RAG, Neuro-Symbolic AI

Originally published at: arunbaby.com/ml-system-design/0034-knowledge-graph-systems
