Semantic Search Systems

“Moving beyond keywords to understand the meaning of a query.”

1. The Problem: Keyword Search is Not Enough

Traditional search engines (like Lucene/Elasticsearch) rely on Lexical Search (BM25/TF-IDF). They match exact words or their stems.

Failure Case:

• Query: “How to fix a flat tire”
• Document: “Guide to repairing a punctured wheel”
• Result: No match! (No shared words: fix/repair, flat/punctured, tire/wheel).

Semantic Search solves this by mapping queries and documents to a vector space where similar meanings are close together. It captures:

• Synonyms: “car” ≈ “automobile”
• Polysemy: “bank” (river) vs “bank” (money)
• Context: “Apple” (fruit) vs “Apple” (company)

2. Dense Retrieval (Bi-Encoders)

Core Idea: Use a Deep Learning model (Transformer) to convert text into a fixed-size vector (embedding).

Architecture:

Query "fix flat tire" → [BERT] → Vector Q (768-dim)
                                      ↓
                                   Similarity (Dot Product)
                                      ↑
Doc "repair wheel"    → [BERT] → Vector D (768-dim)

Bi-Encoder (Siamese Network):

• Two identical BERT models (sharing weights).
• Process Query and Document independently.
• Fast Retrieval: Pre-compute all document vectors. At query time, only encode the query.

from sentence_transformers import SentenceTransformer

model = SentenceTransformer('all-MiniLM-L6-v2')

# 1. Indexing (Offline)
docs = ["Guide to repairing a punctured wheel", "Best pizza in NY"]
doc_embeddings = model.encode(docs)  # [2, 384]

# 2. Search (Online)
query = "How to fix a flat tire"
query_embedding = model.encode(query)  # [1, 384]

# 3. Similarity
import numpy as np
scores = np.dot(doc_embeddings, query_embedding)
# scores[0] will be high, scores[1] low

3. Vector Databases & ANN Search

Problem: Calculating dot product against 1 Billion vectors is too slow ($O(N)$).

• 1B vectors $\times$ 768 dims $\times$ 4 bytes $\approx$ 3 TB RAM.
• Brute force scan takes seconds/minutes.

Solution: Approximate Nearest Neighbor (ANN) Search.

• Trade-off: slightly lower recall (99% instead of 100%) for massive speedup ($O(\log N)$).

HNSW (Hierarchical Navigable Small World)

Mechanism:

• Builds a multi-layer graph (skip list structure).
• Layer 0: All nodes (vectors). High connectivity.
• Layer 1: Subset of nodes.
• Layer N: Very few nodes (entry points).
• Search: Start at top layer, greedily move to the neighbor closest to the query. When local minimum reached, drop to lower layer.

Pros:

• Extremely fast (sub-millisecond).
• High recall.
• Supports incremental updates (unlike IVF).

Cons:

• High memory usage (stores graph edges).

Faiss (Facebook AI Similarity Search)

IVF (Inverted File):

• Cluster vectors into $K$ Voronoi cells (centroids).
• Assign each vector to the nearest centroid.
• Search: Find the closest centroid to the query, then scan only vectors in that cell (and neighbors).

PQ (Product Quantization):

• Compress vectors to save RAM.
• Split 768-dim vector into 8 sub-vectors of 96 dims.
• Quantize each sub-vector to 1 byte (256 centroids).
• Result: 768 floats (3 KB) $\to$ 8 bytes. 300x compression!

import faiss

d = 384  # Dimension
nlist = 100  # Number of clusters (Voronoi cells)
quantizer = faiss.IndexFlatL2(d)
index = faiss.IndexIVFFlat(quantizer, d, nlist)

# Train (find centroids)
index.train(doc_embeddings)

# Add vectors
index.add(doc_embeddings)

# Search
D, I = index.search(query_embedding, k=5)  # Return top 5

4. Cross-Encoders (Re-Ranking)

Problem: Bi-Encoders compress a whole document into one vector. Information is lost (“bottleneck”). Solution: Cross-Encoders process Query and Document together.

[CLS] Query [SEP] Document [SEP] → [BERT] → [Linear] → Score

Mechanism:

• The self-attention mechanism attends to every word in the query against every word in the document.
• Captures subtle interactions (negation, exact phrasing).

Pros:

• Much higher accuracy/NDCG.

Cons:

• Slow: Must run BERT for every (Query, Doc) pair. Cannot pre-compute.
• $O(N)$ inference at query time.

Production Pattern: Retrieve & Re-Rank

1. Retriever (Bi-Encoder/BM25): Get top 100 candidates (Fast, High Recall).
2. Re-Ranker (Cross-Encoder): Score top 100 candidates (Accurate, High Precision).
3. Return: Top 10.

from sentence_transformers import CrossEncoder

cross_encoder = CrossEncoder('cross-encoder/ms-marco-MiniLM-L-6-v2')

# Re-rank candidates
candidates = [("How to fix a flat tire", "Guide to repairing a punctured wheel"), ...]
scores = cross_encoder.predict(candidates)

5. Hybrid Search (Best of Both Worlds)

Problem:

• Semantic Search Fails: Exact matches (Part Number “XJ-900”, Error Code “0x4F”), Out-of-Vocabulary words.
• Keyword Search Fails: Synonyms, typos, conceptual queries.

Solution: Hybrid Search Combine Dense Vector Score + Sparse Keyword Score (BM25).

Linear Combination: \[ \text{Score} = \alpha \cdot \text{VectorScore} + (1 - \alpha) \cdot \text{BM25Score} \] Challenge: Vector scores (cosine: 0-1) and BM25 scores (0-infinity) are hard to normalize.

Reciprocal Rank Fusion (RRF): Instead of scores, use rank positions. Robust and parameter-free. \[ \text{RRF}(d) = \sum_{r \in \text{Rankers}} \frac{1}{k + \text{rank}_r(d)} \] where $k$ is a constant (usually 60).

Example:

• Doc A: Rank 1 in Vector, Rank 10 in BM25. Score = $1/61 + 1/70$.
• Doc B: Rank 5 in Vector, Rank 5 in BM25. Score = $1/65 + 1/65$.

6. Deep Dive: Training Embedding Models

How do we train a model to put “car” and “auto” close together?

Contrastive Loss (InfoNCE):

• Input: A batch of $(Query, PositiveDoc)$ pairs.
• Goal: Maximize similarity of positive pairs, minimize similarity with all other docs in the batch (In-batch Negatives).

\[ \mathcal{L} = -\log \frac{e^{\text{sim}(q, p) / \tau}}{\sum_{n \in \text{Batch}} e^{\text{sim}(q, n) / \tau}} \]

Hard Negative Mining:

• Random negatives (easy) aren’t enough. The model needs to distinguish “Python programming” from “Python snake”.
• Strategy: Use BM25 to find top docs for a query. If a top doc is NOT the ground truth, it’s a Hard Negative.
• Training on hard negatives boosts performance significantly.

Matryoshka Representation Learning (MRL):

• Train embeddings such that the first $k$ dimensions alone are good.
• Loss = $\sum_{k \in {64, 128, 256, 768}} \text{Loss}_k$.
• Benefit: Use 64 dims for fast initial filter (12x faster), 768 dims for re-ranking.

7. Deep Dive: Handling Long Documents

BERT has a 512-token limit. Real-world docs are longer.

Strategies:

1. Truncation: Just take the first 512 tokens. (Works surprisingly well as titles/abstracts contain most info).
2. Chunking: Split doc into 200-word chunks with 50-word overlap.
   • Index each chunk as a separate vector.
   • Retrieval: Return the parent document of the matching chunk.
3. Pooling:
   • Max-Pooling: Doc score = Max(Chunk scores). Good for finding specific passages.
   • Mean-Pooling: Doc score = Average(Chunk scores). Good for overall topic match.

8. Deep Dive: Multilingual Semantic Search

Problem: Query in English, Document in French.

Solution: Multilingual Models (e.g., LaBSE, mE5).

• Trained on parallel corpora (Translation pairs).
• Align vector spaces across 100+ languages.
• “Cat” (En) and “Chat” (Fr) map to the same vector point.

Use Case: Global e-commerce search (User searches “zapatos”, finds “shoes”).

9. Deep Dive: Domain Adaptation (GPL)

Problem: Pre-trained models (on MS MARCO) fail on specialized domains (Medical, Legal). Solution: Generative Pseudo Labeling (GPL).

1. Generate Queries: Use T5 to generate synthetic queries for your domain documents.
2. Mine Negatives: Use BM25 to find hard negatives for these queries.
3. Label: Use a Cross-Encoder to score (Query, Doc) pairs (Teacher).
4. Train: Train the Bi-Encoder (Student) to mimic the Cross-Encoder scores.

Result: Adapts to your domain without human labels!

10. Deep Dive: Evaluation Metrics Implementation

How do we measure success?

NDCG (Normalized Discounted Cumulative Gain): Measures the quality of ranking. Highly relevant items should be at the top.

import numpy as np

def dcg_at_k(r, k):
    r = np.asfarray(r)[:k]
    if r.size:
        return np.sum(r / np.log2(np.arange(2, r.size + 2)))
    return 0.

def ndcg_at_k(r, k):
    dcg_max = dcg_at_k(sorted(r, reverse=True), k)
    if not dcg_max:
        return 0.
    return dcg_at_k(r, k) / dcg_max

# Example: Relevance scores of retrieved items
# 3 = Highly Relevant, 2 = Relevant, 1 = Somewhat, 0 = Irrelevant
relevance = [3, 2, 3, 0, 1, 2]
print(f"NDCG@5: {ndcg_at_k(relevance, 5)}")

MRR (Mean Reciprocal Rank): Focuses on the first relevant item. \[ \text{MRR} = \frac{1}{|Q|} \sum_{i=1}^{|Q|} \frac{1}{\text{rank}_i} \] If the first relevant item is at rank 1, MRR=1. If at rank 2, MRR=0.5.

11. Deep Dive: Production Architecture for 100M QPS

Scaling Semantic Search is hard because ANN search is CPU/RAM intensive.

Architecture:

1. Query Service: Stateless API. Encodes query using ONNX Runtime (faster than PyTorch).
2. Caching Layer: Redis/Memcached. Caches (Query Vector -> Result IDs).
   • Semantic Caching: If query B is very close to query A (cosine > 0.99), return cached result of A.
3. Sharding:
   • Horizontal Sharding: Split 1B vectors into 10 shards of 100M.
   • Query all 10 shards in parallel (Scatter-Gather).
   • Merge results.
4. Replication: Replicate each shard 3x for high availability and throughput.
5. Quantization: Use int8 quantization for the embedding model to speed up inference.

Implementation: End-to-End Semantic Search API

from fastapi import FastAPI
from sentence_transformers import SentenceTransformer
import faiss
import numpy as np

app = FastAPI()

# Load Model
# 'all-MiniLM-L6-v2' is a small, fast model good for English
model = SentenceTransformer('all-MiniLM-L6-v2')

# Mock Database
documents = [
    {"id": 1, "text": "The quick brown fox jumps over the lazy dog."},
    {"id": 2, "text": "A fast auburn canine leaps over a sleepy hound."},
    {"id": 3, "text": "Python is a programming language."},
    {"id": 4, "text": "Pythons are large constricting snakes."},
]

# Build Index
# Normalize embeddings for Cosine Similarity (Dot Product on normalized vectors)
embeddings = model.encode([d['text'] for d in documents])
faiss.normalize_L2(embeddings)

# IndexFlatIP = Exact Inner Product search
index = faiss.IndexFlatIP(384)
index.add(embeddings)

@app.get("/search")
def search(q: str, k: int = 2):
    # Encode Query
    q_emb = model.encode([q])
    q_emb = q_emb.reshape(1, -1)
    faiss.normalize_L2(q_emb)

    # Search
    scores, indices = index.search(q_emb, k)

    results = []
    for score, idx in zip(scores[0], indices[0]):
        if idx == -1: continue
        results.append({
            "id": documents[idx]["id"],
            "text": documents[idx]["text"],
            "score": float(score)
        })

    return results

# Example Usage:
# /search?q=coding -> Returns "Python is a programming language"
# /search?q=reptile -> Returns "Pythons are large constricting snakes"

Top Interview Questions

Q1: How do you handle updates (insert/delete) in a Vector DB? Answer: HNSW graphs are hard to update dynamically.

• Real-time: Use a mutable index (like in Milvus/Pinecone) which uses a buffer for new inserts (LSM-tree style). Periodically merge/rebuild the main index.
• Deletes: Mark as “deleted” in a bitmask/bitmap. Filter out these IDs during search results post-processing.

Q2: How do you evaluate Semantic Search? Answer:

• NDCG@10 (Normalized Discounted Cumulative Gain): Measures ranking quality.
• MRR (Mean Reciprocal Rank): How high is the first relevant result?
• Recall@K: % of relevant docs found in top K.
• Datasets: MS MARCO, BEIR benchmark.

Q3: When should you NOT use Semantic Search? Answer:

• Exact Match: Searching for specific IDs, error codes, or names (e.g., “User 1234”).
• Low Latency: If < 10ms is required, BM25/Inverted Index is faster.
• Interpretability: Vector scores are opaque; BM25 explains “why” (term frequency).

Q4: How to scale to 1 Billion vectors? Answer:

• Compression: Product Quantization (PQ) to reduce RAM (e.g., 4KB → 64 bytes per vector).
• Sharding: Split index across multiple nodes (horizontal scaling).
• GPU Acceleration: Faiss on GPU is 10x faster than CPU.

Q5: What is the “Curse of Dimensionality” in vector search? Answer: As dimensions increase, the distance between the nearest and farthest points becomes negligible. However, for text embeddings (768-dim), this is usually manageable. The bigger issue is the computational cost of distance calculation.

Key Takeaways

1. Bi-Encoders enable fast retrieval by pre-computing document vectors.
2. Cross-Encoders provide high accuracy re-ranking but are computationally expensive.
3. Vector DBs (HNSW, IVF-PQ) are essential for scaling to millions/billions of documents.
4. Hybrid Search (Dense + Sparse) is the robust industry standard to handle both semantic and exact match queries.
5. Hard Negatives are crucial for training effective embedding models.

Summary

Aspect	Insight
Core Idea	Embed text into vector space to capture meaning
Architecture	Retrieve (Bi-Encoder) → Re-Rank (Cross-Encoder)
Indexing	HNSW (Graph), IVF-PQ (Clustering + Compression)
Challenges	Exact match, long docs, scale, domain adaptation

---
