“Organizing the world’s information into a structured hierarchy.”

1. What is Hierarchical Classification?

Hierarchical classification is the task of assigning an item to one or more nodes in a taxonomy tree.

Example: Product Categorization

Electronics
├── Computers
│   ├── Laptops
│   │   ├── Gaming Laptops
│   │   └── Business Laptops
│   └── Desktops
└── Mobile Devices
    ├── Smartphones
    └── Tablets

Problem: Given a product description “Dell XPS 15 with RTX 3050”, classify it into:

  • Electronics > Computers > Laptops > Business Laptops (or Gaming Laptops?)

Challenges:

  1. Large Taxonomies: Amazon has 30,000+ categories.
  2. Multi-path: An item can belong to multiple leaf nodes (e.g., “Wireless Gaming Mouse” → Computers/Accessories AND Gaming/Peripherals).
  3. Imbalanced Data: “Electronics” has millions of items, “Vintage Typewriters” has 100.
  4. Hierarchy Violations: A model might predict “Gaming Laptop” without predicting “Laptop” (parent).

2. Flat vs. Hierarchical Classification

Aspect Flat Classification Hierarchical Classification
Model Single multi-class classifier Tree-structured classifiers
Predictions One label Path in tree
Training One model Multiple models (global or local)
Hierarchy Ignored Exploited
Example CIFAR-10 (10 classes) ImageNet (1000 classes in hierarchy)

Why Hierarchical?

  • Scalability: Training a single model with 30,000 classes is intractable.
  • Interpretability: Users navigate taxonomies (“Show me all Electronics > Computers”).
  • Zero-shot: New subcategories can be added without retraining the entire model.

3. Hierarchical Classification Approaches

Approach 1: Global Classifier (Flat with Post-Processing)

Train a single multi-class classifier predicting all leaf nodes, then use the hierarchy to ensure consistency.

Model:

# Predict all 30,000 leaf categories
logits = model(input)  # Shape: [batch, 30000]
probs = softmax(logits)

# Post-process: ensure parent probabilities >= child probabilities
for node in taxonomy.postorder():
    if node.children:
        node.prob = max(node.prob, max(child.prob for child in node.children))

Pros:

  • Simple: One model.
  • High accuracy if data is sufficient.

Cons:

  • Class Imbalance: Popular categories dominate.
  • No hierarchy exploitation during training.

Approach 2: Local Classifiers Per Node (LCN)

Train a separate classifier at each internal node to choose among its children.

Example:

Root Classifier: Electronics vs. Clothing vs. Books
  ├─ Electronics Classifier: Computers vs. Mobile Devices
  │   ├─ Computers Classifier: Laptops vs. Desktops

Inference:

node = root
while not node.is_leaf():
    probs = node.classifier(input)
    node = node.children[argmax(probs)]
return node

Pros:

  • Balanced: Each classifier handles a small, focused problem.
  • Modular: Can update one classifier without retraining others.

Cons:

  • Error Propagation: If the root classifier is wrong, the entire path is wrong.
  • Many Models: Need to train and deploy K models (where K = number of internal nodes).

Approach 3: End-to-End Hierarchical Model

Use a shared encoder with hierarchical output heads.

Architecture:

class HierarchicalClassifier(nn.Module):
    def __init__(self, taxonomy):
        super().__init__()
        self.encoder = ResNet()  # Shared
        self.heads = nn.ModuleDict({
            node.id: nn.Linear(2048, len(node.children))
            for node in taxonomy.internal_nodes()
        })

    def forward(self, x):
        features = self.encoder(x)
        outputs = {}
        for node_id, head in self.heads.items():
            outputs[node_id] = head(features)
        return outputs

Loss:

total_loss = 0
for node in taxonomy.internal_nodes():
    if node in ground_truth_path:
        target = ground_truth_path[node].child_index
        total_loss += cross_entropy(outputs[node.id], target)

Pros:

  • Shared Representations: Lower layers learn general features.
  • End-to-End Training: Optimizes the entire path jointly.

Cons:

  • Complex: Harder to debug and tune.
  • Memory: All heads must fit in GPU memory.

4. Handling Multi-Label Hierarchy

Some items belong to multiple paths in the tree.

Example: “Logitech Wireless Gaming Mouse”

  • Path 1: Electronics > Computers > Accessories > Mouse
  • Path 2: Electronics > Gaming > Peripherals > Mouse

Approach: Multi-Task Learning

  • Treat each path as a separate task.
  • Loss = Sum of losses for all valid paths.
    loss = sum(path_loss(model(x), path) for path in ground_truth_paths)

5. Hierarchy-Aware Loss Functions

Loss 1: Hierarchical Softmax

Instead of standard softmax over 30,000 classes, factorize: \[ P(\text{Leaf} | x) = P(\text{Root} \to \text{Child}_1 | x) \times P(\text{Child}_1 \to \text{Child}_2 | x) \times \ldots \]

Benefit: Reduces computation from \(O(K)\) to \(O(\log K)\) where K is number of classes.

Loss 2: Hierarchical Cross-Entropy (H-Loss)

Penalize mistakes based on the distance in the tree. \[ \mathcal{L} = \sum_{i=1}^{D} \alpha_i \cdot \text{CE}(\text{pred}_i, \text{true}_i) \] where \(D\) is the depth and \(\alpha_i\) increases with depth (leaf nodes weighted more).

Intuition: Mistaking “Gaming Laptop” for “Business Laptop” (siblings) is less bad than mistaking it for “Tablet” (cousin).

Loss 3: Symmetric KL Divergence

Encourage the model to predict ancestor probabilities >= descendant probabilities. \[ \mathcal{L}{\text{consistency}} = \sum{\text{parent, child}} \max(0, P(\text{child}) - P(\text{parent})) \]

Deep Dive: Amazon’s Product Taxonomy

Amazon has a forest of taxonomies (one per marketplace). Challenge: Items listed in multiple marketplaces need consistent categorization.

Solution: Transfer Learning

  1. Train a base model on US taxonomy (most data).
  2. Fine-tune on UK, Japan, India taxonomies.
  3. Use adapter layers to handle marketplace-specific categories.

Scale:

  • Items: 350M+
  • Categories: 30,000+
  • Languages: 15+

Deep Dive: Extreme Multi-Label Classification (XML)

When the number of labels is in the millions (e.g., Wikipedia categories), standard approaches fail.

Approaches:

  1. Embedding-Based (AnnexML, Bonsai, Parabel):
    • Embed labels and inputs into the same space.
    • Use ANN (Approximate Nearest Neighbors) to retrieve top-K labels.
  2. Attention Mechanisms:
    • Label-Attention: Attend to label descriptions during encoding.
  3. Tree Pruning:
    • Prune unlikely branches early using a lightweight model.

Parabel Architecture:

1. Build a label tree (clustering similar labels).
2. Train classifiers at each node (like LCN).
3. Beam search during inference to explore top-K branches.

Deep Dive: Google’s Knowledge Graph Categories

Google Search uses a hierarchical taxonomy for entities. Example:

Thing
├── Creative Work
│   └── Movie
└── Person
    └── Actor

Challenge: New entities appear daily (new movies, new people). Solution:

  • Zero-Shot Classification: Use a text encoder (BERT) to embed the entity description.
  • Nearest Ancestor: Find the closest category in the embedding space.

Deep Dive: Hierarchical Multi-Task Learning (HMTL)

In HMTL, tasks are organized in a hierarchy where:

  • Lower tasks are easier (e.g., “Is this electronics?”).
  • Higher tasks are harder (e.g., “Is this a gaming laptop?”).

Architecture:

Input → Shared Encoder → Task 1 (Electronics?) ──┐
                         ├→ Task 2 (Computers?)   │
                         └→ Task 3 (Laptops?)     │
                                                   ├→ Final Prediction

Loss: \[ \mathcal{L} = \lambda_1 \mathcal{L}_1 + \lambda_2 \mathcal{L}_2 + \lambda_3 \mathcal{L}_3 \] where \(\lambda_i\) are learned or hand-tuned.

Deep Dive: Taxonomy Expansion (Adding New Categories)

Problem: A new category “Foldable Smartphones” needs to be added.

Approach 1: Retrain from Scratch

  • Expensive and slow.

Approach 2: Continual Learning

  • Fine-tune the model on new data while preserving old knowledge.
  • Challenge: Catastrophic forgetting.
  • Solution: Elastic Weight Consolidation (EWC) or rehearsal buffers.

Approach 3: Few-Shot Learning

  • Train a meta-learner that can adapt to new categories with < 100 examples.
  • Use Prototypical Networks or MAML.

Deep Dive: Handling Imbalanced Hierarchies

Problem: “Laptops” has 1M examples, “Typewriters” has 50.

Solutions:

  1. Class Weighting: \[ w_i = \frac{\text{total samples}}{\text{samples in class } i} \]
  2. Focal Loss: \[ \mathcal{L} = -\alpha (1 - p_t)^\gamma \log(p_t) \] Focuses on hard-to-classify examples.
  3. Oversampling:
    • Augment rare classes.
  4. Hierarchical Sampling:
    • Sample uniformly at each level of the tree, not uniformly across all leaves.

Deep Dive: Evaluation Metrics

Metric 1: Hierarchical Precision and Recall

Standard precision/recall don’t account for hierarchy. Hierarchical Precision: \[ hP = \frac{|\text{predicted path} \cap \text{true path}|}{|\text{predicted path}|} \]

Example:

  • True: Electronics > Computers > Laptops
  • Predicted: Electronics > Computers > Desktops
  • \( hP = \frac{2}{3} \) (got Electronics and Computers right, but wrong at Laptops level).

Metric 2: Tree-Induced Distance

Measure the shortest path between predicted and true leaf in the tree. \[ d(\text{pred}, \text{true}) = \text{depth}(\text{LCA}(\text{pred}, \text{true})) \]

Example:

  • pred = Gaming Laptop, true = Business Laptop
  • LCA = Laptop
  • Distance = depth(Laptop) = 2 (smaller is better)

Metric 3: F1 at Different Levels

Compute F1 separately at each level of the hierarchy.

  • Level 0 (Root): F1 = 100% (trivial).
  • Level 1: F1 on {Electronics, Clothing, Books}.
  • Level 2: F1 on {Computers, Mobile, etc.}.

Deep Dive: Active Learning for Taxonomy Labeling

Problem: Labeling 10M products manually is expensive.

Solution: Active Learning

  1. Train initial model on small labeled set.
  2. Query: Find the most uncertain samples.
    • Entropy: \( H = -\sum_i p_i \log p_i \)
    • Least Confident: \( 1 - \max_i p_i \)
  3. Human labels the queried samples.
  4. Retrain and repeat.

Hierarchical Active Learning:

  • Prioritize samples where the model is uncertain at multiple levels of the tree.

Deep Dive: Hierarchical Attention Networks (HAN)

Idea: Use attention at each level of the hierarchy to focus on relevant features.

Architecture:

class HierarchicalAttention(nn.Module):
    def __init__(self):
        self.word_attention = Attention()
        self.sentence_attention = Attention()
        self.document_attention = Attention()

    def forward(self, document):
        # Level 1: Words → Sentence Representation
        sentence_reps = []
        for sentence in document:
            word_reps = [self.embed(word) for word in sentence]
            sentence_rep = self.word_attention(word_reps)
            sentence_reps.append(sentence_rep)

        # Level 2: Sentences → Document Representation
        doc_rep = self.sentence_attention(sentence_reps)

        # Level 3: Document → Category
        category = self.document_attention(doc_rep)
        return category

Deep Dive: Label Embedding and Matching

Idea: Embed both inputs and labels into the same space.

Training:

input_emb = encoder(product_description)  # [batch, 512]
label_embs = label_encoder(all_labels)     # [30000, 512]

# Dot product similarity
scores = input_emb @ label_embs.T  # [batch, 30000]
loss = cross_entropy(scores, target)

Inference:

# Use FAISS for fast top-K retrieval
top_k_labels = faiss_index.search(input_emb, k=10)

Benefit: Decouples the number of labels from model size. Can add new labels without retraining.

Deep Dive: Hierarchical Reinforcement Learning (HRL) for Sequential Classification

Problem: Some taxonomies require a sequence of decisions.

Example: “Classify this support ticket”

  1. Department? (Sales, Support, Engineering)
  2. If Support, Priority? (Low, Medium, High)
  3. If High, Assign to? (Agent 1, Agent 2, Agent 3)

Approach: Hierarchical RL

  • High-Level Policy: Chooses department.
  • Low-Level Policies: Choose priority, assign agent.
  • Reward: +1 if ticket is resolved quickly.

Implementation Example: PyTorch Hierarchical Classifier

import torch
import torch.nn as nn

class HierarchicalModel(nn.Module):
    def __init__(self, taxonomy, embedding_dim=768):
        super().__init__()
        self.taxonomy = taxonomy
        self.encoder = nn.Sequential(
            nn.Linear(embedding_dim, 1024),
            nn.ReLU(),
            nn.Dropout(0.3),
            nn.Linear(1024, 512)
        )

        # One classifier per internal node
        self.classifiers = nn.ModuleDict()
        for node in taxonomy.internal_nodes():
            self.classifiers[str(node.id)] = nn.Linear(512, len(node.children))

    def forward(self, x, return_all=False):
        features = self.encoder(x)

        if return_all:
            # Return logits for all nodes (for training)
            outputs = {}
            for node_id, classifier in self.classifiers.items():
                outputs[node_id] = classifier(features)
            return outputs
        else:
            # Greedy path prediction (for inference)
            node = self.taxonomy.root
            path = [node]

            while not node.is_leaf():
                logits = self.classifiers[str(node.id)](features)
                child_idx = torch.argmax(logits, dim=1)
                node = node.children[child_idx.item()]
                path.append(node)

            return path

def hierarchical_loss(outputs, true_path):
    loss = 0
    for node in true_path:
        if not node.is_leaf():
            logits = outputs[str(node.id)]
            target = true_path.index(node.get_child_on_path(true_path))
            loss += nn.CrossEntropyLoss()(logits, torch.tensor([target]))
    return loss

Top Interview Questions

Q1: How do you handle products that fit multiple categories? Answer: Use multi-label classification. Train the model to predict multiple paths. At inference, use a threshold (e.g., predict all paths with confidence > 0.3).

Q2: What if the taxonomy is updated (categories added/removed)? Answer: Use modular design (local classifiers) so you can retrain only affected nodes. Or use label embeddings which allow adding new categories without retraining.

Q3: How do you ensure hierarchy consistency? Answer: Post-process predictions to ensure \(P(\text{child}) \leq P(\text{parent})\). During training, add a consistency loss term.

Q4: How do you deal with extreme imbalance (popular vs. rare categories)? Answer:

  • Focal loss to focus on hard examples.
  • Hierarchical sampling (sample uniformly at each level).
  • Data augmentation for rare categories.

Key Takeaways

  1. Hierarchy Exploitation: Use the tree structure during both training and inference.
  2. Local vs. Global: Trade-off between modular (easy to update) and end-to-end (higher accuracy).
  3. Multi-Label: Real-world taxonomies often have overlapping categories.
  4. Scalability: For millions of classes, use embedding-based retrieval (ANN).
  5. Evaluation: Standard metrics don’t account for hierarchy; use hierarchical precision/recall.

Summary

Aspect Insight
Approaches Global, Local (LCN), End-to-End Hierarchical
Loss Functions Hierarchical Softmax, H-Loss, Consistency Loss
Scalability Label embeddings + FAISS for extreme multi-label
Evaluation Hierarchical precision, tree-induced distance

Originally published at: arunbaby.com/ml-system-design/0029-hierarchical-classification

If you found this helpful, consider sharing it with others who might benefit.

Related across topics
