How does Google search 50 billion pages in 0.1 seconds? The answer is the “Ranking Funnel”.

1. Problem Definition

Goal: Given a user query (or context) and a massive corpus of items (1B+), return the top (K) most relevant items sorted by relevance.

Constraints:

  • Latency: < 200ms (P99).
  • Throughput: 100k QPS.
  • Freshness: New items should be searchable within minutes.

2. High-Level Architecture: The Funnel

We cannot score 1 billion items with a heavy BERT model. We use a Multi-Stage Cascade.

[Corpus: 1 Billion Items]
       |
       v
[Stage 1: Retrieval / Candidate Generation] -> Selects Top 10,000
       |  (Fast, Simple, High Recall)
       v
[Stage 2: L1 Ranking (Lightweight)] --------> Selects Top 500
       |  (Two-Tower, Logistic Regression)
       v
[Stage 3: L2 Ranking (Heavyweight)] --------> Selects Top 10
       |  (BERT, LambdaMART, DLRM)
       v
[Stage 4: Re-Ranking / Blending] -----------> Final Output
          (Diversity, Business Logic)

3. Stage 1: Retrieval (Candidate Generation)

Objective: High Recall. Don’t miss the relevant items. Methods:

  1. Inverted Index (BM25): Standard keyword search.
  2. Vector Search (ANN): Embed query and items. Use Faiss/ScaNN to find nearest neighbors.
  3. Collaborative Filtering: “Users who bought X also bought Y”.

4. Stage 2: L1 Ranking (The Two-Tower Model)

Objective: Filter 10k -> 500. Model: Two-Tower Neural Network (Bi-Encoder).

   [User Features]          [Item Features]
         |                        |
    [Deep Net]               [Deep Net]
         |                        |
    [User Vector U]          [Item Vector V]
         \                      /
          \                    /
           \                  /
            Dot Product (U . V)
                    |
                  Score

Why Two-Tower?

  • Cacheable: Item vectors (V) can be precomputed and stored in a Vector DB.
  • Fast: Inference is just a Dot Product.

5. Stage 3: L2 Ranking (The Heavy Lifter)

Objective: Precision. Order the top 500 perfectly. Model: Cross-Encoder (BERT) or LambdaMART (GBDT).

Feature Interaction: Unlike Two-Tower, Cross-Encoders feed User and Item features together into the network.

  • Input: [User_Age, Item_Price, User_History, Item_Title]
  • The network learns interactions: “Young users like cheap items”.

Loss Functions:

  • Pointwise: RMSE / LogLoss. (Predict “Will click?”).
  • Pairwise: RankNet / LambdaRank. (Predict “Is A better than B?”).
  • Listwise: LambdaMART / Softmax. (Optimize NDCG directly).

6. Stage 4: Re-Ranking & Blending

The raw scores aren’t enough. We need:

  1. Diversity: Don’t show 10 shoes. Show shoes, socks, and laces. (MMR Algorithm).
  2. Freshness: Boost new items.
  3. Business Logic: Boost sponsored items (Ads).

Deep Dive: Approximate Nearest Neighbors (ANN)

In Stage 1 (Retrieval), we need to find the top 1000 items closest to query vector (Q) among 1 billion item vectors (V). Brute force scan is (O(N)). Too slow. We use ANN algorithms.

1. HNSW (Hierarchical Navigable Small World)

  • Structure: A multi-layered graph.
  • Top Layer: Sparse long-range links (Highways).
  • Bottom Layer: Dense short-range links.
  • Search: Start at the top, greedily move closer to the target, drop down a layer, repeat.
  • Pros: Extremely fast, high recall.
  • Cons: High memory usage (stores the graph).

2. IVF (Inverted File Index)

  • Training: Cluster the vector space into (C) centroids (using K-Means).
  • Indexing: Assign each item to its closest centroid.
  • Search: Find the closest centroids to (Q), then scan only the items in those clusters.
  • Pros: Low memory (can be compressed with Product Quantization).

3. ScaNN (Google)

  • Optimizes the Anisotropic Quantization loss.
  • State-of-the-art performance for inner-product search (which is what we need for Dot Product).

Deep Dive: Training the Two-Tower Model

How do we train the L1 Ranker? We don’t have explicit “negative” labels (items the user didn’t like). We only have “clicks” (positives).

Negative Sampling: For every positive pair ((U, I^+)), we sample (K) negative items (I^-).

  1. Random Negatives: Pick random items from the catalog. (Easy, but too easy for the model).
  2. Hard Negatives: Pick items that the model thought were good but the user didn’t click. (Harder, learns better boundaries).
  3. In-Batch Negatives: Use the positives from other users in the same batch as negatives for the current user. (Efficient, GPU friendly).

Loss Function (Softmax Cross-Entropy): [ L = -\log \frac{\exp(U \cdot I^+)}{\exp(U \cdot I^+) + \sum \exp(U \cdot I^-)} ]

Deep Dive: Learning to Rank (LTR) Loss Functions

In Stage 3 (L2 Ranking), we care about the order.

1. Pointwise (RMSE / Sigmoid)

  • Treats each item independently.
  • “Predict the probability of click for Item A”.
  • Problem: Doesn’t care if Item A > Item B, only about the absolute score.

2. Pairwise (RankNet / LambdaRank)

  • Takes pairs ((A, B)) where A is clicked and B is not.
  • Minimizes loss if (Score(A) < Score(B)).
  • Problem: Optimizes the number of inversions, not the position (NDCG). An error at rank 100 is treated same as error at rank 1.

3. Listwise (LambdaMART)

  • LambdaMART is a Gradient Boosted Decision Tree (GBDT) method.
  • It modifies the gradients of the pairwise loss by weighting them with the change in NDCG ((\Delta NDCG)).
  • Intuition: If swapping A and B causes a huge drop in NDCG, the gradient should be huge.
  • Status: Still the SOTA for tabular features in L2 ranking.

Deep Dive: DLRM (Deep Learning Recommendation Model)

Facebook open-sourced DLRM. It’s the standard for L2 Ranking.

Architecture:

  1. Sparse Features (Categorical): Mapped to dense embeddings.
  2. Dense Features (Numerical): Processed by an MLP (Bottom MLP).
  3. Interaction: Dot Product between embeddings and MLP output.
  4. Top MLP: Takes the interaction output and predicts CTR.

Why DLRM? It explicitly models the interaction between sparse features (User ID, Item ID) and dense features (Age, Price). It is optimized for training on massive clusters (Model Parallelism for embeddings, Data Parallelism for MLPs).

Deep Dive: The Feature Store (Feast)

In Stage 4 (Feature Fetching), we need low latency. We cannot run SQL queries on a Data Warehouse (Snowflake/BigQuery) in real-time.

The Feature Store Solution:

  1. Offline Store: (S3/Parquet). Used for training. Contains months of history.
  2. Online Store: (Redis/DynamoDB). Used for inference. Contains only the latest values.
  3. Consistency: The Feature Store ensures that the Offline and Online stores are in sync (Point-in-time correctness).

Workflow:

  • Data Engineering pipeline computes user_last_50_clicks.
  • Pushes to Offline Store (for training tomorrow’s model).
  • Pushes to Online Store (for serving today’s traffic).

Deep Dive: A/B Testing for Ranking

How do we know the new model is better? We run an Interleaving Experiment.

Standard A/B Test:

  • Group A sees Model A results.
  • Group B sees Model B results.
  • Compare CTR.
  • Problem: High variance. Users in Group A might just be happier people.

Interleaving:

  • Show every user a mix of Model A and Model B results.
  • Result = [A1, B1, A2, B2, ...]
  • If user clicks A1, Model A gets a point.
  • If user clicks B1, Model B gets a point.
  • Pros: Removes user variance. 100x more sensitive than standard A/B tests.

Deep Dive: Real-time Inference (Triton)

Serving a BERT model in 50ms is hard. NVIDIA Triton Inference Server:

  • Dynamic Batching: Groups incoming requests into a batch to maximize GPU utilization.
  • Model Ensembling: Runs Preprocessing (Python) -> Model (TensorRT) -> Postprocessing (Python) in a single pipeline.
  • Concurrent Execution: Runs multiple models on the same GPU.
