Beam Search Decoding

The industry-standard algorithm for converting probabilistic model outputs into coherent text sequences.

Problem

A sequence model (RNN, LSTM, Transformer) outputs a probability distribution over the vocabulary for the next token, given the history.

P(y_t | y_1, ..., y_{t-1}, X)

Our goal is to find the sequence Y = [y_1, ..., y_T] that maximizes the total probability: argmax_Y P(Y | X) = argmax_Y Π P(y_t | y_{<t}, X)

Since multiplying probabilities results in tiny numbers (underflow), we work with Log Probabilities and sum them: argmax_Y Σ log P(y_t | y_{<t}, X)

Why not Brute Force?

If the vocabulary size is V (e.g., 50,000) and the sequence length is T (e.g., 20), the number of possible sequences is V^T. 50,000^20 is larger than the number of atoms in the universe. We cannot check them all.

A sequence model (RNN, LSTM, Transformer) outputs a probability distribution over the vocabulary for the next token, given the history.

P(y_t | y_1, ..., y_{t-1}, X)

Our goal is to find the sequence Y = [y_1, ..., y_T] that maximizes the total probability: argmax_Y P(Y | X) = argmax_Y Π P(y_t | y_{<t}, X)

Since multiplying probabilities results in tiny numbers (underflow), we work with Log Probabilities and sum them: argmax_Y Σ log P(y_t | y_{<t}, X)

Why not Brute Force?

If the vocabulary size is V (e.g., 50,000) and the sequence length is T (e.g., 20), the number of possible sequences is V^T. 50,000^20 is larger than the number of atoms in the universe. We cannot check them all.

Strategy 1: Greedy Search

The simplest approach: Always pick the token with the highest probability at each step.

Algorithm:

1. Start with <SOS> (Start of Sentence).
2. Feed to model -> Get Top-1 token.
3. Append to sequence.
4. Repeat until <EOS> (End of Sentence).

Pros:

• Fast (O(T)).
• Simple to implement.

Cons:

• Short-sighted: It makes locally optimal decisions that might lead to a dead end.
• Example:
  • Step 1: “The” (0.4), “A” (0.3). Greedy picks “The”.
  • Step 2: “The” -> “dog” (0.1). Total score: 0.4 * 0.1 = 0.04.
  • Alternative: “A” -> “cat” (0.9). Total score: 0.3 * 0.9 = 0.27.
  • Greedy missed the better path because it committed too early.

Strategy 2: Beam Search

Beam Search is a heuristic search algorithm that explores the graph by keeping the Top-K most promising sequences at each step. K is called the Beam Width.

Algorithm:

1. Initialization: Start with 1 hypothesis: [<SOS>] with score 0.0.
2. Expansion: For each of the K hypotheses, generate the top V candidates for the next token.
3. Scoring: Calculate the new score for all K * V candidates.
   • NewScore = OldScore + log(P(token))
4. Pruning: Sort all candidates and keep only the top K.
5. Repeat: Continue until all K hypotheses generate <EOS> or max length is reached.

Visualizing the Beam

Imagine a flashlight (beam) shining into a dark cave.

• Width 1: A laser pointer (Greedy Search). You only see one path.
• Width 5: A flashlight. You see 5 paths.
• Width Infinity: The sun. You see everything (BFS), but it burns your CPU.

Python Implementation

Let’s implement a clean, production-ready Beam Search.

import torch
import torch.nn.functional as F
import math

def beam_search_decoder(model, start_token, end_token, k=3, max_len=20):
    # Hypothesis: (score, sequence)
    # Start with one hypothesis
    hypotheses = [(0.0, [start_token])]

    # Final completed sequences
    completed_hypotheses = []

    for step in range(max_len):
        candidates = []

        # 1. Expand each hypothesis
        for score, seq in hypotheses:
            # If this hypothesis is already done, don't expand
            if seq[-1] == end_token:
                completed_hypotheses.append((score, seq))
                continue

            # Get model prediction for the next token
            # (In reality, you'd cache the hidden state!)
            input_tensor = torch.tensor([seq])
            with torch.no_grad():
                logits = model(input_tensor) # Shape: [1, seq_len, vocab_size]

            # Get log probabilities of the last step
            log_probs = F.log_softmax(logits[0, -1, :], dim=-1)

            # 2. Get Top-K candidates for this branch
            top_k_log_probs, top_k_indices = torch.topk(log_probs, k)

            for i in range(k):
                token_idx = top_k_indices[i].item()
                token_prob = top_k_log_probs[i].item()

                new_score = score + token_prob
                new_seq = seq + [token_idx]
                candidates.append((new_score, new_seq))

        # 3. Prune: Keep only global Top-K
        # Sort by score (descending)
        ordered = sorted(candidates, key=lambda x: x[0], reverse=True)
        hypotheses = ordered[:k]

        # Early stopping: If all K hypotheses are done
        if not hypotheses:
            break

    # Add any remaining running hypotheses to completed
    completed_hypotheses.extend(hypotheses)

    # Sort final results
    completed_hypotheses.sort(key=lambda x: x[0], reverse=True)

    return completed_hypotheses

Complexity Analysis

• Time Complexity: O(T * K * V) (naive) or O(T * K * log K) (optimized with top-k selection).
• Space Complexity: O(T * K). We store K sequences of length T.

Advanced Beam Search Techniques

Standard Beam Search has issues.

1. Length Bias: Longer sentences have more negative terms added to the log-probability (since log(p) < 0). So, Beam Search prefers short sentences.
   • Fix: Length Normalization. Divide the score by length^alpha (usually alpha=0.6 or 0.7).
   • Score = Sum(log_probs) / (Length)^0.7
2. Lack of Diversity: Often, the top K hypotheses differ only by one word (e.g., “I love dog”, “I love dogs”, “I love the dog”).
   • Fix: Diverse Beam Search (DBS). Add a penalty term if hypotheses share the same parent or tokens.
   • Algorithm: Divide the beam into G groups. Perform beam search for each group, but penalize tokens selected by previous groups.
3. Constrained Beam Search:
   • Sometimes you must include a specific word in the output (e.g., “Translate this but ensure ‘Apple’ is capitalized”).
   • Algorithm: We track the “constraint state” (which words have been met) in the hypothesis. A hypothesis is only valid if it satisfies all constraints by the end.

Beam Search vs. Sampling (Nucleus/Top-P)

For Creative Writing (e.g., ChatGPT writing a poem), Beam Search is bad. It’s too optimal. It produces boring, repetitive text. For Translation/ASR, Beam Search is king. We want the correct translation, not a creative one.

1. Temperature

We divide the logits by a temperature T before softmax.

• T < 1: Makes the distribution sharper (more confident).
• T > 1: Makes the distribution flatter (more random).

2. Top-K Sampling

Only sample from the top K most likely tokens.

• Problem: If K=10, but only 2 words make sense, we might pick a garbage word.

3. Top-P (Nucleus) Sampling

Sample from the smallest set of tokens whose cumulative probability exceeds P (e.g., 0.9).

• Dynamic K: If the model is unsure, the set is large. If the model is sure, the set is small.

Feature	Beam Search	Sampling (Top-K / Top-P)
Goal	Maximize Probability	Generate Diversity
Use Case	Translation, ASR, Summarization	Chatbots, Story Generation
Output	Deterministic (mostly)	Stochastic (Random)
Risk	Repetitive loops	Hallucinations

Production Engineering: C++ Implementation

In production, Python is too slow. We implement Beam Search in C++ using std::priority_queue.

#include <queue>
#include <vector>
#include <cmath>
#include <algorithm>

struct Hypothesis {
    std::vector<int> sequence;
    float score;

    bool operator<(const Hypothesis& other) const {
        return score < other.score; // Max-heap
    }
};

std::vector<Hypothesis> beam_search(const Model& model, int k) {
    std::priority_queue<Hypothesis> beam;
    beam.push({ {START_TOKEN}, 0.0 });

    for (int t = 0; t < MAX_LEN; ++t) {
        std::priority_queue<Hypothesis> next_beam;

        // We only pop K times
        int count = 0;
        while (!beam.empty() && count < k) {
            Hypothesis h = beam.top();
            beam.pop();
            count++;

            // Expand
            auto logits = model.forward(h.sequence);
            auto top_k_tokens = get_top_k(logits, k);

            for (auto token : top_k_tokens) {
                float new_score = h.score + std::log(token.prob);
                next_beam.push({ h.sequence + token.id, new_score });
            }
        }
        beam = next_beam;
    }
    // ... return top results
}

KV Caching & Memory Bandwidth

The bottleneck in Beam Search is not compute (FLOPs), it is Memory Bandwidth. Every step, we need to read the entire model weights from VRAM.

• KV Caching: We cache the Key and Value matrices of the attention layers.
• Memory Usage: Batch_Size * Beam_Width * Seq_Len * Hidden_Dim * Layers * 2 (K+V).
• Optimization: PagedAttention (vLLM). Instead of allocating contiguous memory for KV cache (which causes fragmentation), we allocate blocks (pages) on demand, just like an OS manages RAM. This allows 2-4x higher batch sizes.

System Design Considerations

When deploying Beam Search in production (e.g., serving a Transformer model):

1. Latency vs. Width

Increasing K improves accuracy but linearly increases compute time.

• K=1: Fast, lower quality.
• K=5: Standard for Translation.
• K=10+: Diminishing returns.

Optimization: Use Adaptive Beam Width. Start with K=5. If the top 2 candidates have very close scores, keep searching. If the top candidate is way ahead, stop early (shrink K to 1).

2. Batching

Beam Search is hard to batch because different hypotheses finish at different times.

• Padding: We pad finished sequences with <PAD> tokens so we can keep doing matrix math on the whole batch.
• Masking: We mask out the <PAD> tokens so they don’t affect the score.

Case Study: Google Translate

Google Translate uses a variant of Beam Search with:

• Width: ~4-6.
• Length Normalization: Alpha = 0.6.
• Coverage Penalty: Ensures the model translates all parts of the source sentence (prevents dropping words).

Appendix A: Full C++ Production Implementation

Here is a more complete example using LibTorch (PyTorch C++ API).

#include <torch/torch.h>
#include <iostream>
#include <vector>
#include <queue>

// Define a Hypothesis struct
struct Hypothesis {
    std::vector<int64_t> tokens;
    double score;

    // For min-heap (we want to pop the lowest score to keep top-k)
    bool operator>(const Hypothesis& other) const {
        return score > other.score;
    }
};

std::vector<int64_t> beam_search_decode(
    torch::jit::script::Module& model,
    int64_t start_token,
    int64_t end_token,
    int k,
    int max_len
) {
    // Current beam: List of hypotheses
    std::vector<Hypothesis> beam;
    beam.push_back({ {start_token}, 0.0 });

    for (int step = 0; step < max_len; ++step) {
        std::vector<Hypothesis> candidates;

        for (const auto& h : beam) {
            if (h.tokens.back() == end_token) {
                candidates.push_back(h);
                continue;
            }

            // Prepare input tensor
            auto input = torch::tensor(h.tokens).unsqueeze(0); // [1, seq_len]

            // Run model (Forward)
            // In real life, use KV cache!
            auto output = model.forward({input}).toTensor();
            auto logits = output.select(1, -1); // Last step: [1, vocab_size]
            auto log_probs = torch::log_softmax(logits, 1);

            // Get Top-K
            auto top_k = log_probs.topk(k);
            auto top_k_scores = std::get<0>(top_k)[0];
            auto top_k_indices = std::get<1>(top_k)[0];

            for (int i = 0; i < k; ++i) {
                double score = top_k_scores[i].item<double>();
                int64_t idx = top_k_indices[i].item<int64_t>();

                std::vector<int64_t> new_tokens = h.tokens;
                new_tokens.push_back(idx);

                candidates.push_back({ new_tokens, h.score + score });
            }
        }

        // Sort and Prune
        std::sort(candidates.begin(), candidates.end(), [](const Hypothesis& a, const Hypothesis& b) {
            return a.score > b.score; // Descending
        });

        if (candidates.size() > k) {
            candidates.resize(k);
        }
        beam = candidates;

        // Check if all finished
        bool all_finished = true;
        for (const auto& h : beam) {
            if (h.tokens.back() != end_token) {
                all_finished = false;
                break;
            }
        }
        if (all_finished) break;
    }

    return beam[0].tokens;
}

Appendix B: The Ultimate Decoding Glossary

1. Logits: Raw, unnormalized scores output by the last layer of the neural network.
2. Softmax: Function that converts logits into probabilities (sum to 1).
3. Log-Probability: log(p). Used to avoid underflow. Always negative (since p <= 1).
4. Perplexity: exp(-mean(log_probs)). A measure of how “surprised” the model is. Lower is better.
5. Entropy: Measure of randomness in the distribution.
6. Temperature: Hyperparameter to control entropy. High T = High Entropy (Random).
7. Greedy Search: Beam Search with Width 1.
8. Beam Width: Number of hypotheses kept at each step.
9. Length Penalty: Normalization term to prevent bias against long sequences.
10. Coverage Penalty: Penalty for not attending to source tokens (NMT specific).
11. Repetition Penalty: Penalty for generating the same n-gram twice.
12. Nucleus Sampling (Top-P): Sampling from the smallest set of tokens with cumulative probability P.
13. Top-K Sampling: Sampling from the top K tokens.
14. Teacher Forcing: Training technique where we feed the ground truth token as input, not the model’s prediction.
15. Exposure Bias: The mismatch between training (Teacher Forcing) and inference (Autoregressive generation).
16. BLEU Score: Metric for translation quality (n-gram overlap).
17. ROUGE Score: Metric for summarization quality (recall-oriented).
18. METEOR: Metric that considers synonyms and stemming.
19. WER (Word Error Rate): Metric for ASR.
20. KV Cache: Caching Key/Value matrices to speed up Transformer inference.

Appendix C: Key Research Papers Summarized

1. “The Curious Case of Neural Text Degeneration” (Holtzman et al., 2020)

• Problem: Beam Search leads to repetitive, dull text.
• Solution: Introduced Nucleus Sampling (Top-P).
• Key Insight: Human text is not always “high probability”. Humans often use “surprising” words. Beam Search maximizes probability, which is unnatural for creative writing.

2. “Attention Is All You Need” (Vaswani et al., 2017)

• Contribution: Introduced the Transformer architecture.
• Relevance: The Transformer decoder is the standard model used with Beam Search today.

3. “Sequence to Sequence Learning with Neural Networks” (Sutskever et al., 2014)

• Contribution: Proved that LSTM + Beam Search could beat state-of-the-art SMT (Statistical Machine Translation) systems.

Appendix D: Full Python Implementation of Nucleus Sampling

While Beam Search is great for accuracy, Nucleus Sampling is the gold standard for creativity (chatbots).

import torch
import torch.nn.functional as F

def top_p_sampling(logits, p=0.9, temperature=1.0):
    """
    logits: [batch_size, vocab_size]
    p: cumulative probability threshold (e.g., 0.9)
    temperature: softmax temperature
    """
    # 1. Apply Temperature
    logits = logits / temperature

    # 2. Sort logits in descending order
    sorted_logits, sorted_indices = torch.sort(logits, descending=True)

    # 3. Compute cumulative probabilities
    cumulative_probs = torch.cumsum(F.softmax(sorted_logits, dim=-1), dim=-1)

    # 4. Create a mask for tokens to remove
    # We want to keep tokens where cumulative_prob <= p
    # But we must always keep the first token (even if its prob > p)
    sorted_indices_to_remove = cumulative_probs > p

    # Shift the mask to the right to keep the first token above the threshold
    sorted_indices_to_remove[..., 1:] = sorted_indices_to_remove[..., :-1].clone()
    sorted_indices_to_remove[..., 0] = 0

    # 5. Scatter the mask back to the original indices
    indices_to_remove = sorted_indices_to_remove.scatter(1, sorted_indices, sorted_indices_to_remove)

    # 6. Set logits of removed tokens to -infinity
    logits[indices_to_remove] = float('-inf')

    # 7. Sample from the filtered distribution
    probs = F.softmax(logits, dim=-1)
    next_token = torch.multinomial(probs, num_samples=1)

    return next_token

Conclusion

Beam Search is the “Minimum Path Sum” of the NLP world. It’s a graph search algorithm designed to find the optimal path through a probabilistic space.

As an ML Engineer, you won’t just call model.generate(). You will tune K, implement length penalties, and optimize the KV-cache to balance the delicate trade-off between Latency (cost) and Quality (BLEU score).

Key Takeaways:

1. Greedy is fast but risky.
2. Beam Search is standard for “correctness” tasks.
3. Length Normalization is mandatory.
4. KV Caching is essential for speed.

---

Originally published at: arunbaby.com/ml-system-design/0023-beam-search-decoding

If you found this helpful, consider sharing it with others who might benefit.
