Experiment Tracking Systems

Design robust experiment tracking systems that enable systematic exploration, reproducibility, and collaboration across large ML teams.

Problem Statement

Design an Experiment Tracking System for ML teams that:

1. Tracks all experiment metadata: hyperparameters, metrics, code versions, data versions, artifacts
2. Supports large scale: Thousands of experiments, millions of runs, petabyte-scale model artifacts
3. Enables comparison and visualization: Compare runs, plot learning curves, analyze hyperparameter impact
4. Ensures reproducibility: Any experiment can be re-run from tracked metadata
5. Integrates with training pipelines: Minimal code changes, automatic logging
6. Supports collaboration: Share experiments, notebook integration, API access

Functional Requirements

1. Experiment lifecycle management:
   • Create experiments and runs
   • Log parameters, metrics, tags, notes
   • Upload artifacts (models, plots, datasets)
   • Track code versions (Git commit, diff)
   • Track data versions (dataset hashes, splits)
   • Link parent/child runs (hyperparameter sweeps, ensemble members)
2. Query and search:
   • Filter by parameters, metrics, tags
   • Full-text search over notes and descriptions
   • Query by date, user, project
3. Visualization and comparison:
   • Learning curves (metric vs step/epoch)
   • Hyperparameter sweeps (parallel coordinates, scatter)
   • Compare multiple runs side-by-side
   • Export to notebooks (Jupyter, Colab)
4. Artifact management:
   • Store and version models, checkpoints, plots
   • Efficient storage for large artifacts (deduplication, compression)
   • Support for streaming logs (real-time metrics)
5. Reproducibility:
   • Capture full environment (packages, hardware, Docker image)
   • Re-run experiments from tracked metadata
   • Audit trail for compliance
6. Integration:
   • Python SDK (PyTorch, TensorFlow, JAX)
   • CLI for automation
   • REST API for custom clients
   • Webhook/notification support

Non-Functional Requirements

1. Scalability: Support 10K+ concurrent experiments, 1M+ total runs
2. Performance: Log metrics with <10ms latency, query results in <1s
3. Reliability: 99.9% uptime, no data loss
4. Security: Role-based access control, encryption at rest and in transit
5. Cost efficiency: Optimize storage costs for artifacts (tiered storage, compression)

Understanding the Requirements

Why Experiment Tracking Matters

Without systematic tracking, ML teams face:

• Lost experiments: “Which hyperparameters gave us 92% accuracy last month?”
• Wasted compute: Re-running experiments accidentally
• Non-reproducibility: “It worked on my laptop, but we can’t reproduce it”
• Collaboration friction: Hard to share and compare results

A good experiment tracking system is the foundation of MLOps—it enables:

• Systematic exploration of model/data/hyperparameter spaces
• Clear audit trails for model governance
• Faster iteration through better visibility

The Systematic Iteration Connection

Just like Spiral Matrix systematically traverses a 2D structure layer-by-layer:

• Experiment tracking systematically explores multi-dimensional spaces:
  • Hyperparameters × architectures × data configurations × training schedules
• Both require clear state management:
  • Spiral: track boundaries (top, bottom, left, right)
  • Experiments: track runs (completed, running, failed), checkpoints, metrics
• Both enable resumability:
  • Spiral: can pause and resume traversal
  • Experiments: can restart from checkpoints, resume sweeps

High-Level Architecture

┌─────────────────────────────────────────────────────────────────┐
│                  Experiment Tracking System                      │
└─────────────────────────────────────────────────────────────────┘

                            Client Layer
        ┌────────────────────────────────────────────┐
        │  Python SDK  │  CLI  │  Web UI  │  API    │
        └─────────────────────┬──────────────────────┘
                              │
                       API Gateway
                ┌──────────────┴──────────────┐
                │  - Auth & rate limiting      │
                │  - Request routing           │
                │  - Logging & monitoring      │
                └──────────────┬──────────────┘
                               │
              ┌────────────────┼────────────────┐
              │                │                │
      ┌───────▼────────┐ ┌────▼─────┐ ┌───────▼────────┐
      │  Metadata      │ │  Metrics │ │  Artifact      │
      │  Service       │ │  Service │ │  Service       │
      │                │ │          │ │                │
      │ - Experiments  │ │ - Logs   │ │ - Models       │
      │ - Runs         │ │ - Curves │ │ - Plots        │
      │ - Parameters   │ │ - Scalars│ │ - Datasets     │
      │ - Tags         │ │ - Hists  │ │ - Checkpoints  │
      └───────┬────────┘ └────┬─────┘ └───────┬────────┘
              │               │                │
      ┌───────▼────────┐ ┌────▼─────┐ ┌───────▼────────┐
      │  Postgres /    │ │  TimeSeries│ │  Object Store │
      │  MySQL         │ │  DB        │ │  (S3/GCS)     │
      │                │ │  (InfluxDB)│ │                │
      │ - Structured   │ │ - Metrics  │ │ - Large files │
      │   metadata     │ │ - Fast     │ │ - Versioned   │
      └────────────────┘ │   queries  │ │ - Deduped     │
                         └────────────┘ └────────────────┘

Key Components

1. Metadata Service:
   • Stores experiment and run metadata (params, tags, code versions, user, etc.)
   • Relational DB for structured queries
   • Indexes on common query patterns (user, project, date, tags)
2. Metrics Service:
   • High-throughput metric logging (train loss, val accuracy, etc.)
   • Time-series database (InfluxDB, Prometheus, or custom)
   • Support for streaming metrics (real-time plots)
3. Artifact Service:
   • Stores large files (models, checkpoints, plots, datasets)
   • Object storage (S3, GCS, Azure Blob)
   • Deduplication (hash-based), compression, tiered storage
4. API Gateway:
   • Authentication & authorization (OAuth, API keys)
   • Rate limiting (per user/project)
   • Request routing and load balancing
5. Web UI:
   • Dashboards for experiments, runs, metrics
   • Comparison tools (side-by-side, parallel coordinates)
   • Notebook integration (export to Jupyter)

Component Deep-Dive

1. Metadata Schema

Experiments group related runs (e.g., “ResNet ablation study”).

Runs are individual training jobs with:

• Unique run ID
• Parameters (hyperparameters, model config)
• Metrics (logged scalars, step-indexed)
• Tags (labels for filtering)
• Code version (Git commit, diff)
• Data version (dataset hash, split config)
• Environment (Python packages, Docker image, hardware)
• Artifacts (model files, plots, logs)
• Status (running, completed, failed)
• Timestamps (start, end)

Schema example (simplified):

CREATE TABLE experiments (
    experiment_id UUID PRIMARY KEY,
    name VARCHAR(255),
    description TEXT,
    created_at TIMESTAMP,
    user_id VARCHAR(255),
    project_id UUID
);

CREATE TABLE runs (
    run_id UUID PRIMARY KEY,
    experiment_id UUID REFERENCES experiments(experiment_id),
    name VARCHAR(255),
    status VARCHAR(50),  -- running, completed, failed
    start_time TIMESTAMP,
    end_time TIMESTAMP,
    user_id VARCHAR(255),
    git_commit VARCHAR(40),
    git_diff TEXT,
    docker_image VARCHAR(255),
    environment JSONB,  -- packages, hardware
    notes TEXT
);

CREATE TABLE run_params (
    run_id UUID REFERENCES runs(run_id),
    key VARCHAR(255),
    value TEXT,  -- JSON serialized
    PRIMARY KEY (run_id, key)
);

CREATE TABLE run_metrics (
    run_id UUID REFERENCES runs(run_id),
    key VARCHAR(255),  -- e.g., 'train_loss', 'val_accuracy'
    step INT,
    value FLOAT,
    timestamp TIMESTAMP,
    PRIMARY KEY (run_id, key, step)
);

CREATE TABLE run_tags (
    run_id UUID REFERENCES runs(run_id),
    key VARCHAR(255),
    value VARCHAR(255),
    PRIMARY KEY (run_id, key)
);

CREATE TABLE run_artifacts (
    artifact_id UUID PRIMARY KEY,
    run_id UUID REFERENCES runs(run_id),
    path VARCHAR(1024),  -- e.g., 'model.pt', 'plots/loss.png'
    size_bytes BIGINT,
    content_hash VARCHAR(64),  -- SHA-256
    storage_uri TEXT,  -- S3 URI
    created_at TIMESTAMP
);

2. Python SDK (Client Interface)

import experiment_tracker as et

# Initialize client
client = et.Client(api_url="https://tracking.example.com", api_key="...")

# Create experiment
experiment = client.create_experiment(
    name="ResNet50 ImageNet Ablation",
    description="Testing different optimizers and learning rates"
)

# Start a run
run = experiment.start_run(
    name="run_adam_lr0.001",
    tags={"optimizer": "adam", "dataset": "imagenet"}
)

# Log parameters
run.log_params({
    "model": "resnet50",
    "optimizer": "adam",
    "learning_rate": 0.001,
    "batch_size": 256,
    "epochs": 90
})

# Training loop
for epoch in range(90):
    train_loss = train_one_epoch(model, optimizer, train_loader)
    val_acc = validate(model, val_loader)

    # Log metrics
    run.log_metrics({
        "train_loss": train_loss,
        "val_accuracy": val_acc
    }, step=epoch)

# Save model
run.log_artifact("model.pt", local_path="./checkpoints/model_epoch90.pt")

# Mark run as complete
run.finish()

3. Metric Logging & Streaming

For real-time metric visualization:

• Clients send metrics via WebSocket or HTTP streaming
• Metrics Service buffers and batches writes to time-series DB
• Web UI subscribes to metric streams for live plots

# Streaming metrics example
def train_with_streaming_metrics(model, run):
    for step, batch in enumerate(train_loader):
        loss = train_step(model, batch)

        # Log every N steps for live tracking
        if step % 10 == 0:
            run.log_metric("train_loss", loss, step=step)
            # Internally: buffered, batched, sent asynchronously

4. Artifact Storage & Deduplication

Challenge: Models can be GBs–TBs. Storing every checkpoint is expensive.

Solution:

• Content-based deduplication:
  • Hash each artifact (SHA-256).
  • If hash exists, create metadata entry but don’t re-upload.
• Tiered storage:
  • Hot: Recent artifacts on fast storage (SSD, S3 standard).
  • Cold: Old artifacts on cheaper storage (S3 Glacier, tape).
• Compression:
  • Compress models before upload (gzip, zstd).

import hashlib
import gzip

def upload_artifact(run_id: str, path: str, local_file: str):
    # Compute hash
    with open(local_file, 'rb') as f:
        content = f.read()
        content_hash = hashlib.sha256(content).hexdigest()

    # Check if artifact with this hash exists
    existing = artifact_service.get_by_hash(content_hash)
    if existing:
        # Create metadata entry pointing to existing storage
        artifact_service.link_artifact(run_id, path, existing.storage_uri, content_hash)
        return

    # Compress and upload
    compressed = gzip.compress(content)
    storage_uri = object_store.upload(f"{run_id}/{path}.gz", compressed)

    # Create metadata entry
    artifact_service.create_artifact(
        run_id=run_id,
        path=path,
        size_bytes=len(content),
        content_hash=content_hash,
        storage_uri=storage_uri
    )

5. Query & Search

Common queries:

• “Show all runs with learning_rate > 0.01 and val_accuracy > 0.9”
• “Find best run in experiment X by val_accuracy”
• “Show runs created in last 7 days by user Y”

Implementation:

# Query API example
runs = client.search_runs(
    experiment_ids=["exp123"],
    filter_string="params.learning_rate > 0.01 AND metrics.val_accuracy > 0.9",
    order_by=["metrics.val_accuracy DESC"],
    max_results=10
)

for run in runs:
    print(f"Run {run.run_id}: LR={run.params['learning_rate']}, Acc={run.metrics['val_accuracy']}")

Optimization:

• Index on common filter fields (user_id, experiment_id, tags, status, timestamps)
• Cache popular queries (top runs, recent runs)
• Use read replicas for heavy read workloads

Scaling Strategies

1. Sharding Experiments/Runs

For very large deployments:

• Shard metadata DB by experiment_id or user_id
• Each shard handles a subset of experiments
• API Gateway routes requests to correct shard

2. Metric Buffering & Batching

High-throughput training jobs can log metrics at high frequency (100s–1000s/sec):

• Client buffers metrics locally
• Batches and sends every N seconds or M metrics
• Server-side ingestion queue (Kafka, SQS) for further buffering

3. Artifact Caching

Frequently accessed artifacts (latest models, popular checkpoints):

• Cache in CDN (CloudFront, Fastly)
• Local cache on training nodes (NVMe SSD)
• Lazy loading: download only when accessed

4. Distributed Artifact Storage

For petabyte-scale artifact storage:

• Use distributed object stores (S3, GCS, Ceph)
• Implement multipart upload for large files
• Use pre-signed URLs for direct client-to-storage uploads (bypass API server)

Monitoring & Observability

Key Metrics

System metrics:

• Request latency (p50, p95, p99)
• Throughput (requests/sec, metrics logged/sec, artifacts uploaded/sec)
• Error rates (4xx, 5xx)
• Storage usage (DB size, object store size)

User metrics:

• Active experiments/runs
• Average metrics logged per run
• Average artifact size
• Query response times

Dashboards:

• Real-time experiment dashboard (running/completed/failed runs)
• System health dashboard (latency, error rates, resource usage)
• Cost dashboard (storage costs, compute costs)

Failure Modes & Mitigations

Failure Mode	Impact	Mitigation
Metadata DB down	Can’t create/query experiments	Read replicas, automatic failover, local caching
Object store unavailable	Can’t upload/download artifacts	Retry with exponential backoff, fallback to local storage
Metric ingestion backlog	Delayed metric visibility	Buffering, rate limiting, auto-scaling ingest workers
Lost run metadata	Experiment not reproducible	Periodic backups, transaction logs, write-ahead logs
Concurrent write conflicts	Metrics/artifacts overwritten	Optimistic locking, append-only logs
API rate limit hit	Client blocked	Exponential backoff, client-side buffering, increase limits

Real-World Case Study: Large-Scale ML Team

Scenario:

• 100+ ML engineers and researchers
• 50K+ experiments, 1M+ runs
• 10 PB of artifacts (models, datasets, checkpoints)
• Multi-cloud (AWS, GCP)

Architecture:

• Metadata: PostgreSQL with read replicas, sharded by experiment_id
• Metrics: InfluxDB cluster, 100K metrics/sec write throughput
• Artifacts: S3 + GCS with cross-region replication
• API: Kubernetes cluster with auto-scaling (10–100 pods)
• Web UI: React SPA, served via CDN

Key optimizations:

• Pre-signed URLs for large artifact uploads (direct to S3/GCS)
• Client-side metric buffering (log every 10 steps, batch send)
• Artifact deduplication (saved ~30% storage cost)
• Tiered storage (hot: S3 Standard, cold: S3 Glacier, ~50% cost reduction)

Outcomes:

• 99.95% uptime
• Median query latency: 120ms
• p99 metric log latency: 8ms
• $200K/year savings from deduplication and tiered storage

Cost Analysis

Example: Medium-Sized Team

Assumptions:

• 10 researchers
• 100 experiments/month, 1000 runs/month
• Average run: 10 GB artifacts, 10K metrics
• Retention: 2 years

Component	Cost/Month
Metadata DB (PostgreSQL RDS, db.r5.large)	$300
Metrics DB (InfluxDB Cloud)	$500
Object storage (S3, 10 TB)	$230
API compute (Kubernetes, 5 nodes)	$750
Data transfer	$100
Total	$1,880

Optimization levers:

• Deduplication: -20–30% storage cost
• Tiered storage: -30–50% storage cost (move old artifacts to Glacier)
• Reserved instances: -30% compute cost
• Compression: -50% storage and transfer cost

Advanced Topics

1. Hyperparameter Sweep Integration

Integrate with hyperparameter tuning libraries (Optuna, Ray Tune):

import optuna
import experiment_tracker as et

def objective(trial):
    run = experiment.start_run(name=f"trial_{trial.number}")

    # Suggest hyperparameters
    lr = trial.suggest_loguniform("learning_rate", 1e-5, 1e-1)
    batch_size = trial.suggest_categorical("batch_size", [32, 64, 128])

    run.log_params({"learning_rate": lr, "batch_size": batch_size})

    # Train and log metrics
    val_acc = train_and_evaluate(lr, batch_size, run)

    run.finish()
    return val_acc

study = optuna.create_study(direction="maximize")
study.optimize(objective, n_trials=100)

2. Model Registry Integration

Link experiment tracking with model registry:

• Best run → promoted to staging → production
• Track lineage: model → run → experiment → dataset

3. Data Versioning

Track data versions alongside experiments:

• Dataset hash (content-based)
• Data pipeline version (Git commit)
• Train/val/test split configs

run.log_dataset(
    name="imagenet_v2",
    hash="sha256:abc123...",
    split_config={"train": 0.8, "val": 0.1, "test": 0.1}
)

4. Compliance & Audit Trails

For regulated industries (healthcare, finance):

• Immutable experiment logs
• Audit trail for all changes (who, what, when)
• Data lineage tracking
• Access control and encryption

Practical Debugging & Operations Checklist

For Platform Engineers

• Monitor ingestion lag: Metrics should appear in UI within seconds of logging.
• Set up alerts: DB disk space >80%, API error rate >1%, artifact upload failures.
• Test disaster recovery: Can you restore from backups? Time to recover?
• Load test: Can the system handle 10x current load?

For ML Engineers

• Always log hyperparameters: Even “fixed” ones—you’ll want to compare later.
• Use tags liberally: Makes filtering/searching much easier.
• Log environment: Git commit, Docker image, package versions—critical for reproducibility.
• Log artifacts incrementally: Don’t wait until end of training to upload checkpoints.
• Use run names: Descriptive names make comparison easier (resnet50_adam_lr0.001 vs run_42).

Key Takeaways

✅ Experiment tracking is foundational for MLOps—enables reproducibility, collaboration, and systematic exploration.

✅ Scale requires separation of concerns: metadata, metrics, artifacts each have different storage/query needs.

✅ Deduplication and tiered storage are critical for cost efficiency at scale.

✅ Client-side buffering avoids overwhelming the backend with high-frequency metric logging.

✅ Systematic iteration through experiment spaces mirrors structured traversal patterns (like Spiral Matrix).

✅ Integration with existing tools (Git, Docker, hyperparameter tuning) is key for adoption.

✅ Observability and cost monitoring are as important as core functionality.

Connection to Thematic Link: Systematic Iteration and State Tracking

All three Day 19 topics converge on systematic, stateful exploration:

DSA (Spiral Matrix):

• Layer-by-layer traversal with boundary tracking
• Explicit state management (top, bottom, left, right)
• Resume/pause friendly

ML System Design (Experiment Tracking Systems):

• Systematic exploration of hyperparameter/architecture spaces
• Track state of experiments (running, completed, failed)
• Resume from checkpoints, recover from failures

Speech Tech (Speech Experiment Management):

• Organize speech model experiments across multiple dimensions
• Track model versions, data versions, training configs
• Enable reproducibility and comparison

The unifying pattern: structured iteration through complex spaces, with clear state persistence and recoverability.

---

Originally published at: arunbaby.com/ml-system-design/0019-experiment-tracking-systems

If you found this helpful, consider sharing it with others who might benefit.
