Resource Allocation for ML
Build production ML infrastructure that dynamically allocates resources using greedy optimization to maximize throughput and minimize costs.
Problem Statement
Design a Resource Allocation System for ML that efficiently manages compute resources (CPUs, GPUs, memory, storage) across hundreds of ML models and workflows.
Functional Requirements
- Dynamic allocation: Assign resources to training/inference jobs based on priority, deadlines, and resource availability
- Multi-tenancy: Support multiple teams/projects with fair resource sharing
- Cost optimization: Minimize cloud spending while meeting SLAs
- Auto-scaling: Scale resources up/down based on demand
- Resource types: Handle heterogeneous resources (different GPU types, CPU configurations)
- Queue management: Prioritize jobs intelligently
- Preemption: Allow high-priority jobs to preempt lower-priority ones
- Monitoring: Track resource utilization and costs in real-time
Non-Functional Requirements
- Latency: Resource allocation decisions in <100ms
- Utilization: >80% GPU utilization during peak hours
- Fairness: No team monopolizes resources
- Availability: 99.9% uptime
- Scale: Support 1000+ concurrent jobs, 10K+ GPUs
- Cost efficiency: Reduce cloud spending by 30-50% through optimization
- Elasticity: Handle 10x traffic spikes
Understanding the Requirements
This is the infrastructure backbone of any ML organization. Poor resource allocation leads to:
- Wasted money: Idle GPUs cost $1-3/hour each
- Slow iteration: Researchers waiting hours for resources
- Missed deadlines: Production models not trained on time
- Unfairness: Some teams starve while others over-provision
Scale Context
At a typical large tech company:
- Google/Meta: 100K+ GPUs, millions of training jobs/month
- Uber/Netflix: 10K+ GPUs, thousands of models in production
- Startup (Series B+): 100-1000 GPUs, hundreds of models
Cost implications:
- A100 GPU: ~$3/hour on AWS/GCP
- 1000 GPUs at 50% utilization waste: $1.5M/month
- Goal: Increase utilization from 50% → 85% saves $1M+/month
Key Challenges
- Heterogeneous resources: V100 vs A100 vs H100, different memory sizes
- Variable job durations: 5-minute inference vs 3-day training
- Priority conflicts: Production inference vs experimental training
- Resource fragmentation: Many small jobs prevent large jobs from running
- Multi-dimensional constraints: GPU + memory + network bandwidth
- Cost vs performance: Spot instances are cheap but can be preempted
The Greedy Optimization Connection
Just like the Container With Most Water problem:
| Container Problem | Resource Allocation |
|---|---|
| Two lines (heights) | Multiple resource constraints (GPU/memory) |
| Bottleneck (shorter line) | Resource bottleneck (GPU/memory/bandwidth) |
| Maximize area | Maximize utilization × performance |
| Greedy choice: move shorter pointer | Greedy choice: allocate to bottleneck first |
| O(N) efficiency | O(N) scheduling decisions |
Core insight: The bottleneck resource determines system throughput, so optimize for it first.
High-Level Architecture
┌─────────────────────────────────────────────────────────────────┐
│ Resource Allocation System │
└─────────────────────────────────────────────────────────────────┘
┌─────────────┐ ┌──────────────────────────────────────┐
│ Clients │ │ Control Plane │
│ │ │ │
│ - Training │────────▶│ ┌────────────────────────────┐ │
│ - Inference │ │ │ Scheduler │ │
│ - Tuning │ │ │ - Job queue │ │
│ - Batch │ │ │ - Priority management │ │
└─────────────┘ │ │ - Resource matching │ │
│ └────────────┬───────────────┘ │
│ │ │
│ ▼ │
│ ┌────────────────────────────┐ │
│ │ Allocator (Greedy) │ │
┌─────────────┐ │ │ - Bin packing │ │
│ Monitoring │◀────────│ │ - Preemption logic │ │
│ │ │ │ - Fair share calculation │ │
│ - Prometheus│ │ └────────────┬───────────────┘ │
│ - Grafana │ │ │ │
│ - Alerts │ │ ▼ │
└─────────────┘ │ ┌────────────────────────────┐ │
│ │ Resource Manager │ │
│ │ - Available resources │ │
│ │ - Usage tracking │ │
│ │ - Cost accounting │ │
│ └────────────┬───────────────┘ │
└───────────────┼────────────────────┘
│
▼
┌──────────────────────────────────────────────────────────────┐
│ Data Plane │
│ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ Cluster 1 │ │ Cluster 2 │ │ Cluster N │ │
│ │ │ │ │ │ │ │
│ │ ┌───────┐ │ │ ┌───────┐ │ │ ┌───────┐ │ │
│ │ │GPU Pod│ │ │ │GPU Pod│ │ │ │GPU Pod│ │ │
│ │ └───────┘ │ │ └───────┘ │ │ └───────┘ │ │
│ │ ┌───────┐ │ │ ┌───────┐ │ │ ┌───────┐ │ │
│ │ │GPU Pod│ │ │ │CPU Pod│ │ │ │TPU Pod│ │ │
│ │ └───────┘ │ │ └───────┘ │ │ └───────┘ │ │
│ │ │ │ │ │ │ │
│ │ us-west-1 │ │ us-east-1 │ │ eu-west-1 │ │
│ └─────────────┘ └─────────────┘ └─────────────┘ │
└──────────────────────────────────────────────────────────────┘
Key Components
- Scheduler: Receives jobs, manages queue, makes assignment decisions
- Allocator: Implements greedy bin-packing algorithm
- Resource Manager: Tracks available resources across clusters
- Monitoring: Real-time metrics and cost tracking
- Data Plane: Kubernetes clusters running actual ML workloads
Component Deep-Dives
1. Scheduler - Job Queue and Prioritization
The scheduler maintains a priority queue of pending jobs and makes allocation decisions.
from dataclasses import dataclass
from enum import Enum
from typing import List, Optional, Dict
from datetime import datetime, timedelta
import heapq
class JobPriority(Enum):
"""Job priority levels."""
CRITICAL = 0 # Production inference (P0)
HIGH = 1 # Production training (P1)
MEDIUM = 2 # Experimentation (P2)
LOW = 3 # Batch processing (P3)
PREEMPTIBLE = 4 # Can be killed anytime
@dataclass
class ResourceRequest:
"""Resources needed for a job."""
cpus: int
memory_gb: int
gpus: int
gpu_type: str # "V100", "A100", "H100"
disk_gb: int
def __hash__(self):
return hash((self.cpus, self.memory_gb, self.gpus, self.gpu_type))
@dataclass
class Job:
"""ML job to be scheduled."""
job_id: str
user_id: str
team_id: str
priority: JobPriority
resources: ResourceRequest
estimated_duration_hours: float
deadline: Optional[datetime]
submitted_at: datetime
started_at: Optional[datetime] = None
can_preempt: bool = False
def __lt__(self, other):
"""
Priority comparison for heap queue.
Sorting criteria (in order):
1. Priority level (lower is better)
2. Deadline proximity (earlier deadline wins)
3. Submission time (FIFO for same priority)
"""
if self.priority != other.priority:
return self.priority.value < other.priority.value
# If both have deadlines, prioritize closer deadline
if self.deadline and other.deadline:
return self.deadline < other.deadline
# Jobs with deadlines beat those without
if self.deadline:
return True
if other.deadline:
return False
# FIFO for same priority
return self.submitted_at < other.submitted_at
@property
def wait_time(self) -> timedelta:
"""How long has this job been waiting?"""
if self.started_at:
return self.started_at - self.submitted_at
return datetime.now() - self.submitted_at
@property
def is_deadline_critical(self) -> bool:
"""Is this job close to missing its deadline?"""
if not self.deadline:
return False
time_until_deadline = self.deadline - datetime.now()
return time_until_deadline < timedelta(hours=self.estimated_duration_hours * 1.5)
class JobScheduler:
"""
Priority-based job scheduler with fair share and preemption.
Greedy strategy:
1. Prioritize high-priority jobs
2. Within same priority, consider deadlines and wait time
3. Implement fair share to prevent starvation
4. Preempt low-priority jobs for critical ones
"""
def __init__(self, fair_share_window_hours: int = 24):
self.pending_jobs: List[Job] = [] # Min heap by priority
self.running_jobs: Dict[str, Job] = {}
self.fair_share_window = timedelta(hours=fair_share_window_hours)
self.team_usage: Dict[str, float] = {} # GPU-hours used
self.team_quotas: Dict[str, float] = {} # GPU-hours quota
heapq.heapify(self.pending_jobs)
def submit_job(self, job: Job):
"""
Submit a new job to the scheduler.
Why heap?
- O(log N) insertion
- O(1) to peek highest priority
- Automatically maintains priority order
"""
heapq.heappush(self.pending_jobs, job)
def get_next_job(self, available_resources: ResourceRequest) -> Optional[Job]:
"""
Get the next job to schedule using greedy algorithm.
Greedy strategy (like container problem):
1. Check highest priority job
2. If it fits, schedule it
3. If not, check if we can preempt lower-priority jobs
4. Consider fair share quotas
Time: O(log N) - heap operations
"""
if not self.pending_jobs:
return None
# Peek at highest priority job (don't pop yet)
candidate = self.pending_jobs[0]
# Check if resources are sufficient
if self._can_fit(candidate.resources, available_resources):
# Check fair share quota
if self._check_fair_share(candidate):
return heapq.heappop(self.pending_jobs)
# High-priority job can't fit - check for preemption
if candidate.priority in [JobPriority.CRITICAL, JobPriority.HIGH]:
preempt_candidate = self._find_preemptible_job(candidate.resources)
if preempt_candidate:
# Preempt lower-priority job
self._preempt_job(preempt_candidate)
return heapq.heappop(self.pending_jobs)
# Try to find smaller job that fits (avoid fragmentation)
for i, job in enumerate(self.pending_jobs):
if self._can_fit(job.resources, available_resources):
if self._check_fair_share(job):
# Remove from middle of heap (O(N) worst case)
self.pending_jobs[i] = self.pending_jobs[-1]
self.pending_jobs.pop()
heapq.heapify(self.pending_jobs)
return job
return None
def _can_fit(self, request: ResourceRequest, available: ResourceRequest) -> bool:
"""
Check if requested resources fit in available resources.
All dimensions must fit (like multi-dimensional bin packing).
"""
return (
request.cpus <= available.cpus and
request.memory_gb <= available.memory_gb and
request.gpus <= available.gpus and
(request.gpu_type == available.gpu_type or available.gpu_type == "any") and
request.disk_gb <= available.disk_gb
)
def _check_fair_share(self, job: Job) -> bool:
"""
Check if team is within their fair share quota.
Prevent one team from monopolizing resources.
"""
if job.team_id not in self.team_quotas:
return True # No quota set
current_usage = self.team_usage.get(job.team_id, 0.0)
quota = self.team_quotas[job.team_id]
# Allow critical jobs to exceed quota
if job.priority == JobPriority.CRITICAL:
return True
# Check if within quota (with 10% grace)
return current_usage < quota * 1.1
def _find_preemptible_job(self, needed: ResourceRequest) -> Optional[str]:
"""
Find a running job that can be preempted to free resources.
Greedy choice: preempt lowest-priority job that frees enough resources.
"""
preemptible = [
(job_id, job)
for job_id, job in self.running_jobs.items()
if job.can_preempt and job.priority == JobPriority.PREEMPTIBLE
]
# Sort by least resource usage (preempt smallest job if possible)
preemptible.sort(key=lambda x: x[1].resources.gpus)
# Greedy: find first job that frees enough resources
for job_id, job in preemptible:
if self._can_fit(needed, job.resources):
return job_id
return None
def _preempt_job(self, job_id: str):
"""
Preempt a running job.
In production:
- Send SIGTERM, wait for graceful shutdown
- Save checkpoint if training job
- Re-queue job with higher priority
"""
job = self.running_jobs.pop(job_id)
# Re-queue with higher priority (prevent starvation)
job.priority = JobPriority.MEDIUM
job.submitted_at = datetime.now()
self.submit_job(job)
def mark_started(self, job: Job):
"""Mark job as started."""
job.started_at = datetime.now()
self.running_jobs[job.job_id] = job
def mark_completed(self, job_id: str):
"""Mark job as completed and update usage."""
if job_id in self.running_jobs:
job = self.running_jobs.pop(job_id)
# Update team usage for fair share
gpu_hours = job.resources.gpus * (
(datetime.now() - job.started_at).total_seconds() / 3600
)
self.team_usage[job.team_id] = self.team_usage.get(job.team_id, 0) + gpu_hours
2. Allocator - Greedy Bin Packing
The allocator implements a greedy algorithm to pack jobs onto available resources.
from typing import List, Dict, Tuple, Optional
@dataclass
class Node:
"""A compute node (e.g., GPU instance)."""
node_id: str
available: ResourceRequest
capacity: ResourceRequest
cost_per_hour: float
region: str
is_spot: bool = False # Spot/preemptible instance
@property
def utilization(self) -> float:
"""GPU utilization percentage."""
if self.capacity.gpus == 0:
return 0.0
return 1.0 - (self.available.gpus / self.capacity.gpus)
class ResourceAllocator:
"""
Greedy resource allocator using bin packing.
Similar to Container With Most Water:
- Multiple bins (nodes) with capacities
- Jobs to pack (containers to fill)
- Greedy choice: pack job to minimize waste
"""
def __init__(self):
self.nodes: Dict[str, Node] = {}
self.allocations: Dict[str, str] = {} # job_id -> node_id
def add_node(self, node: Node):
"""Add a compute node to the pool."""
self.nodes[node.node_id] = node
def allocate(self, job: Job) -> Optional[str]:
"""
Allocate resources for a job using greedy algorithm.
Greedy strategies (in order of preference):
1. Best fit: minimize wasted resources
2. First fit: fill nodes to capacity (consolidation)
3. Worst fit: spread load evenly
We use BEST FIT for cost efficiency.
Returns:
node_id if allocation successful, None otherwise
"""
best_node = None
min_waste = float('inf')
for node_id, node in self.nodes.items():
# Check if job fits
if not self._can_allocate(job.resources, node):
continue
# Calculate waste (remaining resources after allocation)
waste = self._calculate_waste(job.resources, node)
# Greedy choice: minimize waste (best fit)
if waste < min_waste:
min_waste = waste
best_node = node_id
if best_node:
self._allocate_to_node(job, best_node)
return best_node
return None
def allocate_multi_node(self, job: Job, max_nodes: int = 8) -> Optional[List[str]]:
"""
Allocate job across multiple nodes (for distributed training).
Greedy approach:
1. Find nodes with most available resources
2. Allocate greedily to top candidates
3. Prefer nodes in same region (reduce network latency)
"""
if max_nodes == 1:
node = self.allocate(job)
return [node] if node else None
# Calculate per-node resource requirement
gpus_per_node = (job.resources.gpus + max_nodes - 1) // max_nodes
per_node_request = ResourceRequest(
cpus=job.resources.cpus // max_nodes,
memory_gb=job.resources.memory_gb // max_nodes,
gpus=gpus_per_node,
gpu_type=job.resources.gpu_type,
disk_gb=job.resources.disk_gb // max_nodes
)
# Find candidate nodes
candidates = [
(node_id, node)
for node_id, node in self.nodes.items()
if self._can_allocate(per_node_request, node)
]
if len(candidates) < max_nodes:
return None # Not enough nodes
# Greedy: sort by region to co-locate
region_groups = {}
for node_id, node in candidates:
region_groups.setdefault(node.region, []).append((node_id, node))
# Pick largest region group
best_region = max(region_groups.keys(), key=lambda r: len(region_groups[r]))
best_nodes = region_groups[best_region][:max_nodes]
# Allocate to all nodes
allocated = []
for node_id, node in best_nodes:
self._allocate_to_node_partial(per_node_request, node_id)
allocated.append(node_id)
return allocated
def deallocate(self, job_id: str):
"""Release resources when job completes."""
if job_id not in self.allocations:
return
node_id = self.allocations.pop(job_id)
# In practice, restore node.available resources
def _can_allocate(self, request: ResourceRequest, node: Node) -> bool:
"""Check if request fits in node."""
return (
request.cpus <= node.available.cpus and
request.memory_gb <= node.available.memory_gb and
request.gpus <= node.available.gpus and
request.gpu_type == node.capacity.gpu_type and
request.disk_gb <= node.available.disk_gb
)
def _calculate_waste(self, request: ResourceRequest, node: Node) -> float:
"""
Calculate resource waste if we allocate request to node.
Waste metric: sum of fractional unused resources.
Lower waste = better fit.
"""
cpu_waste = (node.available.cpus - request.cpus) / node.capacity.cpus
mem_waste = (node.available.memory_gb - request.memory_gb) / node.capacity.memory_gb
gpu_waste = (node.available.gpus - request.gpus) / node.capacity.gpus if node.capacity.gpus > 0 else 0
# Weighted sum (GPU waste matters most)
return 0.5 * gpu_waste + 0.3 * mem_waste + 0.2 * cpu_waste
def _allocate_to_node(self, job: Job, node_id: str):
"""Actually allocate job to node."""
node = self.nodes[node_id]
# Decrease available resources
node.available.cpus -= job.resources.cpus
node.available.memory_gb -= job.resources.memory_gb
node.available.gpus -= job.resources.gpus
node.available.disk_gb -= job.resources.disk_gb
# Track allocation
self.allocations[job.job_id] = node_id
def _allocate_to_node_partial(self, request: ResourceRequest, node_id: str):
"""Allocate partial resources (for multi-node jobs)."""
node = self.nodes[node_id]
node.available.cpus -= request.cpus
node.available.memory_gb -= request.memory_gb
node.available.gpus -= request.gpus
node.available.disk_gb -= request.disk_gb
def get_utilization_stats(self) -> Dict:
"""Calculate cluster utilization statistics."""
total_gpus = sum(node.capacity.gpus for node in self.nodes.values())
used_gpus = sum(
node.capacity.gpus - node.available.gpus
for node in self.nodes.values()
)
return {
"total_gpus": total_gpus,
"used_gpus": used_gpus,
"utilization": used_gpus / total_gpus if total_gpus > 0 else 0,
"num_nodes": len(self.nodes),
"active_jobs": len(self.allocations)
}
3. Auto-Scaler - Dynamic Resource Provisioning
from typing import List
from dataclasses import dataclass
from datetime import datetime, timedelta
@dataclass
class ScalingPolicy:
"""Auto-scaling policy configuration."""
min_nodes: int
max_nodes: int
target_utilization: float = 0.80
scale_up_threshold: float = 0.90
scale_down_threshold: float = 0.50
cooldown_minutes: int = 5
class AutoScaler:
"""
Auto-scaler for dynamic resource provisioning.
Greedy scaling decisions:
- Scale up: when utilization > threshold OR queue is growing
- Scale down: when utilization < threshold AND queue is empty
"""
def __init__(self, policy: ScalingPolicy, allocator: ResourceAllocator):
self.policy = policy
self.allocator = allocator
self.last_scale_action = datetime.now()
self.pending_queue_size_history: List[int] = []
def should_scale_up(self, current_utilization: float, queue_size: int) -> bool:
"""
Decide if we should scale up.
Greedy conditions:
1. High utilization (>90%)
2. Growing queue
3. Not in cooldown period
"""
# Check cooldown
if (datetime.now() - self.last_scale_action).total_seconds() < self.policy.cooldown_minutes * 60:
return False
# Check if at max capacity
if len(self.allocator.nodes) >= self.policy.max_nodes:
return False
# High utilization trigger
if current_utilization > self.policy.scale_up_threshold:
return True
# Growing queue trigger
self.pending_queue_size_history.append(queue_size)
if len(self.pending_queue_size_history) > 5:
self.pending_queue_size_history.pop(0)
if len(self.pending_queue_size_history) >= 3:
# Queue is growing consistently
if all(
self.pending_queue_size_history[i] < self.pending_queue_size_history[i+1]
for i in range(len(self.pending_queue_size_history) - 1)
):
return True
return False
def should_scale_down(self, current_utilization: float, queue_size: int) -> bool:
"""
Decide if we should scale down.
Conservative approach:
- Only scale down if utilization is low AND queue is empty
- Respect minimum nodes
"""
# Check cooldown
if (datetime.now() - self.last_scale_action).total_seconds() < self.policy.cooldown_minutes * 60:
return False
# Check if at min capacity
if len(self.allocator.nodes) <= self.policy.min_nodes:
return False
# Low utilization and empty queue
return (
current_utilization < self.policy.scale_down_threshold and
queue_size == 0
)
def scale_up(self, num_nodes: int = 1) -> List[str]:
"""
Add nodes to the cluster.
In practice:
- Call cloud provider API (AWS/GCP/Azure)
- Choose instance type based on queue composition
- Prefer spot instances for cost savings
"""
new_nodes = []
for i in range(num_nodes):
node_id = f"node-{len(self.allocator.nodes) + i}"
# Create node (example: A100 instance)
node = Node(
node_id=node_id,
available=ResourceRequest(
cpus=32,
memory_gb=244,
gpus=8,
gpu_type="A100",
disk_gb=1000
),
capacity=ResourceRequest(
cpus=32,
memory_gb=244,
gpus=8,
gpu_type="A100",
disk_gb=1000
),
cost_per_hour=24.48, # AWS p4d.24xlarge pricing
region="us-west-2",
is_spot=True # Use spot for cost savings
)
self.allocator.add_node(node)
new_nodes.append(node_id)
self.last_scale_action = datetime.now()
return new_nodes
def scale_down(self, num_nodes: int = 1) -> List[str]:
"""
Remove nodes from the cluster.
Greedy choice: remove least utilized nodes first.
"""
# Find nodes with lowest utilization
nodes_by_util = sorted(
self.allocator.nodes.items(),
key=lambda x: x[1].utilization
)
removed = []
for node_id, node in nodes_by_util[:num_nodes]:
if node.available.gpus == node.capacity.gpus: # Fully idle
del self.allocator.nodes[node_id]
removed.append(node_id)
# In practice: call cloud API to terminate instance
if removed:
self.last_scale_action = datetime.now()
return removed
Data Flow
Job Submission to Completion
1. User submits job
└─> API validates request
└─> Scheduler adds to priority queue
2. Scheduler loop (every 1 second)
└─> Get next job from queue (greedy priority)
└─> Check resource availability
└─> If available: allocate
└─> If not: check preemption or wait
3. Allocator assigns job to node(s)
└─> Best fit bin packing
└─> Update node available resources
└─> Send job to Kubernetes
4. Job runs on GPU pod
└─> Training/inference executes
└─> Metrics streamed to monitoring
5. Job completes
└─> Resources released
└─> Usage logged for billing
└─> Fair share quotas updated
6. Auto-scaler (every 30 seconds)
└─> Check utilization
└─> Decide scale up/down
└─> Provision/deprovision nodes
Resource Allocation Decision Tree
Job arrives
│
├─> Priority: CRITICAL?
│ ├─> Yes: Preempt lower-priority jobs if needed
│ └─> No: Continue
│
├─> Resources available?
│ ├─> Yes: Allocate immediately (greedy)
│ └─> No: Continue
│
├─> Team within quota?
│ ├─> Yes: Continue
│ └─> No: Wait or reject
│
├─> Can preempt?
│ ├─> Yes: Preempt and allocate
│ └─> No: Add to queue
│
└─> Queue job by priority
Scaling Strategies
Horizontal Scaling
Challenge: How many nodes to add when scaling up?
def calculate_scale_up_nodes(queue: List[Job], current_nodes: int) -> int:
"""
Greedy calculation: how many nodes to add?
Strategy:
1. Calculate total resource requirements in queue
2. Divide by node capacity
3. Add 20% buffer
4. Cap at max_nodes
"""
if not queue:
return 0
# Aggregate resource needs
total_gpus_needed = sum(job.resources.gpus for job in queue)
total_memory_needed = sum(job.resources.memory_gb for job in queue)
# Assume 8 GPUs per node (A100 instance)
gpus_per_node = 8
nodes_for_gpus = (total_gpus_needed + gpus_per_node - 1) // gpus_per_node
# Add 20% buffer
nodes_to_add = int(nodes_for_gpus * 1.2)
return max(1, nodes_to_add)
Vertical Scaling
Challenge: Should we use bigger instances?
| Instance Type | GPUs | Memory | Cost/hr | Use Case |
|---|---|---|---|---|
| p3.2xlarge | 1×V100 | 61GB | $3.06 | Small jobs |
| p3.8xlarge | 4×V100 | 244GB | $12.24 | Medium jobs |
| p4d.24xlarge | 8×A100 | 1152GB | $32.77 | Large jobs |
| p5.48xlarge | 8×H100 | 2048GB | $98.32 | Frontier models |
Greedy choice: Match instance type to job requirements to minimize cost.
Handling Spot Instance Interruptions
class SpotInstanceManager:
"""
Manage spot/preemptible instances for cost savings.
Spot instances are 70-90% cheaper but can be interrupted.
"""
def __init__(self):
self.checkpointing_jobs: Dict[str, str] = {} # job_id -> checkpoint_path
def handle_interruption(self, node_id: str, notice_seconds: int = 120):
"""
Handle spot instance interruption (2-minute warning).
Greedy strategy:
1. Save checkpoints for training jobs
2. Re-queue jobs to on-demand instances
3. Prioritize critical jobs
"""
# Find jobs running on this node
jobs_on_node = [
job for job in running_jobs.values()
if job.node_id == node_id
]
for job in jobs_on_node:
if job.priority in [JobPriority.CRITICAL, JobPriority.HIGH]:
# Move to on-demand instance immediately
self._migrate_to_on_demand(job)
else:
# Save checkpoint and re-queue
self._checkpoint_and_requeue(job)
def _checkpoint_and_requeue(self, job: Job):
"""Save model checkpoint and re-queue job."""
# Trigger checkpoint save
checkpoint_path = f"s3://checkpoints/{job.job_id}/latest"
# ... save logic ...
# Re-queue with checkpoint resume
job.resume_from_checkpoint = checkpoint_path
scheduler.submit_job(job)
Implementation: Complete System
Here’s a simplified but functional implementation:
import asyncio
from typing import Dict, List
import logging
class MLResourceManager:
"""
Complete ML resource allocation system.
Integrates scheduler, allocator, and auto-scaler.
"""
def __init__(self, scaling_policy: ScalingPolicy):
self.scheduler = JobScheduler()
self.allocator = ResourceAllocator()
self.auto_scaler = AutoScaler(scaling_policy, self.allocator)
self.logger = logging.getLogger(__name__)
# Initialize with some nodes
self._bootstrap_cluster()
def _bootstrap_cluster(self):
"""Start with minimum nodes."""
for i in range(self.auto_scaler.policy.min_nodes):
node = Node(
node_id=f"node-{i}",
available=ResourceRequest(32, 244, 8, "A100", 1000),
capacity=ResourceRequest(32, 244, 8, "A100", 1000),
cost_per_hour=24.48,
region="us-west-2"
)
self.allocator.add_node(node)
async def run(self):
"""Main control loop."""
self.logger.info("Starting ML Resource Manager")
while True:
try:
# 1. Process pending jobs
await self._schedule_jobs()
# 2. Check auto-scaling
await self._check_scaling()
# 3. Update metrics
self._update_metrics()
# Sleep before next iteration
await asyncio.sleep(1)
except Exception as e:
self.logger.error(f"Error in control loop: {e}")
async def _schedule_jobs(self):
"""Schedule pending jobs to available resources."""
while True:
# Get available resources
stats = self.allocator.get_utilization_stats()
# Get next job
# Create aggregate ResourceRequest for available resources
# (simplified - in practice, check per-node)
total_available = self._get_total_available()
job = self.scheduler.get_next_job(total_available)
if not job:
break # No more jobs or no jobs fit
# Allocate resources
allocation = self.allocator.allocate(job)
if allocation:
self.scheduler.mark_started(job)
self.logger.info(f"Scheduled job {job.job_id} to node {allocation}")
# In production: submit to Kubernetes
await self._submit_to_k8s(job, allocation)
else:
# Put back in queue
self.scheduler.submit_job(job)
break
async def _check_scaling(self):
"""Check if we need to scale cluster."""
stats = self.allocator.get_utilization_stats()
queue_size = len(self.scheduler.pending_jobs)
if self.auto_scaler.should_scale_up(stats["utilization"], queue_size):
num_nodes = calculate_scale_up_nodes(
self.scheduler.pending_jobs,
stats["num_nodes"]
)
new_nodes = self.auto_scaler.scale_up(num_nodes)
self.logger.info(f"Scaled up: added {len(new_nodes)} nodes")
elif self.auto_scaler.should_scale_down(stats["utilization"], queue_size):
removed = self.auto_scaler.scale_down(1)
self.logger.info(f"Scaled down: removed {len(removed)} nodes")
def _get_total_available(self) -> ResourceRequest:
"""Get aggregate available resources."""
total_gpus = sum(node.available.gpus for node in self.allocator.nodes.values())
# Simplified: return max available for any single node
if not self.allocator.nodes:
return ResourceRequest(0, 0, 0, "none", 0)
max_node = max(self.allocator.nodes.values(), key=lambda n: n.available.gpus)
return max_node.available
async def _submit_to_k8s(self, job: Job, node_id: str):
"""Submit job to Kubernetes (placeholder)."""
# In production: create Kubernetes Job/Pod
# kubectl apply -f job.yaml
pass
def _update_metrics(self):
"""Update monitoring metrics."""
stats = self.allocator.get_utilization_stats()
# Send to Prometheus/Datadog
# metrics.gauge("ml.gpu.utilization", stats["utilization"])
# metrics.gauge("ml.queue.size", len(self.scheduler.pending_jobs))
pass
def submit_job(self, job: Job):
"""Public API to submit a job."""
self.scheduler.submit_job(job)
self.logger.info(f"Job {job.job_id} submitted")
# Usage example
async def main():
# Configure scaling policy
policy = ScalingPolicy(
min_nodes=2,
max_nodes=50,
target_utilization=0.80,
scale_up_threshold=0.90,
scale_down_threshold=0.50,
cooldown_minutes=5
)
# Create resource manager
manager = MLResourceManager(policy)
# Submit some jobs
for i in range(10):
job = Job(
job_id=f"job-{i}",
user_id="user1",
team_id="ml-team",
priority=JobPriority.MEDIUM,
resources=ResourceRequest(
cpus=8,
memory_gb=61,
gpus=1,
gpu_type="A100",
disk_gb=100
),
estimated_duration_hours=2.0,
deadline=None,
submitted_at=datetime.now(),
can_preempt=True
)
manager.submit_job(job)
# Run manager
await manager.run()
if __name__ == "__main__":
asyncio.run(main())
Monitoring & Metrics
Key Metrics to Track
class MetricsCollector:
"""Collect and export metrics for monitoring."""
def collect_metrics(self, manager: MLResourceManager) -> Dict:
"""Collect current system metrics."""
stats = manager.allocator.get_utilization_stats()
return {
# Resource utilization
"gpu_utilization": stats["utilization"],
"total_gpus": stats["total_gpus"],
"used_gpus": stats["used_gpus"],
"idle_gpus": stats["total_gpus"] - stats["used_gpus"],
# Queue metrics
"queue_size": len(manager.scheduler.pending_jobs),
"running_jobs": len(manager.scheduler.running_jobs),
# Performance metrics
"avg_wait_time_minutes": self._calculate_avg_wait_time(manager),
"p95_wait_time_minutes": self._calculate_p95_wait_time(manager),
# Cost metrics
"hourly_cost": self._calculate_hourly_cost(manager),
"cost_per_job": self._calculate_cost_per_job(manager),
# Fair share
"teams_over_quota": self._count_teams_over_quota(manager),
}
def _calculate_avg_wait_time(self, manager: MLResourceManager) -> float:
"""Average wait time for jobs in queue."""
if not manager.scheduler.pending_jobs:
return 0.0
total_wait = sum(
job.wait_time.total_seconds() / 60
for job in manager.scheduler.pending_jobs
)
return total_wait / len(manager.scheduler.pending_jobs)
def _calculate_hourly_cost(self, manager: MLResourceManager) -> float:
"""Current hourly cost of running cluster."""
return sum(
node.cost_per_hour
for node in manager.allocator.nodes.values()
)
Alerts to Configure
- High utilization: GPU utilization > 95% for 10+ minutes
- Low utilization: GPU utilization < 30% for 30+ minutes (wasting money)
- Long queue: >50 jobs waiting for >30 minutes
- Failed jobs: >10% job failure rate
- Cost spike: Hourly cost increases >50% from baseline
- Quota exceeded: Team uses >120% of quota
- Preemptions: >10 preemptions per hour (indicates resource pressure)
Failure Modes
1. Resource Fragmentation
Problem: Many small free slots but can’t fit large jobs.
def defragment_cluster(allocator: ResourceAllocator) -> int:
"""
Defragment cluster by migrating jobs to consolidate resources.
Greedy approach:
1. Find fragmented nodes (partial utilization)
2. Migrate small jobs to create large free nodes
3. Prioritize migration of preemptible jobs
"""
# Find nodes with <50% utilization
fragmented = [
(node_id, node)
for node_id, node in allocator.nodes.items()
if 0 < node.utilization < 0.5
]
migrations = 0
for node_id, node in fragmented:
# Try to migrate jobs off this node
# ... implementation ...
migrations += 1
return migrations
Solution:
- Periodic defragmentation
- Bin packing improvements (first-fit decreasing)
- Reserved nodes for large jobs
2. Priority Inversion
Problem: Low-priority job holds resources needed by high-priority job.
Solution:
- Preemption (implemented above)
- Priority aging (gradually increase priority of waiting jobs)
- Resource reservations for critical jobs
3. Spot Instance Interruptions
Problem: Spot instances terminated mid-job.
Solution:
- Checkpointing (every N minutes)
- Fallback to on-demand for critical jobs
- Distribute jobs across spot and on-demand mix
4. Quota Gaming
Problem: Teams submit fake jobs to consume quota before reset.
Solution:
- Rolling quotas (not daily reset)
- Job validation (reject suspiciously short jobs)
- Charge-back system with real money
5. Deadline Missed
Problem: Job with deadline doesn’t get scheduled in time.
Solution:
- Deadline-aware scheduling (EDF - Earliest Deadline First)
- Reserve capacity for deadline-critical jobs
- Alert teams early if deadline at risk
Real-World Case Study: Meta’s Resource Allocation
Meta’s Approach
Meta runs one of the world’s largest ML infrastructure:
- 100K+ GPUs across multiple data centers
- Millions of ML jobs per month
- Hundreds of teams competing for resources
Their solution:
- Twine: Resource allocation system
- Priority-based scheduling with fair share
- Dynamic bin packing across heterogeneous GPUs
- Supports preemption for critical jobs
- Fair Share Model:
- Each team gets base quota (proportional to headcount)
- Can burst above quota if resources available
- Long-running over-quota usage results in throttling
- Cost Attribution:
- Every GPU-hour tracked and charged to team budget
- Creates incentive to optimize job efficiency
- Teams can trade quota allocations
- Auto-scaling:
- Scales down underutilized clusters during off-hours
- Scales up aggressively during model release crunch times
- Predictive scaling based on historical patterns
Results:
- 85%+ GPU utilization (up from 60%)
- 40% cost reduction through spot instances and optimization
- <5 minute wait time for p95 of jobs
- $10M+ annual savings
Key Lessons
- Greedy works: Simple greedy bin packing beats complex optimizations
- Fair share essential: Prevents monopolization
- Cost visibility drives efficiency: When teams see costs, they optimize
- Preemption is necessary: For handling urgent production issues
- Heterogeneous resources are hard: V100 vs A100 vs H100 requires smart matching
Cost Analysis
Cost Breakdown
For a typical mid-size ML team (1000 GPUs):
| Component | Monthly Cost | Optimization |
|---|---|---|
| Compute (on-demand A100) | $1.8M | Use spot (-70%) → $540K |
| Storage (model checkpoints) | $50K | Lifecycle policies → $30K |
| Network (multi-region) | $20K | Co-location → $15K |
| Orchestration overhead | $10K | - |
| Total | $1.88M | $595K |
| Savings | 68% reduction |
Optimization Strategies
- Spot/Preemptible Instances:
- 70-90% cheaper than on-demand
- Risk: can be interrupted (2-min warning)
- Use for: training jobs with checkpointing
- Right-sizing:
- Match instance type to job requirements
- Don’t use 8-GPU instance for 1-GPU job
- Savings: 30-40%
- Off-peak Training:
- Schedule large training jobs during off-hours
- Take advantage of lower spot prices
- Savings: 20-30%
- Model Optimization:
- Quantization, pruning, distillation reduce compute needs
- Faster training → less GPU time
- Savings: 50%+ for inference
- Batch Processing:
- Batch multiple inference requests
- Increase GPU utilization from 30% → 85%
- Savings: 60%+
ROI Calculation
Investment in resource allocation system:
- Engineering: 3 engineers × 6 months = $300K
- Infrastructure: $50K/year
Returns (1000 GPU cluster):
- Before: 50% utilization, all on-demand = $1.8M/month
- After: 85% utilization, 70% spot = $595K/month
- Savings: $1.2M/month = $14.4M/year
ROI: 48x in first year!
Key Takeaways
✅ Resource allocation is a greedy optimization problem - like Container With Most Water, allocate to bottlenecks first
✅ Multi-dimensional bin packing is the core algorithm for job placement
✅ Priority queues with fair share prevent starvation and monopolization
✅ Auto-scaling based on utilization + queue length maintains efficiency
✅ Preemption is necessary for handling critical production jobs
✅ Spot instances + checkpointing save 70%+ on costs
✅ Monitoring and cost visibility drive team optimization behaviors
✅ Defragmentation prevents resource fragmentation waste
✅ Real-world systems use greedy algorithms because they’re fast and effective
✅ Similar principles apply to container optimization (DSA) and speech compute allocation
Connection to Thematic Link: Greedy Optimization and Resource Management
All three topics share the same core insight:
DSA (Container With Most Water):
- Greedy choice: move pointer at bottleneck (shorter line)
- Maximize area under constraints
ML System Design (Resource Allocation):
- Greedy choice: allocate to highest-priority job that fits
- Maximize utilization under budget constraints
Speech Tech (Compute Allocation):
- Greedy choice: allocate compute to slowest pipeline stage
- Maximize throughput under latency constraints
The bottleneck principle is universal: optimize the limiting factor first.
Originally published at: arunbaby.com/ml-system-design/0013-resource-allocation-for-ml
If you found this helpful, consider sharing it with others who might benefit.
