Voice Activity Detection (VAD)

“The art of knowing when to shut up.”

1. Introduction: The Turn-Taking Problem

In a text chat, the user hits “Enter”. This is an explicit signal: “I am done. Your turn.” It is a deterministic, boolean event. In voice, there is no “Enter” key. There is only Silence.

But silence is ambiguous.

• Silence (300ms): A comma. “I went to the store…” (thinking) “…and bought milk.”
• Silence (800ms): A period. “I went to the store.” (Done).

This creates the Turn-Taking Threshold Paradox:

• If the agent speaks at 400ms silence, it interrupts the user mid-thought. (Rude / “Aggressive”).
• If the agent waits for 1500ms silence, it feels slow and confused. (Dumb / “Laggy”).

Voice Activity Detection (VAD) is the algorithmic subsystem responsible for answering two questions:

1. “Is the user speaking right now?” (Binary State).
2. “Has the user finished speaking?” (State Transition).

---

2. The Physics of Sound

How do we detect speech without understanding words? We rely on the physical properties of the waveform.

2.1 Amplitude / Energy

The simplest method.

• Logic: Calculate Root Mean Square (RMS) of the audio amplitude. If RMS > Threshold, then Speech.
• Failures: A slamming door, typing on a keyboard, a fan, or a cough triggers it. Noise usually has high energy. It cannot distinguish a Human from a Truck.

2.2 Zero-Crossing Rate (ZCR)

Speech signals (especially vowels) oscillate at fundamental frequencies using the vocal cords. Noise is often chaotic. ZCR measures how often the waveform crosses the X-axis (0).

• Speech: Low/Stable ZCR.
• Noise: High/Random ZCR.

2.3 Frequency Analysis (FFT)

Human speech lives in specific bands (300Hz - 3400Hz).

• Logic: Run Fast Fourier Transform (FFT). If energy density is high in the 300-3400Hz band and low elsewhere, it’s likely speech.
• Failures: Music, TV background noise, or a Podcast playing in the background.

---

3. Algorithms: From Gaussian to Neural

3.1 WebRTC VAD (The Classic)

Google opened sourced the VAD from Chrome’s WebRTC stack.

• Algorithm: Gaussian Mixture Models (GMM). It learns the statistical distribution of “Speech” vs “Noise” frames dynamically.
• Pros: Ultra fast (C++). Runs in the browser using WASM. Almost zero CPU usage.
• Cons: Not Robust. It struggles with “Cocktail Party” noise (background chatter). It triggers easily on breathing.

3.2 Silero VAD (The Modern Standard)

Silero is a pre-trained Neural Network (Enterprise Grade).

• Algorithm: RNN/LSTM architecture trained on thousands of hours of speech and noise datasets.
• Pros: High accuracy. Can distinguish a cough from a word. Low latency (< 30ms chunk processing). Lightweight (runs on CPU).
• Output: A probability score 0.0 to 1.0.

---

4. Engineering the VAD State Machine

Using Silero gives you a probability stream. You must build a State Machine on top of it to separate “Bursts” from “Turns”.

4.1 The Parameters

Implementing VAD is about tuning three critical variables.

1. Probability Threshold:
   • Sensitivity. 0.5 is standard.
   • 0.8 eliminates heavy breathing but misses soft whispers.
2. Min Speech Duration (start_patience):
   • To trigger “Start of Turn”, sound must persist for X ms.
   • Setting: 250ms.
   • Why: Prevents “Clicks”, “Pops”, or short “Uhh” sounds from waking the agent.
3. Min Silence Duration (end_patience):
   • The most critical param. To trigger “End of Turn”, silence must persist for Y ms.
   • 700ms - 1000ms: Standard conversation.
   • 500ms: “Interrupt mode” (Very snappy, high false positive).
   • 2000ms: “Dictation mode” (User is thinking heavily).

4.2 Handling “Humming” and “Laughing”

Humans make non-speech sounds. “Hahaha”, “Mmhmm”.

• Strict VADs filter these out.
• Conversational Agents should hear these. “Mmhmm” is a “Backchannel” signal meaning “I am listening, continue.”
• Optimization: Detect Backchannels and do not trigger a full LLM response. Just continue speaking or stay silent.

---

5. Advanced: Semantic End-of-Turn

VAD is “Acoustic”. It relies on sound. It fails on Structural Incompleteness.

• User: “I want to buy…” (Silence 1s).
• Acoustic VAD: “Turn Over (Silence > 700ms).” Agent interrupts.
• User semantics: “Sentence incomplete.”

Solution: Hybrid VAD We use a small, fast Language Model (or a dedicated model like TurnGPT) to score the “Completeness” of the transcript.

• Logic:
  1. STT Stream: “I want to buy”
  2. Check: LLM.predict_completion("I want to buy").
  3. Result: Low (0.1).
  4. Action: Extend Silence Timeout dynamically from 700ms to 2000ms.
  5. User (after 1.5s): “…a ticket.”
  6. Check: LLM.predict_completion("I want to buy a ticket").
  7. Result: High (0.9).
  8. Action: Trigger Turn End immediately.

This allows for “Pacing”. The agent waits when you are thinking, and replies instantly when you are done.

---

6. Code: Implementing Silero VAD Wrapper

A robust Python wrapper for processing audio chunks.

import torch
import numpy as np

# Load Silero (JIT)
model, utils = torch.hub.load(repo_or_dir='snakers4/silero-vad', model='silero_vad')
(get_speech_timestamps, save_audio, read_audio, VADIterator, collect_chunks) = utils

class VADState:
    SILENCE = 0
    SPEECH = 1

class VADEngine:
    def __init__(self, threshold=0.5, min_silence_duration_ms=700):
        self.model = model
        self.threshold = threshold
        self.min_silence_samples = min_silence_duration_ms * 16 # assuming 16khz
        self.state = VADState.SILENCE
        self.silence_counter = 0

    def process_chunk(self, audio_chunk_bytes: bytes):
        """
        Input: 512 bytes of PCM Int16
        Output: Event (START, END, NONE)
        """
        # 1. Convert bytes to float32 tensor
        # Real implementation needs robust float conversion
        audio_int16 = np.frombuffer(audio_chunk_bytes, np.int16)
        # Normalize to -1.0 to 1.0
        audio_float32 = audio_int16.astype(np.float32) / 32768.0
        tensor = torch.from_numpy(audio_float32)

        # 2. Inference
        speech_prob = self.model(tensor, 16000).item()

        # 3. State Machine
        if self.state == VADState.SILENCE:
            if speech_prob > self.threshold:
                self.state = VADState.SPEECH
                self.silence_counter = 0
                return "SPEECH_START"

        elif self.state == VADState.SPEECH:
            if speech_prob < self.threshold:
                self.silence_counter += len(audio_int16) # Add duration
                if self.silence_counter > self.min_silence_samples:
                    self.state = VADState.SILENCE
                    self.silence_counter = 0
                    return "SPEECH_END"
            else:
                self.silence_counter = 0 # Reset if speech returns

        return "NONE"

---

7. Summary

VAD is the heartbeat of a Voice Agent. It defines the “Rhythm” of conversation.

• WebRTC VAD is fast but noisy.
• Silero VAD is the standard for robust detection.
• State Machines are required to handle the jitter of raw probabilities.
• Semantic Analysis prevents interrupting users who are thinking.

Beyond VAD, the frontier of voice is Real-Time Speech-to-Speech Agents, removing text from the loop entirely.
