Real-time Keyword Spotting
Build lightweight models that detect specific keywords in audio streams with minimal latency and power consumption for voice interfaces.
TL;DR
Keyword spotting enables always-on wake word detection (“Hey Siri”, “Alexa”) with sub-50ms latency and sub-1MB models on edge devices. Production systems use a two-stage pipeline: a tiny CNN (~50KB) screens continuously, then a larger model confirms detections, saving up to 90% battery. Key techniques include mel-spectrogram features, model quantization (INT8) for 4x speedup, binary search for optimal detection thresholds, and on-device personalization. Related: streaming speech pipelines for the audio transport layer and voice activity detection for silence detection fundamentals.
Introduction
Keyword spotting (KWS) detects specific words or phrases in continuous audio streams, enabling voice-activated interfaces.
Common applications:
- Wake word detection (“Hey Siri”, “Alexa”, “OK Google”)
- Voice commands (“Play”, “Stop”, “Next”)
- Accessibility features (voice navigation)
- Security (speaker verification)
Key requirements:
- Ultra-low latency: < 50ms detection time
- Low power: Run continuously on battery
- Small model: Fit on edge devices (< 1MB)
- High accuracy: < 1% false acceptance rate
- Noise robust: Work in real-world conditions
Problem Formulation
Task Definition
Given audio input, classify whether a target keyword is present:
Input: Audio waveform (e.g., 1 second, 16kHz = 16,000 samples)
Output: {keyword, no_keyword}
Example:
Audio: "Hey Siri, what's the weather?"
Output: keyword="hey_siri", timestamp=0.0s
Challenges
- Always-on constraint: Must run 24/7 without draining battery
- False positives: Accidental activations frustrate users
- False negatives: Missed detections break user experience
- Noise robustness: Background noise, music, TV
- Speaker variability: Different accents, ages, genders
System Architecture
┌─────────────────────────────────────────────────────────┐
│ Microphone Input │
└────────────────────┬────────────────────────────────────┘
│ Continuous audio stream
▼
┌────────────────────────┐
│ Audio Preprocessing │
│ - Noise reduction │
│ - Normalization │
└───────────┬────────────┘
│
▼
┌────────────────────────┐
│ Feature Extraction │
│ - MFCC / Mel-spec │
│ - Sliding window │
└───────────┬────────────┘
│
▼
┌────────────────────────┐
│ KWS Model (Tiny NN) │
│ - CNN / RNN / TCN │
│ - < 1MB, < 10ms │
└───────────┬────────────┘
│
▼
┌────────────────────────┐
│ Post-processing │
│ - Threshold / Smooth │
│ - Reject false pos │
└───────────┬────────────┘
│
▼
┌────────────────┐
│ Trigger Event │
│ (Wake system) │
└────────────────┘
Model Architectures
Approach 1: CNN-based KWS
Small convolutional network on spectrograms
import torch
import torch.nn as nn
class KeywordSpottingCNN(nn.Module):
"""
Lightweight CNN for keyword spotting
Input: Mel-spectrogram (n_mels, time_steps)
Output: Keyword confidence score
Model size: ~100KB
Inference time: ~5ms on CPU
"""
def __init__(self, n_mels=40, n_classes=2):
super().__init__()
# Convolutional layers
self.conv1 = nn.Sequential(
nn.Conv2d(1, 64, kernel_size=3, padding=1),
nn.BatchNorm2d(64),
nn.ReLU(),
nn.MaxPool2d(2)
)
self.conv2 = nn.Sequential(
nn.Conv2d(64, 64, kernel_size=3, padding=1),
nn.BatchNorm2d(64),
nn.ReLU(),
nn.MaxPool2d(2)
)
# Global average pooling
self.gap = nn.AdaptiveAvgPool2d((1, 1))
# Classifier
self.fc = nn.Linear(64, n_classes)
def forward(self, x):
"""
Args:
x: [batch, 1, n_mels, time_steps]
Returns:
[batch, n_classes]
"""
x = self.conv1(x)
x = self.conv2(x)
x = self.gap(x)
x = x.view(x.size(0), -1)
x = self.fc(x)
return x
# Create model
model = KeywordSpottingCNN(n_mels=40, n_classes=2)
# Count parameters
n_params = sum(p.numel() for p in model.parameters())
print(f"Model parameters: {n_params:,}") # ~30K parameters
# Estimate model size
model_size_mb = n_params * 4 / (1024 ** 2) # 4 bytes per float32
print(f"Model size: {model_size_mb:.2f} MB")
Approach 2: RNN-based KWS
Temporal modeling with GRU
class KeywordSpottingGRU(nn.Module):
"""
GRU-based keyword spotting
Better for temporal patterns, slightly larger
"""
def __init__(self, n_mels=40, hidden_size=64, n_layers=2, n_classes=2):
super().__init__()
self.gru = nn.GRU(
input_size=n_mels,
hidden_size=hidden_size,
num_layers=n_layers,
batch_first=True,
bidirectional=False # Unidirectional for streaming
)
self.fc = nn.Linear(hidden_size, n_classes)
def forward(self, x):
"""
Args:
x: [batch, time_steps, n_mels]
Returns:
[batch, n_classes]
"""
# GRU forward pass
out, hidden = self.gru(x)
# Use last hidden state
x = out[:, -1, :]
# Classifier
x = self.fc(x)
return x
model_gru = KeywordSpottingGRU(n_mels=40, hidden_size=64)
Approach 3: Temporal Convolutional Network
Efficient temporal modeling
class TemporalBlock(nn.Module):
"""Single temporal convolutional block"""
def __init__(self, n_inputs, n_outputs, kernel_size, dilation):
super().__init__()
self.conv1 = nn.Conv1d(
n_inputs, n_outputs, kernel_size,
padding=(kernel_size-1) * dilation // 2,
dilation=dilation
)
self.relu = nn.ReLU()
self.dropout = nn.Dropout(0.2)
# Residual connection
self.downsample = nn.Conv1d(n_inputs, n_outputs, 1) \
if n_inputs != n_outputs else None
def forward(self, x):
out = self.conv1(x)
out = self.relu(out)
out = self.dropout(out)
res = x if self.downsample is None else self.downsample(x)
return out + res
class KeywordSpottingTCN(nn.Module):
"""
Temporal Convolutional Network for KWS
Combines efficiency of CNNs with temporal modeling
"""
def __init__(self, n_mels=40, n_classes=2):
super().__init__()
self.blocks = nn.Sequential(
TemporalBlock(n_mels, 64, kernel_size=3, dilation=1),
TemporalBlock(64, 64, kernel_size=3, dilation=2),
TemporalBlock(64, 64, kernel_size=3, dilation=4),
)
self.gap = nn.AdaptiveAvgPool1d(1)
self.fc = nn.Linear(64, n_classes)
def forward(self, x):
"""
Args:
x: [batch, time_steps, n_mels]
Returns:
[batch, n_classes]
"""
# Transpose for conv1d: [batch, n_mels, time_steps]
x = x.transpose(1, 2)
# Temporal blocks
x = self.blocks(x)
# Global average pooling
x = self.gap(x).squeeze(-1)
# Classifier
x = self.fc(x)
return x
model_tcn = KeywordSpottingTCN(n_mels=40)
Feature Extraction Pipeline
import librosa
import numpy as np
class KeywordSpottingFeatureExtractor:
"""
Extract features for keyword spotting
Optimized for real-time processing
"""
def __init__(self, sample_rate=16000, window_size_ms=30,
hop_size_ms=10, n_mels=40):
self.sample_rate = sample_rate
self.n_fft = int(sample_rate * window_size_ms / 1000)
self.hop_length = int(sample_rate * hop_size_ms / 1000)
self.n_mels = n_mels
# Precompute mel filterbank
self.mel_basis = librosa.filters.mel(
sr=sample_rate,
n_fft=self.n_fft,
n_mels=n_mels,
fmin=0,
fmax=sample_rate / 2
)
def extract(self, audio):
"""
Extract mel-spectrogram features
Args:
audio: Audio samples [n_samples]
Returns:
Mel-spectrogram [n_mels, time_steps]
"""
# Compute STFT
stft = librosa.stft(
audio,
n_fft=self.n_fft,
hop_length=self.hop_length,
window='hann'
)
# Power spectrogram
power = np.abs(stft) ** 2
# Apply mel filterbank on power
mel_power = np.dot(self.mel_basis, power)
# Log compression (power → dB)
mel_db = librosa.power_to_db(mel_power, ref=np.max)
return mel_db
def extract_from_stream(self, audio_chunk):
"""
Extract features from streaming audio
Optimized for low latency
"""
return self.extract(audio_chunk)
# Usage
extractor = KeywordSpottingFeatureExtractor(sample_rate=16000)
# Extract features from 1-second audio
audio = np.random.randn(16000)
features = extractor.extract(audio)
print(f"Feature shape: {features.shape}") # (40, 101)
Training Pipeline
Data Preparation
import torch
from torch.utils.data import Dataset, DataLoader
import librosa
import numpy as np
class KeywordSpottingDataset(Dataset):
"""
Dataset for keyword spotting training
Handles positive (keyword) and negative (non-keyword) examples
"""
def __init__(self, audio_files, labels, feature_extractor,
augment=True):
self.audio_files = audio_files
self.labels = labels
self.feature_extractor = feature_extractor
self.augment = augment
def __len__(self):
return len(self.audio_files)
def __getitem__(self, idx):
# Load audio
audio, sr = librosa.load(
self.audio_files[idx],
sr=self.feature_extractor.sample_rate
)
# Pad or trim to 1 second
target_length = self.feature_extractor.sample_rate
if len(audio) < target_length:
audio = np.pad(audio, (0, target_length - len(audio)))
else:
audio = audio[:target_length]
# Data augmentation
if self.augment:
audio = self._augment(audio)
# Extract features
features = self.feature_extractor.extract(audio)
# Convert to tensor
features = torch.FloatTensor(features).unsqueeze(0) # Add channel dim
label = torch.LongTensor([self.labels[idx]])
return features, label
def _augment(self, audio):
"""
Data augmentation
- Add noise
- Time shift
- Speed perturbation
"""
# Add background noise
noise_level = np.random.uniform(0, 0.005)
noise = np.random.randn(len(audio)) * noise_level
audio = audio + noise
# Time shift
shift = np.random.randint(-1600, 1600) # ±100ms at 16kHz
audio = np.roll(audio, shift)
# Speed perturbation (simplified)
speed_factor = np.random.uniform(0.9, 1.1)
# In practice, use librosa.effects.time_stretch
return audio
# Create dataset
dataset = KeywordSpottingDataset(
audio_files=['audio1.wav', 'audio2.wav', ...],
labels=[1, 0, ...], # 1=keyword, 0=no keyword
feature_extractor=extractor,
augment=True
)
dataloader = DataLoader(dataset, batch_size=32, shuffle=True)
Training Loop
import torch
import torch.nn as nn
def train_keyword_spotting_model(model, train_loader, val_loader,
n_epochs=50, device='cuda'):
"""
Train keyword spotting model
Args:
model: PyTorch model
train_loader: Training data loader
val_loader: Validation data loader
n_epochs: Number of epochs
device: Device to train on
"""
model = model.to(device)
# Loss and optimizer
criterion = nn.CrossEntropyLoss()
optimizer = torch.optim.Adam(model.parameters(), lr=0.001)
scheduler = torch.optim.lr_scheduler.ReduceLROnPlateau(
optimizer, mode='max', patience=5
)
best_val_acc = 0
for epoch in range(n_epochs):
# Training
model.train()
train_loss = 0
train_correct = 0
train_total = 0
for features, labels in train_loader:
features = features.to(device)
labels = labels.squeeze().to(device)
# Forward pass
outputs = model(features)
loss = criterion(outputs, labels)
# Backward pass
optimizer.zero_grad()
loss.backward()
optimizer.step()
# Track metrics
train_loss += loss.item()
_, predicted = torch.max(outputs, 1)
train_correct += (predicted == labels).sum().item()
train_total += labels.size(0)
train_acc = train_correct / train_total
# Validation
model.eval()
val_correct = 0
val_total = 0
with torch.no_grad():
for features, labels in val_loader:
features = features.to(device)
labels = labels.squeeze().to(device)
outputs = model(features)
_, predicted = torch.max(outputs, 1)
val_correct += (predicted == labels).sum().item()
val_total += labels.size(0)
val_acc = val_correct / val_total
# Learning rate scheduling
scheduler.step(val_acc)
# Save best model
if val_acc > best_val_acc:
best_val_acc = val_acc
torch.save(model.state_dict(), 'best_kws_model.pth')
print(f"Epoch {epoch+1}/{n_epochs}: "
f"Train Acc={train_acc:.4f}, Val Acc={val_acc:.4f}")
return model
# Train
model = KeywordSpottingCNN()
trained_model = train_keyword_spotting_model(
model, train_loader, val_loader, n_epochs=50
)
Deployment Optimization
Model Quantization
def quantize_kws_model(model):
"""
Apply dynamic quantization to linear layers for edge deployment
"""
import torch
import torch.nn as nn
model.eval()
qmodel = torch.quantization.quantize_dynamic(model, {nn.Linear}, dtype=torch.qint8)
return qmodel
# Quantize
model_quantized = quantize_kws_model(model)
# Compare serialized sizes for accurate measurement
import io
import torch
def get_model_size_mb(m):
buffer = io.BytesIO()
torch.save(m.state_dict(), buffer)
return len(buffer.getvalue()) / (1024 ** 2)
original_size = get_model_size_mb(model)
quantized_size = get_model_size_mb(model_quantized)
print(f"Original: {original_size:.2f} MB")
print(f"Quantized: {quantized_size:.2f} MB")
print(f"Compression: {original_size / max(quantized_size, 1e-6):.1f}x")
TensorFlow Lite Conversion
def convert_to_tflite(model, sample_input):
"""
Convert PyTorch model to TensorFlow Lite
For deployment on mobile/edge devices
"""
import torch
import onnx
import tensorflow as tf
from onnx_tf.backend import prepare
# Step 1: PyTorch → ONNX
torch.onnx.export(
model,
sample_input,
'kws_model.onnx',
input_names=['input'],
output_names=['output'],
dynamic_axes={'input': {0: 'batch'}, 'output': {0: 'batch'}}
)
# Step 2: ONNX → TensorFlow
onnx_model = onnx.load('kws_model.onnx')
tf_rep = prepare(onnx_model)
tf_rep.export_graph('kws_model_tf')
# Step 3: TensorFlow → TFLite
converter = tf.lite.TFLiteConverter.from_saved_model('kws_model_tf')
# Optimization
converter.optimizations = [tf.lite.Optimize.DEFAULT]
converter.target_spec.supported_types = [tf.float16]
tflite_model = converter.convert()
# Save
with open('kws_model.tflite', 'wb') as f:
f.write(tflite_model)
print(f"TFLite model size: {len(tflite_model) / 1024:.1f} KB")
# Convert
convert_to_tflite(model, sample_input)
Real-time Inference
Streaming KWS System
import sounddevice as sd
import numpy as np
import torch
from collections import deque
class StreamingKeywordSpotter:
"""
Real-time keyword spotting system
Continuously monitors audio and detects keywords
"""
def __init__(self, model, feature_extractor,
threshold=0.8, cooldown_ms=1000):
self.model = model
self.model.eval()
self.feature_extractor = feature_extractor
self.threshold = threshold
self.cooldown_samples = int(cooldown_ms * 16000 / 1000)
# Audio buffer (1 second)
self.buffer_size = 16000
self.audio_buffer = deque(maxlen=self.buffer_size)
# Detection cooldown
self.last_detection = -self.cooldown_samples
self.sample_count = 0
def process_audio_chunk(self, audio_chunk):
"""
Process incoming audio chunk
Args:
audio_chunk: Audio samples [n_samples]
Returns:
(detected, confidence) tuple
"""
# Add to buffer
self.audio_buffer.extend(audio_chunk)
self.sample_count += len(audio_chunk)
# Wait until buffer is full
if len(self.audio_buffer) < self.buffer_size:
return False, 0.0
# Check cooldown
if self.sample_count - self.last_detection < self.cooldown_samples:
return False, 0.0
# Extract features
audio = np.array(self.audio_buffer)
features = self.feature_extractor.extract(audio)
# Add batch and channel dimensions
features_tensor = torch.FloatTensor(features).unsqueeze(0).unsqueeze(0)
# Run inference
with torch.no_grad():
output = self.model(features_tensor)
probs = torch.softmax(output, dim=1)
confidence = probs[0][1].item() # Probability of keyword
# Check threshold
if confidence >= self.threshold:
self.last_detection = self.sample_count
return True, confidence
return False, confidence
def start_listening(self, callback=None):
"""
Start continuous listening
Args:
callback: Function called when keyword detected
"""
print("🎤 Listening for keywords...")
def audio_callback(indata, frames, time_info, status):
"""Process audio in callback"""
if status:
print(f"Audio status: {status}")
# Process chunk
detected, confidence = self.process_audio_chunk(indata[:, 0])
if detected:
print(f"✓ Keyword detected! (confidence={confidence:.3f})")
if callback:
callback(confidence)
# Start audio stream
with sd.InputStream(
samplerate=16000,
channels=1,
blocksize=1600, # 100ms chunks
callback=audio_callback
):
print("Press Ctrl+C to stop")
sd.sleep(1000000) # Sleep indefinitely
# Usage
model = KeywordSpottingCNN()
model.load_state_dict(torch.load('best_kws_model.pth'))
spotter = StreamingKeywordSpotter(
model=model,
feature_extractor=extractor,
threshold=0.8,
cooldown_ms=1000
)
def on_keyword_detected(confidence):
"""Callback when keyword detected"""
print(f"🔔 Activating voice assistant... (conf={confidence:.2f})")
# Trigger downstream processing
spotter.start_listening(callback=on_keyword_detected)
Connection to Binary Search (DSA)
Keyword spotting uses binary search for threshold optimization:
class KeywordThresholdOptimizer:
"""
Find optimal detection threshold using binary search
Balances false accepts vs false rejects
"""
def __init__(self, model, feature_extractor):
self.model = model
self.feature_extractor = feature_extractor
self.model.eval()
def find_optimal_threshold(self, positive_samples, negative_samples,
target_far=0.01):
"""
Binary search for threshold that achieves target FAR
FAR = False Acceptance Rate
Args:
positive_samples: List of keyword audio samples
negative_samples: List of non-keyword audio samples
target_far: Target false acceptance rate (e.g., 0.01 = 1%)
Returns:
Optimal threshold
"""
# Get confidence scores for all samples
pos_scores = self._get_scores(positive_samples)
neg_scores = self._get_scores(negative_samples)
# Binary search on threshold space [0, 1]
left, right = 0.0, 1.0
best_threshold = 0.5
for iteration in range(20): # 20 iterations for precision
mid = (left + right) / 2
# Calculate FAR at this threshold
false_accepts = sum(1 for score in neg_scores if score >= mid)
far = false_accepts / len(neg_scores)
# Calculate FRR at this threshold
false_rejects = sum(1 for score in pos_scores if score < mid)
frr = false_rejects / len(pos_scores)
print(f"Iteration {iteration}: threshold={mid:.4f}, "
f"FAR={far:.4f}, FRR={frr:.4f}")
# Adjust search space
if far > target_far:
# Too many false accepts, increase threshold
left = mid
else:
# FAR is good, try lowering threshold to reduce FRR
right = mid
best_threshold = mid
return best_threshold
def _get_scores(self, audio_samples):
"""Get confidence scores for audio samples"""
scores = []
for audio in audio_samples:
# Extract features
features = self.feature_extractor.extract(audio)
features_tensor = torch.FloatTensor(features).unsqueeze(0).unsqueeze(0)
# Inference
with torch.no_grad():
output = self.model(features_tensor)
probs = torch.softmax(output, dim=1)
confidence = probs[0][1].item()
scores.append(confidence)
return scores
# Usage
optimizer = KeywordThresholdOptimizer(model, extractor)
optimal_threshold = optimizer.find_optimal_threshold(
positive_samples=keyword_audios,
negative_samples=background_audios,
target_far=0.01 # 1% false accept rate
)
print(f"Optimal threshold: {optimal_threshold:.4f}")
Advanced Model Architectures
1. Attention-Based KWS
import torch
import torch.nn as nn
class AttentionKWS(nn.Module):
"""
Keyword spotting with attention mechanism
Learns to focus on important parts of audio
"""
def __init__(self, n_mels=40, hidden_dim=128, n_classes=2):
super().__init__()
# Bidirectional LSTM
self.lstm = nn.LSTM(
input_size=n_mels,
hidden_size=hidden_dim,
num_layers=2,
batch_first=True,
bidirectional=True
)
# Attention layer
self.attention = nn.Sequential(
nn.Linear(hidden_dim * 2, 64),
nn.Tanh(),
nn.Linear(64, 1)
)
# Classifier
self.fc = nn.Linear(hidden_dim * 2, n_classes)
def forward(self, x):
"""
Args:
x: [batch, time_steps, n_mels]
Returns:
[batch, n_classes]
"""
# LSTM
lstm_out, _ = self.lstm(x) # [batch, time, hidden*2]
# Attention scores
attention_scores = self.attention(lstm_out) # [batch, time, 1]
attention_weights = torch.softmax(attention_scores, dim=1)
# Weighted sum
context = torch.sum(lstm_out * attention_weights, dim=1) # [batch, hidden*2]
# Classify
output = self.fc(context)
return output, attention_weights
# Usage
model = AttentionKWS(n_mels=40, hidden_dim=128)
# Train and visualize attention
x = torch.randn(1, 100, 40) # 1 sample
output, attention = model(x)
# Visualize which parts of audio model focuses on
import matplotlib.pyplot as plt
plt.figure(figsize=(12, 4))
plt.plot(attention[0].detach().numpy())
plt.title('Attention Weights Over Time')
plt.xlabel('Time Step')
plt.ylabel('Attention Weight')
plt.savefig('attention_visualization.png')
2. Res-Net Based KWS
import torch
import torch.nn as nn
class ResNetBlock(nn.Module):
"""Residual block for audio"""
def __init__(self, channels):
super().__init__()
self.conv1 = nn.Conv2d(channels, channels, 3, padding=1)
self.bn1 = nn.BatchNorm2d(channels)
self.conv2 = nn.Conv2d(channels, channels, 3, padding=1)
self.bn2 = nn.BatchNorm2d(channels)
self.relu = nn.ReLU()
def forward(self, x):
residual = x
out = self.relu(self.bn1(self.conv1(x)))
out = self.bn2(self.conv2(out))
out += residual
out = self.relu(out)
return out
class ResNetKWS(nn.Module):
"""
ResNet-based keyword spotting
Deeper network for better accuracy
"""
def __init__(self, n_mels=40, n_classes=2):
super().__init__()
# Initial conv
self.conv1 = nn.Sequential(
nn.Conv2d(1, 32, kernel_size=3, padding=1),
nn.BatchNorm2d(32),
nn.ReLU()
)
# Residual blocks
self.res_blocks = nn.Sequential(
ResNetBlock(32),
ResNetBlock(32),
ResNetBlock(32)
)
# Pooling
self.pool = nn.AdaptiveAvgPool2d((1, 1))
# Classifier
self.fc = nn.Linear(32, n_classes)
def forward(self, x):
"""
Args:
x: [batch, 1, n_mels, time_steps]
"""
x = self.conv1(x)
x = self.res_blocks(x)
x = self.pool(x)
x = x.view(x.size(0), -1)
x = self.fc(x)
return x
model_resnet = ResNetKWS(n_mels=40)
3. Transformer-Based KWS
import torch
import torch.nn as nn
import numpy as np
class TransformerKWS(nn.Module):
"""
Transformer for keyword spotting
State-of-the-art performance but larger model
"""
def __init__(self, n_mels=40, d_model=128, nhead=4,
num_layers=2, n_classes=2):
super().__init__()
# Input projection
self.input_proj = nn.Linear(n_mels, d_model)
# Positional encoding
self.pos_encoder = PositionalEncoding(d_model)
# Transformer encoder
encoder_layer = nn.TransformerEncoderLayer(
d_model=d_model,
nhead=nhead,
dim_feedforward=d_model * 4,
dropout=0.1,
batch_first=True
)
self.transformer = nn.TransformerEncoder(
encoder_layer,
num_layers=num_layers
)
# Classifier
self.fc = nn.Linear(d_model, n_classes)
def forward(self, x):
"""
Args:
x: [batch, time_steps, n_mels]
"""
# Project input
x = self.input_proj(x)
# Add positional encoding
x = self.pos_encoder(x)
# Transformer
x = self.transformer(x)
# Global average pooling
x = x.mean(dim=1)
# Classify
x = self.fc(x)
return x
class PositionalEncoding(nn.Module):
"""Positional encoding for transformer"""
def __init__(self, d_model, max_len=5000):
super().__init__()
pe = torch.zeros(max_len, d_model)
position = torch.arange(0, max_len, dtype=torch.float).unsqueeze(1)
div_term = torch.exp(
torch.arange(0, d_model, 2).float() *
(-np.log(10000.0) / d_model)
)
pe[:, 0::2] = torch.sin(position * div_term)
pe[:, 1::2] = torch.cos(position * div_term)
self.register_buffer('pe', pe.unsqueeze(0))
def forward(self, x):
return x + self.pe[:, :x.size(1)]
model_transformer = TransformerKWS(n_mels=40)
Data Augmentation Strategies
For foundational augmentation techniques (time stretching, pitch shifting, noise mixing, SpecAugment), see Audio Preprocessing & Signal Processing.
Advanced Audio Augmentation
import librosa
import numpy as np
class AudioAugmenter:
"""
Comprehensive audio augmentation for KWS training
Improves robustness to real-world conditions
"""
def __init__(self):
self.sample_rate = 16000
def time_stretch(self, audio, rate=None):
"""
Stretch/compress audio in time
Args:
audio: Audio samples
rate: Stretch factor (0.8-1.2 typical)
"""
if rate is None:
rate = np.random.uniform(0.9, 1.1)
return librosa.effects.time_stretch(audio, rate=rate)
def pitch_shift(self, audio, n_steps=None):
"""
Shift pitch without changing speed
Args:
n_steps: Semitones to shift (-3 to +3 typical)
"""
if n_steps is None:
n_steps = np.random.randint(-2, 3)
return librosa.effects.pitch_shift(
audio,
sr=self.sample_rate,
n_steps=n_steps
)
def add_background_noise(self, audio, noise_audio, snr_db=None):
"""
Add background noise at specified SNR
Args:
noise_audio: Background noise samples
snr_db: Signal-to-noise ratio in dB (10-30 typical)
"""
if snr_db is None:
snr_db = np.random.uniform(10, 30)
# Calculate noise scaling factor
audio_power = np.mean(audio ** 2)
noise_power = np.mean(noise_audio ** 2)
snr_linear = 10 ** (snr_db / 10)
noise_scale = np.sqrt(audio_power / (snr_linear * noise_power))
# Mix audio and noise
return audio + noise_scale * noise_audio
def room_simulation(self, audio, room_size='medium'):
"""
Simulate room acoustics (reverb)
Args:
room_size: 'small', 'medium', or 'large'
"""
# Room impulse response parameters
params = {
'small': {'delay': 0.05, 'decay': 0.3},
'medium': {'delay': 0.1, 'decay': 0.5},
'large': {'delay': 0.2, 'decay': 0.7}
}
delay_samples = int(params[room_size]['delay'] * self.sample_rate)
decay = params[room_size]['decay']
# Simple reverb simulation
reverb = np.zeros_like(audio)
reverb[delay_samples:] = audio[:-delay_samples] * decay
return audio + reverb
def apply_compression(self, audio, threshold_db=-20):
"""
Dynamic range compression
Makes quiet sounds louder, loud sounds quieter
"""
threshold = 10 ** (threshold_db / 20)
compressed = np.copy(audio)
# Compress samples above threshold
mask = np.abs(audio) > threshold
compressed[mask] = threshold + (audio[mask] - threshold) * 0.5
return compressed
def augment(self, audio):
"""
Apply random augmentation pipeline
Returns augmented audio
"""
# Random selection of augmentations
aug_functions = [
lambda x: self.time_stretch(x),
lambda x: self.pitch_shift(x),
lambda x: self.apply_compression(x),
]
# Apply 1-2 random augmentations
n_augs = np.random.randint(1, 3)
for _ in range(n_augs):
aug_fn = np.random.choice(aug_functions)
audio = aug_fn(audio)
# Add background noise (always)
noise = np.random.randn(len(audio)) * 0.005
audio = self.add_background_noise(audio, noise)
return audio
# Usage in training
augmenter = AudioAugmenter()
# Augment training data
augmented_audio = augmenter.augment(original_audio)
Production Deployment Patterns
Multi-Stage Detection Pipeline
import torch
class MultiStageKWSPipeline:
"""
Multi-stage KWS for production
Stage 1: Lightweight detector (always-on)
Stage 2: Accurate model (triggered by stage 1)
Optimizes power consumption vs accuracy
"""
def __init__(self, stage1_model, stage2_model,
stage1_threshold=0.7, stage2_threshold=0.9):
self.stage1_model = stage1_model # Tiny model (~50KB)
self.stage2_model = stage2_model # Accurate model (~500KB)
self.stage1_threshold = stage1_threshold
self.stage2_threshold = stage2_threshold
self.stats = {
'stage1_triggers': 0,
'stage2_confirms': 0,
'false_positives': 0
}
self.total_chunks = 0
def detect(self, audio_chunk):
"""
Two-stage detection
Returns: (detected, confidence, stage)
"""
# Increment processed chunks counter
self.total_chunks += 1
# Stage 1: Lightweight screening
stage1_conf = self._run_stage1(audio_chunk)
if stage1_conf < self.stage1_threshold:
# Not a keyword, skip stage 2
return False, stage1_conf, 1
self.stats['stage1_triggers'] += 1
# Stage 2: Accurate verification
stage2_conf = self._run_stage2(audio_chunk)
if stage2_conf >= self.stage2_threshold:
self.stats['stage2_confirms'] += 1
return True, stage2_conf, 2
else:
self.stats['false_positives'] += 1
return False, stage2_conf, 2
def _run_stage1(self, audio_chunk):
"""Run lightweight model"""
features = extract_features_fast(audio_chunk)
with torch.no_grad():
output = self.stage1_model(features)
confidence = torch.softmax(output, dim=1)[0][1].item()
return confidence
def _run_stage2(self, audio_chunk):
"""Run accurate model"""
features = extract_features_high_quality(audio_chunk)
with torch.no_grad():
output = self.stage2_model(features)
confidence = torch.softmax(output, dim=1)[0][1].item()
return confidence
def get_precision(self):
"""Calculate precision of two-stage system"""
total_detections = self.stats['stage2_confirms'] + self.stats['false_positives']
if total_detections == 0:
return 0.0
return self.stats['stage2_confirms'] / total_detections
def get_power_savings(self):
"""Estimate power savings from two-stage approach"""
# Stage 2 ~10x power of stage 1 (normalized units)
stage2_invocations = self.stats['stage1_triggers']
total = max(self.total_chunks, 1)
cost_stage1 = 1.0
cost_stage2 = 10.0
energy_two_stage = total * cost_stage1 + stage2_invocations * cost_stage2
energy_single_stage = total * cost_stage2
savings = 1.0 - (energy_two_stage / energy_single_stage)
return max(0.0, min(1.0, savings))
# Usage
pipeline = MultiStageKWSPipeline(
stage1_model=lightweight_model,
stage2_model=accurate_model
)
# Continuous monitoring
for chunk in audio_stream:
detected, confidence, stage = pipeline.detect(chunk)
if detected:
print(f"Keyword detected! (stage={stage}, conf={confidence:.3f})")
print(f"Precision: {pipeline.get_precision():.2%}")
print(f"Power savings: {pipeline.get_power_savings():.2%}")
On-Device Learning
class OnDeviceKWSLearner:
"""
Personalized KWS with on-device learning
Adapts to user's voice without sending data to cloud
"""
def __init__(self, base_model):
self.base_model = base_model
# Freeze base model
for param in self.base_model.parameters():
param.requires_grad = False
# Add personalization layer
self.personalization_layer = nn.Linear(
self.base_model.output_dim,
2
)
self.optimizer = torch.optim.SGD(
self.personalization_layer.parameters(),
lr=0.01
)
self.user_examples = []
self.max_examples = 50 # Limited on-device storage
def collect_user_example(self, audio, label):
"""
Collect user-specific training example
Args:
audio: User's audio sample
label: 1 for keyword, 0 for non-keyword
"""
features = extract_features(audio)
self.user_examples.append((features, label))
# Keep only recent examples
if len(self.user_examples) > self.max_examples:
self.user_examples.pop(0)
def personalize(self, n_epochs=10):
"""
Personalize model to user
Quick fine-tuning on device
"""
if len(self.user_examples) < 5:
print("Not enough user examples yet")
return
print(f"Personalizing with {len(self.user_examples)} examples...")
for epoch in range(n_epochs):
total_loss = 0
for features, label in self.user_examples:
# Extract base features
with torch.no_grad():
base_output = self.base_model(features)
# Personalization layer
output = self.personalization_layer(base_output)
# Loss
loss = nn.CrossEntropyLoss()(
output.unsqueeze(0),
torch.tensor([label])
)
# Update
self.optimizer.zero_grad()
loss.backward()
self.optimizer.step()
total_loss += loss.item()
if epoch % 5 == 0:
print(f"Epoch {epoch}: Loss = {total_loss / len(self.user_examples):.4f}")
print("Personalization complete!")
def predict(self, audio):
"""Predict with personalized model"""
features = extract_features(audio)
with torch.no_grad():
base_output = self.base_model(features)
output = self.personalization_layer(base_output)
confidence = torch.softmax(output, dim=1)[0][1].item()
return confidence
# Usage
learner = OnDeviceKWSLearner(base_model)
# User trains their custom wake word
print("Please say your wake word 5 times...")
for i in range(5):
audio = record_audio()
learner.collect_user_example(audio, label=1)
print("Please say 5 non-wake-word phrases...")
for i in range(5):
audio = record_audio()
learner.collect_user_example(audio, label=0)
# Personalize on-device
learner.personalize(n_epochs=20)
# Use personalized model
confidence = learner.predict(test_audio)
Real-World Integration Examples
Smart Speaker Integration
This pattern shows how KWS feeds into streaming speech pipelines for full voice assistant workflows.
import time
class SmartSpeakerKWS:
"""
KWS integrated with smart speaker
Handles wake word → command processing pipeline
"""
def __init__(self, wake_word_model, command_asr_model):
self.wake_word_model = wake_word_model
self.command_asr_model = command_asr_model
self.state = 'listening' # 'listening' or 'processing'
self.wake_word_detected = False
self.command_timeout = 5.0 # seconds
async def process_audio_stream(self, audio_stream):
"""
Main processing loop
Always listening for wake word, then processes command
"""
wake_word_detector = StreamingKeywordSpotter(
model=self.wake_word_model,
feature_extractor=KeywordSpottingFeatureExtractor(sample_rate=16000)
)
async for chunk in audio_stream:
if self.state == 'listening':
# Check for wake word
detected, confidence = wake_word_detector.process_audio_chunk(chunk)
if detected:
print("🔊 Wake word detected!")
await self.play_sound('ding.wav') # Audio feedback
# Switch to command processing
self.state = 'processing'
self.wake_word_detected = True
# Start command capture
command_audio = await self.capture_command(audio_stream)
# Process command
await self.process_command(command_audio)
# Return to listening
self.state = 'listening'
async def capture_command(self, audio_stream, timeout=5.0):
"""Capture user command after wake word"""
command_chunks = []
start_time = time.time()
async for chunk in audio_stream:
command_chunks.append(chunk)
# Check timeout
if time.time() - start_time > timeout:
break
# Check for silence (end of command)
if self.is_silence(chunk):
break
return np.concatenate(command_chunks)
async def process_command(self, command_audio):
"""Process voice command"""
# Transcribe command
transcription = self.command_asr_model.transcribe(command_audio)
print(f"Command: {transcription}")
# Execute command
response = await self.execute_command(transcription)
# Speak response
await self.speak(response)
async def execute_command(self, command):
"""Execute voice command"""
# Command routing
if 'weather' in command.lower():
return await self.get_weather()
elif 'music' in command.lower():
return await self.play_music()
elif 'timer' in command.lower():
return await self.set_timer(command)
else:
return "Sorry, I didn't understand that."
# Usage
speaker = SmartSpeakerKWS(wake_word_model, command_asr_model)
await speaker.process_audio_stream(microphone_stream)
Mobile App Integration
class MobileKWSManager:
"""
KWS manager for mobile apps
Handles battery optimization and background processing
"""
def __init__(self, model_path):
self.model = self.load_optimized_model(model_path)
self.is_active = False
self.battery_saver_mode = False
# Performance tracking
self.battery_usage = 0
self.detections = 0
def load_optimized_model(self, model_path):
"""Load quantized model for mobile"""
# Load TFLite model
import tensorflow as tf
interpreter = tf.lite.Interpreter(model_path=model_path)
interpreter.allocate_tensors()
return interpreter
def start_listening(self, battery_level=100):
"""Start KWS with battery-aware mode"""
self.is_active = True
# Enable battery saver if low battery
if battery_level < 20:
self.enable_battery_saver()
# Start audio capture thread
self.audio_thread = threading.Thread(target=self._audio_processing_loop)
self.audio_thread.start()
def enable_battery_saver(self):
"""Enable battery saving mode"""
self.battery_saver_mode = True
# Reduce processing frequency
self.chunk_duration_ms = 200 # Longer chunks = less processing
# Lower threshold for stage 1
self.stage1_threshold = 0.8 # Higher threshold = fewer stage 2 triggers
print("⚡ Battery saver mode enabled")
def _audio_processing_loop(self):
"""Background audio processing"""
while self.is_active:
# Capture audio
audio_chunk = self.capture_audio_chunk()
# Process
detected, confidence = self.detect_keyword(audio_chunk)
if detected:
self.detections += 1
self.trigger_callback(confidence)
# Track battery usage (simplified)
self.battery_usage += 0.001 # mAh per iteration
# Sleep to save battery
if self.battery_saver_mode:
time.sleep(0.1)
def detect_keyword(self, audio_chunk):
"""Run inference on mobile"""
# Extract features
features = extract_features(audio_chunk)
# TFLite inference
input_details = self.model.get_input_details()
output_details = self.model.get_output_details()
self.model.set_tensor(input_details[0]['index'], features)
self.model.invoke()
output = self.model.get_tensor(output_details[0]['index'])
confidence = output[0][1]
return confidence > 0.8, confidence
def get_battery_impact(self):
"""Estimate battery impact"""
return {
'total_usage_mah': self.battery_usage,
'detections': self.detections,
'usage_per_hour': self.battery_usage * 3600 # Extrapolate
}
# Usage in mobile app
kws_manager = MobileKWSManager('kws_model.tflite')
kws_manager.start_listening(battery_level=get_battery_level())
# Check battery impact
impact = kws_manager.get_battery_impact()
print(f"Battery usage: {impact['usage_per_hour']:.2f} mAh/hour")
Key Takeaways
✅ Ultra-lightweight models - < 1MB for edge deployment ✅ Real-time processing - < 50ms latency requirement ✅ Always-on capability - Low power consumption ✅ Noise robustness - Data augmentation and preprocessing critical ✅ Binary search optimization - Find optimal detection thresholds ✅ Model compression - Quantization, pruning for deployment ✅ Streaming architecture - Process continuous audio efficiently
FAQ
Q: What model architecture is best for keyword spotting on edge devices? A: A lightweight CNN operating on mel-spectrogram input is the best starting point for edge keyword spotting. With roughly 30K parameters (~100KB), it achieves sub-5ms inference on CPU. For higher accuracy, use a two-stage pipeline where the CNN screens candidates and a larger GRU or attention-based model confirms detections.
Q: How do I reduce false activations in wake word detection? A: Use a multi-stage detection pipeline: a lightweight Stage 1 model with a lower threshold screens candidates, then a more accurate Stage 2 model with a higher threshold confirms. Combine this with a cooldown period (1-2 seconds) between detections and binary search to find the optimal threshold that achieves less than 1% false acceptance rate.
Q: How much training data do I need for keyword spotting? A: You need at least a few thousand positive examples of the target keyword from diverse speakers, plus 5-10x more negative examples including similar-sounding words. The Google Speech Commands dataset provides a good baseline. Data augmentation (noise, pitch shift, time stretch, room simulation) can effectively multiply your dataset size by 5-10x.
Originally published at: arunbaby.com/speech-tech/0009-keyword-spotting
If you found this helpful, consider sharing it with others who might benefit.
Want to work together?
I take on projects, advisory roles, and fractional CTO engagements in AI/ML. I also help businesses go AI-native with agentic workflows and agent orchestration.
Get in touch
