Advanced Caching for ML Systems

“In the world of high-scale machine learning, the fastest inference is the one you never had to compute. Caching is not just about saving time; it’s about making the impossible latency targets possible.”

TL;DR

ML caching goes far beyond “put it in Redis.” Production systems use a three-tier hierarchy: in-process caches (nanosecond latency) for hot keys, distributed Redis clusters (1-5ms) for user features, and persistent SSD stores (5-20ms) for historical data. Semantic caching with vector similarity can reuse LLM generations for semantically identical prompts, saving 30-40% of inference costs. Consistent hashing with virtual nodes prevents cache miss storms during node failures, and KV cache management via PagedAttention is the difference between serving 10 versus 1,000 concurrent LLM users per GPU. For more on scaling the inference layer that caching protects, see the inference optimization techniques and the chatbot system design.

1. Introduction: The Inference Bottleneck

As machine learning models grow from simple Decision Trees to 70B parameter Transformers, the “Cost per Inference” has become a defining business metric.

• A single LLM generate call can cost cents.
• A real-time ranking call for 10,000 items can take hundreds of milliseconds.
• Storing pre-computed features for 1 billion users often requires Petabytes of storage.

If you are designing the Recommendation System for TikTok or the Search Ranking for Amazon, you cannot afford to call the heavy Re-ranking Model for every single user interaction. You must use Advanced Caching Strategies.

This post moves beyond the basics of “put it in Redis.” We explore the Multi-Tiered Cache Architecture, Semantic Caching for LLMs, Feature Store Hydration, and how to solve the dreaded Thundering Herd problem in distributed systems.

---

2. Functional Requirements of an ML Cache

ML Caching is distinct from standard Web Caching (e.g., caching HTML pages).

1. High Throughput, Low Latency: We need to fetch 1,000 features for a candidate batch in < 5ms.
2. Approximate Correctness: Unlike a Bank Ledger, it’s okay if a user’s “Interest Vector” is 5 minutes stale.
3. High Dimensionality: We aren’t just caching strings; we are caching Vectors (Embeddings) and Tensors.
4. Semantic Retrieval: Use Vector Similarity to find “near-matches” for user queries, allowing us to reuse LLM generations for similar prompts.

---

3. The Architecture: The Latency Hierarchy

Modern ML systems (like those at Netflix or Facebook) use a strictly tiered memory hierarchy.

3.1 Tier 1: The Local (In-Process) Cache

• Technology: Python dict, C++ std::unordered_map.
• Latency: Nanoseconds (Reference access) to Microseconds.
• Capacity: Small (1GB - 10GB).
• Strategy: Hot-Keys Only. We use algorithms like TinyLFU to greedily admit only the top 1% most popular items (e.g., The “Global Bias” features or “Justin Bieber” embedding).
• Gotcha: Cache Coherency. If Node A updates the cache, Node B doesn’t know. We accept this inconsistency.

3.2 Tier 2: The Distributed (Remote) Cache

• Technology: Redis (Cluster Mode), Memcached, Amazon ElastiCache.
• Latency: 1ms - 5ms (Network RTT).
• Capacity: Medium to Large (Terabytes).
• Strategy: Sharded & Replica. We shard data across 100+ nodes using Consistent Hashing.

3.3 Tier 3: The Persistent (SSD) Cache

• Technology: Aerospike, DynamoDB (DAX), NVMe Pools.
• Latency: 5ms - 20ms.
• Capacity: Petabytes.
• Role: Feature Store History. When you need to backfill data or fetch user history from 30 days ago.

3.4 Summary Table

| Tier | Technology | Latency | Capacity | Use Case | | :— | :— | :— | :— | :— | | L1 | Python dict, C++ map | < 0.1ms | 1-10GB | Hot keys, Global features | | L2 | Redis, Memcached | 1-5ms | 1-10TB | User features, Session data | | L3 | Aerospike, DAX | 5-20ms | Petabytes | Historical features, Cold users |

4. Deep Dive: Consistent Hashing for Distributed Caching

When you scale Redis to 100 nodes, efficient key distribution is critical. Naive hashing hash(key) % N is broken. If one node dies, N changes to N-1, and 100% of keys are remapped. This causes a “Cache Miss Storm” that can take down your database.

4.1 The Solution: Virtual Nodes on a Ring

We map both Nodes and Keys to a 32-bit integer ring.

• A Key belongs to the first Node found moving clockwise on the ring.
• Virtual Nodes: To balance load, one physical server is hashed to 1,000 points on the ring.
• Result: If a node dies, only 1/N of keys need to be moved to the neighbor. (N-1)/N keys stay put.

import hashlib
import bisect

class ConsistentHash:
    def __init__(self, nodes=None, replicas=100):
        self.replicas = replicas
        self.ring = {}
        self.sorted_keys = []
        if nodes:
            for node in nodes:
                self.add_node(node)

    def add_node(self, node):
        for i in range(self.replicas):
            key = self._hash(f"{node}:{i}")
            self.ring[key] = node
            bisect.insort(self.sorted_keys, key)

    def remove_node(self, node):
        for i in range(self.replicas):
            key = self._hash(f"{node}:{i}")
            del self.ring[key]
            self.sorted_keys.remove(key)

    def get_node(self, key):
        if not self.ring: return None
        h = self._hash(key)
        # Binary Search for the next node on the ring
        idx = bisect.bisect(self.sorted_keys, h)
        if idx == len(self.sorted_keys):
            idx = 0
            return self.ring[self.sorted_keys[idx]]

    def _hash(self, key):
        return int(hashlib.md5(key.encode()).hexdigest(), 16)

4.2 Replication for Read Scalability

Each shard can have read replicas.

• Primary: Handles writes.
• Replicas (2-3): Handle reads.
• Trade-off: Replication Lag. A write to Primary might not be visible on Replica for 10ms. For ML features, this is usually acceptable.

---

5. Embedding Caching: The ML-Specific Challenge

Standard caching assumes values are small (< 1KB). ML embeddings are large (512-dim float32 = 2KB) and there are billions of them.

5.1 Storage Optimization

• Quantization: Store embeddings as int8 instead of float32. Reduces storage by 4x with < 1% accuracy loss.
• Dimension Reduction: Use PCA or learned projections to reduce 512-dim to 128-dim. 4x storage reduction.

5.2 Batch Fetching

When ranking 1000 items, we need 1000 embeddings.

• Naive: 1000 sequential GET calls = 1000ms.
• Pipeline: MGET (multi-get) = 5ms. ```python

  Bad: Sequential

  embeddings = [redis.get(f”item:{id}”) for id in item_ids]

Good: Batch Pipeline

pipe = redis.pipeline() for id in item_ids: pipe.get(f”item:{id}”) embeddings = pipe.execute()

### 5.3 Precomputation vs. On-Demand
-   **User Embeddings**: Change slowly (daily). Precompute and cache with 24h TTL.
-   **Item Embeddings**: Change on edit. Cache on first access, invalidate on update.
-   **Query Embeddings**: Ephemeral. Compute on-the-fly, cache for 5 minutes for repeat queries.

---

## 5. The "Thundering Herd" Problem & Solutions

Scenario: A celebrity tweets. Millions of users request their profile.
The cache key `user_profile:123` expires at 12:00:00.
At 12:00:01, 10,000 concurrent requests hit the cache -> Miss -> Hit the Database.
**The Database Dies.**

### 5.1 Solution 1: Request Coalescing (SingleFlight)
Only ONE request per key is allowed to compute. All other requests for that key **wait** (block) until the first one returns.
-   Implemented in Go (`singleflight`), Nginx (`proxy_cache_lock`).

### 5.2 Solution 2: Probabilistic Early Expiration (PER)
Instead of a hard TTL, we fetch based on a probability.
-   `gap = time.now() - lease_start`
-   `probability = gap / TTL`
-   If `random() < probability`, we recompute *before* expiry.
-   This spreads the refresh load over time.

---

## 6. Semantic Caching for LLMs (GPT-4 / Llama 3)

LLM queries are expensive and slow.
-   Q1: "Who is the President of France?"
-   Q2: "Who is the current leader of France?"
Traditional cache says **MISS** (Strings don't match).
**Semantic Cache** says **HIT**.

### 6.1 The Logic
1.  **Embed Query**: `v1 = BERT("Who is the President of France?")`
2.  **Vector Search**: Search Milvus/Faiss for nearest neighbor `v2`.
3.  **Distance Threshold**: If `Cosine_Similarity(v1, v2) > 0.95`, return the cached answer associated with `v2`.

### 6.2 Architecture
-   **Store**: Vectors in Faiss, Metadata in Redis.
-   **Tradeoff**: 5ms Latency (Embedding + Search) vs 2000ms Latency (LLM Generation).
-   **Cost Savings**: Massive. 30-40% of queries in production chat apps are semantically identical.

---

## 7. Feature Caching Strategies

In Recommender Systems, we need to fetch user features (`[age, gender, clicks_7d]`) and item features (`[category, price, ctr]`).

### 7.1 Row-Oriented vs Column-Oriented Caching
-   **Row Cache (Redis Strings)**: `key=user:123` -> `val=protobuf_blob`.
    -   Good for fetching single entities.
    -   **Serialization Formats**: Protobuf (fast, compact), JSON (readable, slower), MessagePack (good balance).
-   **Column Cache (Redis Lists/Bitmaps)**: `key=clicked_item:55` -> `val=[user1, user2, user3]`.
    -   Good for "Find all users who clicked X."
    -   **Use Case**: Co-occurrence matrices for collaborative filtering.

### 7.2 Feature Versioning
ML features evolve. You might change `ctr_7d` calculation from "clicks/views" to "clicks/(views + 100)".
-   **Problem**: Old cached values are now stale/incorrect.
-   **Solution**: Include version in key: `user:123:v2`.
-   **Deployment**: On deploy, warm cache with new version keys. Old keys expire naturally.

### 7.3 TTL Strategies by Feature Type
| Feature Type | TTL | Rationale |
| :--- | :--- | :--- |
| **Static** (age, gender) | 24h | Changes rarely |
| **Slowly Changing** (preferences) | 1h | Updates daily |
| **Real-Time** (clicks_5min) | 60s | Must be fresh |
| **Computed** (ML score) | 5min | Expensive to compute |

### 7.2 The Cache Pushing Pattern (Write-Around vs Write-Through)
-   **Write-Through**: The application writes to DB and Cache simultaneously. Safe but slow.
-   **Cache-Aside (Lazy Loading)**: Read DB on miss. Preferred for most features.
-   **Push-Based (Stream Hydration)**:
    -   User clicks item.
    -   Kafka Event triggers Flink Job.
    -   Flink computes `clicks_7d`.
    -   Flink **Pushes** update directly to Redis.
    -   The Inference service serves strictly from Redis (never computes).

---

## 8. Failure Modes

### 8.1 Hot Keys
One key (e.g., "Justin Bieber") gets more traffic than a single Redis shard can handle.
-   **Fix**: **Local Cache Replica**. Detect hot keys and replicate them to L1 (Application Memory).
-   **Fix**: **Key Splitting**. Store `bieber` as `bieber:1`, `bieber:2`. Randomly read one.

### 8.2 Network Bandwidth Saturation
Fetching 1000 items * 2KB embedding = 2MB payload per request.
At 1000 QPS, that is **2 GB/s**. This saturates a 10Gbps NIC.
-   **Fix**: Compression (Zstd, LZ4).
-   **Fix**: Quantization (Store float32 embeddings as int8).

---

## 9. Real-World Look: Facebook TAO

Facebook's "The Association Object" (TAO) cache handles billions of reads/sec.
-   **Graph-Aware**: It caches edges (`User -> Likes -> Page`) not just keys.
-   **Eventual Consistency**: It allows followers to be stale for seconds.
-   **Lease Mechanism**: Preventing thundering herds using "Leases" (tokens) given to clients.

---

## 10. Cache Invalidation: The Two Hardest Problems

Phil Karlton famously said: "There are only two hard things in Computer Science: cache invalidation and naming things."

### 10.1 Time-Based Invalidation (TTL)
The simplest strategy. Set `EXPIRE key 3600` (1 hour).
-   **Pros**: Simple. No coordination needed.
-   **Cons**: User might see stale data for up to 1 hour. Hot features like "Live Stock Price" cannot tolerate this.

### 10.2 Event-Based Invalidation (CDC)
Use Change Data Capture (Debezium, Maxwell) to listen to database changes.
-   User updates their profile in PostgreSQL.
-   Debezium captures the WAL event.
-   Kafka delivers `{user_id: 123, type: UPDATE}` to our Invalidation Consumer.
-   Consumer calls `DEL user:123` on Redis.
-   Next read fetches fresh data from DB and populates cache.

**Implementation Pattern**:
```python
from kafka import KafkaConsumer
import redis

consumer = KafkaConsumer('db.users', bootstrap_servers=['kafka:9092'])
r = redis.Redis()

for message in consumer:
    event = json.loads(message.value)
    user_id = event['after']['id']

    # Invalidate the cache for this user
    r.delete(f"user:{user_id}")
    r.delete(f"user_embedding:{user_id}")

    print(f"Invalidated cache for user {user_id}")

10.3 The Dual-Write Anti-Pattern

Never do this in production:

# WRONG: Race Condition!
db.update(user)
cache.delete(user_key)

If cache.delete fails (network hiccup), your cache is forever stale.

Safer Pattern:

# RIGHT: Transactional Outbox
db.update(user)
db.insert_into_outbox(event)

# Separate worker polls outbox
for event in db.poll_outbox():
    cache.delete(event.key)
    db.delete_from_outbox(event.id)

---

11. Monitoring and Observability

You cannot manage what you cannot measure. A production cache requires rigorous observability.

11.1 Key Metrics to Track

| Metric | Target | Alarm Threshold | | :— | :— | :— | | Cache Hit Ratio (CHR) | > 90% | < 80% | | p99 Latency (Redis) | < 5ms | > 15ms | | Memory Utilization | < 80% | > 90% | | Eviction Rate | Low | Sudden Spike | | Connection Pool Exhaustion | 0 | > 0 |

11.2 Instrumenting Your Cache Client

Wrap your Redis calls with metrics.

import time
from prometheus_client import Histogram, Counter

CACHE_LATENCY = Histogram('cache_latency_seconds', 'Cache operation latency', ['op', 'status'])
CACHE_HITS = Counter('cache_hits_total', 'Number of cache hits')
CACHE_MISSES = Counter('cache_misses_total', 'Number of cache misses')

class InstrumentedCache:
    def __init__(self, redis_client):
        self.redis = redis_client

    def get(self, key):
        start = time.time()
        value = self.redis.get(key)
        duration = time.time() - start

        if value is None:
            CACHE_MISSES.inc()
            CACHE_LATENCY.labels(op='get', status='miss').observe(duration)
        else:
            CACHE_HITS.inc()
            CACHE_LATENCY.labels(op='get', status='hit').observe(duration)

            return value

11.3 Dashboards You Need

1. Hit Ratio over Time: Detects model drift or changed usage patterns.
2. Latency Heatmap: Identifies slow shards or network issues.
3. Memory Fragmentation: Redis can use 2x memory due to fragmentation. Track mem_fragmentation_ratio.

---

12. KV Cache for Transformers (LLM Inference)

This is a specialized cache that lives inside the model inference, not in the infrastructure.

12.1 The Problem

In Transformers (GPT-4, Llama 3), generating 100 tokens requires computing Attention N times. Each Attention computation re-uses the same Key and Value vectors for the previous tokens. Without caching, you recompute these KV pairs at every step. This is O(N^2) for N tokens.

12.2 The KV Cache Solution

We store the Key and Value matrices in GPU VRAM.

• Token 1: Compute K1, V1. Store.
• Token 2: Load K1, V1. Compute K2, V2. Store K1, K2, V1, V2.
• Token 50: Load K1..K49, V1..V49. Compute K50, V50. Store.

VRAM Cost: For Llama 70B, the KV Cache for 4096 tokens can consume 40GB of VRAM. This is often the bottleneck, not the model weights.

12.3 Optimization: Paged Attention (vLLM)

vLLM (from UC Berkeley) treats KV Cache like OS Virtual Memory.

• Pages: Divide the cache into fixed-size “Pages” (e.g., 256 tokens per page).
• On-Demand Allocation: Only allocate pages when needed.
• Sharing: If two prompts share a prefix, they can share the KV pages for that prefix.
• Result: 24x higher throughput than naive HuggingFace generate().

---

13. Production Case Study: Pinterest’s Feature Store Caching

Pinterest serves 500M+ users. Their recommender system needs to fetch ~1000 features per request.

13.1 The Architecture

• L1 (Application): 5GB LRU cache per pod. Holds global features (e.g., “is_weekend”).
• L2 (Redis Cluster): 500 nodes, 10TB capacity. Holds user features.
• L3 (Rockstore/SSTable): Hourly snapshots of the feature store for cold users.

13.2 Key Optimizations

1. Feature Packing: Instead of 1000 GET calls, they pack all features for a user into a single Protobuf blob. 1 GET per user.
2. Speculative Warming: When a user logs in, a background job pre-fetches their features into L2 before the first recommendation request.
3. Tiered Eviction: Global features have TTL=infinity. User features have TTL=7 days. Ephemeral features (session data) have TTL=10 minutes.

13.3 Results

• p50 Latency: 2ms (L1 hit).
• p99 Latency: 8ms (L2 hit).
• Cache Hit Ratio: 98.5%.
• Cost Savings: 90% reduction in Feature Store SSD reads.

---

14. Advanced Topic: Negative Caching

What happens when you query for a user that doesn’t exist?

• Request: GET user:99999999
• Redis: MISS
• Database: SELECT * FROM users WHERE id=99999999 -> Empty.
• Problem: Next request repeats this expensive DB query.

14.1 The Solution: Cache the Null

Store a special sentinel value:

value = db.get_user(user_id)
if value is None:
    cache.set(f"user:{user_id}", "NULL", ttl=300)  # Cache the non-existence
else:
    cache.set(f"user:{user_id}", serialize(value), ttl=3600)

On read:

cached = cache.get(f"user:{user_id}")
if cached == "NULL":
    return None  # Don't hit DB

14.2 Danger: Botnet Attacks

If an attacker queries millions of random non-existent IDs, you fill your cache with “NULL” entries, evicting real data.

• Fix: Use a Bloom Filter in front of the cache. Only check DB if the Bloom Filter says “Maybe Exists.”

---

15. Cache Warming Strategies

A cold cache is a dangerous cache. The first 5 minutes after deployment can see massive latency spikes.

15.1 Pre-Warming on Deploy

Before routing traffic to a new pod:

1. Query Log Replay: Replay the last hour of cache access logs against the new pod.
2. Feature Snapshot Load: Load a snapshot of the top 10,000 most popular features directly into L1.
3. Health Check with Warm Threshold: Don’t mark the pod “Ready” until Cache Hit Ratio > 50%.

15.2 Shadow Traffic

Before cutting over to a new cache cluster:

• Fork Traffic: Send a copy of all production requests to the new cluster (without returning results to users).
• Goal: Pre-populate the cache with real access patterns.
• Duration: Run for 10 minutes before cutting over.

15.3 Scheduled Warming for Time-Bound Features

Features like day_of_week or is_holiday are known in advance.

• CRON Job: At midnight, compute and push all time-based features for the next 24 hours.
• Result: Zero cold-start latency for the first recommendation of the day.

---

16. Production Best Practices

Based on experience operating ML caches at scale:

16.1 Separate Caches by SLA

Don’t mix real-time serving cache with batch processing cache.

• Serving Cache: Low TTL, High Memory Priority, Strict SLA.
• Training Cache: High TTL, Lower Priority, Best Effort.
• Risk: A batch job could evict serving data.

16.2 Use Client-Side Connection Pooling

Every Redis call opens a TCP connection. Opening connections is slow (3ms handshake).

• Use a Connection Pool (e.g., redis-py with ConnectionPool).
• Set max_connections based on your QPS and concurrency.

16.3 Monitor Memory Fragmentation

Redis uses jemalloc. Heavy SET/DEL cycles lead to fragmentation.

• Metric: mem_fragmentation_ratio > 1.5 is a warning sign.
• Fix: Schedule periodic MEMORY DOCTOR and consider activedefrag yes.

16.4 Implement Circuit Breakers

If Redis is down, don’t hammer it with retries.

• Use a Circuit Breaker (Hystrix, resilience4j, pybreaker).
• When open, serve from L1 cache only or return a default/fallback prediction.

---

17. Key Takeaways

1. Caching is the First Line of Defense: Protect your expensive GPU inference layers with a multi-tier hierarchy.
2. Consistency vs. Latency: In ML, it is often better to serve a stale prediction (eventual consistency) than to wait.
3. Context Matters: Choose your eviction policy based on the “intent” of the data. LFU for popular items, LRU for temporal access.
4. Semantic Search is the Future: Move beyond exact-match keys to vector similarity for LLM caching.
5. Invalidation is Hard: Use CDC/Event-based invalidation, not dual-writes.
6. Monitor Everything: Cache Hit Ratio, Latency p99, Eviction Rate are your core metrics.

FAQ

What is semantic caching for LLMs and how does it work?

Semantic caching uses vector embeddings to find queries that are semantically similar rather than string-identical. When a new query’s embedding has a cosine similarity above a threshold (typically 0.95) with a cached query, the cached answer is returned instead of calling the LLM. This saves expensive generation time and typically cuts 30-40% of compute costs in production chat applications.

How do you solve the thundering herd problem in ML caching?

Two proven approaches: Request Coalescing (SingleFlight) allows only one request per cache key to compute while others wait for the result. Probabilistic Early Expiration refreshes cache entries before they expire based on a probability function, spreading the refresh load over time so thousands of concurrent requests never simultaneously hit the database.

What is consistent hashing and why is it important for distributed caches?

Consistent hashing maps both nodes and keys to a ring structure. A key belongs to the first node found clockwise on the ring. When a node fails, only 1/N of keys need remapping instead of 100% with naive modulo hashing. Virtual nodes (1,000 per physical server) ensure even load distribution and prevent data hotspots across the cluster.

How does PagedAttention optimize KV cache memory for LLM inference?

PagedAttention treats KV cache like OS virtual memory, dividing it into fixed-size pages (typically 256 tokens) allocated on demand. This eliminates memory fragmentation from pre-allocating maximum sequence lengths. Shared prefixes between requests can point to the same physical pages, achieving up to 24x higher throughput compared to naive HuggingFace implementations.

---

Originally published at: arunbaby.com/ml-system-design/0060-advanced-caching

Want to work together?

I take on projects, advisory roles, and fractional CTO engagements in AI/ML. I also help businesses go AI-native with agentic workflows and agent orchestration.

Get in touch
