Data Preprocessing Pipeline Design

How to build production-grade pipelines that clean, transform, and validate billions of data points before training.

TL;DR

Data preprocessing consumes 60-80 percent of ML engineering time but determines model quality. This post covers schema and statistical validation, missing value and outlier handling, feature engineering patterns, distributed processing with Spark and Beam, training-serving skew prevention via unified preprocessing libraries and feature stores, and data drift detection using KS and chi-square tests. Privacy compliance and performance optimization with parallel processing and efficient formats round out the production design. For how preprocessing connects to the full ML system design lifecycle, start here. See also how feature stores solve the training-serving consistency problem.

Introduction

Data preprocessing is the most time-consuming yet critical part of ML systems. Industry surveys show data scientists spend 60-80% of their time on data preparation, cleaning, transforming, and validating data before training.

Why it matters:

• Garbage in, garbage out: Poor data quality → poor models
• Scale: Process terabytes/petabytes efficiently
• Repeatability: Same transformations in training & serving
• Monitoring: Detect data drift and quality issues

This post covers end-to-end preprocessing pipeline design at scale.

What you’ll learn:

• Architecture for scalable preprocessing
• Data cleaning and validation strategies
• Feature engineering pipelines
• Training/serving skew prevention
• Monitoring and data quality
• Real-world examples from top companies

---

Problem Definition

Design a scalable data preprocessing pipeline for a machine learning system.

Functional Requirements

1. Data Ingestion
   • Ingest from multiple sources (databases, logs, streams)
   • Support batch and streaming data
   • Handle structured and unstructured data
2. Data Cleaning
   • Handle missing values
   • Remove duplicates
   • Fix inconsistencies
   • Outlier detection and handling
3. Data Transformation
   • Normalization/standardization
   • Encoding categorical variables
   • Feature extraction
   • Feature selection
4. Data Validation
   • Schema validation
   • Statistical validation
   • Anomaly detection
   • Data drift detection
5. Feature Engineering
   • Create derived features
   • Aggregations (time-based, user-based)
   • Interaction features
   • Embedding generation

Non-Functional Requirements

1. Scale
   • Process 1TB+ data/day
   • Handle billions of records
   • Support horizontal scaling
2. Latency
   • Batch: Process daily data in < 6 hours
   • Streaming: < 1 second latency for real-time features
3. Reliability
   • 99.9% pipeline success rate
   • Automatic retries on failure
   • Data lineage tracking
4. Consistency
   • Same transformations in training and serving
   • Versioned transformation logic
   • Reproducible results

---

High-Level Architecture

┌─────────────────────────────────────────────────────────────┐
│ Data Sources │
├─────────────────────────────────────────────────────────────┤
│ Databases │ Event Logs │ File Storage │ APIs │
└──────┬──────┴──────┬──────┴───────┬─────────┴──────┬────────┘
 │ │ │ │
 └─────────────┼──────────────┼────────────────┘
 ↓ ↓
 ┌─────────────────────────────┐
 │ Data Ingestion Layer │
 │ (Kafka, Pub/Sub, Kinesis) │
 └──────────────┬──────────────┘
 ↓
 ┌─────────────────────────────┐
 │ Raw Data Storage │
 │ (Data Lake: S3/GCS) │
 └──────────────┬──────────────┘
 ↓
 ┌─────────────────────────────┐
 │ Preprocessing Pipeline │
 │ │
 │ ┌──────────────────────┐ │
 │ │ 1. Data Validation │ │
 │ └──────────────────────┘ │
 │ ┌──────────────────────┐ │
 │ │ 2. Data Cleaning │ │
 │ └──────────────────────┘ │
 │ ┌──────────────────────┐ │
 │ │ 3. Feature Extraction│ │
 │ └──────────────────────┘ │
 │ ┌──────────────────────┐ │
 │ │ 4. Transformation │ │
 │ └──────────────────────┘ │
 │ ┌──────────────────────┐ │
 │ │ 5. Quality Checks │ │
 │ └──────────────────────┘ │
 │ │
 │ (Spark/Beam/Airflow) │
 └──────────────┬──────────────┘
 ↓
 ┌─────────────────────────────┐
 │ Processed Data Storage │
 │ (Feature Store/DW) │
 └──────────────┬──────────────┘
 ↓
 ┌─────────────────────────────┐
 │ Model Training │
 │ & Serving │
 └─────────────────────────────┘

---

Component 1: Data Validation

Validate data quality and schema before processing.

Schema Validation

from dataclasses import dataclass
from typing import List, Dict, Any, Optional
from enum import Enum
import pandas as pd

class DataType(Enum):
    INT = "int"
    FLOAT = "float"
    STRING = "string"
    TIMESTAMP = "timestamp"
    BOOLEAN = "boolean"

    @dataclass
    class FieldSchema:
        name: str
        dtype: DataType
        nullable: bool = True
        min_value: Optional[float] = None
        max_value: Optional[float] = None
        allowed_values: Optional[List[Any]] = None

    class SchemaValidator:
        """
        Validate data against expected schema

        Use case: Ensure incoming data matches expectations
        """

    def __init__(self, schema: List[FieldSchema]):
        self.schema = {field.name: field for field in schema}

    def validate(self, df: pd.DataFrame) -> Dict[str, List[str]]:
        """
        Validate DataFrame against schema

        Returns:
            Dict of field_name → list of errors
            """
            errors = {}

            # Check for missing columns
            expected_cols = set(self.schema.keys())
            actual_cols = set(df.columns)
            missing = expected_cols - actual_cols
            if missing:
                errors['_schema'] = [f"Missing columns: {missing}"]

                # Validate each field
                for field_name, field_schema in self.schema.items():
                    if field_name not in df.columns:
                        continue

                        field_errors = self._validate_field(df[field_name], field_schema)
                        if field_errors:
                            errors[field_name] = field_errors

                            return errors

    def validate_record(self, record: Dict[str, Any]) -> Dict[str, List[str]]:
        """
        Validate a single record (dict) against schema
        """
        df = pd.DataFrame([record])
        return self.validate(df)

    def _validate_field(self, series: pd.Series, schema: FieldSchema) -> List[str]:
        """Validate a single field"""
        errors = []

        # Check nulls
        if not schema.nullable and series.isnull().any():
            null_count = series.isnull().sum()
            errors.append(f"Found {null_count} null values (not allowed)")

            # Check data type
            if schema.dtype == DataType.INT:
                if not pd.api.types.is_integer_dtype(series.dropna()):
                    errors.append("Expected integer type")
                elif schema.dtype == DataType.FLOAT:
                    if not pd.api.types.is_numeric_dtype(series.dropna()):
                        errors.append("Expected numeric type")
                    elif schema.dtype == DataType.STRING:
                        if not pd.api.types.is_string_dtype(series.dropna()):
                            errors.append("Expected string type")
                        elif schema.dtype == DataType.BOOLEAN:
                            if not pd.api.types.is_bool_dtype(series.dropna()):
                                errors.append("Expected boolean type")
                            elif schema.dtype == DataType.TIMESTAMP:
                                if not pd.api.types.is_datetime64_any_dtype(series.dropna()):
                                    try:
                                        pd.to_datetime(series.dropna())
                                    except Exception:
                                        errors.append("Expected timestamp/datetime type")

                                        # Check value ranges
                                        if schema.min_value is not None:
                                            below_min = (series < schema.min_value).sum()
                                            if below_min > 0:
                                                errors.append(f"{below_min} values below minimum {schema.min_value}")

                                                if schema.max_value is not None:
                                                    above_max = (series > schema.max_value).sum()
                                                    if above_max > 0:
                                                        errors.append(f"{above_max} values above maximum {schema.max_value}")

                                                        # Check allowed values
                                                        if schema.allowed_values is not None:
                                                            invalid = ~series.isin(schema.allowed_values)
                                                            invalid_count = invalid.sum()
                                                            if invalid_count > 0:
                                                                invalid_vals = series[invalid].unique()[:5]
                                                                errors.append(
                                                                f"{invalid_count} values not in allowed set. "
                                                                f"Examples: {invalid_vals}"
                                                                )

                                                                return errors

                                                                # Usage
                                                                user_schema = [
                                                                FieldSchema("user_id", DataType.INT, nullable=False, min_value=0),
                                                                FieldSchema("age", DataType.INT, nullable=True, min_value=0, max_value=120),
                                                                FieldSchema("country", DataType.STRING, nullable=False,
                                                                allowed_values=["US", "UK", "CA", "AU"]),
                                                                FieldSchema("signup_date", DataType.TIMESTAMP, nullable=False)
                                                                ]

                                                                validator = SchemaValidator(user_schema)
                                                                errors = validator.validate(user_df)

                                                                if errors:
                                                                    print("Validation errors found:")
                                                                    for field, field_errors in errors.items():
                                                                        print(f" {field}: {field_errors}")

Statistical Validation

import numpy as np
from scipy import stats

class StatisticalValidator:
    """
    Detect statistical anomalies in data

    Compare current batch against historical baseline
    """

    def __init__(self, baseline_stats: Dict[str, Dict]):
        """
        Args:
            baseline_stats: Historical statistics per field
            {
            'age': {'mean': 35.2, 'std': 12.5, 'median': 33},
            'price': {'mean': 99.5, 'std': 25.0, 'median': 95}
            }
            """
            self.baseline = baseline_stats

    def validate(self, df: pd.DataFrame, threshold_sigma=3) -> List[str]:
        """
        Detect fields with distributions far from baseline

        Returns:
            List of warnings
            """
            warnings = []

            for field, baseline in self.baseline.items():
                if field not in df.columns:
                    continue

                    current = df[field].dropna()

                    # Check mean shift
                    current_mean = current.mean()
                    expected_mean = baseline['mean']
                    expected_std = baseline['std']

                    denom = expected_std if expected_std > 1e-9 else 1e-9
                    z_score = abs(current_mean - expected_mean) / denom

                    if z_score > threshold_sigma:
                        warnings.append(
                        f"{field}: Mean shifted significantly "
                        f"(current={current_mean:.2f}, "
                        f"baseline={expected_mean:.2f}, "
                        f"z-score={z_score:.2f})"
                        )

                        # Check distribution shift (KS test)
                        baseline_samples = np.random.normal(
                        baseline['mean'],
                        baseline['std'],
                        size=len(current)
                        )

                        ks_stat, p_value = stats.ks_2samp(current, baseline_samples)

                        if p_value < 0.01: # Significant difference
                            warnings.append(
                            f"{field}: Distribution changed "
                            f"(KS statistic={ks_stat:.3f}, p={p_value:.3f})"
                            )

                            return warnings

---

Component 2: Data Cleaning

Handle missing values, duplicates, and inconsistencies.

Missing Value Handling

class MissingValueHandler:
    """
    Handle missing values with different strategies
    """

    def __init__(self):
        self.imputers = {}

    def fit(self, df: pd.DataFrame, strategies: Dict[str, str]):
        """
        Fit imputation strategies

        Args:
            strategies: {column: strategy}
            strategy options: 'mean', 'median', 'mode', 'forward_fill', 'drop'
            """
            for col, strategy in strategies.items():
                if col not in df.columns:
                    continue

                    if strategy == 'mean':
                        self.imputers[col] = df[col].mean()
                    elif strategy == 'median':
                        self.imputers[col] = df[col].median()
                    elif strategy == 'mode':
                        self.imputers[col] = df[col].mode()[0]
                        # forward_fill and drop don't need fitting

    def transform(self, df: pd.DataFrame, strategies: Dict[str, str]) -> pd.DataFrame:
        """Apply imputation"""
        df = df.copy()

        for col, strategy in strategies.items():
            if col not in df.columns:
                continue

                if strategy in ['mean', 'median', 'mode']:
                    df[col].fillna(self.imputers[col], inplace=True)

                elif strategy == 'forward_fill':
                    df[col].fillna(method='ffill', inplace=True)

                elif strategy == 'backward_fill':
                    df[col].fillna(method='bfill', inplace=True)

                elif strategy == 'drop':
                    df.dropna(subset=[col], inplace=True)

                elif strategy == 'constant':
                    # Fill with a constant (e.g., 0, 'Unknown')
                    fill_value = 0 if pd.api.types.is_numeric_dtype(df[col]) else 'Unknown'
                    df[col].fillna(fill_value, inplace=True)

                    return df

Outlier Detection & Handling

class OutlierHandler:
    """
    Detect and handle outliers
    """

    def detect_outliers_iqr(self, series: pd.Series, multiplier=1.5):
        """
        IQR method: values outside [Q1 - 1.5*IQR, Q3 + 1.5*IQR]
        """
        Q1 = series.quantile(0.25)
        Q3 = series.quantile(0.75)
        IQR = Q3 - Q1

        lower_bound = Q1 - multiplier * IQR
        upper_bound = Q3 + multiplier * IQR

        outliers = (series < lower_bound) | (series > upper_bound)

        return outliers

    def detect_outliers_zscore(self, series: pd.Series, threshold=3):
        """
        Z-score method: |z| > threshold
        """
        z_scores = np.abs(stats.zscore(series.dropna()))
        outliers = z_scores > threshold

        return outliers

    def handle_outliers(self, df: pd.DataFrame, columns: List[str], method='clip'):
        """
        Handle outliers

        Args:
            method: 'clip', 'remove', 'cap', 'transform'
            """
            df = df.copy()

            for col in columns:
                outliers = self.detect_outliers_iqr(df[col])

                if method == 'clip':
                    # Clip to [Q1 - 1.5*IQR, Q3 + 1.5*IQR]
                    Q1 = df[col].quantile(0.25)
                    Q3 = df[col].quantile(0.75)
                    IQR = Q3 - Q1
                    lower = Q1 - 1.5 * IQR
                    upper = Q3 + 1.5 * IQR
                    df[col] = df[col].clip(lower, upper)

                elif method == 'remove':
                    # Remove outlier rows
                    df = df[~outliers]

                elif method == 'cap':
                    # Cap at 99th percentile
                    upper = df[col].quantile(0.99)
                    df[col] = df[col].clip(upper=upper)

                elif method == 'transform':
                    # Log transform to reduce skew
                    df[col] = np.log1p(df[col])

                    return df

Deduplication

class Deduplicator:
    """
    Remove duplicate records
    """

    def deduplicate(
    self,
    df: pd.DataFrame,
    key_columns: List[str],
    keep='last',
    timestamp_col: Optional[str] = None
    ) -> pd.DataFrame:
        """
        Remove duplicates

        Args:
            key_columns: Columns that define uniqueness
            keep: 'first', 'last', or False (remove all duplicates)
            timestamp_col: If provided, keep most recent
            """
            if timestamp_col:
                # Sort by timestamp descending, then drop duplicates keeping first
                df = df.sort_values(timestamp_col, ascending=False)
                df = df.drop_duplicates(subset=key_columns, keep='first')
            else:
                df = df.drop_duplicates(subset=key_columns, keep=keep)

                return df

---

Component 3: Feature Engineering

Transform raw data into ML-ready features.

Numerical Transformations

from sklearn.preprocessing import StandardScaler, MinMaxScaler, RobustScaler

class NumericalTransformer:
    """
    Apply numerical transformations
    """

    def __init__(self):
        self.scalers = {}

    def fit_transform(self, df: pd.DataFrame, transformations: Dict[str, str]):
        """
        Apply transformations

        transformations: {column: transformation_type}
        'standard': StandardScaler (mean=0, std=1)
        'minmax': MinMaxScaler (range [0, 1])
        'robust': RobustScaler (use median, IQR - robust to outliers)
        'log': Log transform
        'sqrt': Square root transform
        """
        df = df.copy()

        for col, transform_type in transformations.items():
            if col not in df.columns:
                continue

                if transform_type == 'standard':
                    scaler = StandardScaler()
                    df[col] = scaler.fit_transform(df[[col]])
                    self.scalers[col] = scaler

                elif transform_type == 'minmax':
                    scaler = MinMaxScaler()
                    df[col] = scaler.fit_transform(df[[col]])
                    self.scalers[col] = scaler

                elif transform_type == 'robust':
                    scaler = RobustScaler()
                    df[col] = scaler.fit_transform(df[[col]])
                    self.scalers[col] = scaler

                elif transform_type == 'log':
                    df[col] = np.log1p(df[col]) # log(1 + x) to handle 0

                elif transform_type == 'sqrt':
                    df[col] = np.sqrt(df[col])

                elif transform_type == 'boxcox':
                    # Box-Cox transform (requires positive values)
                    df[col], _ = stats.boxcox(df[col] + 1) # +1 to handle 0

                    return df

Categorical Encoding

class CategoricalEncoder:
    """
    Encode categorical variables
    """

    def __init__(self):
        self.encoders = {}

    def fit_transform(self, df: pd.DataFrame, encodings: Dict[str, str]):
        """
        Apply encodings

        encodings: {column: encoding_type}
        'onehot': One-hot encoding
        'label': Label encoding (0, 1, 2, ...)
        'target': Target encoding (mean of target per category)
        'frequency': Frequency encoding
        'ordinal': Ordinal encoding with custom order
        """
        df = df.copy()

        for col, encoding_type in encodings.items():
            if col not in df.columns:
                continue

                if encoding_type == 'onehot':
                    # One-hot encoding
                    dummies = pd.get_dummies(df[col], prefix=col)
                    df = pd.concat([df, dummies], axis=1)
                    df.drop(col, axis=1, inplace=True)
                    self.encoders[col] = list(dummies.columns)

                elif encoding_type == 'label':
                    # Label encoding
                    categories = df[col].unique()
                    mapping = {cat: idx for idx, cat in enumerate(categories)}
                    df[col] = df[col].map(mapping)
                    self.encoders[col] = mapping

                elif encoding_type == 'frequency':
                    # Frequency encoding
                    freq = df[col].value_counts(normalize=True)
                    df[col] = df[col].map(freq)
                    self.encoders[col] = freq

                    return df

Temporal Features

class TemporalFeatureExtractor:
    """
    Extract features from timestamps
    """

    def extract(self, df: pd.DataFrame, timestamp_col: str) -> pd.DataFrame:
        """
        Extract temporal features from timestamp column
        """
        df = df.copy()
        df[timestamp_col] = pd.to_datetime(df[timestamp_col])

        # Basic temporal features
        df[f'{timestamp_col}_hour'] = df[timestamp_col].dt.hour
        df[f'{timestamp_col}_day_of_week'] = df[timestamp_col].dt.dayofweek
        df[f'{timestamp_col}_day_of_month'] = df[timestamp_col].dt.day
        df[f'{timestamp_col}_month'] = df[timestamp_col].dt.month
        df[f'{timestamp_col}_quarter'] = df[timestamp_col].dt.quarter
        df[f'{timestamp_col}_year'] = df[timestamp_col].dt.year

        # Derived features
        df[f'{timestamp_col}_is_weekend'] = df[f'{timestamp_col}_day_of_week'].isin([5, 6]).astype(int)
        df[f'{timestamp_col}_is_business_hours'] = df[f'{timestamp_col}_hour'].between(9, 17).astype(int)

        # Cyclical encoding (for periodic features like hour)
        df[f'{timestamp_col}_hour_sin'] = np.sin(2 * np.pi * df[f'{timestamp_col}_hour'] / 24)
        df[f'{timestamp_col}_hour_cos'] = np.cos(2 * np.pi * df[f'{timestamp_col}_hour'] / 24)

        return df

---

Component 4: Pipeline Orchestration

Orchestrate the entire preprocessing workflow.

Apache Beam Pipeline

import apache_beam as beam
from apache_beam.options.pipeline_options import PipelineOptions

class PreprocessingPipeline:
    """
    End-to-end preprocessing pipeline using Apache Beam

    Handles:
        - Data validation
        - Cleaning
        - Feature engineering
        - Quality checks
        """

    def __init__(self, pipeline_options: PipelineOptions):
        self.options = pipeline_options

    def run(self, input_path: str, output_path: str):
        """
        Run preprocessing pipeline
        """
        with beam.Pipeline(options=self.options) as pipeline:
            (
            pipeline
            | 'Read Data' >> beam.io.ReadFromText(input_path)
            | 'Parse JSON' >> beam.Map(json.loads)
            | 'Validate Schema' >> beam.ParDo(ValidateSchemaFn())
            | 'Clean Data' >> beam.ParDo(CleanDataFn())
            | 'Extract Features' >> beam.ParDo(FeatureExtractionFn())
            | 'Quality Check' >> beam.ParDo(QualityCheckFn())
            | 'Write Output' >> beam.io.WriteToText(output_path)
            )

    class ValidateSchemaFn(beam.DoFn):
        """Beam DoFn for schema validation"""

    def process(self, element):
        # Lazily initialize schema validator (avoid re-creating per element)
        if not hasattr(self, 'validator'):
            self.validator = SchemaValidator(get_schema())
            errors = self.validator.validate_record(element)

            if errors:
                # Log to dead letter queue
                yield beam.pvalue.TaggedOutput('invalid', (element, errors))
            else:
                yield element

    class CleanDataFn(beam.DoFn):
        """Beam DoFn for data cleaning"""

    def process(self, element):
        # Handle missing values
        element = handle_missing(element)

        # Handle outliers
        element = handle_outliers(element)

        # Remove duplicates (stateful processing)
        # ...

        yield element

---

Preventing Training/Serving Skew

Critical problem: Different preprocessing in training vs serving leads to poor model performance.

Solution 1: Unified Preprocessing Library

class PreprocessorV1:
    """
    Versioned preprocessing logic

    Same code used in training and serving
    """

    VERSION = "1.0.0"

    def __init__(self, config: Dict):
        self.config = config
        self.fitted_params = {}

    def fit(self, df: pd.DataFrame):
        """Fit on training data"""
        # Compute statistics needed for transform
        self.fitted_params['age_mean'] = df['age'].mean()
        self.fitted_params['price_scaler'] = MinMaxScaler().fit(df[['price']])
        # ...

    def transform(self, df: pd.DataFrame) -> pd.DataFrame:
        """Apply same transformations"""
        df = df.copy()

        # Use fitted parameters
        df['age_normalized'] = (df['age'] - self.fitted_params['age_mean']) / 10
        df['price_scaled'] = self.fitted_params['price_scaler'].transform(df[['price']])

        return df

    def save(self, path: str):
        """Save fitted preprocessor"""
        import pickle
        with open(path, 'wb') as f:
            pickle.dump(self, f)

            @staticmethod
    def load(path: str):
        """Load fitted preprocessor"""
        import pickle
        with open(path, 'rb') as f:
            return pickle.load(f)

            # Training
            preprocessor = PreprocessorV1(config)
            preprocessor.fit(training_data)
            preprocessor.save('models/preprocessor_v1.pkl')
            X_train = preprocessor.transform(training_data)

            # Serving
            preprocessor = PreprocessorV1.load('models/preprocessor_v1.pkl')
            X_serve = preprocessor.transform(serving_data)

Solution 2: Feature Store

Store pre-computed features, ensuring consistency.

class FeatureStore:
    """
    Centralized feature storage

    Benefits:
        - Features computed once, used everywhere
        - Versioned features
        - Point-in-time correct joins
        """

    def __init__(self, backend):
        self.backend = backend

    def write_features(
    self,
    entity_id: str,
    features: Dict[str, Any],
    timestamp: datetime,
    feature_set_name: str,
    version: str
    ):
        """
        Write features for an entity
        """
        key = f"{feature_set_name}:{version}:{entity_id}:{timestamp}"
        self.backend.write(key, features)

    def read_features(
    self,
    entity_id: str,
    feature_set_name: str,
    version: str,
    as_of_timestamp: datetime
    ) -> Dict[str, Any]:
        """
        Read features as of a specific timestamp

        Point-in-time correctness: Only use features available at inference time
        """
        # Query features created before as_of_timestamp
        features = self.backend.read_point_in_time(
        entity_id,
        feature_set_name,
        version,
        as_of_timestamp
        )

        return features

---

Monitoring & Data Quality

Track data quality metrics over time.

from dataclasses import dataclass
from datetime import datetime

@dataclass
class DataQualityMetrics:
    """Metrics for a data batch"""
    timestamp: datetime
    total_records: int
    null_counts: Dict[str, int]
    duplicate_count: int
    schema_errors: int
    outlier_counts: Dict[str, int]
    statistical_warnings: List[str]

    class DataQualityMonitor:
        """
        Monitor data quality over time
        """

    def __init__(self, metrics_backend):
        self.backend = metrics_backend

    def compute_metrics(self, df: pd.DataFrame) -> DataQualityMetrics:
        """Compute quality metrics for a batch"""

        metrics = DataQualityMetrics(
        timestamp=datetime.now(),
        total_records=len(df),
        null_counts={col: df[col].isnull().sum() for col in df.columns},
        duplicate_count=df.duplicated().sum(),
        schema_errors=0, # From validation
        outlier_counts={},
        statistical_warnings=[]
        )

        # Detect outliers
        outlier_handler = OutlierHandler()
        for col in df.select_dtypes(include=[np.number]).columns:
            outliers = outlier_handler.detect_outliers_iqr(df[col])
            metrics.outlier_counts[col] = outliers.sum()

            return metrics

    def log_metrics(self, metrics: DataQualityMetrics):
        """Log metrics to monitoring system"""
        self.backend.write(metrics)

    def alert_on_anomalies(self, metrics: DataQualityMetrics):
        """Alert if metrics deviate significantly"""

        # Alert if > 5% nulls in critical fields
        critical_fields = ['user_id', 'timestamp', 'label']
        for field in critical_fields:
            null_rate = metrics.null_counts.get(field, 0) / metrics.total_records
            if null_rate > 0.05:
                self.send_alert(f"High null rate in {field}: {null_rate:.2%}")

                # Alert if > 10% duplicates
                dup_rate = metrics.duplicate_count / metrics.total_records
                if dup_rate > 0.10:
                    self.send_alert(f"High duplicate rate: {dup_rate:.2%}")

---

Real-World Examples

Netflix: Data Preprocessing for Recommendations

Scale: Billions of viewing events/day

Architecture:

Event Stream (Kafka)
 ↓
Flink/Spark Streaming
 ↓
Feature Engineering
 - User viewing history aggregations
 - Time-based features
 - Content embeddings
 ↓
Feature Store (Cassandra)
 ↓
Model Training & Serving

Key techniques:

• Streaming aggregations (last 7 days views, etc.)
• Incremental updates to user profiles
• Point-in-time correct features

Uber: Preprocessing for ETAs

Challenge: Predict arrival times using GPS data

Pipeline:

1. Map Matching: Snap GPS points to road network
2. Outlier Removal: Remove impossible speeds
3. Feature Extraction:
   • Time of day, day of week
   • Traffic conditions
   • Historical average speed
4. Validation: Check for data drift

Latency: < 100ms for real-time predictions

Google: Search Ranking Data Pipeline

Scale: Process billions of queries and web pages

Preprocessing steps:

1. Query normalization: Lowercasing, tokenization, spelling correction
2. Feature extraction from documents:
   • PageRank scores
   • Content embeddings (BERT)
   • Click-through rate (CTR) features
3. User context features:
   • Location
   • Device type
   • Search history embeddings
4. Join multiple data sources:
   • User profile data
   • Document metadata
   • Real-time signals (freshness)

Key insight: Distributed processing using MapReduce/Dataflow for petabyte-scale data.

---

Distributed Preprocessing with Spark

When data doesn’t fit on one machine, use distributed frameworks.

Spark Preprocessing Pipeline

from pyspark.sql import SparkSession
from pyspark.sql.functions import col, when, mean, stddev, count
from pyspark.ml.feature import VectorAssembler, StandardScaler
from pyspark.ml import Pipeline

class DistributedPreprocessor:
    """
    Large-scale preprocessing using Apache Spark

    Use case: Process 1TB+ data across cluster
    """

    def __init__(self):
        self.spark = SparkSession.builder \\
        .appName("MLPreprocessing") \\
        .getOrCreate()

    def load_data(self, path: str, format='parquet'):
        """Load data from distributed storage"""
        return self.spark.read.format(format).load(path)

    def clean_data(self, df):
        """Distributed data cleaning"""

        # Remove nulls
        df = df.dropna(subset=['user_id', 'timestamp'])

        # Handle outliers (clip at 99th percentile)
        for col_name in ['price', 'quantity']:
            quantile_99 = df.approxQuantile(col_name, [0.99], 0.01)[0]
            df = df.withColumn(
            col_name,
            when(col(col_name) > quantile_99, quantile_99).otherwise(col(col_name))
            )

            # Remove duplicates
            df = df.dropDuplicates(['user_id', 'item_id', 'timestamp'])

            return df

    def feature_engineering(self, df):
        """Distributed feature engineering"""

        # Time-based features
        df = df.withColumn('hour', hour(col('timestamp')))
        df = df.withColumn('day_of_week', dayofweek(col('timestamp')))
        df = df.withColumn('is_weekend',
        when(col('day_of_week').isin([1, 7]), 1).otherwise(0))

        # Aggregation features (window functions)
        from pyspark.sql.window import Window

        # User's average purchase price (last 30 days)
        window_30d = Window.partitionBy('user_id') \\
        .orderBy(col('timestamp').cast('long')) \\
        .rangeBetween(-30*24*3600, 0)

        df = df.withColumn('user_avg_price_30d',
        avg('price').over(window_30d))

        return df

    def normalize_features(self, df, numeric_cols):
        """Normalize numeric features"""

        # Assemble features into vector
        assembler = VectorAssembler(
        inputCols=numeric_cols,
        outputCol='features_raw'
        )

        # Standard scaling
        scaler = StandardScaler(
        inputCol='features_raw',
        outputCol='features_scaled',
        withMean=True,
        withStd=True
        )

        # Create pipeline
        pipeline = Pipeline(stages=[assembler, scaler])

        # Fit and transform
        model = pipeline.fit(df)
        df = model.transform(df)

        return df, model

    def save_preprocessed(self, df, output_path, model_path):
        """Save preprocessed data and fitted model"""

        # Save data (partitioned for efficiency)
        df.write.mode('overwrite') \\
        .partitionBy('date') \\
        .parquet(output_path)

        # Save preprocessing model for serving
        # model.save(model_path)

        # Usage
        preprocessor = DistributedPreprocessor()
        df = preprocessor.load_data('s3://bucket/raw_data/')
        df = preprocessor.clean_data(df)
        df = preprocessor.feature_engineering(df)
        df, model = preprocessor.normalize_features(df, ['price', 'quantity'])
        preprocessor.save_preprocessed(df, 's3://bucket/processed/', 's3://bucket/models/')

---

Advanced Feature Engineering Patterns

1. Time-Series Features

class TimeSeriesFeatureExtractor:
    """
    Extract features from time-series data

    Use case: User engagement over time, sensor readings, stock prices
    """

    def extract_lag_features(self, df, value_col, lag_periods=[1, 7, 30]):
        """Create lagged features"""
        for lag in lag_periods:
            df[f'{value_col}_lag_{lag}'] = df.groupby('user_id')[value_col].shift(lag)
            return df

    def extract_rolling_statistics(self, df, value_col, windows=[7, 30]):
        """Rolling mean, std, min, max"""
        for window in windows:
            df[f'{value_col}_rolling_mean_{window}'] = \\
            df.groupby('user_id')[value_col].transform(
            lambda x: x.rolling(window, min_periods=1).mean()
            )
            df[f'{value_col}_rolling_std_{window}'] = \\
            df.groupby('user_id')[value_col].transform(
            lambda x: x.rolling(window, min_periods=1).std()
            )
            return df

    def extract_trend_features(self, df, value_col):
        """
        Trend: difference from moving average
        """
        df['rolling_mean_7'] = df.groupby('user_id')[value_col].transform(
        lambda x: x.rolling(7, min_periods=1).mean()
        )
        df[f'{value_col}_trend'] = df[value_col] - df['rolling_mean_7']
        return df

2. Interaction Features

class InteractionFeatureGenerator:
    """
    Create interaction features between variables

    Captures relationships not visible in individual features
    """

    def polynomial_features(self, df, cols, degree=2):
        """
        Create polynomial features

        Example: x, y → x, y, x², y², xy
        """
        from sklearn.preprocessing import PolynomialFeatures

        poly = PolynomialFeatures(degree=degree, include_bias=False)
        poly_features = poly.fit_transform(df[cols])

        feature_names = poly.get_feature_names_out(cols)
        poly_df = pd.DataFrame(poly_features, columns=feature_names)

        return pd.concat([df, poly_df], axis=1)

    def ratio_features(self, df, numerator_cols, denominator_cols):
        """
        Create ratio features

        Example: revenue/cost, clicks/impressions (CTR)
        """
        for num_col in numerator_cols:
            for den_col in denominator_cols:
                df[f'{num_col}_per_{den_col}'] = df[num_col] / (df[den_col] + 1e-9)
                return df

    def categorical_interactions(self, df, cat_cols):
        """
        Combine categorical variables

        Example: city='SF', category='Tech' → 'SF_Tech'
        """
        if len(cat_cols) >= 2:
            df['_'.join(cat_cols)] = df[cat_cols].astype(str).agg('_'.join, axis=1)
            return df

3. Embedding Features

class EmbeddingFeatureGenerator:
    """
    Generate embedding features from high-cardinality categoricals

    Use case: user_id, item_id, text
    """

    def train_category_embeddings(self, df, category_col, embedding_dim=50):
        """
        Train embeddings for categorical variable

        Uses skip-gram approach: predict co-occurring categories
        """
        from gensim.models import Word2Vec

        # Create sequences (e.g., user's purchase history)
        sequences = df.groupby('user_id')[category_col].apply(list).tolist()

        # Train Word2Vec
        model = Word2Vec(
        sentences=sequences,
        vector_size=embedding_dim,
        window=5,
        min_count=1,
        workers=4
        )

        # Get embeddings
        embeddings = {}
        for category in df[category_col].unique():
            if category in model.wv:
                embeddings[category] = model.wv[category]

                return embeddings

    def text_to_embeddings(self, df, text_col, model='sentence-transformers'):
        """
        Convert text to dense embeddings

        Use pre-trained models (BERT, etc.)
        """
        from sentence_transformers import SentenceTransformer

        model = SentenceTransformer('all-MiniLM-L6-v2')
        embeddings = model.encode(df[text_col].tolist())

        # Add as features
        for i in range(embeddings.shape[1]):
            df[f'{text_col}_emb_{i}'] = embeddings[:, i]

            return df

---

Handling Data Drift

Data distributions change over time - models degrade if not monitored.

Drift Detection

from scipy.stats import ks_2samp, chi2_contingency

class DataDriftDetector:
    """
    Detect when data distribution changes
    """

    def __init__(self, reference_data: pd.DataFrame):
        """
        Args:
            reference_data: Historical "good" data (training distribution)
            """
            self.reference = reference_data

    def detect_numerical_drift(self, current_data: pd.DataFrame, col: str, threshold=0.05):
        """
        Kolmogorov-Smirnov test for numerical columns

        Returns:
            (drifted: bool, p_value: float)
            """
            ref_values = self.reference[col].dropna()
            curr_values = current_data[col].dropna()

            statistic, p_value = ks_2samp(ref_values, curr_values)

            drifted = p_value < threshold

            return drifted, p_value

    def detect_categorical_drift(self, current_data: pd.DataFrame, col: str, threshold=0.05):
        """
        Chi-square test for categorical columns
        """
        ref_dist = self.reference[col].value_counts(normalize=True)
        curr_dist = current_data[col].value_counts(normalize=True)

        # Align distributions
        all_categories = set(ref_dist.index) | set(curr_dist.index)
        ref_counts = [ref_dist.get(cat, 0) * len(self.reference) for cat in all_categories]
        curr_counts = [curr_dist.get(cat, 0) * len(current_data) for cat in all_categories]

        # Chi-square test
        contingency_table = [ref_counts, curr_counts]
        chi2, p_value, dof, expected = chi2_contingency(contingency_table)

        drifted = p_value < threshold

        return drifted, p_value

    def detect_all_drifts(self, current_data: pd.DataFrame):
        """
        Check all columns for drift
        """
        drifts = {}

        # Numerical columns
        for col in current_data.select_dtypes(include=[np.number]).columns:
            drifted, p_value = self.detect_numerical_drift(current_data, col)
            if drifted:
                drifts[col] = {'type': 'numerical', 'p_value': p_value}

                # Categorical columns
                for col in current_data.select_dtypes(include=['object', 'category']).columns:
                    drifted, p_value = self.detect_categorical_drift(current_data, col)
                    if drifted:
                        drifts[col] = {'type': 'categorical', 'p_value': p_value}

                        return drifts

                        # Usage
                        detector = DataDriftDetector(training_data)
                        drifts = detector.detect_all_drifts(current_production_data)

                        if drifts:
                            print("⚠️ Data drift detected in:", drifts.keys())
                            # Trigger retraining or alert

---

Production Best Practices

1. Idempotency

Ensure pipeline can be re-run safely without side effects.

class IdempotentPipeline:
    """
    Pipeline that can be safely re-run
    """

    def process_batch(self, batch_id: str, input_path: str, output_path: str):
        """
        Process a batch idempotently
        """
        # Check if already processed
        if self.is_processed(batch_id):
            print(f"Batch {batch_id} already processed, skipping")
            return

            # Process
            data = self.load(input_path)
            processed = self.transform(data)

            # Write with batch ID
            self.save_with_checksum(processed, output_path, batch_id)

            # Mark as complete
            self.mark_processed(batch_id)

    def is_processed(self, batch_id: str) -> bool:
        """Check if batch already processed"""
        # Query metadata store
        return self.metadata_store.exists(batch_id)

    def mark_processed(self, batch_id: str):
        """Mark batch as processed"""
        self.metadata_store.write(batch_id, timestamp=datetime.now())

2. Data Versioning

Track versions of datasets and transformations.

class VersionedDataset:
    """
    Version datasets for reproducibility
    """

    def save(self, df: pd.DataFrame, name: str, version: str):
        """
        Save versioned dataset

        Path: s3://bucket/{name}/{version}/data.parquet
        """
        path = f"s3://bucket/{name}/{version}/data.parquet"

        # Save data
        df.to_parquet(path)

        # Save metadata
        metadata = {
        'name': name,
        'version': version,
        'timestamp': datetime.now().isoformat(),
        'num_rows': len(df),
        'num_cols': len(df.columns),
        'schema': df.dtypes.to_dict(),
        'checksum': self.compute_checksum(df)
        }

        self.save_metadata(name, version, metadata)

    def load(self, name: str, version: str) -> pd.DataFrame:
        """Load specific version"""
        path = f"s3://bucket/{name}/{version}/data.parquet"
        return pd.read_parquet(path)

3. Lineage Tracking

Track data transformations for debugging and compliance.

class LineageTracker:
    """
    Track data lineage
    """

    def __init__(self):
        self.graph = {}

    def record_transformation(
    self,
    input_datasets: List[str],
    output_dataset: str,
    transformation_code: str,
    parameters: Dict
    ):
        """
        Record a transformation
        """
        self.graph[output_dataset] = {
        'inputs': input_datasets,
        'transformation': transformation_code,
        'parameters': parameters,
        'timestamp': datetime.now()
        }

    def get_lineage(self, dataset: str) -> Dict:
        """
        Get full lineage of a dataset

        Returns tree of upstream datasets and transformations
        """
        if dataset not in self.graph:
            return {'dataset': dataset, 'inputs': []}

            node = self.graph[dataset]

            return {
            'dataset': dataset,
            'transformation': node['transformation'],
            'inputs': [self.get_lineage(inp) for inp in node['inputs']]
            }

---

Common Preprocessing Challenges & Solutions

Challenge 1: Imbalanced Classes

Problem: 95% of samples are class 0, 5% are class 1. Model always predicts class 0.

Solutions:

class ImbalanceHandler:
    """
    Handle class imbalance
    """

    def upsample_minority(self, df, target_col):
        """
        Oversample minority class
        """
        from sklearn.utils import resample

        # Separate majority and minority classes
        df_majority = df[df[target_col] == 0]
        df_minority = df[df[target_col] == 1]

        # Upsample minority class
        df_minority_upsampled = resample(
        df_minority,
        replace=True, # Sample with replacement
        n_samples=len(df_majority), # Match majority class size
        random_state=42
        )

        # Combine
        df_balanced = pd.concat([df_majority, df_minority_upsampled])

        return df_balanced

    def downsample_majority(self, df, target_col):
        """
        Undersample majority class
        """
        df_majority = df[df[target_col] == 0]
        df_minority = df[df[target_col] == 1]

        # Downsample majority class
        df_majority_downsampled = resample(
        df_majority,
        replace=False,
        n_samples=len(df_minority),
        random_state=42
        )

        df_balanced = pd.concat([df_majority_downsampled, df_minority])

        return df_balanced

    def smote(self, X, y):
        """
        Synthetic Minority Over-sampling Technique

        Generate synthetic samples for minority class
        """
        from imblearn.over_sampling import SMOTE

        smote = SMOTE(random_state=42)
        X_resampled, y_resampled = smote.fit_resample(X, y)

        return X_resampled, y_resampled

Challenge 2: High-Cardinality Categoricals

Problem: User IDs have 10M unique values. One-hot encoding creates 10M columns.

Solutions:

class HighCardinalityEncoder:
    """
    Handle high-cardinality categorical features
    """

    def target_encoding(self, df, cat_col, target_col):
        """
        Encode category by mean of target

        Example:
            city='SF' → mean(target | city='SF') = 0.65
            city='NY' → mean(target | city='NY') = 0.52

            Warning: Risk of overfitting. Use cross-validation encoding.
            """
            # Compute target mean per category
            target_means = df.groupby(cat_col)[target_col].mean()

            # Map
            df[f'{cat_col}_target_enc'] = df[cat_col].map(target_means)

            return df

    def frequency_encoding(self, df, cat_col):
        """
        Encode by frequency

        Common categories → higher values
        """
        freq = df[cat_col].value_counts(normalize=True)
        df[f'{cat_col}_freq'] = df[cat_col].map(freq)

        return df

    def hashing_trick(self, df, cat_col, n_features=100):
        """
        Hash categories into fixed number of buckets

        Pros: Fixed dimension
        Cons: Hash collisions
        """
        from sklearn.feature_extraction import FeatureHasher

        hasher = FeatureHasher(n_features=n_features, input_type='string')
        hashed = hasher.transform(df[[cat_col]].astype(str).values)

        # Convert to DataFrame
        hashed_df = pd.DataFrame(
        hashed.toarray(),
        columns=[f'{cat_col}_hash_{i}' for i in range(n_features)]
        )

        return pd.concat([df, hashed_df], axis=1)

Challenge 3: Streaming Data Preprocessing

Problem: Need to preprocess real-time streams with low latency.

Solution:

from kafka import KafkaConsumer, KafkaProducer
import json

class StreamingPreprocessor:
    """
    Real-time preprocessing for streaming data
    """

    def __init__(self):
        self.consumer = KafkaConsumer(
        'raw_events',
        bootstrap_servers=['localhost:9092'],
        value_deserializer=lambda m: json.loads(m.decode('utf-8'))
        )

        self.producer = KafkaProducer(
        bootstrap_servers=['localhost:9092'],
        value_serializer=lambda v: json.dumps(v).encode('utf-8')
        )

        # Load fitted preprocessor (from training)
        self.preprocessor = PreprocessorV1.load('models/preprocessor_v1.pkl')

    def process_stream(self):
        """
        Process events in real-time
        """
        for message in self.consumer:
            event = message.value

            # Preprocess
            processed = self.preprocess_event(event)

            # Validate
            if self.validate(processed):
                # Send to processed topic
                self.producer.send('processed_events', processed)

    def preprocess_event(self, event):
        """
        Preprocess single event (must be fast!)
        """
        # Convert to DataFrame
        df = pd.DataFrame([event])

        # Apply preprocessing
        df = self.preprocessor.transform(df)

        # Convert back to dict
        return df.to_dict('records')[0]

    def validate(self, event):
        """Quick validation"""
        required_fields = ['user_id', 'timestamp', 'features']
        return all(field in event for field in required_fields)

Challenge 4: Privacy & Compliance (GDPR, CCPA)

Problem: Need to handle PII (Personally Identifiable Information).

Solutions:

import hashlib

class PrivacyPreserver:
    """
    Handle PII in preprocessing
    """

    def anonymize_user_ids(self, df, id_col='user_id'):
        """
        Hash user IDs to anonymize
        """
        df[f'{id_col}_anonymized'] = df[id_col].apply(
        lambda x: hashlib.sha256(str(x).encode()).hexdigest()
        )
        df.drop(id_col, axis=1, inplace=True)
        return df

    def remove_pii(self, df, pii_cols=['email', 'phone', 'address']):
        """
        Remove PII columns
        """
        df.drop(pii_cols, axis=1, inplace=True, errors='ignore')
        return df

    def differential_privacy_noise(self, df, numeric_cols, epsilon=1.0):
        """
        Add Laplacian noise for differential privacy

        Args:
            epsilon: Privacy parameter (lower = more privacy, less utility)
            """
            for col in numeric_cols:
                sensitivity = df[col].max() - df[col].min()
                noise_scale = sensitivity / epsilon

                noise = np.random.laplace(0, noise_scale, size=len(df))
                df[col] = df[col] + noise

                return df

---

Performance Optimization

1. Parallelize Transformations

from multiprocessing import Pool
import numpy as np

class ParallelPreprocessor:
    """
    Parallelize preprocessing across CPU cores
    """

    def __init__(self, n_workers=4):
        self.n_workers = n_workers

    def process_parallel(self, df, transform_fn):
        """
        Apply transformation in parallel
        """
        # Split dataframe into chunks
        chunks = np.array_split(df, self.n_workers)

        # Process chunks in parallel
        with Pool(self.n_workers) as pool:
            processed_chunks = pool.map(transform_fn, chunks)

            # Combine results
            return pd.concat(processed_chunks)

2. Use Efficient Data Formats

# Bad: CSV (slow to read/write, no compression)
df.to_csv('data.csv') # 1 GB file, 60 seconds

# Better: Parquet (columnar, compressed)
df.to_parquet('data.parquet') # 200 MB file, 5 seconds

# Best for streaming: Avro or Protocol Buffers

3. Cache Intermediate Results

class CachedPreprocessor:
    """
    Cache preprocessing results
    """

    def __init__(self, cache_dir='./cache'):
        self.cache_dir = cache_dir

    def process_with_cache(self, df, batch_id):
        """
        Check cache before processing
        """
        cache_path = f"{self.cache_dir}/{batch_id}.parquet"

        if os.path.exists(cache_path):
            print(f"Loading from cache: {batch_id}")
            return pd.read_parquet(cache_path)

            # Process
            processed = self.preprocess(df)

            # Save to cache
            processed.to_parquet(cache_path)

            return processed

---

Key Takeaways

✅ Data quality is critical - bad data → bad models ✅ Schema validation catches errors early before expensive processing ✅ Handle missing values with domain-appropriate strategies (mean/median/forward-fill) ✅ Feature engineering is where domain knowledge creates value ✅ Prevent training/serving skew with unified preprocessing code ✅ Monitor data quality continuously - detect drift and anomalies ✅ Use feature stores for consistency and reuse at scale ✅ Distributed processing (Spark/Beam) required for large-scale data ✅ Version datasets and transformations for reproducibility ✅ Track data lineage for debugging and compliance ✅ Handle class imbalance with resampling or SMOTE ✅ Encode high-cardinality categoricals with target/frequency encoding or hashing ✅ Optimize performance with parallel processing, efficient formats, caching

FAQ

What causes training-serving skew in ML systems?

Training-serving skew happens when the preprocessing logic differs between the training pipeline and the online serving path. The fix is to use a single versioned preprocessing library or a feature store that ensures identical transformations in both environments.

How do you detect data drift in preprocessing pipelines?

Use the Kolmogorov-Smirnov test for numerical columns and the chi-square test for categorical columns to compare current data distributions against the training baseline. Alert when p-values drop below 0.01.

What is the best way to handle missing values in production?

Choose strategies based on domain knowledge: mean or median imputation for numerical fields, mode for categorical, forward-fill for time series, and explicit drop for critical fields. Fit imputation parameters on training data and reuse them in serving.

When should you use Spark instead of Pandas for preprocessing?

Use Spark or Apache Beam when data exceeds what fits in memory on a single machine, typically above 10-50 GB. Spark handles distributed cleaning, feature engineering with window functions, and normalization across clusters.

---

Originally published at: arunbaby.com/ml-system-design/0003-data-preprocessing

Want to work together?

I take on projects, advisory roles, and fractional CTO engagements in AI/ML. I also help businesses go AI-native with agentic workflows and agent orchestration.

Get in touch
